resi-linx digi-MOD IP RL-IP1000 Installation & Configuration Manual

Hd ip streaming server

Advertisement

Quick Links

INSTALLATION & CONFIGURATION MANUAL
SAFETY PRECAUTIONS...........................................................................................2
PACKAGE CONTENTS..............................................................................................2
PRODUCT DESCRIPTION.........................................................................................3
SPECIFICATIONS......................................................................................................4
INSTALLATION, UNPACKING and INSPECTION....................................................5
HARDWARE INSTALLATION and CONNECTIONS.................................................5
Front-Panel.................................................................................................................6
Streaming Methods...................................................................................6
Case 1: DLNA...........................................................................................................16
Case 2: UDP/RTP Multicasting...............................................................................18
Case 3: TCP/UDP/RTP Unicasting..........................................................................20
HDIP Streaming Server Notes................................................................................22
resi-linx.com
resi-linx RL-IP1000
HD IP Streaming Server

TABLE OF CONTENTS

Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the digi-MOD IP RL-IP1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for resi-linx digi-MOD IP RL-IP1000

  • Page 1: Table Of Contents

    INSTALLATION & CONFIGURATION MANUAL resi-linx RL-IP1000 HD IP Streaming Server TABLE OF CONTENTS SAFETY PRECAUTIONS...................2 PACKAGE CONTENTS....................2 PRODUCT DESCRIPTION..................3 SPECIFICATIONS......................4 INSTALLATION, UNPACKING and INSPECTION............5 HARDWARE INSTALLATION and CONNECTIONS..........5 Front‐Panel.........................6 Streaming Methods………………………………………………………………………..6 Procedure to connect to the Streaming Server via the Network port....7 Case 1: DLNA......................16...
  • Page 2: Safety Precautions

     One installation / configuration manual Inspect the package before starting installation to ensure there is no damage and all supplied contents are present. Contact your distributor or dealer should the device be damaged or package contents are incomplete. resi-linx.com Page 2...
  • Page 3: Product Description

    PRODUCT DESCRIPTION resi-linx RL-IR1000 HD IP Streamer allows the user to stream any one audio/video source over a IP Network to up to any 16 Smart HDTV's or connected computers within the IP Network. The IP Streamer accepts a HDMI, Component, or Composite video input and the unit is designed to deliver a rich HD/SD Streaming experience for its users deploying MPEG-2 or MPEG-4 standards.
  • Page 4: Specifications

    Streaming Protocols multicasting, UDP/RTP unicasting, TCP unicast Digital Living Network MISC MediaServer 1.5 Alliance (DLNA) Closed Caption Power Supply 12VDC 1.5Amp. Consumption 500mA Dimension 236mm x 155mm x 35mm Weight 940g *Specifications subject to change without prior notice resi-linx.com Page 4...
  • Page 5: Installation, Unpacking And Inspection

    2. If a DHCP server is present in the private network, the HDIP streaming server will use the IP address assigned by the DHCP server. 3. If no DHCP server is present, the HDIP streaming server will use an assigned IP address (169.254.xxx.x). resi-linx.com Page 5...
  • Page 6: Front-Panel

    Indicates device is encoding video using MPEG-2 Indicates device is encoding video using AVC Indicates device is encoding audio using MPEG-1 Layer 2 Indicates device is encoding audio using AAC AC-3 Indicates device is encoding audio using AC-3 resi-linx.com Page 6...
  • Page 7: Procedure To Connect To The Streaming Server Via The Network Port

    TV and PC. 2. Set the PC via the Control Panel to “Obtain an IP address automatically” Start- Control Panel ==> View Network Status and Tasks 3. Select 'Change Adapter Settings' from the left plane resi-linx.com Page 7...
  • Page 8 4. Select Local Area Connection Icon Then Right Click – Select Properties Internet Protocol Version 4(TCP/IPv4) Properties 5. Select “Obtain an IP address automatically” & “Obtain DNS server address automatically” resi-linx.com Page 8...
  • Page 9 6. After setting the PC to obtain IP address & Obtain DNS server automatically Select Start ==> Computer ==> Network 7. After selecting Network- the HDIP Icon will show up on the right side under Media Devices. Each device found will be displayed by the Device Address. resi-linx.com Page 9...
  • Page 10 8. Right Click on the icon, Select 'View Device Webpage' 9. Overview Welcome page will be displayed resi-linx.com Page 10...
  • Page 11 Press the LED ON button (shown below). This will cause the CFG LED light to flash continuously for the installer to identify and locate the HDIP. To turn off, simply press the LED tool again. resi-linx.com Page 11...
  • Page 12 User Name: admin Default Password: Admin123 Encoder Setup : Once the Welcome Page is displayed select the Encoder Setup tab and the below Login “Authentication Required” screen will be presented. Enter the User Name and Password then click Login. resi-linx.com Page 12...
  • Page 13 3. A supporting Closed Caption Player/TV must be used for this function. Streaming Setup: Allows the user to configure the streaming settings: HTTP (DLNA default), UDP/RTP Multicasting, UDP/RTP Unicasting, and/or TCP Unicasting. HDIP Streaming Server accepts concurrent streaming; you can set multiple streaming at the same time. resi-linx.com Page 13...
  • Page 14 Network Configuration: resi-linx.com Page 14...
  • Page 15 We highly recommend saving the settings of your encoder. A “config.cfg” file will be created. Locate the file My Computer> C Directory > Documents and Settings> User>My Documents>Downloads>configs.cfg. resi-linx.com Page 15...
  • Page 16: Case 1: Dlna

    Streaming methods: ( Note: If using VLC player, please install version 2.0.8 or newer version) Case 1: DLNA resi-linx.com Page 16...
  • Page 17 Using VLC media player, select Media ==> Open Network Stream... On the Network Protocol, key in the Output IP address and Output Port as following example, http://172.21.6.88:8888/VideoInput/play.ts Press Play button to view the video resi-linx.com Page 17...
  • Page 18: Case 2: Udp/Rtp Multicasting

    Case 2: UDP/RTP Multicasting resi-linx.com Page 18...
  • Page 19 Using VLC media player, select Media ==> Open Network Stream... On the Network Protocol, key in the Output IP address and Output Port as following example, ex. rtp://@224.1.1.8:1234 Press Play button to view the video. resi-linx.com Page 19...
  • Page 20: Case 3: Tcp/Udp/Rtp Unicasting

    Case 3: TCP/UDP/RTP Unicasting resi-linx.com Page 20...
  • Page 21 Using VLC media player, select Media ==> Open Network Stream... On the Network Protocol, key in Output Port as following example, udp://@1234 Press Play button to view the video. resi-linx.com Page 21...
  • Page 22: Hdip Streaming Server Notes

    HDIP Streaming Server Notes PRODUCT NOTES: ITEM VALUE USER NAME / PASSWORD SERIAL NUMBER INSTALLATION DATE PURCHASE DATE DEVICE NAME FIRMWARE VERSION STREAMING METHOD resi-linx.com Page 22...
