Data Transmission ..........9 Search for Sensor ..........10 Power ..............17 About Oregon Scientific™ ........17 Clock ..............10 Turn Clock ON / OFF ........10 For BAR623P Set Clock / Calendar Manually ..11 Set The Calendar Clock ........11...
INTRODUCTION PRODUCT OVERVIEW Thank you for selecting the Oregon Scientific™ FRONT VIEW Barometer Projection Clock (BAR623P/ BAA623PH). This device bundles precise time keeping with a projection clock, weather forecast, and indoor and outdoor temperature monitoring features into a single tool you can use from the convenience of your home.
LCD DISPLAY 1. Weather display 2. Radio Frequency (RF) reception icon (BAR623P) 3. Alarm activated 4. Alarm setting 5. Time 6. Indoor temperature 7. Low battery icon for main unit 8. °C / °F (Outdoor temperature) 9. Sensor signal 10. Low battery icon for sensor 11.
GETTING STARTED Installing the batteries: BATTERIES Batteries are supplied with this product: Main unit 3 x UM-3 (AA) 1.5V batteries Remote unit 2 x UM-4 (AAA) 1.5V batteries Insert batteries before first use, matching the polarity (+ and -) as shown in the battery compartment. For best results, install batteries in the remote sensor before the main unit.
AC ADAPTOR CHANGE SETTINGS The main unit has a 4.5V AC / DC adaptor with jack, To change, time, calendar and language settings: which provides continuous clock / temperature projection. 1. Press and hold MODE for 2 seconds to enter setting Inserting the adaptor: mode.
Installing the batteries: REMOTE SENSOR (THN122N) This product is shipped with a THN122N Thermometer Sensor that collects Temperature data. The main unit can be connected to only 1 remote sensor. SETUP SENSOR 1. Open the remote sensor battery compartment with a small screwdriver.
For best results: DATA TRANSMISSION Data is sent from the sensor every 40 seconds. The Insert the batteries and select the channel before reception icon shown in the Temperature Area shows you mount the sensor. the status. Place the sensor out of direct sunlight and moisture.
BAA623PH Please follow the instructions for setting the clock and CLOCK calendar manually. BAR623P ONLY The clock automatically synchronizes the current time TURN CLOCK ON / OFF and date when it is brought within range of the radio Perform this step if you cannot receive clock signals.
FOR BAR623P SET CLOCK / CALENDAR MANUALLY ALARM You only need to do this if you have disabled the clock This product is equipped with a 2-minute crescendo feature (for example, if you are too far from or cannot alarm.
SILENCE ALARM WEATHER FORECAST When the alarm time is reached, the crescendo alarm This product forecasts the next 12 to 24 hours of weather will sound for 2 minutes. To silence the alarm: within a 30-50 km (19-31 mile) radius with 70 to 75 percent accuracy.
TEMPERATURE MOON PHASE This product can display current, minimum, and The Calendar must be set for this feature to work, see maximum temperature information collected by the “Set Clock” section. remote sensor and main (indoor) unit. Press to view the moon phase for the next Outdoor data is collected and displayed every 40 or previous day.
This product is designed to give you years of service if continuous projection. However, this function will handled properly. Oregon Scientific will not be not work unless the AC / DC adaptor is used. responsible for any deviations in the usage of the device from those specified in the user instructions or any unapproved alterations or repairs of the product.
TROUBLESHOOTING Never immerse the product in water. This can cause electrical shock and damage the product. PROBLEM SYMPTOM REMEDY Do not subject the main unit to extreme force, Calendar Strange date / Change shock, or fluctuations in temperature or humidity. month language (P.11) Do not tamper with the internal components.
MAIN UNIT DIMENSIONS L x W x H 92 x 167 x 53 mm (3.6 x 6.6 x 2.1 inches) REMOTE SENSOR (THN122N) RF frequency 433MHz (BAR623P) / Weight 228 grams (8.04 ounces) 315 MHz (BAA623PH) without battery Range 30 metres (98 feet)
Calendar DD / MM; weekday in 5 languages (E, F, D, I, S) Visit our website (www.oregonscientific.com) to learn more about Oregon Scientific™ products such as digital Alarm Single alarm with cameras; MP3 players; children's electronic learning 2-minute crescendo and products and games;...
