- Page 1 CRT1081IRD-S2-MX USER’s MANUAL USER’S MANUAL CRT1081IRD-S2-MX Compact size 8-channel multiplexing DVB-S2 IRD Crypton, January 2013...
-
Page 2: Table Of Contents
4.6 P ROGRAM FILTERING 4.6.1 Input PSI/SI acuiring..............................19 4.6.2 Program service information preview...........................20 4.6.3 Program assignment to multiplexes..........................22 4.6.4 PSI/SI edit..................................23 4.6.5 CRT1081IRD-S2-MX output configuration........................25 4.7 NIT & EIT I NSERTION 4.7.1 EIT program scadule broadcast............................27 4.7.2 NIT broadcast................................28 ...........................................2 4.8 O... -
Page 3: General Information
General information Description CRT1081IRD-S2-MX – is a compact size eight channel DVB-S2 integrated receiver decoder with embedded four channel DVB remultiplexer. The device consists of 8 full featured DVB-S/S2 receivers, 4 DVB-ASI input interfaces, flexibly configurable 8-channel Common Interface for descrambling services and 4-channel DVB remultiplexer with DVB EPG processor, DVB-ASI and DVB-over-IP outputs, all in one 19-inch, 1U case. -
Page 4: Technical Specifications
Streaming type Multicast/Unicast Number of DVB-over-IP streams 4 (ASI bound MPTS) Network interface 1 Gbit Ethernet Control software HTTP server (Web) Control interface 100 Mbit Ethernet, TCP/IP Supply voltage 100-240 V Max. power 60 W Operational conditions Crypton, January 2013... - Page 5 CRT1081IRD-S2-MX USER’s MANUAL Temperature 10…30 ºC Relative Humidity Up to 95 %, without condensation Dimensions Width, mm Depth, mm Height, mm Crypton, January 2013...
-
Page 6: Safety Guidelines
Use only specified power supply and signals. • Have device power off when doing connections. • Proper cable types must be used. • Use the device under the specified environmental conditions. • Do not obstruct the ventilation system. Crypton, January 2013... -
Page 7: Installation And Setup
6. Common Interface slots for CAM modules. 3.1.2 Rear view Fig. 2 Rear view 8 DVB-S/S2 receiver LNB inputs; 8 DVB-S/S2 receiver Loop outputs; 4 DVB-ASI outputs from multiplexers; 4 DVB-ASI multiplexers inputs; Power socket; Power switch. Crypton, January 2013... -
Page 8: Hardware Installation
6. Insert CAM Modules into Common Interface slots. To prevent damage of the interface only use EN50221 specified CAM Modules, push them gently no exceeding effort is required. 7. Switch the device power on. Short period LED lights signal the device is ready to operate. Crypton, January 2013... -
Page 9: Hardware Setup
You can reset the device configuration to the factory settings. When the device is operating please carefully press IP RESET button on the front panel and hold at least 20 seconds antil LEDs start blinking. The device will automatically start reboot for new settings to take effect. Factory configuration appears after reboot. Crypton, January 2013... -
Page 10: Configuring The Device Using Web Interface
Loging in to the WEB interface Before you start please check the following. • An IP address that identifies the CRT1081IRD-S2-MX Ethernet interface on the LAN, and the Subnet Mask for the LAN segment. • A 10BaseT or 100BaseT network connection. -
Page 11: Main Page
• Find language selector and context help switch button in the right up conner. • You can find the component configuration window in the center of the screen or brief device configuration instructions immediately after loging in. Crypton, January 2013... -
Page 12: Input Page
USER’s MANUAL Inputs page 4.3.1 Tuners setting up CRT1081IRD-S2-MX take signal from 8 DVB-S/S2 receivers (tuners) and 4 DVB-ASI inputs. The following tuner settings are available. • Frequency – Transponder frequency MHz; • Symbol rate – DVB-S/S2 modulation symbol rate Msym/s;... -
Page 13: Common Interface Setting Up For Cam Descrambling
Press Save to start descrambling. Note. Multiple program descrambling is supported with CRT1081IRD-S2-MX CI interface. Only CA Modules supporting that mode can be used to open several programs. -
Page 14: Asi Input State Monitor
CRT1081IRD-S2-MX USER’s MANUAL 4.3.3 ASI input state monitor CRT1081IRD-S2-MX has four DVB-ASI inputs that atomatically tune to proper operation mode. You can see current ASI input interface state on the ASI input page. Fig. 7 ASI input page. Crypton, January 2013... -
Page 15: Asi Output Configuration
4.5.1 Device control IP configuration Fig. 9 Device IP options page • MAC address – Unique Ethernet network address of CRT1081IRD-S2-MX IPE (1Gbit) port. • IP address – Unique sourcr IP address of the device IPE port; • IP encapsulation mode – Only UDP encapsulation is supported;... -
Page 16: Dvb-Over-Ip Streaming Configuration
USER’s MANUAL current settings if you need them later. 4.5.2 DVB-over-IP streaming configuration Each of four CRT1081IRD-S2-MX embedded multiplexers can deliver output CBR MPTS over IP. Fig. 10 IP outputs page The following settings can be made. • Streaming type – Unicast or Multicast ip delivery can be selected;... -
Page 17: Program Filtering
Fig. 11 Program Filtering page You can use this page to set program filters for all device inputs. Only filtered programs will be maintained by CRT1081IRD-S2-MX stream processor no other programs can be got on the device outputs. The following actions can be done. -
Page 18: Input Psi/Si Acuiring
No signal massage shows that there is no reliable connection on the requested Input/Inputs. Note. If list of Inputs or All Inputs Acquire is selected it can take rather long time to get information. Scan time is also depends of how much services contains the selected transponder. Crypton, January 2013... -
Page 19: Program Service Information Preview
Program name. The name that program comes to the system with. Provider. Program provider information. Program number. Unique for the current transponder program number. Source. Input information the program received from. PID PCR. Current program reference time stamp PID PID PMT.Current program PMT table PID Crypton, January 2013... - Page 20 Service type. Type of a service the selected program cosists of. Pid. Service ID. Service descriptors. List of descriptors for the current service. Program descriptors. List of descriptors for the current program. Use this information to plan your network DTV network. Press OK to close information window. Crypton, January 2013...
-
Page 21: Program Assignment To Multiplexes
4.6.3 Program assignment to multiplexes Fig. 16 Program assignment to multiplexes Any program of the selected input can be assigned to one of four CRT1081IRD-S2-MX output multiplexes. Only point the multiplex the program have to be distributed in. You can only map a program with only one multiplex. -
Page 22: Psi/Si Edit
USER’s MANUAL 4.6.4 PSI/SI edit CRT1081IRD-S2-MX let you edit service information of eatch multiplex. Right after you save programs to multiplexes mapping information new edit option appears on the program filter page. Click this new link to enter PSI/SI edit window. - Page 23 Note. Unmark service if wont it to be blocked on the output. Note. If you have Video PID the same as PCR PID, PCR stream is leaft with it’s PID but Video elementary stream is blocked. Press Save to apply new PSI/SI data. Crypton, January 2013...
-
Page 24: Crt1081Ird-S2-Mx Output Configuration
USER’s MANUAL 4.6.5 CRT1081IRD-S2-MX output configuration After CRT1081IRD-S2-MX outputs were set up you can open output page make some extra settings. Only list of programs for the current multiplexer appears in the window as below. Рис. 20 Output configuration window Only brief information is presented when you select the window. -
Page 25: Nit & Eit Insertion
Pig. 21 EIT/NIT tables are not uploaded to the device You can use EPGEditor and NITEditor service programs from Crypton Software Suite to make EIT/NIT data files to be downloaded to a SI generator of a proper multiplex. All necessary detailes You can find in CSS_UserManual. -
Page 26: Eit Program Scadule Broadcast
Every time EIT data is uploaded you can see it in proper information window. State: On make the EIT information visible in the TS. Status: Shows if valid data present. Note. Please make sure system time, STB time and EIT data are synchrinized for correct events visualization. Crypton, January 2013... -
Page 27: Nit Broadcast
State: On/Off let you stop or release network infomation injection. Status: Shows if correct data are uplodet for the current multiplex. Fig. 23 Satellite transponder infomation Note. For reliable service descovery STB needs that all information of NIT exactly reflected your device settings. Crypton, January 2013... -
Page 28: Options Menu
Note. After reset to the factory settings (4.3.2) your network setting will reset to default. Note. MAC address change may result connection loss for a long period of time (it depends of PC operation system settings) for new ARP routine accomplishing. Crypton, January 2013... -
Page 29: Authentication
CRT1081IRD-S2-MX USER’s MANUAL 4.8.2 Authentication CRT1081IRD-S2-MX can be managed over internet. To prevent illegal device access user authentication is required. Fig. 25 User accounts settings Enter your Current Login and password before you set new password. Press Save to store new account settings. -
Page 30: Time And Data Setiings
Fig. 26 Date and Time setting up Note. After power off please update date and time settings to synchronize network services. Note. After reset to the factory settings (4.3.2) current Date and Time will be reset to default. Crypton, January 2013... -
Page 31: Firmware Update
CRT1081IRD-S2-MX USER’s MANUAL 4.8.4 Firmware update CRT1081IRD-S2-MX supports firmware update capability. Use this feature only if you are shure that the device really needs to be upgraded. Fig. 27 Firmware update main page Current device F/W version is seen on the main Firmware page. - Page 32 Note. In case you face sudden flashing problems Do Not power off the device and try to restart the process again. Fig. 30 New F/W successfully downloaded To start CRT1081IRD-S2-MX operate with new F/W turn the device power off at least for 30 sec and power On it again. Crypton, January 2013...
-
Page 33: Fimware Recovery
USER’s MANUAL 4.8.5 Fimware recovery. CRT1081IRD-S2-MX is capable to withstand to F/W upgrade accidental failure due to power off or connection loss. F/W recovery process starts automatically every time you turn the device power On after base device F/W is damaged. -
Page 34: Import And Export Configuration Information
CRT1081IRD-S2-MX USER’s MANUAL 4.8.6 Import and export configuration information. CRT1081IRD-S2-MX can export all configuration information to be imported with an other device. This feature is exeptionally important when you build realtime broadcast network where hardware reservation is absolutly obligatory. Export data to the file and save it until reserve device is required or F/W update is made.
