ENDAT‐N3410 User's Manual

UNICORN COMPUTER CORP.
ENDAT-N3410
















For ENDAT-N3410 PCB ver. A01
Document version: 0.7
Release Date: Mar.08.2016
Copyright 2015 Unicorn Computer Corporation. All rights reserved.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ENDAT-N3410 and is the answer not in the manual?

Questions and answers

Summary of Contents for Unicorn ENDAT-N3410

  • Page 1 ENDAT‐N3410 User’s Manual    UNICORN COMPUTER CORP. ENDAT-N3410                                  For ENDAT-N3410 PCB ver. A01 Document version: 0.7 Release Date: Mar.08.2016 Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 2 The manufacturer is not responsible for any damage to the motherboard due to improper operation. Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 3: Table Of Contents

    2.7. REAL‐TIME CLOCK SUBSYSTEM   ....................21  2.8. AUDIO SUBSYSTEM   ...................... 22  2.9. LAN SUBSYSTEM   ..................23  2.10. HARDWARE MONITORING   ........................24  2.11. ACPI   ....................27  2.12. HARDWARE SUPPORT     ......................28 ONBOARD Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 4   ..................28  3.1. CONNECTORS AND HEADERS   ...................... 31  3.2. JUMPER SETTING   ....................34  3.3. PIN HEADER DEFINED     ......................45 APPENDIX   ................45 4.1. WDT AND DIGITAL I/O PROGRAMMING Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 5 Dec 17, 2015 Modified information and add connector defined for VGA and JFP1, Feb 25, 2016 Add procedure for BIOS refresh. Mar 06, 2016 Changed label for KB/MS and Audio Line-in. Mar 08, 2016 Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 6: Disclaimer

    Disclaimer    This product specification applies to only the Unicorn Computer ENDAT-N3410 series. All Unicorn Computer Boards are evaluated as Information Technology Equipment (I.T.E.) for use in personal computers (PC) for installation in homes, computer rooms, and similar locations. The suitability of this product for other PC or embedded non-PC applications or other environments, such as medical, industrial, alarm systems, test equipment, etc.
  • Page 7: Introduction

    UNICORN COMPUTER CORP. Introduction  The ENDAT-N3410 Mini-ITX board uses Intel N3000 series boards, Single, Dual, or Quad-core CPU. It is compatible with Unicorn Computer ENDAT-N3410 specification and incorporates a single 10/100/1000 Mbps Ethernet controller, 10 digital I/O signals, four serial ports, one port of HDMI 1.4 video (with digital audio support), and one port of HDMI display interface (without digital audio support).
  • Page 8: Product Description

    RS232/422/485 by System BIOS; the COM2 ~ COM4 are box header type USB 2.0 / USB 3.0  8 USB ports include 6 USB 2.0 + 2 USB 3.0  Other  2 x POE    EXPANSION SLOT  2 mini‐PCIe socket design with One Full and One Half  2 x PoE + RJ‐45 connector  COM1,    2 x HDMI, 1 x VGA (For ENDAT‐N3410)  I/O PORT (Rear Window)  USB 2.0 x 4 (ENDAT‐N3410S: USB2.0 x 2), USB 3.0 x 2  DC Jack  2.00mm Box Header support COM2 ~ COM4  2.00mm Pin Header suppot Line‐In, Line‐Out, MIC‐in and Speaker out  BOX Header / Header  2.00mm Pin Header suppot USB 2.0 x 2  2.00mm Box Header for LPT;    2.00mm Pin Header for PS2 KB/MS  POWER SUPPLY  Wide range DC 9 ‐ 35V input  Board Size  mini‐iTX    form factor of 170mm x 170mm  Figure1 - Product specifications Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 9: Board Layout

    ENDAT‐N3410 User’s Manual    UNICORN COMPUTER CORP. 1.2. Board Layout Show the location of the major components on the top-side of Unicorn Board ENDAT-N3410. Figure2 - Board Components “▪” Represents the 1 Pin. Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 10 Two Port USB 3.0 Connector HDMI1 Connector (DDI0 ) VGA Connector (DDI2,this for “N3410” only) HDMI2 Connector (DDI1 )( Option: Switch LVDS by H/W BOM Changed) Serial Port1 (Serial console function support) Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 11: Components List

    Serial port 4 Box Header JLPT1 Parallel Port Box Header JUSB1 USB 2.0 header JUSB2 USB 2.0 header JLVDS LVDS Socket Connectors HDDPWR2 HDD Power Table 1: Onboard jumper setting for PCB: A0 Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 12: Block Diagram

    ENDAT‐N3410 User’s Manual    UNICORN COMPUTER CORP. 1.4. Block Diagram Block diagram of the major functional areas of the board. Figure5 - Block Diagram Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 13: Technical Reference

      UNICORN COMPUTER CORP. Technical Reference 2.1. Processor Unicorn Computer ENDAT-N3410 has a soldered-down System-on-a-Chip (SoC), which consists of a dual-core Intel Celeron processor N3150 with up to 6 W TDP. • Integrated graphics • Integrated memory controller • Integrated PCH Processor Number...
  • Page 14: System Memory

    To be fully compliant with all applicable DDR SDRAM memory specifications, if non-SPD memory is installed, the BIOS will attempt to correctly configure the memory settings, but performance and reliability may be impacted or the SO-DIMMs may not function under the determined frequency. Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 15 DIMMA1: 512MB/1GB/2GB/4GB/8GB DIMMB1: 512MB/1GB/2GB/4GB/8GB Max is 8GB   C. Dual Channel Memory Installation  Please refer to the following requirements to activate Dual Channel function: Install memory module of the same density in pairs, shown in the table. Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 16: Memory Resources

    4 GB boundary to an equivalent sized logical address range located just above the 4 GB boundary. All installed system memory can be used when there is no overlap of system addresses. Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 17: Processor Graphics Subsystem

    The following audio technologies are supported by the HDMI 1.4b interfaces directly from the SoC: • AC3 - Dolby* Digital and Dolby Digital Plus • This HDMI audio support on HDMI only. Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 18: Usb 3.0 And 2.0 Host Controller

    Computer systems that have an unshielded cable attached to a USB port may not meet FCC Class B requirements, even if no device is attached to the cable. Use a shielded cable that meets the requirements for full-speed Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 19: Sata Interface

    ATA device is connected to a board through a cable from the power supply. We support the SATA can switch with Power on Pin 7 by jumper, making it possible to plug your flash storage device onto your board without the need for any external cable. Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 20: Real‐Time Clock Subsystem

    2. When the voltage drops below a certain level, the BIOS Setup program settings stored in CMOS RAM (for example, the date and time) might not be accurate. Replace the battery with an equivalent one.   Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 21: Audio Subsystem

    • Internal 2.00mm header support Line-in, Line-out, MIC-in, Speaker. Pins Define: Speakers Headphones Microphone Line-In   • Audio Software Audio software and drivers are available from Unicorn Computer World Wide Web site.  Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 22: Lan Subsystem

    • Power management capabilities   ACPI technology support   LAN wake capabilities • Support POE+ (PD) function support. • TCP, IP, and UDP checksum offload (for IPv4 and IPv6) • Full device driver compatibility Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 23: Hardware Monitoring

    The hardware monitoring and fan control subsystem is based on Nuvoton embedded controller, which supports the following: • Processor and system ambient temperature monitoring • Chassis fan speed monitoring • Voltage monitoring of +12v, +5 V, +3.3 V, • SM-Bus interface Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 24: Acpi

    More than six seconds Power-off (ACPI G2/G5 – Soft off) Table 4 - Effects of Pressing the Power Switch   Note:    This is depending on power management setting in operating system. Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 25 1. Total system power is dependent on the system configuration, including add-in boards and peripherals powered by the system chassis’ power supply. 2. Dependent on the standby power consumption of wake-up devices used in the system. Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 26 1. Monitor will remain in “sleep” state 2. “S5 WoL after G3” supported w/Deep Sleep disabled 3. Wake from S3 and S4 only supported. 4. Wake from device/event not supported immediately upon return from DC loss Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 27: Hardware Support

    When the WAKE# signal on the PCI Express bus is asserted, the computer wakes from an ACPI S3, S4, or S5 state. •Wake from S5 When the RTC Date and Time is set in the BIOS, the computer will automatically wake from an ACPI S5 Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 28: Onboard

    This section describes the board’s connectors and headers. The connectors and headers can be divided into these groups: Figure 7 & figure 8 shows the location of the back panel connector for the board    Figure 7 – Rear I/O Figure 8 – Rear I/O for N3410S Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 29 44 to 57 Vdc for PoE. Also, consider this: the current for PoE is 350mA, while the current for PoE+ is a whopping 600mA. This provides as much as 25W at the powered device after allowing for cable voltage drops. Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 30 (Table 8). Four-pair PDs may exhibit different class levels for each of their connections.   Table8. Power Classes (for Two‐Pair Powering)  Power Class Maximum Average Power Available at PD Class 0 Class 1 3.84W Class 2 6.49W Class 0 Class 3 25.5W Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 31: Jumper Setting

    4. After clearing the CMOS values, be sure the jumper is “Pin 1-2 open”. 5. Plug-in DC power input. 6. Power on the system, then hold function key”F2” enter to BIOS SETUP by keyboard Press 7. Load Optimal Defaults and save settings in CMOS. Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 32 Please carefully follow the procedures to avoid damaging the motherboard. Item +12V Pin Close 1-2 (Default) JP3: SATA#1, Power select for SATA‐DOM module  The jumper for 5V selected, provide pin7 with +5V power for SATA DOM device Item Pin Close 1-2 (Default) Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 33 11-12 JP8: LVDS back‐light Active power select  The jumper allows users to restore the BIOS safe setting and the CMOS data. Please carefully follow the procedures to avoid damaging the motherboard. Item +3.3V Pin Close 1-2 (Default) Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 34 JCOM3 Serial port 3 Box Header JCOM4 Serial port 4 Box Header JLPT1 Parallel Port Box Header JUSB1 USB 2.0 header JUSB2 USB 2.0 header JLVDS LVDS Socket Connectors HDDPWR2 HDD Power Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 35 None Close None Close Mini-PCIE2 Pin Close \Type 1.2 (Default) Close None 9-10 None Close 11-12 None Close   J1: MIC / Line‐In audio connector  Line‐In  MIC  Pins Defined Pins Defined LINE1_L_HDR_CN MICIN1_L LINE1_JD MIC1_JD AUD_GND AUD_GND Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 36 SDIO3 output +3.3VSB +3.3VSB JKBMS: Keyboard & Mouse header  Pins Defined Pins Defined KBDA Key Lock Key Lock KBCLK MCLK JCPUFAN1: Processor fan header  Pins Defined Pins Defined +12V FAN Speed Control JSYSFAN1: System fan header  Pins Defined Pins Defined +12V FAN Speed Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 37 AD 3 LPC_PORT80_CLK LPC_IRQ JCOM2, JCOM3, JCOM4: COM Port 2, 3, 4 Headers  Pins RS-232 RS-422 RS-485 Data - Data + By Jumper JP6 & JP7 RS-422 and RS-485 function only for COM2 and COM3, function changed by BIOS SETUP Manual Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 38 BUSY Paper Out Select Line Feed Error Reset Select Print     VGA Connector:    Pins  Defined  Pins  Defined  VGA_RED VGA_GREEN VGA_BLUE +V5S_VGA VGA_GND LCD-PWR LCD-PWR +V5S_VGA VGA_DDCDAT VGA_HSYNC_R VGA_VSYNC_R VGA_DDCCLK     Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 39 Odd 3+ Odd 3- Odd CLK+ Odd CLK - Even 0+ Even 0-. Even 1+ Even 1- Even 2+ Even 2- Even 3+ Even 3- Even CLK+ Even CLK- LCD-PWR LCD-PWR     Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 40 PWM duty cycle range: from 30~100%, the output frequency from PWM Out can be up to 400 kHz and Voltage level is +3.3V   JP1: LCD Voltage Select (2x3 with 2.0mm)  Voltage +3.3V * +12V   JP2: LCD Backlight Voltage Select (1x3 with 2.0mm)  Voltage +5V * +12V   JP8: LCD Backlight Control Voltage Select (1x3 with 2.0mm)  Voltage +3.3V * Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 41 ENDAT‐N3410 User’s Manual    UNICORN COMPUTER CORP. HDMI: HDMI Connector              HDDPWR2: SATA HDD Power:      Pins  Defined  Pins  Defined  +12V       Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 42 ENDAT‐N3410 User’s Manual    UNICORN COMPUTER CORP. Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 43 2. Plug the bootable USB thumb drive into the USB port of your system. 3. Power on your system & hold [F5] to get the “Boot menu”. 4. Select “Internal shell”. 5. Changed dir to your drive, for example Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 44 Fpt64.efi –f    “BIOS name.extension”      Note: “BIOS name.extension” stands for the full name of the BIOS file you intend to update with. Example:        “fpt64.efi    –f    N3410‐xxx.bin”      Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 45 // 1: Watchdog Timer I is reset by keyboard interrupt. outportb(0x2e,0xf0); //set WDTO Control Mode outportb(0x2f,0x00); //set register value Default :00h // (bit3=1: minute. =0: second) outportb(0x2e,0xf1); //set WDT Counter outportb(0x2f,tt); //set time out value of WDT void show_ver() Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 46 // Bit 0~3 DIO-O0~ DIO3 / Bit4~7 DIO-I0~DIO-I3. outportb(0x2e,0xE9); //Read DIO-Input register. //Bit7~Bit4 = DIO-I3~DIO-I0.(Read Only) read_data=inportb(input_port); // Read digital input data printf("DIO-Input=%02X\n",read_data); //Show digital input data on screen ----------------------------------------------------------------------------------End-------------------------------------------------------------------------------//           Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 47 // Bit 0~3 DIO-O0~ DIO3 / Bit4~7 DIO-I0~DIO-I3. outportb(0x2e,0xE9); //Read DIO-Input register. outportb(0x2f,0xnm); // n=DIO-I0~DIO-I3 / m=DIO-O0~DIO-O3. Bit7~Bit3 = DIO-I3~DIO-I0.(Read Only)   ----------------------------------------------------------------------------------End-------------------------------------------------------------------------------//                               Copyright 2015 Unicorn Computer Corporation. All rights reserved.
  • Page 48 ENDAT‐N3410 User’s Manual    UNICORN COMPUTER CORP.     Copyright 2015 Unicorn Computer Corporation. All rights reserved.
