30 Litre

Microwave Oven

Manual

MODEL

IM30SE3

Installation and Operation

Table of Contents

Need help?

Do you have a question about the IM30SE3 and is the answer not in the manual?

Questions and answers

Summary of Contents for ARC Appliances IM30SE3

Page 1 30 Litre Microwave Oven Manual MODEL IM30SE3 Installation and Operation...
Page 2: Important Safety Instructions Read Carefully And Keep For Future Reference
IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE The appliance is not intended for use by persons including children with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervised or instruction concerning use of the appliance by a responsible person for their safety.
Page 3 Approx. 17.5kg BUILDING-IN the IM30SE3 The IM30SE3 and IM30SE4 can be built in with stainless trim kit to surround the microwave oven, matching trim to kitchen doors or simply placed in an opening in the kitchen furniture. Proper airflow must be present around the microwave oven in any of these installations.
Page 4: Before You Call For Service
BEFORE YOU CALL FOR SERVICE 1. If the oven will not perform at all, the display does not test the outlet with another appliance. appear or the display disappears: 2. If the microwave power does not function: a) Check to ensure that the oven is plugged in securely. If it a) Check to see whether the timer is set.
Page 5: Warning! This Appliance Must Be Earthed
INSTALLATION 1. Make sure all the packing materials are removed from 3. This Microwave Oven weighs 17.5 kg and must be the inside of the door. placed on a horizontal surface strong enough to support this weight. 2. Inspect the oven after unpacking for any visual 4.
Page 6: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS -WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person; -WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy;...
Page 7: Feature Diagram
6. Do not insert any object into the openings on the outer removed from the oven, please remember that case. the food/liquid inside will be releasing the same 7. Do not at any time remove parts from the oven such as amount of steam and/or spitting when the lid is the feet, coupling, screws, etc.
Page 8: Control Panel
CONTROL PANEL (4)DISPLAY WINDOW Micro (1)Micro Memory (2)Memory Auto Menu (3)Auto Menu Clock/Timer (5)Clock/Timer Start/Reset (6)Start/Reset (7)Defrost/Time setting...
Page 9 etc. b) Press the button "Start/Reset", the microwave oven will work on 100% power for 1 minute. b) Press "Start/Reset" twice c) Press "Start/Reset" Touching times Microwave power Display 100% P100 3.Auto weight defrost Select the food weight, it will automatically help you to adjust the power level and time. Example:defrost 0.5kg frozen meat.
Page 10 Weight Menu Rice Vegetable Meat Noodle Fish Reheat (kg) (A-1) (A-2) (A-3) (A-4) (A-5) (A-6) Touching Times 5.Setting the Clock The oven has a 24-hour digital clock, To input the time, for example to 4:30pm: a) Press "Clock/Timer", the display will flash, adjust the hour with the knob "Defrost/Time Setting" b) Press "Clock/Timer"...
Page 11 7. Child-safety-lock . To activate the child safety lock, press "Auto menu" and "Clock/Timer" at the same time for 2 seconds. Press "Auto menu" and "clock/Timer" at the same time for 2 seconds again, it will unlock the machine. 8. Start/Reset a) In the course of operation, pressing "Start/Reset"...
Page 12: Care Of Your Microwave Oven
CARE OF YOUR MICROWAVE OVEN 1.Turn the oven off and remove the power plug from the wall socket before cleaning. 2.Keep the inside of the oven clean.When food splatters or spilled liquids adhere to oven walls,wipe with a damp cloth.The use of harsh detergent or abrasives is not recommended. 3.The outside oven surface should be cleaned with a damp cloth.To prevent damage to the operating parts inside the oven,water should not be allowed to seep into the ventilation openings.
Page 13: Schematic Diagram
SCHEMATIC DIAGRAM ( DOOR OPENED,COOK OFF CONDITION) NOISE FILTER TRANSFORMER MAGNETRON N E L P( OUT) R4-2 T( IN) R4-1 D_ SW CONTROLLER L: LAMP SWA: PRIMARY INTERLOCK SWITCH SWB: SECONDARY INTERLOCK SWITCH FM: FAN MOTOR TM: TURNTABLE MOTOR SWC: THE MONITOR INTERLOCK SWITCH *CIRCUIT SUBJECT TO CHANGE WITHOUT NOTICE...
