Digital Wireless Computer
User's Manual
- English -

Advertisement

Table of Contents
loading

Related Manuals for Giant NEOS SYNC

Summary of Contents for Giant NEOS SYNC

  • Page 1 Digital Wireless Computer User’s Manual - English -...

  • Page 2: Table Of Contents

    Table of contents Preface Log overview Computer firmware update Package contents System setup Computer display language setup Installation instructions Power meter calibration Import trip logs to app Display & buttons Select connection mode Troubleshooting ANT+ sensor paring and Quick setup Specifications Bluetooth phone pairing Trip logs...

  • Page 3: Preface

    Preface Thank you for purchasing Giant's Neos Sync Digital Wireless Computer. For your safety, we recommend that you look straight ahead while riding. Avoid staring at the computer screen. This may compromise your awareness, leading to a serious accident. Ensure that the head unit has been paired with the speed sensor before using your computer.

  • Page 4: Package Contents

    Package contents The Neos sync comes with one head Head Unit Straps Sensor Unit unit and three accessories FOR 410000048 ONLY 1.Head unit 2.Charging cable 3.Base and handlebar extension 4.Rubber straps 5.Speed and cadence sensor 6.Speed sensor battery 7.Speed sensor magnet 8.Cadence sensor magnet...

  • Page 5: Installation Instructions

    Installation instructions Mounting Locations of Components The head unit can be mounted in three different locations: (A) Stem (B) Handlebar (C) Handlebar extension (optional). Mount the speed and cadence sensor to the non-drive chainstay with zip ties, as shown. Mount the speed sensor magnet to a spoke and the cadence sensor to the non-drive crankarm.

  • Page 6: Display & Buttons

    Display & buttons 12 13 Default Functions Other Functions 1. RIDE TIME Trip ride time Odometer Max Altitude Maximum altitude 2. SPEED Current speed TOT Ride Time Total riding time Max Ascent % Maximum uphill slope Current cadence 3. CADENCE TOT Calories Total calories burnt Ave Ascent %...
  • Page 7 Display & buttons General Display Setup Menu Power Off Press M2 key in general display mode to enter the quick menu: L: Press the L key to power off M: Press the M key to exit the quick menu R: Press the R key to enter the setup menu Auto Backlight Auto Backlight:...
  • Page 8 Display & buttons The computer prompts you to start Start Riding recording ride data when a signal is received from the speed sensor. Press the R key to record, press the L key to ignore. After pressing the R key, the computer prompts you to start a new ride log or to continue recording an existing ride log.
  • Page 9 Display & buttons Incoming Call: Incoming Call Unanswered Call The computer displays an incoming call talert when call is received while riding. Press any key to close the alert and go back to the ride page. Unanswered Call: The computer displays a missed call alert if an incoming call is not answered.
  • Page 10 Display & buttons P.13 P.14 P.15 Press the M2 key to enter the quick menu. Press the L or R key to enter to select quick start. Press the M key to confirm and enter units setup. Quick setup (P.9) → Trip logs (P.13) →...

  • Page 11: Quick Setup

    Quick setup After entering units setup, press the L Set Units Set Date or R key to select either metric or imperial units. Press the M key to confirm and move to time setup. Set time...
  • Page 12 Quick setup After entering time setup, press the L Set time or R key to select either 12 or 24 hour format. Press the M key to confirm and move to wheel size setup. Set wheel size...
  • Page 13 Quick setup After entering wheel size setup, press the L or R key to select from ten pre-programmed wheel sizes. *Same as Bike2 setting Press the M key to confim and move to gender and weight setup mode. If wheel size is not shown, WHEEL CIRCUMFERENCE select custom and enter youra measured wheel circumference.
  • Page 14 Quick setup After entering heart rate setup, press Set Heart Rate Pair Sensors the L or R key to select your upper heart rate limit. Press the M key to confirm. Press the L or R key to select your lower heart rate limit. Press the M key to confim and move to pair sen- sors mode.

  • Page 15: Trip Logs

    Trip logs After entering the quick menu, press Set Trip Logs L or R key to select history. Press the M key to confirm. Press the L or R key to select the ride date. Press the M key to confirm and enter the trip log display page.

  • Page 16: Log Overview

    Log overview After entering the quick menu, press Set Log Overview L or R key to select statistics. Press the M key to confirm and enter the statistics page. Data shown in the statistics page are all cumulative. After entering the statistics page, press the R key to go to the next page.

  • Page 17: System Setup

    System setup Set Options P.16 P.17 P.18 P.19 P.20 After entering the quick menu, press the L or R key to select setup. Press the M key to confirm and move to the setup menu. User data (P.16)→ Wheel size (P.17)→ Riding page display (P.18) →...
  • Page 18 System setup After entering the setup menu, press User data L or R key to select user data. Press the M key to confirm and move to user data setup. After entering user data setup, press the L or R key to select male or female.
  • Page 19 System setup After entering the setup menu, press Wheel size the L or R key to select wheel size. Press the M key to confirm and move to wheel size setup. After entering wheel size setup, press L or R key to select from ten pre-programmed wheel sizes.
  • Page 20 System setup After entering the setup menu, press Set Ride Page Display L or R key to select display. Press the M key to confim and move to display setup. After entering display setup, press the L or R key to select the number of cells to display on the custom ride page.
  • Page 21 System setup After entering the setup menu, press Set Units the L or R key to select unit. Press the M key to confirm and move to unit setup. After entering unit setup, press the L or R key to select kilograms or pounds.
  • Page 22 System setup After entering the setup menu, press Bike Selection the L or R key to select bike select. Press the M key to confirm and move to bike select. After entering bike select, press the L or R key to select Bike 1 or Bike 2. Press the M key to confirm and exit to the setup menu.
  • Page 23 System setup After entering the setup menu, press Set Date and Time the L or R key to select date/time. Press the M key to confirm and move to date/time setup. After entering date/time setup, press the L or R key to select the year. Press the M key to confirm.
  • Page 24 System setup After entering the setup menu, press Altitude the L or R key to select altitude. Press the M key to confirm and move to altitude setup. After entering altitude setup, press the L or R key to select altitude. Press the M key to confirm and exit to the setup menu.
  • Page 25 System setup After entering the setup menu, press Memory Service Reminder the L or R key to select memory. Press the M key to confirm and move to memory setup. After entering memory setup, press the R key to erase data in memory. Press the L key to exit to the setup menu.

  • Page 26: Power Meter Calibration

    Power calibration After entering the setup menu, press Calibration the L or R key to select calibartion. 2s later Press the M key to confirm and move to calibration. After entering calibration, press the R key to start power calibration or press the L key to exit to the setup menu.

  • Page 27: Select Connection Mode

    Select connection mode After entering the setup menu, press Select Mode the L or R key to select mode select. Press the M key to confirm and move to mode select. After entering mode select, press the L or R key to switch between sensor and phone modes.

  • Page 28: Ant+ Sensor Paring And Bluetooth Phone Pairing

    ANT+ sensor paring and Bluetooth phone pairing After entering the setup menu, press the L or R key to select pair sensors. Press the M key to confirm and move to pair sensors mode. Sensor pairing After entering pair sensors mode, press the R key to pair ANT+ devices including speed, cadence, heart rate, and power.
  • Page 29 Please download and install Giant RideSync App to your smartphone. App connection Compatible with iPhone 4s/ Compatible with Android 4.3/ iOS 7 or later Bluetooth 4.0 or later First riding...
  • Page 30 App connection First riding Second riding...

  • Page 31: Computer Firmware Update

    Computer firmware update Auto update Manual update...
  • Page 32 Computer firmware update Manual update...

  • Page 33: Computer Display Language Setup

    Computer display language setup...

  • Page 34: Import Trip Logs To App

    Import the trip logs to app...

  • Page 35: Troubleshooting

    Troubleshooting Problem Possible cause Solution Problem Possible cause Solution 1.Adjust the sensor or magnet to Battery is not installed Install battery 1.Gap between the cadence sensor reduce the gap to less than 5 mm Cadence is not and magnet is too large displayed 2.Pair the computer to Bluetooth No image on...
  • Page 36 Specifications 20~199Kg Current speed 0 ~ 99.9km/mi Time (12/24) 12:00:00 / 0:00:00 Weight Low battery alert 3.4V 44~331Lb Average speed 0 ~ 99.9km/mi Calories burnt 0~9999Kcal Backlight Auto detection Battery life 1h/day 1 week Operating -10 ~ + 50 ℃ Km / mi, Kg / Lb Maximum speed 0 ~ 99.9km/mi...
