Monit Rally TC100 Operation & Installation

Hide thumbs Also See for TC100:
Table of Contents

Advertisement

Quick Links

See also: Operation & Installation Manual
TC100/200 Operation
& Installation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC100 and is the answer not in the manual?

Questions and answers

Related Manuals for Monit Rally TC100

Summary of Contents for Monit Rally TC100

  • Page 1 TC100/200 Operation & Installation...

  • Page 3: Table Of Contents

    Contents Installation Quick Start User Interface Basics Distance Calibration Fuel Calibration Turning On & Off Operation Customising the Telemetry Menu Using the Sprint Timer Entering a Distance Manually Adjusting the Calibration Configuring the Auxiliary Inputs Troubleshooting Error Messages...

  • Page 5: Installation

    Installation Warning: Installation of the TC100/200 requires modifications to be made to your vehicle’s electrical system. If this is not done correctly, expensive damage may be caused to both the product and your vehicle. It is strongly recommended that you seek the services of a qualified automotive electrician to carry out this work.
  • Page 6 Step 1: Before You Start Check that you have the items shown below. You will also need a selection of tools, wiring sundry, and a safe place to work. (A) Rally Computer; (B) Wiring Loom; (C) Speed Sensor Installation...
  • Page 7 Step 2: Fitting to the Vehicle Securely attach the Rally Computer to the interior of your vehicle. The most common locations for this are either on the dashboard or passenger door frame. When fitting the device, ensure that: • It will not come free of its mounting during an accident. There are two M4 bosses on the back that can be used to fasten it securely.
  • Page 8 Step 3: Electrical Connections All connections to the Rally Computer are made through the color-coded wiring loom supplied with it. Connect this loom to your vehicle’s electrical system as shown in the wiring diagram. BLACK WHITE (Aux. A) BROWN (Aux. B) Speed Sensor Connector GREEN...
  • Page 9 Connect to a 12 Volt power source that is able to supply power when the ignition is +12V turned off. Use a common ground point for all parts of the circuit. Do not use the vehicle’s chassis. (Optional) Attach up to two hand or foot switches to use the Auxiliary Inputs.
  • Page 10 Fuel Sender Signal (TC200 only) To use the TC200’s fuel measurement system, connect the output signal from your vehicle’s fuel sender directly to the green wire on the loom. Points to note during installation are: • The TC200 works by measuring the output voltage of your vehicle’s fuel sender.
  • Page 11 Speed Sensor This generates the signal used by the Rally Computer to measure speed and distance. You should have selected a Monit Speed Sensor to suit your vehicle when you purchased the product. For detailed installation instructions, refer to the information supplied with your sensor.
  • Page 12 Step 4: Final Checks Before you apply power to the system check that all your electrical connections are correct. Also make sure that any exposed wires in the circuit are covered with insulation tape or heat-shrink. Installation...

  • Page 13: Quick Start

    Quick Start The TC100/200 works in a similar way to a portable music player or mobile phone and is designed to be very easy to use. Read this section to quickly learn how to perform a calibration, view vehicle data, and access commonly used features.

  • Page 14: User Interface Basics

    User Interface Basics The Rally Computer’s user interface consists of a graphics screen surrounded by four buttons. When the device starts up you will see the following image on the screen. On the left and right edges of the screen there are two vertical bands that contain text labels.
  • Page 15 Telemetry Menu This appears when the device first starts up. It allows you to easily view your vehicle’s distance, speed, timing and fuel information, and is the menu you will use most of the time. Interval Distance Counter The upper half of the menu always shows the Interval Distance Counter. Use the upper right CLR button to reset this instantly.
  • Page 16 Total Distance Counter Second distance counter. Hold the CLR button down for one second to reset. Current Speed The current vehicle speed in kph or mph. Average Speed (TC200 only) The average vehicle speed since the function was last reset. This includes any time spent stationary. Hold the CLR button down for one second to reset.
  • Page 17 Time of Day (TC200 only) The current time in 24-hour format. Use the SET button to adjust the value. Fuel (TC200 only) The current fuel level in litres or gallons. When the vehicle is moving the value may fluctuate as the fuel in the tank moves about.

  • Page 18: Menu System

    Menu System You can use the Rally Computer’s powerful menu system to quickly adjust settings and access advanced features. Press the MENU button when in the Telemetry Menu to enter the menu system. Use the two buttons on the right to navigate through the menu options, and the OK button to make a selection.

  • Page 19: Distance Calibration

    Distance Calibration Before you can use the Rally Computer to measure distance, you will need to perform a calibration. The device includes a special calibration wizard that guides you through this process using simple on-screen instructions. To calibrate the distance: Find a piece of road with an accurately known distance.

  • Page 20: Fuel Calibration

    Fuel Calibration (TC200 only) The TC200’s fuel measurement system is designed to work with a wide range of tank sizes and shapes. Before it can be used, the system must be calibrated to suit your particular vehicle. This is done using a special calibration wizard that guides you through the process using simple on-screen instructions.
  • Page 21 The calibration wizard works by recording a number of set points as you add fuel to the tank. For best results: • Use at least five set points (up to a maximum of ten). • Add about 5 to 10 litres of fuel between each point. Notes: Many vehicles will not give a correct fuel signal unless the ignition is turned on.

  • Page 22: Turning On & Off

    Changing the Display Units The Rally Computer can display distance and fuel information in a number of different measurement units. To change this, select Settings > Units. Note: The device does not need to be re-calibrated when this is changed. Adjusting the Backlight When in the Telemetry Menu, the intensity of the backlight can be reduced by holding down the MENU button for one second.

  • Page 23: Operation

    Operation Once you’ve mastered the basic functions of the TC100/200, read this section to learn about its more advanced features. Customise the user interface, setup a foot switch and measure the performance of your vehicle—quickly and conveniently. Operation...

  • Page 24: Customising The Telemetry Menu

    Customising the Telemetry Menu The lower half of the Telemetry Menu can be used to display up to seven different speed, distance, timing and fuel parameters. To reduce clutter, the device allows you to select which parameters you want to use. To enable or disable a parameter select Settings >...

  • Page 25: Using The Sprint Timer

    Using the Sprint Timer The built-in Sprint Timer can be used to accurately measure your vehicle’s 0-100kph (0-60mph) and 0-400m (1/4 mile)* acceleration times. To use the Sprint Timer: Select the Performance menu. Choose the type of sprint you want (0-100kph or 400m*). Bring the vehicle to a halt and press OK to arm the system.

  • Page 26: Entering A Distance

    Entering a Distance In some situations, you may want to set one of the distance counters to a particular starting value. To enter a distance: Select the Set Distance menu. Choose the counter (Interval or Total) that you want to set. Enter the new value.

  • Page 27: Manually Adjusting The Calibration

    Manually Adjusting the Calibration The Rally Computer’s distance calibration is stored as the number of pulses produced by the speed sensor for every kilometre/mile travelled. If you share the device between vehicles, or change tyre sizes frequently, you may want to view and edit this number manually.

  • Page 28: Configuring The Auxiliary Inputs

    Configuring the Auxiliary Inputs The two Auxiliary Inputs can be used to attach external hand or foot switches to the Rally Computer. These can then be configured in software to perform one of the tasks shown in the table on the next page. To assign a task to an input: Select the Settings menu.
  • Page 29 Task Name Description None The Auxiliary Input is not used. Clear Interval Clears the Interval Distance. Clear Total Clears the Total Distance. Freeze Toggles Freeze mode on and off. When Freeze mode is active, the display will not update while the counters continue to oper- ate in the background.
  • Page 30 Using the Fuel Gauge (TC200 only) You can view your vehicle’s current fuel level using either the Telemetry Menu (page 15) or a full-screen gauge. Select the Fuel Gauge item from the Main Menu to view this. Setting the Counting Direction The Rally Computer’s distance counters can be configured to either count up or down.
  • Page 31 Adjusting the Contrast The display contrast can be adjusted to improve clarity under extreme operating conditions. To adjust this, select Settings > Contrast. The normal contrast setting is 50%. Changing the Display Resolution The distance counters normally have a resolution of ten metres. If you require a higher level of accuracy, this can be increased to one metre.
  • Page 32 Operation...

  • Page 33: Troubleshooting

    Troubleshooting If you’re having trouble getting fuel or distance measurements working, read through this section for solutions to some common problems. And if you can’t find an answer here, don’t hesitate to contact Monit directly for help. Troubleshooting...
  • Page 34 The distance measurements are not consistent / The distance increments when my vehicle is stationary. The TC100/200 works by counting the pulses produced by a speed sensor. Noise from other parts of your vehicle’s electrical system can interfere with this signal and cause distance measurement errors.
  • Page 35 The fuel level changes when I turn my engine on and off The output signal from some fuel senders is proportional to the vehicle’s battery voltage. When the engine is running, this voltage is boosted by the charging action of the alternator. The corresponding change in the sender’s output will affect the fuel level shown on the TC200.
  • Page 36 The fuel level measurements are not very accurate The TC200 uses your vehicle’s fuel sender to measure the level of fuel in the tank. If this does not generate a good quality signal, the TC200 will not be able to make accurate measurements. Unfortunately, many factory fuel senders are designed for low cost, not accuracy.

  • Page 37: Error Messages

    Error Messages ‘Error: No pulses detected’ The Rally Computer is not detecting any signal from the speed sensor. Check your connections and the instructions supplied with the speed sensor. ‘Error: Too many pulses’ The Rally Computer is receiving too many pulses from the speed sensor. Reduce the number of pulses by fitting a divider unit.
  • Page 38 ‘Error: Invalid Fuel Signal. Refer to user’s manual.’ Some fuel tank senders produce a voltage that increases as fuel is added, while others produce a voltage that decreases. The TC200 uses the first two set points in the calibration process to detect which type of sender you have. If this error appears the software has detected the wrong type of sender.
  • Page 39 ‘Error: Level must increase between set points.’ The amount of fuel you specified for this set point is less than what you specified for the previous one. Check your calculations. ‘Error: Maximum number of set points reached.’ The TC200 can store a maximum of ten fuel set points. Repeat the calibration using an increased amount of fuel between each set point.
  • Page 40 © Monit Limited 2009 http://www.monitrally.com...
