VEHICLE D I S M A N T L I N G M A N U A L
Corvette
GMP/01-Y-ELV

Advertisement

Table of Contents
loading

Related Manuals for Chevrolet Corvette 2001

Summary of Contents for Chevrolet Corvette 2001

  • Page 1 VEHICLE D I S M A N T L I N G M A N U A L Corvette GMP/01-Y-ELV...
  • Page 2 Cautions Provide additional support when a vehicle is on a hoist in the following ways: - Before removing parts, support the opposite end. This helps prevent the vehicle from slipping off. - Before removing major components, chain the vehicle frame to the hoist pads at the same end as the removal.

  • Page 3: Table Of Contents

    Page No. Introduction..................1 Activity Area 0..................3 Activity Area 1..................4 Activity Area 2..................6 Activity Area 3..................8 Activity Area 4...................10 Activity Area 5...................12 Activity Area 6...................14 Activity Area 7...................16...
  • Page 4 This Page Intentionally Left Blank...

  • Page 5: Introduction

    INTRODUCTION This manual contains dismantling data for the following vehicles: MODEL YEAR MAKE MODEL VARIANT ENGINE TRANSMSSION 2001 Chevrolet Corvette Coupe 5.7L V8 6M/4L60E 2001 Chevrolet Corvette Convertible 5.7L V8 6M/4L60E...
  • Page 6 This Page Intentionally Left Blank...

  • Page 7: Activity Area 0

    Dismantling Manual 2001 Chevrolet Corvette Activity Area 0 -- Pretreatment Area: Pretreatment Model: Corvette Total Volume or Activity Ref Area # Weight Part Name Material Engine oil 5.20 L Engine oil filter Multiple 0.42 kg Transmission oil 7.80 L Refrigerant 134A Refrigerant 134 0.31 kg...

  • Page 8: Activity Area 1

    2001 CORVETTE ACTIVITY AREA 1 DOORS AND GLAZING GLASS EPDM GLASS EPDM PMMA EPDM EPDM EPDM EPDM GLASS GLASS OTHER PMMA EPDM GLASS...
  • Page 9 Dismantling Manual 2001 Chevrolet Corvette Activity Area 1 -- Doors and Glazing Area: Doors and Glazing Model: Corvette Total Material Activity Ref Area # Weight (kg) Part Name Material Windshield Glass 16.37 Front door window, lh, rh Glass 8.48 Front door, lh, rh 12.42...

  • Page 10: Activity Area 2

    2001 CORVETTE ACTIVITY AREA 2 EXTERIOR TRIM 2.14 2.20 2.11 RRIM/PUR 2.13 PA-66 2.15 2.19 2.16 2.17 2.15 2.10 2.18 2.12 OTHER RRIM/PUR...
  • Page 11 Dismantling Manual 2001 Chevrolet Corvette Activity Area 2 -- Exterior Trim Area: Exterior Trim Model: Corvette Total Material Activity Ref Area # Weight (kg) Part Name Material Hood 8.63 Hood substrate 5.16 Front bumper fascia RRIM/PUR 6.74 Front bumper energy absorber 1.27...

  • Page 12: Activity Area 3

    2001 CORVETTE ACTIVITY AREA 3 INSTRUMENT PANEL NO PARTS WERE RECORDED AS REMOVED FROM THIS ACTIVITY AREA...
  • Page 13 Dismantling Manual 2001 Chevrolet Corvette Activity Area 3 -- Instrument Panel Area: Instrument Panel Model: Corvette Total Material Activity Ref Area # Weight (kg) Part Name Material NO PARTS WERE RECORDED AS REMOVED FROM THIS ACTIVITY AREA...

  • Page 14: Activity Area 4

    2001 CORVETTE ACTIVITY AREA 4 SEATING S-RIM S-RIM OTHER...
  • Page 15 Dismantling Manual 2001 Chevrolet Corvette Activity Area 4 -- Seating Area: Seating Model: Corvette Total Material Activity Ref Area # Weight (kg) Part Name Material Front seat foam, lower, lh, rh 1.26 Front seat belt webbing 0.30 Front seat foam, center, lh, rh 1.18...

  • Page 16: Activity Area 5

    2001 CORVETTE ACTIVITY AREA 5 INTERIOR TRIM NO PARTS WERE RECORDED AS REMOVED FROM THIS ACTIVITY AREA...
  • Page 17 Dismantling Manual 2001 Chevrolet Corvette Activity Area 5 -- Interior Trim Area: Interior Trim Model: Corvette Total Material Activity Ref Area # Weight (kg) Part Name Material NO PARTS WERE RECORDED AS REMOVED FROM THIS ACTIVITY AREA...

  • Page 18: Activity Area 6

    2001 CORVETTE ACTIVITY AREA 6 ENGINE COMPARTMENT EPDM PA-66 PA-66 PA-66 PA-66 6.10 PA-66 6.11 6.13 6.11 6.12 6.12 PA-66 PA-66 PA-66 PA-66 PA-66 6.14 6.15 EPDM 6.16 PA-66...
  • Page 19 Dismantling Manual 2001 Chevrolet Corvette Activity Area 6 -- Engine Compartment Area: Engine Compartment Model: Corvette Total Material Activity Ref Area # Weight (kg) Part Name Material Hood weatherstrip EPDM 0.34 Master cylinder reservoir 0.15 Valve cover shield PA-66 0.64...

  • Page 20: Activity Area 7

    2001 CORVETTE ACTIVITY AREA 7 LOAD SPACE NO PARTS WERE RECORDED AS REMOVED FROM THIS ACTIVITY AREA...
  • Page 21 Dismantling Manual 2001 Chevrolet Corvette Activity Area 7 -- Load Space Area: Load Space Model Corvette Total Material Activity Ref Area # Weight (kg) Part Name Material NO PARTS WERE RECORDED AS REMOVED FROM THIS ACTIVITY AREA...
  • Page 22 VEHICLE D I S M A N T L I N G M A N UA L Printed January 2001...
