BELT TYPE
AIR COMPRESSOR
IMPORTANT：
PLEASE READ CAREFULLY BEFORE USE.
Record these numbers in the space below and retain for future reference：
Power source： 240 V
Model No：
Serial No：________________________________________
Purchased Date: ___________________________________
OPERATING INSTRUCTION
50 Hz
Single Phase
Advertisement
Table of Contents
Related Manuals for Paslode C10060
Summary of Contents for Paslode C10060
-
Page 1: Air Compressor
BELT TYPE AIR COMPRESSOR OPERATING INSTRUCTION IMPORTANT： PLEASE READ CAREFULLY BEFORE USE. Record these numbers in the space below and retain for future reference： Power source： 240 V 50 Hz Single Phase Model No： Serial No：________________________________________ Purchased Date: ___________________________________... -
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE 1：IMPORTANT SAFETY INSTRUCTIONS --------------------------------------------- 2：GENERAL DESCRIPTION ------------------------------------------------------------ 3：ON RECEIPT INSPECTION ---------------------------------------------------------- 4：GENERAL REQUIREMENT --------------------------------------------------------- 5：INSTALLATION -------------------------------------------------------------------------- 6：COMPRESSOR LUBRICATION ----------------------------------------------------- 7：START UP PROCEDURE ------------------------------------------------------------- 8：MAINTENANCE CHECK LIST ------------------------------------------------------- 9：STORAGE -------------------------------------------------------------------------------- 10：TROUBLE SHOOTING -------------------------------------------------------------- 9-10... -
Page 3: Important Safety Instructions
1：IMPORTANT SAFETY INSTRUCTION IMPROPER OPERATION OR MAINTENANCE OF THIS PRODUCT COULD RESULT IN SERIOUS INJURY AND PROPERTY DAMAGE. PLEASE READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE USING YOUR AIR COMPRESSOR. KEEP THIS BOOKLET FOR FUTURE REFERENCE. 1-1：RISK OF FIRE ● DO NOT SPRAY COMBUSTIBLE OR FLAMMABLE LIQUID IN A CONFINED AREA, SPRAY AREA MUST BE WELL VENTILATED. - Page 4 1-4：RISK OF BURNS ● HOT SURFACE CAN CAUSE SERIOUS INJURY. NEVER TOUCH ANY EXPOSED METAL PARTS ON COMPRESSOR DURING OR IMMEDIATELY AFTER OPERATION. TOUCHING THESE AREAS MAY CAUSE SEVERE BURNS. ● DO NOT REACH AROUND PROTECTIVE SHROUDS OR ATTEMPT MAINTENANCE UNTIL UNIT HAS BEEN ALLOWED TO COOL.
-
Page 5: General Description
2：GENERAL DESCRIPTION OF AIR COMPRESSOR The air compressor pump works with the up and down of a piston in the cylinder. During the down-stroke, ambient air is drawn in through the inlet valve, while the discharge valve remains closed. On the up-stroke of the piston, the air is forced into the compressor tank through the discharge valve and the check valve. - Page 6 5.2：ELECTRICAL Please ensure that the air compressor is electrically connected in a safe and correct manner. Any electrical work should be carried out by an electrician and installed in a way which meets all applicable codes and regulations. Failure to connect the air compressor correctly to power source may result in serious personal injury or damage to the equipment.
-
Page 7: Compressor Lubrication
6：COMPRESSOR LUBRICATION Do not add or change oil while the compressor is in operation, use the recommended 30 weight non-detergent oil only. 6-1：OIL FILLING 6-1-1：Remove the oil filler plug. 6-1-2：Slowly pour the proper oil into the pump crankcase. 6-1-3：Always keep oil level between the marks “HIGH” and “LOW” level on the oil stick or on the red circle of the sight glass. -
Page 8: Maintenance Check List
8：MAINTENANCE CHECK LIST Before doing any maintenance or adjustments to your air compressor, the following safety precautions should be taken. (1)：DISCONNECT ELECTRICAL POWER. (2)：RELEASE PRESSURE IN AIR RECEIVER. 8-1：Daily checklist 8-1-1：Check oil level. 8-1-2：Drain condensation from air receiver tank. 8-1-3：Check for any unusual noise or vibration. 8-1-4：Be sure all nuts and bolts are tight. -
Page 9: Trouble Shooting
10：TROUBLE SHOOTING： CONDITION CAUSE CORRECTIVE 1：Fuse blown or circuit breaker tripped 1：Check for cause of blown fuse or breaker and replace or reset 2：Check wiring connection Won’t start 2：Loose electrical connection 3：Press reset button 3：Motor overheated 1：Malfunction in valves 1：Check inlet and exhaust valves 2：Loose tube or fittings 2：Tighten fittings 3：Restricted air filter... - Page 10 CONDITION CAUSE CORRECTIVE 1：Undersized unit for air requirements 1：Contact your compressor distributor 2：Compressor location 2：See installation section 3：Pump rotating the wrong way 3：See pump rotation 4：Air leaks in the system 4：Fix leaks 5：Restricted air filter Compressor over heated 5：Clean or replace filter 6：Improper grade or level of oil 6：Use SAE 30 non-detergent 7：Worn, damage or carbon build up on...
- Page 12 Paslode Australia Head Office 47 -55 Williamson Road Ingleburn NSW 2565 Australia www.paslode.com.au ABN 63 004 235 063 2C03-AX01(1212)
