Team Durango DEX210v2 Instruction Manual page 11

1:1
B H M 3 x 8 m m
7 0 5 0 0 2 x 2
S H I M 3 x 5 x 0 . 1 m m
7 0 9 0 1 8 x 4
S h i m 3 x 6 x 0 . 5 m m
7 0 9 0 3 2 x 2
3 2 0 1 2 4 - 4
B B 3 x 7 x 3 m m
6 0 1 0 2 3 x 4
S TO P N U T: M 3 LO W
7 1 5 0 0 1 x 2
6 0 1 0 2 3
P I V O T B A L L C -T Y P E
3 3 0 6 0 2 x 3
C S M 3 x 1 8 m m
7 0 4 0 0 1 x 2
S T E E R I N G K N U C K L E B U S H I N G
3 4 0 0 0 4 x 2
.11.
Thread Lock
FRONT
F C B
6 0 1 0 2 3
7 1 5 0 0 1
3 2 0 1 2 4 - 1 3
6 0 1 0 2 3
3 2 0 1 2 4 - 1 3
3 2 0 1 2 4 - 3
6 0 1 0 2 3
3 3 0 6 0 2
3 2 0 1 5 7
3 4 0 0 0 4
3 4 0 0 0 4
ENSURE FREE
MOVEMENT
7 0 9 0 3 2
7 0 5 0 0 2
DO NOT
OVERTIGHTEN
7 0 4 0 0 1
3 3 0 6 0 2
3 3 0 6 0 2
7 0 9 0 1 8
7 1 5 0 0 1
7 0 9 0 1 8
7 0 9 0 1 8
7 0 9 0 3 2
7 0 5 0 0 2
3 2 0 1 2 4 - 1 0
7 0 9 0 1 8
3 2 0 1 2 4 - 1 1
