WIRELESS DRIVE-ALERT OPTIONAL ANTENNA AND SENSORS

DA-660 DA-610TO DA-611TO
The DA-660 Long Range Antenna is an option that can be used with all of Mier's Wireless Drive-Alert Systems to boost the recep-
tion-range from the sensor to the control panel up to 1/2- mile. This is a factory installed accessory and must be ordered at the time
of purchase by adding an "LR" to the end of the part number. Example: a DA-600 or DA-605P Drive-Alert with the with a DA-660
long range option would be a DA-600LR or DA-605PLR.
The DA-610TO Sensor/Transmitter is the standard sensor that comes with a DA-600 or DA-605P. The sensor and transmitter are
encased inside a durable NEMA 4 outdoor enclosure (see the DA-611TO if an external sensor is needed). The DA-610TO monitors
a 14 foot radius (28 foot sphere). Mier's sensors/transmitters require two AA batteries which will last more than a year under normal
residential usage. These sensors may be placed up to 1000 feet from the control panel, and up to 2500 feet when used with an "LR"
system which includes the DA-660 Long Range Reception Antenna. The sensors are tamper resistant due to the fact that if anyone
touches or moves one, the alert will be triggered.
The DA-611TO Sensor/Transmitter is an optional wireless sensor that can be used in place of, or in conjunction with, the
standard DA-610TO Sensor that comes with a DA-600 or DA-605P Drive-Alert. The DA-611TO is used in applications where it is
impossible to place a DA-610TO close to the driveway or area needing monitoring. The DA-611TO allows you to bury the sensor
right next to, or under, the driveway and then place the transmitter up to 50 feet away on a tree/pole (which also helps increase
transmission reception). If you want this option without the standard DA-610TO, order a Drive-Alert control panel only by adding
a "CP" to the end of the part number as well as the DA-611TO. Example: a DA-600 or DA-605P Drive-Alert with the DA-611TO
would be a DA-600CP or DA-605CP and a DA-611TO. Note: If you order a DA-605CP, make sure you also remember to order DA-
068 and/or DA-070 chimes too. An unlimited number of, or combination of, wireless sensors may be used to monitor several areas.
NOTE: If needed, Mier's wireless systems can be completely battery operated allowing them to be entirely mobile.
See the following pages for Installation Instructions of these options
