Teldat M12AB Instruction Manual

Digital answering machine with caller id phone
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INTRODUCTION
Thank you very much for purchasing the new intelligent (DSP) Digital Answering Machine with
Caller ID phone of our company. Backed up by the most advanced high quality IC and standard
transmitting and receiving circuit, it assures the authenticity and low noise. It is really the best
choice for you in its useful functions and novel design. In order to use the advanced functions
freely, please read the following specifications before using.
SAFETY INSTRUCTION
When using your telephone with answering system equipment, the following basic safety
precautions should always be followed to reduce the risk of fire, electric shock and injury to
persons:
1. Read and understand all instructions
2. Follow all warnings and instructions.
3. Unplug the product from the wall outlet before cleaning. Do not uses liquid cleaners or
aerosol cleaner. Use damp clothes for cleaning.
4. Do not place this product on an unstable cart, stand or table. The product may fall, causing
serious damage to the product.
5. This product should only operate on the type of power source indicated on the marking label.
If you are not sure of the type of power supply to your home, consult your dealer or local
power company (only a modular telephone jack is required on power source).
6. Do not allow anything to rest on the power cord. Do not place this product where persons
walking on it will abuse the cord.
7. Do not overload wall outlets and extension cords as this can result in the risk of fire or electric
shock.
8. Never push objects of any kind into this product through cabinet slots as they may touch
dangerous voltage points or short out parts that could result in a risk of fire or electric shock.
Never spill liquid of any kind on the product.
9. Avoid using this unit during an electrical storm, move or disconnect the unit, there may be a
remote risk of electronic shock from lightning and thunder.
FEATURES
FSK/DTMF compatible with auto-detection
15-digit and 15-character LCD display
Menu interface and voice prompt in German, French and English for selection
Maximum 99 incoming and 50 outgoing call memories
120 groups phonebook with number and name
High and low recording voice quality for selection, corresponding to 21 minutes and 42
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M12AB and is the answer not in the manual?

Questions and answers

Summary of Contents for Teldat M12AB

  • Page 1 INTRODUCTION Thank you very much for purchasing the new intelligent (DSP) Digital Answering Machine with Caller ID phone of our company. Backed up by the most advanced high quality IC and standard transmitting and receiving circuit, it assures the authenticity and low noise. It is really the best choice for you in its useful functions and novel design.

  • Page 2: Getting Started

    minutes of voice storage time Recorded messages up to 59 groups Three default outgoing message (OGM) The length of Memo and ICM records can be selected 3-digit user’s access password for remote control Remote control to play and record OGM Remote control to play and delete Memo, ICM, 2-WAY records Ringing times setting for Auto-Answer Redial function...

  • Page 3: Location Description

    LOCATION DESCRIPTION...

  • Page 4: Menu Setting

    CID FUNCTIONS OPERATION MENU SETTING In on-hook or off-hook state, press SET key to enter the setting menu, LCD will display OPTIONS MENU ▲▼. Press UP or DOWN key to choose the setting item and press ENTER key to enter this setting. Press UP or DOWN key to adjust the entire item chosen. After finished, press ENTER key to confirm and return to superior menu.
  • Page 5 Message length setting In on-hook or off-hook state press SET key to enter the setting menu, then press UP key six times, LCD will display MESSAGE LENGTH. Press ENTER key, LCD displays MESSAGE LENGTH 1, using UP or DOWN to select the message length at 1 - 2 minutes, press ENTER to confirm.

  • Page 6: Basic Usage

    Voice quality setting In on-hook or off-hook state, press SET key to enter the setting menu, then press UP key eleven times, LCD will display TAM HD: ON. Press ENTER key, ON flashes, use UP or DOWN to select ON or OFF and press ENTER to confirm. NOTE: ON means high voice quality and the total voice storage time is only 21 minutes;...

  • Page 7: Phone Book Operation

    pick up the handset, the number is dialed out after 2 seconds. Redial Press key or pick up the handset, then press REDIAL/P key, the last dialed number is dialed out again. INCOMING MEMORIES OPERATION Reviewing In on-hook or off-hook state, press UP or DOWN key to review the incoming number information. Deleting In on-hook or off-hook state, review the desired number, press DEL key once, LCD displays DELETE CALL?, press DEL key again to delete it.

  • Page 8: Ringing Volume Adjustment

    using number keys directly. For example, input “C” letter, just continuously press 2 key three times. Press BOOK key to confirm the name. When input the phone number and name, pressing UP or DOWN key can move the cursor. Or review an incoming or outgoing number, press BOOK key. A cursor flashes at the first digit, press BOOK key to confirm the number.
  • Page 9 1. Press HOLD key to release hold mode and continue to talk over handset, or 2. Hang up handset, it enters hands-free hold mode. When talking at hands-free mode, press HOLD key to enter the hold mode and the hold music is sent out.

  • Page 10: Operation Procedure

    Press ON/OFF/STOP to stop message recording or playback. Press ON/OFF/STOP to stop remote control operation. Press ON/OFF/STOP to change the Answering mode to “ANSWER A1” or “ANSWER A2” Press and hold OGM key for 2 seconds to start recording the answer-record OGM Press once OGM key to play recorded OGM or the default OGM.
  • Page 11 Auto-answer OGM is a conventional message to tell the caller some information of the owner. There are two groups OGM can be recorded, one for “ANSWER A1” mode and another for “ANSWER A2” mode. Record OGM for “ANSWER A1” mode as follows: In on-hook state press ON/OFF/STOP key to select “ANSWER A1”, press OGM key for about 2 seconds and release;...
  • Page 12 retrieving messages locally or remotely will hear it. Record Memo as follows: Press and hold the MEMO/SKIP key for about 2 seconds and release the key, after a long beep Memo recording will start. Stop recording by pressing ON/OFF/STOP key once, or stop automatically after up to the set length (1 or 2 minutes).
  • Page 13 c) Erase single message Press DEL key twice to erase the current played message. d) Stop message play Press ON/OFF/STOP key to stop the message play. Answer-Only Mode When the total numbers of saved messages exceed 59 or the memory is full during recording, the answering machine will be changed to answer-only mode automatically.

  • Page 14: Simplified Troubleshooting

    Press 5 to record announcement (Note: To OGM recording end recording, please press 6 key) Stop (Record/Play) Press 6 to stop Delete current message Press 7 to erase message Answering off Press 8 to set Answer off Press 9 to set Answer on (press 9 again to Answering on;...
  • Page 15 The machine cuts off Maximum recording time The incoming message is too incoming incoming message (ICM) is 1 or 2 long. message minutes Improper cable connection Make sure the cable is properly No sound between the microphones and connected or replace it the cord wire 1)The connected...
