START
Click the button and follow the in-
structions.
+
CATEYE VELO WIRELESS
CC-VT235W
Quick Start

Advertisement

loading
Need help?

Need help?

Do you have a question about the Velo Wireless+ CC-VT235W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cateye Velo Wireless+ CC-VT235W

Summary of Contents for Cateye Velo Wireless+ CC-VT235W

  • Page 1 START Click the button and follow the in- structions. CATEYE VELO WIRELESS CC-VT235W Quick Start...
  • Page 2 Thank you for purchasing our cyclocomputer CATEYE VELO WIRELESS This Quick Start Manual explains how to set up the computer and how to install the unit on your bicycle. Please set up the unit according to the specified procedure, then it will be ready for use as a cyclocomputer.
  • Page 3 This PDF contains a movie file. When you click on the movie screen, a message regarding security appears. Click the “Trust in the text” or “Play” button to close the message. Click the screen again to play the movie. Next...
  • Page 4 CATEYE VELO WIRELESS Return to a Cover Quick Start Manual Contents Click the item you wish to view. Setting up the computer How to install the bracket (movie) How to install the speed sensor (movie) Backlight (Night Mode)
  • Page 5 Operation of buttons Set up the computer by operating the buttons as follows. Check the button position before you start setting up. Front Back MENU MODE Press the MODE button on the front Press the MENU button on the back of the computer.

  • Page 6: Setting Up The Computer

    CATEYE VELO WIRELESS Return to Contents Quick Start Manual Setting up the computer Clear all data (initialization) Formatting operation Press the AC button on the back of the computer. After full lighting of the screen, the computer switches to the speed unit setting screen to start Setting the speed unit setup.
  • Page 7 CATEYE VELO WIRELESS Return to Contents Quick Start Manual Setting up the computer Setting the speed unit Formatting operation When the MODE button is pressed, either “km/h” or “mph” is selected for the speed unit display. Select the display of your choice.
  • Page 8 CATEYE VELO WIRELESS Return to Contents Quick Start Manual Setting up the computer Setting the tire size Formatting operation There are two different ways to set the tire size with this unit; simple setting by selecting the tire size in inches, and detailed setting by entering the tire circumference.
  • Page 9 CATEYE VELO WIRELESS Return to Contents Quick Start Manual Setting up the computer Setting the tire size (Simple setting) Formatting operation When the MODE button is pressed, different sizes in inches are displayed. Select the display of your choice. After selecting, press the MENU button to proceed to the Setting the speed unit next step “Setting the clock display”.
  • Page 10 CATEYE VELO WIRELESS Return to Contents Quick Start Manual Setting up the computer Setting the tire size (Detailed setting) Formatting operation When the MODE button is pressed, different sizes in inches are displayed. Press the MODE button until “205[]” is displayed.
  • Page 11 CATEYE VELO WIRELESS Return to Contents Quick Start Manual Setting up the computer Setting the tire size (Detailed setting) Formatting operation Enter the tire circumference (cm) of your bicycle with 3 digits using the tire circumference reference table. Pressing the MODE button increases the value flashing,...
  • Page 12 CATEYE VELO WIRELESS Return to Contents Quick Start Manual Setting up the computer Setting the clock display Formatting operation When the MODE button is pressed, either “12h” or “24h” is selected for the clock display. Select the display of your choice.
  • Page 13 CATEYE VELO WIRELESS Return to Contents Quick Start Manual Setting up the computer Setting the hour Formatting operation Pressing the MODE button increases the value flashing (“Hour” of the clock). Enter any value. When 12h is selected, enter the value while checking...
  • Page 14 CATEYE VELO WIRELESS Return to Contents Quick Start Manual Setting up the computer Setting the minute Formatting operation Pressing the MODE button increases the value flashing (“Minute” of the clock). Enter any value (Pressing and holding MODE rapidly increases the value).
  • Page 15 CATEYE VELO WIRELESS Return to Contents Quick Start Manual Setting up the computer Now, setup of the computer is completed. Formatting operation If the bracket and speed sensor are not installed on your bicycle, return to Contents, click the movies of how to...

  • Page 16: How To Install The Bracket (Movie)

    CATEYE VELO WIRELESS Return to Contents Quick Start Manual How to install the bracket...

  • Page 17: How To Install The Speed Sensor (Movie)

    CATEYE VELO WIRELESS Return to Contents Quick Start Manual How to install the speed sensor...

  • Page 18: Backlight (Night Mode)

    CATEYE VELO WIRELESS Return to Contents Quick Start Manual Backlight (Night Mode) When you press the MODE or MENU button How to use How to use during the specified time that night mode is ON turns on), the backlight will turn on for 5 seconds.
  • Page 19 CATEYE VELO WIRELESS Return to Contents Quick Start Manual Backlight (Night Mode) From the measurement screen, press the MENU button to dis- How to use play the menu screen, “Night mode”. Press and hold the MODE button, and then set the night mode ON/OFF and set the start time and the end time.
  • Page 20 CATEYE VELO WIRELESS Return to Contents Quick Start Manual Setting up the computer Tire circumference reference table ETRTO Tire size L (cm) ETRTO Tire size L (cm) ETRTO Tire size L (cm) ETRTO Tire size L (cm) ETRTO Tire size L (cm) 40-254 14x1.50...
