  • Page 1 Infinate Blu Striker HD User’s Guide Striker HD How to use this set-top box...
  • Page 2 Striker HDis between 50º C (122º F) to 60º C (140º F). IMPORTANT SAFETY CONSIDERATIONS The Striker HD set-top box requires careful handling to avoid potential damage to its internal parts. Be sure to follow these requirements during transportation and installation. The plug is the main disconnect device.
  • Page 3 Striker HD-User’s Guide During Transportation to the Subscriber Home Transport the Striker HD in its shipping box or an equally padded container. Do not expose it to rain or moisture. During Installation  Do not place Striker HD in an enclosed area where the cooling vents are blocked or impede the flow of air through the ventilation openings.
  • Page 4 Striker HD-User’s Guide  Install Striker HD on a hard flat surface not prone to vibration or impact and not on top of another electronic device  Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
  • Page 5 20 cm from all persons and must be co-located for operating in conjunction with any other antenna or transmitter. CARING FOR THE ENVIRONMENT BY RECYCLING When you see this symbol on a Infinate Blu product, do not dispose of the product with residential or commercial waste. Recycling your Infinate Blu Equipment Please do not dispose of this product with your residential or commercial waste.
  • Page 6 HD-User’s Guide © 2014 Infinate Blu Limited All rights reserved. No part of this publication may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or adaptation) without written permission from Infinate Blu Limited.

  • Page 7: Table Of Contents

    Adjusting the Volume ........................ 13 Interactive Programming Guide ....................14 Video Output Format Option ..................... 14 3.CONNECTING YOUR Striker HD SET TOP BOX TO YOUR HOME .......... 15 4.HOW TO MANUALLYCONFIGURE THE T-503SET-TOP BOX ..........20 5.TROUBLESHOOTING ......................... 36 7/ 36...

  • Page 8: Introduction

    HD-User’s Guide 1. INTRODUCTION We congratulate you on receiving this Striker HD Series High-Definition All-Digital set-top box, one of the most compact and advanced interactive digital IPTV set-top boxes available today. Infinate Blu has combined the extraordinary features of IPTV — the interactive programming guides, almost endless programming options, Video on Demand (VOD), the incredible sound and picture quality of High-Definition TV (HDTV), and so much more.
  • Page 9 Striker HD-User’s Guide  Fast 1620 DMIPS MIPS Architecture CPU  512 MB of 1600 MHz DDR3  256 MB NAND Flash  USB support for mass storage playback, keyboard, and mouse  Video format support: MPEG-1 MPEG-2 MP@HL, MPEG-4.2 ASP, MPEG 4.10 AVC (H.264 & H.263), MP &...

  • Page 10: Front Panel

    Striker HD-User’s Guide Front Panel Power and Activity LED IR Receiver 10/ 36...

  • Page 11: Rear Panel

    Striker HD-User’s Guide Rear Panel T-CONNECTOR OPTICAL SPDIF HDMI 1.4 USB 2.0 ETHERNET/RJ-45 IR Dongle POWER 11/ 36...

  • Page 12: Operation

    Turning Power On and Off Plug in the supplied power adapter to the electrical outlet and to the back of Striker HD set-top box or use a remote control to turn it on or off (standby). When using the remote control, pressing the POWER button once will put Striker HD set-top box on a standby mode while pressing and holding the same button for approximately 3 seconds will turn it off.

  • Page 13: Interactive Programming Guide

    (1920 x 1080 pixels) source content over the HDMI video output. Striker HD allows you to select a video output format that is compatible with a connected display device. This option provides an easy method for selecting an output format that is compatible with your television.

  • Page 14: Connecting Your Striker Hd Set Top Box To Your Home

    Striker HD-User’s Guide 3. CONNECTING YOUR Striker HD SET TOP BOX TO YOUR HOME Instructions and diagrams are included for the following connections:  High-Definition Television (HDTV)  Standard-Definition TV (SDTV)  WiFi Router  Before you move or change components on your entertainment system, review the following: ...
  • Page 15 Striker HD-User’s Guide 15/ 36...
  • Page 16 Make sure you’re connected to the Internet without any problem (either with a router or a modem). Plug in the power adapter of the Striker HD set-top box to the nearby power outlet. Connect the network cable from the set-top box to the router.
  • Page 17 Make sure you’re connected to the Internet without any problem (either with a router or a modem). Plug in the power adapter of the Striker HD set-top box to the nearby power outlet. Connect the network cable from the set-top box to the router.
  • Page 18 Make sure you’re connected to the Internet without any problem (either with a router or a modem). Plug in the power adapter of the Striker HD set-top box to the nearby power outlet. Connect the network cable from the set-top box to the router.

  • Page 19: How To Manuallyconfigure The T-503Set-Top Box

    Striker HD-User’s Guide 4. HOW TO MANUALLYCONFIGURE THE Striker HD SET-TOP BOX  On the Main Menu page, use the remote control buttons to navigate and select Settings tab.  Press Enter on the remote control to enter the Settings page.
  • Page 20 Striker HD-User’s Guide  On the Settings page, use the remote control buttons to navigate up and down selection. Select General tab and press right arrow button to enter the page. At any point of the operation if you wish to go back to the left side menu selection, you can either press the left arrow button or the Back button on the remote control.
  • Page 21 Striker HD-User’s Guide  There are 3 different languages supported by T-503: English, Russian, and German. Use the remote control to navigate up and down selecting your desired language. Once you have made a selection, press Enter on the remote control. It will automatically change the system language to the language of your selection.
  • Page 22 Striker HD-User’s Guide  On the Location page, select your location and press Enter. Striker HD will then set itself to the location of your selection.  On the Settings page, use the remote control buttons to navigate to Skins tab, and press right arrow button on the remote control to select it.
  • Page 23 Striker HD-User’s Guide  There are 5 different skins you can choose from. Use the remote control buttons to navigate up and down to select your desired skin for your T-503.  Once you have made your selection, press Enter on the remote control to change the system skin to the one that you choose.
  • Page 24 Network tab, and press right arrow button on the remote control.  If you want to connect the Striker HD to your home network by means of a network cable, then select LAN (Local Area Network) tab and press Enter.
  • Page 25 Select Static tab and press right arrow button only if you have the necessary information about your network and want to manually configure the network connection of Striker HD into your home network.  Press any numeric button on the remote control, and it will bring up the soft keyboard onto the screen.
  • Page 26 Striker HD-User’s Guide  On the Network settings page, use the navigation buttons on the remote control to move up and down to select between tabs.  Select DHCP if you don’t want or need to manually configure the IP address for your T-503. Press right arrow button to select it.
  • Page 27 Striker HD-User’s Guide  You will then be asked to confirm if you want the DHCP mode to be enabled or not.  Once you have selected yes, and press Enter on the remote control, then the DHCP mode is enabled from then on.
  • Page 28 Striker HD-User’s Guide  On the Network settings page, use the navigation buttons on the remote control to move up and down to select between tabs. Select PPPoE and press right arrow button on the remote control to enter.  Press any numeric button on the remote control to bring up the soft keyboard.
  • Page 29 Striker HD-User’s Guide  Please wait while Striker HD is trying to establish the network connection for you.  When it has successfully established the connection you will see the check mark next to the PPPoE tab. 29/ 36...
  • Page 30 Network page select WIFI and press the right arrow button on the remote control to enter the WIFI page.  Striker HD then will display a list of all the available wireless connections nearby that it can find for you to select.
  • Page 31 Striker HD-User’s Guide  Once you have made your selection, and press Enter on the remote control you will then be asked for the password. Here you can press any numeric button on the remote control to bring up the soft keyboard for ease of entering information into the required field.
  • Page 32 Striker HD-User’s Guide  The next time you enter the Network page you will see that you’re connected to your home network by WiFi when you see the check mark next to the WIFI tab.  On the Settings page, use the navigation buttons on the remote control to select Video, and press right arrow button to enter the display mode page.
  • Page 33 Striker HD-User’s Guide  On the Display Mode tab, press right arrow button to select it.  Select the display mode that you want by pressing Enter on the remote control. Please base your selection on what your television unit can support. Once you have made the right display mode selection, you will see a check mark next to the display mode of your selection.
  • Page 34 Striker HD-User’s Guide  On the Settings page, use the navigation buttons on the remote control and select About tab and press right arrow button to know more information about your T- 503. You might need to provide this information to your service provider or for some customer assistance.

  • Page 35: Troubleshooting

    If the Striker HD set-top box is connected to a switched outlet on another unit, verify that that unit is powered on. Unplug the power cord from the Striker HD set-top box AC outlet, plug it back it in. It is recommended to use an unswitched outlet, if possible.
  • Page 36 No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of Infinate Blu Limited Under the law, reproducing includes translating into another language or format.
