OM47614U_PRIUS_U.book Page 1 Monday, January 11, 2010 11:02 AM
TABLE OF CONTENTS
Before driving
1
When driving
2
Interior
3
features
Maintenance
4
and care
When trouble
5
arises
Vehicle
6
specifications
For owners
7
Index
PRIUS_U_(OM47614U)
Adjusting and operating features such as door locks,
mirrors, and steering column.
Driving, stopping and safe-driving information.
Air conditioning and audio systems, as well as other in-
terior features for a comfortable driving experience.
Cleaning and protecting your vehicle, performing do-it-
yourself maintenance, and maintenance information.
What to do if the vehicle needs to be towed, gets a flat
tire, or is involved in an accident.
Detailed vehicle information.
Reporting safety defects for U.S. owners and seat belt
instructions for Canadian owners.
Alphabetical listing of information contained in this
manual.
1

Advertisement

Table of Contents
loading

Related Manuals for Toyota Prius 2009

Summary of Contents for Toyota Prius 2009

  • Page 1 OM47614U_PRIUS_U.book Page 1 Monday, January 11, 2010 11:02 AM TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. When driving Driving, stopping and safe-driving information. Interior Air conditioning and audio systems, as well as other in- features terior features for a comfortable driving experience.

  • Page 2: Table Of Contents

    OM47614U_PRIUS_U.book Page 2 Monday, January 11, 2010 11:02 AM TABLE OF CONTENTS Index 1-6. Refueling Before driving Opening the fuel tank cap..79 1-7. Theft deterrent system 1-1. Hybrid system Immobilizer system....82 Hybrid system ...... 22 Alarm ........84 Theft prevention labels 1-2.
  • Page 3 OM47614U_PRIUS_U.book Page 3 Monday, January 11, 2010 11:02 AM 2-3. Operating the lights and 3-2. Using the air conditioning windshield wipers system and defogger Headlight switch....152 Automatic air conditioning system (Vehicles with Fog light switch ....155 AUX adapter) ....197 Windshield wipers and Automatic air conditioning washer ......
  • Page 4 OM47614U_PRIUS_U.book Page 4 Monday, January 11, 2010 11:02 AM TABLE OF CONTENTS Index Optimal use of the audio Maintenance and care system (Vehicle without AUX adapter) ....263 Using the AUX adapter ..265 4-1. Maintenance and care Using the steering Cleaning and protecting the switches ......
  • Page 5 OM47614U_PRIUS_U.book Page 5 Monday, January 11, 2010 11:02 AM When trouble arises Vehicle specifications 5-1. Essential information 6-1. Specifications Emergency flashers .... 412 Maintenance data (fuel, oil level, etc.) ... 460 If your vehicle needs to be towed ......413 Fuel information....
  • Page 6 OM47614U_PRIUS_U.book Page 6 Monday, January 11, 2010 11:02 AM Pictorial index Exterior Windshield wipers P. 156 Turn signal light P. 142 Outside rear view mirror P. 74 Hood P. 357 Side marker light/Parking light P. 152 Headlight P. 152 ∗ Fog light P.
  • Page 7 OM47614U_PRIUS_U.book Page 7 Monday, January 11, 2010 11:02 AM Rear window wiper P. 158 Rear window defogger P. 213 Fuel filler door P. 79 Back door P. 54 Side door P. 51 Licence plate lights P. 152 Tire Rotation P. 375 Replacement P.
  • Page 8 OM47614U_PRIUS_U.book Page 8 Monday, January 11, 2010 11:02 AM Pictorial index Interior Bottle holder P. 323 Seat belt P. 64 Driver airbag P. 89 Head restraint P. 62 Floor mat P. 332 Power window switch P. 76 Auxiliary box P. 324 Front passenger airbag P.
  • Page 9 OM47614U_PRIUS_U.book Page 9 Monday, January 11, 2010 11:02 AM Personal light Interior light P. 317 P. 317 Overhead console box P. 321 Vanity mirror P. 327 Interior light P. 317 ∗ SRS curtain shield airbag P. 89 ∗ Garage door opener switches P.
  • Page 10 OM47614U_PRIUS_U.book Page 10 Monday, January 11, 2010 11:02 AM Pictorial index Interior Door lock switch P. 51 Power rear view mirror control switch P. 74 ITYPP005 Window lock switch P. 76 Power window switches P. 76 PRIUS_U_(OM47614U)
  • Page 11 OM47614U_PRIUS_U.book Page 11 Monday, January 11, 2010 11:02 AM Auxiliary box P. 324 Cup holders P. 322 Power outlet P. 329 ∗ AUX adapter P. 265 Cup holders P. 322 ∗ : If equipped PRIUS_U_(OM47614U)
  • Page 12 OM47614U_PRIUS_U.book Page 12 Monday, January 11, 2010 11:02 AM Pictorial index Instrument panel Gauges and meters P. 145 Windshield wipers and washer switch P. 156 “P” position switch P. 139 Headlight switch P. 152 Turn signal lever P. 142 Auxiliary box P.
  • Page 13 OM47614U_PRIUS_U.book Page 13 Monday, January 11, 2010 11:02 AM Touch screen P. 182 Navigation system MPH or km/h button P. 146 Clock P. 328 Audio system P. 215 Trip meter reset button P. 146 Emergency flashers P. 412 ∗ : If equipped : Refer to “Navigation System Owner’s Manual”.
  • Page 14 OM47614U_PRIUS_U.book Page 14 Monday, January 11, 2010 11:02 AM Pictorial index Instrument panel “INFO” button P. 27 Power (ignition) switch P. 132 ∗ Telephone switch P. 269 Climate remote control switches P. 211 ∗ Cruise control switch P. 159 Talk switch P.
  • Page 15 OM47614U_PRIUS_U.book Page 15 Monday, January 11, 2010 11:02 AM Audio remote control switches P. 266 Horn P. 144 Climate remote control switches P. 211 Instrument panel light control P. 146 ∗ : If equipped : Refer to “Navigation System Owner’s Manual”. PRIUS_U_(OM47614U)

  • Page 16: For Your Information

    Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehi- cle. This vehicle should not be modified with non-genuine Toyota prod- ucts.
  • Page 17 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle. Perchlorate Material Special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate.
  • Page 18 In the event of that your vehicle must be disposed of, the hybrid battery must be disposed of your Toyota dealer or a qualified service shop. If the hybrid battery is not disposed of properly, they may cause electric shock that can result in death or serious injury.
  • Page 19 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
  • Page 20 OM47614U_PRIUS_U.book Page 20 Monday, January 11, 2010 11:02 AM PRIUS_U_(OM47614U)

  • Page 21: Hybrid System Hybrid System

    OM47614U_PRIUS_U.book Page 22 Monday, January 11, 2010 11:02 AM 1-1. Hybrid system Hybrid system Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the char- acteristics of your vehicle, and operate with care. The hybrid system combines a gasoline engine and an electric motor (traction motor) according to driving conditions, improving fuel efficiency and reducing exhaust emissions.
  • Page 22 OM47614U_PRIUS_U.book Page 23 Monday, January 11, 2010 11:02 AM 1-1. Hybrid system When stopped/during take-off The gasoline engine stops when the vehicle is stopped. During take-off, the electric motor (traction motor) drives the vehicle. At slow speeds or when traveling down a gentle slope, the engine is stopped and the motor is used.
  • Page 23 After the 12 volt battery has discharged or has been changed or removed The gasoline engine may not stop even if the vehicle is running on the hybrid battery (traction battery). If this continues for a few days, contact your Toyota dealer. PRIUS_U_(OM47614U)
  • Page 24 You may hear cooling fan sounds coming from the air intake vents behind the rear seat. Maintenance, repair, recycling, and disposal Contact your Toyota dealer regarding maintenance, repair, recycling and dis- posal. Do not dispose of the vehicle yourself. PRIUS_U_(OM47614U)
  • Page 25 OM47614U_PRIUS_U.book Page 26 Monday, January 11, 2010 11:02 AM 1-1. Hybrid system High voltage components Air conditioning compressor Hybrid battery (Traction bat- tery) High voltage cables (orange color) Service plug Power control unit Caution label Electric motor (Traction motor) Take care when handling the hybrid system, as it contains a high volt- age system (about 500V at maximum) as well as parts that become extremely hot when the hybrid system is operating.
  • Page 26 If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Toyota dealer. Energy monitor/consumption screen You can view the status of your hybrid system on the touch screen (→P.

  • Page 27: Energy Monitor

    OM47614U_PRIUS_U.book Page 28 Monday, January 11, 2010 11:02 AM 1-1. Hybrid system Energy monitor How to display on the touch screen: Press STEP Touch on the “Information” screen. STEP If the “Consumption” screen is displayed, touch How to display with steering switch: Press STEP If the “Consumption”...
  • Page 28 OM47614U_PRIUS_U.book Page 29 Monday, January 11, 2010 11:02 AM 1-1. Hybrid system Touch screen Type A Type B When the vehicle is charging the hybrid battery (traction bat- tery) When there is no energy flow Full Full Hybrid battery (trac- tion battery) status PRIUS_U_(OM47614U)
  • Page 29 OM47614U_PRIUS_U.book Page 30 Monday, January 11, 2010 11:02 AM 1-1. Hybrid system Consumption How to display on the touch screen: Press STEP Touch on the “Information” screen. STEP If the “Energy Monitor” screen is displayed, touch How to display with steering switch: Press STEP If the “Consumption”...
  • Page 30 If a warning light comes on or a warning message is displayed, or the 12 volt battery is disconnected The hybrid system may not start. In that case, try to start the system again. If the “READY” light does not come on, contact your Toyota dealer. PRIUS_U_(OM47614U)
  • Page 31 OM47614U_PRIUS_U.book Page 32 Monday, January 11, 2010 11:02 AM 1-1. Hybrid system CAUTION High voltage precautions The vehicle has high voltage DC and AC systems as well as a 12 volt sys- tem. DC and AC high voltage is very dangerous and can cause severe burns and electric shock that may result in death or serious injury.
  • Page 32 OM47614U_PRIUS_U.book Page 33 Monday, January 11, 2010 11:02 AM 1-1. Hybrid system CAUTION Road accident cautions Observe the following precautions to reduce the risk of injury. Pull your vehicle off the road, put the shift lever in “P”, apply the parking brake, turn the hybrid system off.

  • Page 33: 1-2. Key Information

    OM47614U_PRIUS_U.book Page 34 Monday, January 11, 2010 11:02 AM 1-2. Key information Keys The following keys are provided with the vehicle. Vehicles with smart key system Electronic keys • Operating the smart key system (→P. 36) • Operating the wireless remote control function (→P.
  • Page 34 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a mechanical key is lost, a new key can be made at your Toyota dealer using the key number plate. (→P. 447)

  • Page 35: Smart Key System

    OM47614U_PRIUS_U.book Page 36 Monday, January 11, 2010 11:02 AM 1-3. Opening, closing and locking the doors and back door ∗ Smart key system The following operations can be performed simply by carrying the electronic key, for example in your pocket. (The driver should always carry the electronic key.) Locks and unlocks the side doors (→P.
  • Page 36 OM47614U_PRIUS_U.book Page 37 Monday, January 11, 2010 11:02 AM 1-3. Opening, closing and locking the doors and back door Unlocking and locking the doors (front door handles only) Grip the handle to unlock the door. Make sure to touch the sensor on the back of the handle.
  • Page 37 OM47614U_PRIUS_U.book Page 38 Monday, January 11, 2010 11:02 AM 1-3. Opening, closing and locking the doors and back door Locking and unlocking the back door Press the lock button to lock the door. Press the open switch to unlock the door. The door cannot be unlocked for 3 seconds after the door is locked.

  • Page 38: Antenna Location

    OM47614U_PRIUS_U.book Page 39 Monday, January 11, 2010 11:02 AM 1-3. Opening, closing and locking the doors and back door Antenna location and effective range Antenna location Antennas outside cabin Antennas inside cabin Antenna outside back door PRIUS_U_(OM47614U)
  • Page 39 OM47614U_PRIUS_U.book Page 40 Monday, January 11, 2010 11:02 AM 1-3. Opening, closing and locking the doors and back door Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 3ft.
  • Page 40 OM47614U_PRIUS_U.book Page 41 Monday, January 11, 2010 11:02 AM 1-3. Opening, closing and locking the doors and back door To disable smart key system If you do not intend to drive your vehicle for a long time, push the can- cel switch to deactivate the smart key system.
  • Page 41 OM47614U_PRIUS_U.book Page 42 Monday, January 11, 2010 11:02 AM 1-3. Opening, closing and locking the doors and back door Operation signals A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) Conditions affecting operation The smart key system uses weak radio waves.
  • Page 42 OM47614U_PRIUS_U.book Page 43 Monday, January 11, 2010 11:02 AM 1-3. Opening, closing and locking the doors and back door Switching the door unlock function It is possible to set which doors the entry function unlocks. STEP Turn the “POWER” switch OFF. STEP When the indicator on the key surface is turned off, push and hold for approximately 5 seconds while pushing the...
  • Page 43 OM47614U_PRIUS_U.book Page 44 Monday, January 11, 2010 11:02 AM 1-3. Opening, closing and locking the doors and back door Battery-saving function In the following circumstances, the entry function is disabled in order to pre- vent the vehicle and electronic key batteries from discharging. When the entry function has not been used for 2 weeks or more When the electronic key has been left within approximately 3 ft.
  • Page 44 OM47614U_PRIUS_U.book Page 45 Monday, January 11, 2010 11:02 AM 1-3. Opening, closing and locking the doors and back door Note for the smart key system Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases. •...
  • Page 45 OM47614U_PRIUS_U.book Page 46 Monday, January 11, 2010 11:02 AM 1-3. Opening, closing and locking the doors and back door Alarms and warning indicators A combination of exterior and interior alarms are used to prevent theft of the vehicle and unforeseeable accidents resulting from erroneous operation. Take appropriate measures according to which warning light comes on.
  • Page 46 Starting the hybrid system: →P. 134 When the electronic key battery is fully depleted →P. 392 Customization that can be configured at Toyota dealer Settings (e.g. smart key system) can be changed. (Customizable features →P. 486) Certification for the smart key system For vehicles sold in the U.S.A.
  • Page 47 (→P. 39) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves.

  • Page 48: Wireless Remote Control

    OM47614U_PRIUS_U.book Page 49 Monday, January 11, 2010 11:02 AM 1-3. Opening, closing and locking the doors and back door Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle and the back door from outside the vehicle. Locks all doors Unlocks all doors Pressing the button unlocks...
  • Page 49 If the wireless remote control does not function or if it only operates very close to the vehicle, the battery may be low. (→P. 392) Customization that can be configured at Toyota dealer Settings (e.g. 2-step unlocking function) can be changed.

  • Page 50: Side Doors

    OM47614U_PRIUS_U.book Page 51 Monday, January 11, 2010 11:02 AM 1-3. Opening, closing and locking the doors and back door Side doors The vehicle can be locked and unlocked using the entry function, wireless remote control or door lock switch. Smart key system →P.
  • Page 51 OM47614U_PRIUS_U.book Page 52 Monday, January 11, 2010 11:02 AM 1-3. Opening, closing and locking the doors and back door Locking the front doors from the outside without a key Move the inside lock button to the lock position. STEP Close the door. STEP Vehicles with smart key system The door cannot be locked if the “POWER”...
  • Page 52 Using the mechanical key The doors can also be locked and unlocked with the mechanical key. (→P. 448) Customization that can be configured at Toyota dealer Settings (e.g. unlocking function using a key) can be changed. (Customizable features →P. 486)

  • Page 53: Back Door

    OM47614U_PRIUS_U.book Page 54 Monday, January 11, 2010 11:02 AM 1-3. Opening, closing and locking the doors and back door Back door The back door can be opened using the back door opener. Back door opener Press the open switch to unlock the door.
  • Page 54 OM47614U_PRIUS_U.book Page 55 Monday, January 11, 2010 11:02 AM 1-3. Opening, closing and locking the doors and back door Luggage compartment light ITY13P015 When closing the back door Lower the back door using the back door handle, and make sure to push the back door down from the outside to close it.
  • Page 55 OM47614U_PRIUS_U.book Page 56 Monday, January 11, 2010 11:02 AM 1-3. Opening, closing and locking the doors and back door CAUTION Caution while driving Keep the back door closed. This not only keeps personal belongings from being thrown out, but also pre- vents exhaust gases from entering the vehicle.

  • Page 56: Adjustable Components

    OM47614U_PRIUS_U.book Page 57 Monday, January 11, 2010 11:02 AM 1-4. Adjustable components (seats, mirrors, steering wheel) Front seats Seat position adjustment lever Seatback angle adjustment lever Flattening seatbacks Move the seat forward and STEP remove the head restraint. After returning seat to its original position, be certain to replace the head restraint.
  • Page 57 OM47614U_PRIUS_U.book Page 58 Monday, January 11, 2010 11:02 AM 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION Reclining adjustment Do not recline the seat more than necessary when the vehicle is in motion, to reduce the risk of sliding under the lap belt. If the seat is too reclined, during an accident the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoulder belt, increasing the risk of death or serious injury.

  • Page 58: Rear Seats

    OM47614U_PRIUS_U.book Page 59 Monday, January 11, 2010 11:02 AM 1-4. Adjustable components (seats, mirrors, steering wheel) Rear seats Seatback angle adjustment button Press the button down until the lock is completely released. Folding down rear seatbacks Before folding down rear seatbacks Stow the rear center seat belt buckle.
  • Page 59 OM47614U_PRIUS_U.book Page 60 Monday, January 11, 2010 11:02 AM 1-4. Adjustable components (seats, mirrors, steering wheel) Folding down rear seatbacks Remove the seat belt from the STEP guide. In case you do not remove the seat belt from the guide, the seat belt might be locked when you fold down the rear seatbacks.
  • Page 60 OM47614U_PRIUS_U.book Page 61 Monday, January 11, 2010 11:02 AM 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION Seat adjustment Do not recline the seat more than necessary when the vehicle is in motion to reduce the risk of sliding under the lap belt. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdo- men or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of an accident.

  • Page 61: Head Restraints

    OM47614U_PRIUS_U.book Page 62 Monday, January 11, 2010 11:02 AM 1-4. Adjustable components (seats, mirrors, steering wheel) Head restraints Vertical adjustment Vertical adjustment Down Lock release Push and hold the lock release button button when lowering the head restraint. Removing the head restraints Grip head restraint and remove while holding the lock release button.
  • Page 62 OM47614U_PRIUS_U.book Page 63 Monday, January 11, 2010 11:02 AM 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. Use the head restraints designed for each respective seat. Adjust the head restraints to the correct position at all times.

  • Page 63: Seat Belts

    OM47614U_PRIUS_U.book Page 64 Monday, January 11, 2010 11:02 AM 1-4. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. Correct use of the seat belts l Extend the shoulder belt so that it comes fully over the shoulder, does...
  • Page 64 OM47614U_PRIUS_U.book Page 65 Monday, January 11, 2010 11:02 AM 1-4. Adjustable components (seats, mirrors, steering wheel) Adjusting the height of the belt (front seats) Down Move the height adjuster up and down as needed until you hear a click. Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt...
  • Page 65 OM47614U_PRIUS_U.book Page 66 Monday, January 11, 2010 11:02 AM 1-4. Adjustable components (seats, mirrors, steering wheel) Emergency locking retractor (ELR) The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend, and you can move around fully.
  • Page 66 Seat belt extender If your seat belts cannot be fastened securely because they are not long enough, personalized seat belt extender is available from your Toyota dealer free of charge. PRIUS_U_(OM47614U)
  • Page 67 Ensure that the belt and tab are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
  • Page 68 Seat belt damage and wear Do not attempt to install, remove, modify, disassemble or dispose of a seat belt. Have any necessary repairs carried out by your Toyota dealer. Inap- propriate handling of the pretensioner may cause it to activate or operate improperly and may cause death or serious injury.
  • Page 69 OM47614U_PRIUS_U.book Page 70 Monday, January 11, 2010 11:02 AM 1-4. Adjustable components (seats, mirrors, steering wheel) NOTICE When using a seat belt extender When releasing the seat belt, press on the buckle release button on the extender, not on the seat belt. This helps prevent damage to the vehicle interior and the extender itself.

  • Page 70: Steering Wheel

    OM47614U_PRIUS_U.book Page 71 Monday, January 11, 2010 11:02 AM 1-4. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Hold steering STEP wheel and press the lever down. Adjust to the ideal STEP position by moving the steering wheel verti-...

  • Page 71: Anti-Glare Inside Rear View Mirror

    OM47614U_PRIUS_U.book Page 72 Monday, January 11, 2010 11:02 AM 1-4. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror Manual anti-glare inside rear view mirror Normal position Anti-glare position Auto anti-glare inside rear view mirror In the “AUTO” mode, sensors are used to detect the headlights of vehicles behind and automatically reduces the reflected light.
  • Page 72 OM47614U_PRIUS_U.book Page 73 Monday, January 11, 2010 11:02 AM 1-4. Adjustable components (seats, mirrors, steering wheel) To prevent sensor error (vehicles with auto anti-glare inside rear view mirror) To ensure correct functioning of the sen- sors, do not touch or cover the sensors. CAUTION While driving Do not adjust the position of the mirror while driving.

  • Page 73: Outside Rear View Mirrors

    OM47614U_PRIUS_U.book Page 74 Monday, January 11, 2010 11:02 AM 1-4. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch when the “POWER” switch is in ACCESSORY or ON mode. Select a mirror to adjust Left Right Adjust the mirror...
  • Page 74 OM47614U_PRIUS_U.book Page 75 Monday, January 11, 2010 11:02 AM 1-4. Adjustable components (seats, mirrors, steering wheel) When the mirrors are fogged up (vehicle with mirror defoggers) Turn on the mirror heaters to defog the mirrors. (→P. 213) CAUTION While driving Observe the following precautions.

  • Page 75: Opening And Closing The Windows And Moon Roof Power Windows

    OM47614U_PRIUS_U.book Page 76 Monday, January 11, 2010 11:02 AM 1-5. Opening and closing the windows and moon roof Power windows The power windows can be opened and closed using the following switches. Closing One-touch closing (driver’s window only) Opening One-touch opening (driver’s window only) :Pushing the switch in the opposite direction will stop...
  • Page 76 1 second. The indicator on the switch changes from a flashing pattern to being on when initial settings are complete. Customization that can be configured at Toyota dealer Settings (e.g. linked door lock operation) can be changed. (Customizable features →P. 486)
  • Page 77 OM47614U_PRIUS_U.book Page 78 Monday, January 11, 2010 11:02 AM 1-5. Opening and closing the windows and moon roof CAUTION When closing the windows Observe the following precautions. Failing to do so may result in death or serious injury. Check to make sure that all passengers do not have any part of their body in a position where it could be caught when a window is being operated.

  • Page 78: 1-6. Refueling

    OM47614U_PRIUS_U.book Page 79 Monday, January 11, 2010 11:02 AM 1-6. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. Before refueling the vehicle Turn the “POWER” switch OFF and ensure that all the doors and windows are closed.
  • Page 79 OM47614U_PRIUS_U.book Page 80 Monday, January 11, 2010 11:02 AM 1-6. Refueling Closing the fuel tank cap After refueling, turn the fuel tank cap clockwise until you hear a click. The cap will revolve slightly in the opposite direction once released. Fuel types Use unleaded gasoline.
  • Page 80 When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Failure to do so may cause a fire or other incident which may result in death or serious injury.

  • Page 81: Theft Deterrent System Immobilizer System

    OM47614U_PRIUS_U.book Page 82 Monday, January 11, 2010 11:02 AM 1-7. Theft deterrent system Immobilizer system The vehicle’s keys have built-in transponder chips that prevent the hybrid system from starting if the key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle.
  • Page 82 OM47614U_PRIUS_U.book Page 83 Monday, January 11, 2010 11:02 AM 1-7. Theft deterrent system System maintenance The vehicle has a maintenance-free type of immobilizer system. Conditions that may cause the system to malfunction If the grip portion of the key is in contact with a metallic object. If the key is in close proximity to or touching a key to the security system (key with a built-in transponder chip) of another vehicle.

  • Page 83: Alarm

    OM47614U_PRIUS_U.book Page 84 Monday, January 11, 2010 11:02 AM 1-7. Theft deterrent system ∗ Alarm The system sounds the alarm and flashes the vehicle lights when an attempt to steal the vehicle is detected. Triggering the alarm The alarm is triggered in the following situations. l A locked door or back door is unlocked or opened in any way other than using the entry function, wireless remote door lock function or using the mechanical key.
  • Page 84 OM47614U_PRIUS_U.book Page 85 Monday, January 11, 2010 11:02 AM 1-7. Theft deterrent system Items to check before locking the vehicle To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following Nobody is in the vehicle. The windows are closed before the alarm is set.

  • Page 85: Theft Prevention Labels (U.s.a.)

    OM47614U_PRIUS_U.book Page 86 Monday, January 11, 2010 11:02 AM 1-7. Theft deterrent system Theft prevention labels (U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from sto- len vehicles. Do not remove under penalty of law.

  • Page 86: Safety Information Correct Driving Posture

    OM47614U_PRIUS_U.book Page 87 Monday, January 11, 2010 11:02 AM 1-8. Safety information Correct driving posture Drive with a good posture as follows: Sit upright and well back in the seat. Adjust the position of the seat forward or backward to ensure the pedals can be reached easily...
  • Page 87 OM47614U_PRIUS_U.book Page 88 Monday, January 11, 2010 11:02 AM 1-8. Safety information CAUTION While driving Do not adjust the position of the driver’s seat. Doing so could cause the driver to lose control of the vehicle. Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.

  • Page 88: Srs Airbags

    OM47614U_PRIUS_U.book Page 89 Monday, January 11, 2010 11:02 AM 1-8. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury.
  • Page 89 OM47614U_PRIUS_U.book Page 90 Monday, January 11, 2010 11:02 AM 1-8. Safety information Airbag system components Front passenger airbag Side and curtain shield airbag sensor (if equipped) Side airbag (if equipped) Front airbag sensor Curtain shield airbag (if equipped) Airbag sensor assembly SRS warning light “AIR BAG ON”...
  • Page 90 OM47614U_PRIUS_U.book Page 91 Monday, January 11, 2010 11:02 AM 1-8. Safety information Your vehicle is equipped with “ADVANCED AIRBAGS” designed based on US motor vehicle safety standards (FMVSS208). The air- bag system controls airbag deployment power for the driver and front passenger.
  • Page 91 OM47614U_PRIUS_U.book Page 92 Monday, January 11, 2010 11:02 AM 1-8. Safety information Operating conditions (front airbags) The SRS front airbags will deploy if the severity of the frontal impact is above the designed threshold level, comparable to an approximate 15 mph (25 km/h) collision, when the vehicle impacts straight into a fixed barrier that does not move or deform.
  • Page 92 OM47614U_PRIUS_U.book Page 93 Monday, January 11, 2010 11:02 AM 1-8. Safety information Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. Hitting a curb, edge of pavement or hard surface Falling into or jumping over a deep hole...
  • Page 93 OM47614U_PRIUS_U.book Page 94 Monday, January 11, 2010 11:02 AM 1-8. Safety information Types of collisions that may not deploy the SRS airbag (side and curtain shield airbags [if equipped]) The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli- sion to the side of the vehicle body other than the passenger compartment.
  • Page 94 OM47614U_PRIUS_U.book Page 95 Monday, January 11, 2010 11:02 AM 1-8. Safety information When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. Do not disconnect the 12 volt battery cables before contacting your Toyota dealer.
  • Page 95 OM47614U_PRIUS_U.book Page 96 Monday, January 11, 2010 11:02 AM 1-8. Safety information CAUTION SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. The driver and all passengers in the vehicle must wear their seat belts properly.
  • Page 96 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are the safest for infants and children.
  • Page 97 OM47614U_PRIUS_U.book Page 98 Monday, January 11, 2010 11:02 AM 1-8. Safety information CAUTION SRS airbag precautions Do not sit on the edge of the seat or lean against the dashboard. Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
  • Page 98 If the areas where the SRS airbags are stored, such as the steering wheel pad and front pillar garnish, are damaged or cracked, have them replaced by your Toyota dealer. Do not place anything, such as a cushion, on the front passenger’s seat.
  • Page 99 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbag may malfunction or deploy (inflate) accidentally, causing death or serious injury.

  • Page 100: Front Passenger Occupant Classification System

    OM47614U_PRIUS_U.book Page 101 Monday, January 11, 2010 11:02 AM 1-8. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for front passenger. SRS warning light “AIR BAG OFF”...
  • Page 101 OM47614U_PRIUS_U.book Page 102 Monday, January 11, 2010 11:02 AM 1-8. Safety information Condition and operation in the front passenger occupant classi- fication system Adult “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights ON” Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Flashing Front passenger airbag...
  • Page 102 OM47614U_PRIUS_U.book Page 103 Monday, January 11, 2010 11:02 AM 1-8. Safety information Unoccupied “AIR BAG ON” and “AIR BAG OFF” Not illumi- indicator lights nated Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Side airbag on the right side passenger seats...
  • Page 103 OM47614U_PRIUS_U.book Page 104 Monday, January 11, 2010 11:02 AM 1-8. Safety information There is a malfunction in the system “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights OFF” Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Side airbag on the right side...
  • Page 104 OM47614U_PRIUS_U.book Page 105 Monday, January 11, 2010 11:02 AM 1-8. Safety information CAUTION Front passenger occupant classification system precautions Observe the following precautions regarding front passenger occupant clas- sification system. Failure to do so may cause death or serious injury. Wear the seat belt properly.
  • Page 105 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction on the detection system. In this case, contact your Toyota dealer immediately. Child restraint systems installed on the rear seat should not contact the front seatbacks.

  • Page 106: Child Restraint Systems

    OM47614U_PRIUS_U.book Page 107 Monday, January 11, 2010 11:02 AM 1-8. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt.
  • Page 107 OM47614U_PRIUS_U.book Page 108 Monday, January 11, 2010 11:02 AM 1-8. Safety information Forward facing ⎯ Convertible seat Booster seat Selecting an appropriate child restraint system Use a child restraint system appropriate for the child until the child becomes large enough to properly wear the vehicle’s seat belt. If a child is too large for a child restraint system, sit the child on a rear seat and use the vehicle’s seat belt.
  • Page 108 In an accident, the child can be crushed against the windshield, or between you and the vehicle’s interior. Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
  • Page 109 OM47614U_PRIUS_U.book Page 110 Monday, January 11, 2010 11:02 AM 1-8. Safety information CAUTION Child restraint precautions Do not allow the child to lean his/her head or any part of his/her body against the door or the area of the seat, front and rear pillars or roof side rail from which the side airbags or curtain shield airbags deploy even if the child is seated in the child restraint system.

  • Page 110: Installing Child Restraints

    OM47614U_PRIUS_U.book Page 111 Monday, January 11, 2010 11:02 AM 1-8. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the outboard rear seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint.
  • Page 111 OM47614U_PRIUS_U.book Page 112 Monday, January 11, 2010 11:02 AM 1-8. Safety information Installation with LATCH system Type A Widen the gap between STEP the seat cushion and seatback slightly. Latch the hooks of the STEP lower straps onto the LATCH anchors. If the child restraint has a STEP top tether strap, the top...
  • Page 112 OM47614U_PRIUS_U.book Page 113 Monday, January 11, 2010 11:02 AM 1-8. Safety information Type B Widen the gap between STEP the seat cushion and seatback slightly. Latch the buckles onto STEP the LATCH anchors. If the child restraint has a STEP top tether strap, the top tether strap should be latched...
  • Page 113 OM47614U_PRIUS_U.book Page 114 Monday, January 11, 2010 11:02 AM 1-8. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear facing ⎯ Infant seat/convertible seat Place the child seat on the rear STEP seat facing the rear of the vehi- cle.
  • Page 114 OM47614U_PRIUS_U.book Page 115 Monday, January 11, 2010 11:02 AM 1-8. Safety information While pushing the child seat STEP down into the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
  • Page 115 OM47614U_PRIUS_U.book Page 116 Monday, January 11, 2010 11:02 AM 1-8. Safety information While pushing the child seat into STEP the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
  • Page 116 OM47614U_PRIUS_U.book Page 117 Monday, January 11, 2010 11:02 AM 1-8. Safety information Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap Secure the child restraint using a STEP seat belt or lower anchors, and...
  • Page 117 OM47614U_PRIUS_U.book Page 118 Monday, January 11, 2010 11:02 AM 1-8. Safety information Reinstall the head restraint. STEP ITY18P041 Laws and regulations pertaining to anchorages The LATCH system conform to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifica- tions can be used.
  • Page 118 OM47614U_PRIUS_U.book Page 119 Monday, January 11, 2010 11:02 AM 1-8. Safety information CAUTION When installing a child restraint system Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place. If the child restraint system is not correctly fixed in place, the child or other passengers may be injured or even killed in the event of sudden braking or an accident.
  • Page 119 OM47614U_PRIUS_U.book Page 120 Monday, January 11, 2010 11:02 AM 1-8. Safety information CAUTION When installing a child restraint system After securing a child restraint system, never adjust the seat. Follow all installation instructions provided by the child restraint system manufacturer. Do not use a seat belt extender If a seat belt extender is used when installing a child restraint system, the seat belt will not securely hold the child restraint system, which could cause...

  • Page 120: 2-1. Driving Procedures

    OM47614U_PRIUS_U.book Page 122 Monday, January 11, 2010 11:02 AM 2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. Starting the hybrid system (→P. 133) Driving With the brake pedal depressed, shift the shift lever to “D”. STEP (→P.
  • Page 121 Breaking in your new Toyota To extend the life of the vehicle, the following precautions are recommended...
  • Page 122 OM47614U_PRIUS_U.book Page 124 Monday, January 11, 2010 11:02 AM 2-1. Driving procedures Avoid repeated acceleration Repeated acceleration consumes hybrid battery (traction battery) power, resulting in poor acceleration. Battery power can be restored by driving with the accelerator pedal slightly released. Push the “P”...
  • Page 123 Large amounts of exhaust in the vehi- cle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immediately. PRIUS_U_(OM47614U)
  • Page 124 OM47614U_PRIUS_U.book Page 126 Monday, January 11, 2010 11:02 AM 2-1. Driving procedures CAUTION When driving the vehicle Do not under any circumstances shift the shift lever to “R”, “N” or push the “P” position switch while the vehicle is moving. Doing so can cause significant damage to the transmission and may result in a loss of vehicle control.
  • Page 125 OM47614U_PRIUS_U.book Page 127 Monday, January 11, 2010 11:02 AM 2-1. Driving procedures CAUTION When driving on slippery road surfaces Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle, resulting in an accident. Sudden changes in engine speed, such as engine braking caused by up- shifting or down-shifting, may cause the vehicle to skid, resulting in an accident.
  • Page 126 Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
  • Page 127 OM47614U_PRIUS_U.book Page 129 Monday, January 11, 2010 11:02 AM 2-1. Driving procedures CAUTION When taking a nap in the vehicle Always turn the hybrid system off. Otherwise, you may accidentally move the shift lever or depress the accelerator pedal, which could cause an accident or fire due to hybrid system overheating.
  • Page 128 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have your Toyota dealer check and replace the brake pads as soon as pos- sible. The rotor damage can result if the pads are not replaced when needed.
  • Page 129 Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following. Brake function Changes in quantity and quality of engine oil, transmission fluid for the hybrid system, etc.

  • Page 130: Power (Ignition) Switch

    OM47614U_PRIUS_U.book Page 132 Monday, January 11, 2010 11:02 AM 2-1. Driving procedures Power (ignition) switch Performing the following operations when carrying the electronic key on your person starts the hybrid system or changes “POWER” switch modes. Changing “POWER” switch mode Modes can be changed by pressing the “POWER”...
  • Page 131 OM47614U_PRIUS_U.book Page 133 Monday, January 11, 2010 11:02 AM 2-1. Driving procedures Starting the hybrid system (vehicle with smart key system) Check that the parking brake is set. STEP Turn off unnecessary lights and accessories. STEP Check that the shift position is set in “P”. STEP Sit in the driver’s seat and firmly depress the brake pedal.
  • Page 132 OM47614U_PRIUS_U.book Page 134 Monday, January 11, 2010 11:02 AM 2-1. Driving procedures Starting the hybrid system (vehicle without smart key sys- tem) Check that the parking brake is set. STEP Turn off unnecessary lights and accessories. STEP Check that the shift position is set in “P”. STEP Insert the key into the key slot STEP...
  • Page 133 OM47614U_PRIUS_U.book Page 135 Monday, January 11, 2010 11:02 AM 2-1. Driving procedures Press the “POWER” switch. STEP After a few seconds, the “READY” light will flash and come on with a beep sound. The vehicle can move when the “READY” light is on, even if the hybrid system is stopped.
  • Page 134 If the “READY” light does not come on If the “READY” light does not come on when you press the power switch with the shift lever in “P” and the brake pedal pressed, contact your Toyota dealer immediately. When the “POWER” switch indicator flashes in amber The system may be malfunctioning.
  • Page 135 OM47614U_PRIUS_U.book Page 137 Monday, January 11, 2010 11:02 AM 2-1. Driving procedures CAUTION When starting the hybrid system Always start the hybrid system while sitting in the driver’s seat. Do not press the accelerator pedal while starting the hybrid system under any circum- stances.

  • Page 136: Transmission

    OM47614U_PRIUS_U.book Page 138 Monday, January 11, 2010 11:02 AM 2-1. Driving procedures Transmission Select a shift position appropriate for the driving conditions. Shifting the shift lever You can operate the shift lever only in “D”. Keep the shift lever in “N”...
  • Page 137 OM47614U_PRIUS_U.book Page 139 Monday, January 11, 2010 11:02 AM 2-1. Driving procedures Shift position uses Shift position Function Parking the vehicle or starting the hybrid system Reversing Neutral Normal driving Engine braking position : Shown only while in “D” position. Changing shift ranges in “P”...
  • Page 138 If the system malfunctions The following conditions, there is some problem in the system. Immediately stop the vehicle in a safe place and contact your Toyota dealer. The indicator on the “P” position switch flashes. However, this does not indicate a malfunction unless a warning message appears in the touch screen.
  • Page 139 OM47614U_PRIUS_U.book Page 141 Monday, January 11, 2010 11:02 AM 2-1. Driving procedures Alarms The following table describes circumstances and correction procedures when only alarms are sound. Alarm Situation Correction procedure The transmission will The driver attempts to shift not move out of the “P” out of the “P”...

  • Page 140: Turn Signal Lever

    OM47614U_PRIUS_U.book Page 142 Monday, January 11, 2010 11:02 AM 2-1. Driving procedures Turn signal lever Left turn Right turn Move and hold the lever partway to signal a lane change The left hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change...

  • Page 141: Parking Brake

    OM47614U_PRIUS_U.book Page 143 Monday, January 11, 2010 11:02 AM 2-1. Driving procedures Parking brake Sets the parking brake (Depressing the pedal again releases the parking brake.) U.S.A. Canada :Fully depress the parking brake pedal with your left foot while depressing the brake pedal with your right foot.

  • Page 142: Horn

    OM47614U_PRIUS_U.book Page 144 Monday, January 11, 2010 11:02 AM 2-1. Driving procedures Horn To sound the horn Press on or close to the mark. After adjusting the steering wheel Mark sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (→P.

  • Page 143: 2-2. Instrument Cluster

    OM47614U_PRIUS_U.book Page 145 Monday, January 11, 2010 11:02 AM 2-2. Instrument cluster Gauges and meters The following gauges and meters illuminate when the “POWER” switch is in ON mode. Shift position indicator Displays the shift position Speedometer Displays the vehicle speed. Fuel gauge Displays the quantity of fuel remaining in the tank.
  • Page 144 OM47614U_PRIUS_U.book Page 146 Monday, January 11, 2010 11:02 AM 2-2. Instrument cluster Odometer/trip meter and trip meter reset button Odometer Trip meter A Trip meter B : Pushing and holding the but- ton will reset the trip meter. MPH or km/h button The speed units can be selected MPH or km/h.
  • Page 145 OM47614U_PRIUS_U.book Page 147 Monday, January 11, 2010 11:02 AM 2-2. Instrument cluster NOTICE To prevent damage to the hybrid system and its components The hybrid system may be overheating if the high coolant temperature warn- ing light is displayed on the touch screen. In this case, immediately stop the vehicle in a safe place.

  • Page 146: Indicators And Warning Lights

    OM47614U_PRIUS_U.book Page 148 Monday, January 11, 2010 11:02 AM 2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems.
  • Page 147 OM47614U_PRIUS_U.book Page 149 Monday, January 11, 2010 11:02 AM 2-2. Instrument cluster Touch screen (Type B) ITY22P007 PRIUS_U_(OM47614U)
  • Page 148 OM47614U_PRIUS_U.book Page 150 Monday, January 11, 2010 11:02 AM 2-2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator SRS airbag on-off indi- (→P. 142) cator (→P. 101) Headlight high beam Recirculate mode indi- indicator (→P.

  • Page 149: Warning Lights

    Have the vehicle inspected by your Toyota dealer immediately if this occurs.

  • Page 150: Headlight Switch

    OM47614U_PRIUS_U.book Page 152 Monday, January 11, 2010 11:02 AM 2-3. Operating the lights and windshield wipers Headlight switch The headlights can be operated manually or automatically. The side marker, park- ing, tail, license plate and instrument panel U.S.A. Canada lights turn on. The headlights and all lights listed above turn The headlights and all...
  • Page 151 If the indicator flashes... It may indicate a malfunction in the system. Contact your Toyota dealer. Customization that can be configured at Toyota dealer Settings (e.g. light sensor sensitivity) can be changed.
  • Page 152 OM47614U_PRIUS_U.book Page 154 Monday, January 11, 2010 11:02 AM 2-3. Operating the lights and windshield wipers NOTICE To prevent 12 volt battery discharge Do not leave the lights on longer than necessary if the hybrid system is not operating. PRIUS_U_(OM47614U)

  • Page 153: Fog Light Switch

    OM47614U_PRIUS_U.book Page 155 Monday, January 11, 2010 11:02 AM 2-3. Operating the lights and windshield wipers ∗ Fog light switch The fog lights improve visibility in difficult driving conditions, such as in rain or fog. They can be turned on only when the headlights are on low beam.

  • Page 154: Windshield Wipers And Washer

    OM47614U_PRIUS_U.book Page 156 Monday, January 11, 2010 11:02 AM 2-3. Operating the lights and windshield wipers Windshield wipers and washer Wiper intervals can be adjusted for intermittent operation (when is selected). Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield...
  • Page 155 OM47614U_PRIUS_U.book Page 157 Monday, January 11, 2010 11:02 AM 2-3. Operating the lights and windshield wipers Wash/wipe operation Wipers operate automatically. The windshield wiper and washer can be operated when The “POWER” switch is in ON mode. If no windshield washer fluid sprays Check that the washer nozzles are not blocked and if there is washer fluid in the windshield washer fluid reservoir.

  • Page 156: Rear Window Wiper And Washer

    OM47614U_PRIUS_U.book Page 158 Monday, January 11, 2010 11:02 AM 2-3. Operating the lights and windshield wipers Rear window wiper and washer Intermittent window wiper operation Normal window wiper oper- ation Washer/wiper dual opera- tion Washer/wiper dual opera- tion The rear window wiper and washer can be operated when The “POWER”...

  • Page 157: Using Other Driving Systems Cruise Control

    OM47614U_PRIUS_U.book Page 159 Monday, January 11, 2010 11:02 AM 2-4. Using other driving systems ∗ Cruise control Use the cruise control to maintain a set speed without using the accelerator. Indicator Cruise control switch Set the vehicle speed STEP Turn the “ON-OFF” button ON. Push the button once more to deactivate the cruise control.
  • Page 158 OM47614U_PRIUS_U.book Page 160 Monday, January 11, 2010 11:02 AM 2-4. Using other driving systems Adjusting the speed setting Increase speed Decrease speed Hold the lever until the desired speed setting is obtained. Fine adjustment of the set speed (approximately 1.0 mph [1.6 km/h]) can be made by lightly pressing the lever up or down and releasing it.
  • Page 159 Turn the “ON-OFF” button off once, and then reactivate the system. If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. PRIUS_U_(OM47614U)
  • Page 160 OM47614U_PRIUS_U.book Page 162 Monday, January 11, 2010 11:02 AM 2-4. Using other driving systems CAUTION To avoid operating the cruise control by mistake Keep the “ON-OFF” button off when not in use. Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in control of the vehicle being lost and could cause seri- ous or fatal accident.

  • Page 161: Rear View Monitor System

    OM47614U_PRIUS_U.book Page 163 Monday, January 11, 2010 11:02 AM 2-4. Using other driving systems ∗ Rear view monitor system The rear view monitor system assists the driver by displaying an image of the view behind the vehicle while reversing. The image is displayed in reverse on the screen.
  • Page 162 OM47614U_PRIUS_U.book Page 164 Monday, January 11, 2010 11:02 AM 2-4. Using other driving systems Rear view monitor system camera In the following cases, it may be difficult to see the images on the screen, even when the system is functioning correctly. •...
  • Page 163 Conditions which may affect the rear view monitor system If the back of the vehicle is hit, the camera’s position and mounting angle may change. Contact your Toyota dealer. Rapid temperature changes, such as when hot water is poured on the vehicle in cold weather, may cause the system to function abnormally.

  • Page 164: Driving Assist Systems

    OM47614U_PRIUS_U.book Page 166 Monday, January 11, 2010 11:02 AM 2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle.
  • Page 165 OM47614U_PRIUS_U.book Page 167 Monday, January 11, 2010 11:02 AM 2-4. Using other driving systems Sounds and vibrations caused by the ABS, brake assist and Enhanced A sound may be heard from the hybrid system compartment when the hybrid system is started or just after the vehicle begins to move. This sound does not indicate that a malfunction has occurred in any of these systems.
  • Page 166 In addition, make sure that the tires are inflated to the speci- fied tire pressure level. The ABS and Enhanced VSC will not function correctly if different tires are fitted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. PRIUS_U_(OM47614U)

  • Page 167: 2-5. Driving Information

    OM47614U_PRIUS_U.book Page 169 Monday, January 11, 2010 11:02 AM 2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. l Stow cargo and luggage in the luggage compartment when- ever possible. Be sure all items are secured in place. l Be careful to keep the vehicle level.
  • Page 168 Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. (→P. 172) Toyota does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing. Example on your vehicle...
  • Page 169 OM47614U_PRIUS_U.book Page 171 Monday, January 11, 2010 11:02 AM 2-5. Driving information CAUTION Storage precautions Do not stack anything in the luggage compartment higher than the seatbacks. Such items may be thrown about and possibly injure people in the vehicle during sudden braking or in an accident. Do not place anything on the luggage cover.

  • Page 170: Vehicle Load Limits

    Even if the number of occupants are within the seating capacity, do not exceed the total load capacity. Towing capacity Toyota does not recommend towing a trailer with your vehicle. Cargo capacity Cargo capacity may increase or decrease depending on the weight and the number of occupants.

  • Page 171: Winter Driving Tips

    OM47614U_PRIUS_U.book Page 173 Monday, January 11, 2010 11:02 AM 2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. Pre-winter preparations l Use fluids that are appropriate to the prevailing outside tem- peratures.
  • Page 172 OM47614U_PRIUS_U.book Page 174 Monday, January 11, 2010 11:02 AM 2-5. Driving information Before driving the vehicle Perform the following according to the driving conditions. l Do not try to forcibly open a window or move a wiper that is frozen. Pour warm water over the frozen area to melt the ice. Wipe away the water immediately to prevent it from freezing.
  • Page 173 OM47614U_PRIUS_U.book Page 175 Monday, January 11, 2010 11:02 AM 2-5. Driving information Regulations on the use of snow chains l Regulations regarding the use of tire chains vary according to loca- tion and type of road. Always check local regulations before install- ing chains.
  • Page 174 NOTICE Repairing or replacing snow tires Request repairs of and obtain replacement snow tires from Toyota dealers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.

  • Page 175: Trailer Towing

    Your Toyota is not designed for trailer towing or for the use of tow hitch mounted carriers.

  • Page 176: Dinghy Towing

    OM47614U_PRIUS_U.book Page 178 Monday, January 11, 2010 11:02 AM 2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. ITY25P002 NOTICE To avoid serious damage to your vehicle Do not tow your vehicle with four wheels on the ground.
  • Page 177 OM47614U_PRIUS_U.book Page 179 Monday, January 11, 2010 11:02 AM 2-5. Driving information PRIUS_U_(OM47614U)

  • Page 178: 3-1. Using The Touch Screen

    OM47614U_PRIUS_U.book Page 182 Monday, January 11, 2010 11:02 AM 3-1. Using the touch screen Touch screen By touching the screen with your finger, you can control the audio system and air-conditioning, adjust the screen display etc. Vehicles with navigation system Vehicles without navigation system (Type A) PRIUS_U_(OM47614U)
  • Page 179 OM47614U_PRIUS_U.book Page 183 Monday, January 11, 2010 11:02 AM 3-1. Using the touch screen Vehicles without navigation system (Type B) The “Information” screen shown in the above illustration is displayed when is pressed. Switches Page “CLIMATE” P. 197, 204 “AUDIO” P.
  • Page 180 OM47614U_PRIUS_U.book Page 184 Monday, January 11, 2010 11:02 AM 3-1. Using the touch screen The initial screen Vehicles with navigation system and vehicles without navigation system (Type A) If the “POWER” switch is set to ACCESSORY or ON mode, the initializing screen will be dis- played for a few seconds as the system starts up.
  • Page 181 OM47614U_PRIUS_U.book Page 185 Monday, January 11, 2010 11:02 AM 3-1. Using the touch screen Outside temperature display The outside temperature is shown ranging from -22 °F (-30 °C) up to 122 °F (50 °C) at the upper right of the energy consumption or energy monitor screen or the upper left/right of the air conditioner screen.
  • Page 182 OM47614U_PRIUS_U.book Page 186 Monday, January 11, 2010 11:02 AM 3-1. Using the touch screen To avoid damaging the touch screen Touch the screen lightly with your finger. If there is no response, remove your finger from the screen and try again. Remove any dirt on the screen by wiping with a soft cloth.

  • Page 183: Setting The Touch Screen (Vehicles With Aux Adapter)

    OM47614U_PRIUS_U.book Page 187 Monday, January 11, 2010 11:02 AM 3-1. Using the touch screen Setting the touch screen (Vehicles with AUX adapter) You can change the touch screen to your desired settings. Language settings The language used for all voice guidance, messages and touch screen switches may be changed.
  • Page 184 OM47614U_PRIUS_U.book Page 188 Monday, January 11, 2010 11:02 AM 3-1. Using the touch screen STEP Touch Adjusting the display Press STEP Adjust the display as desired using STEP If you do not touch the screen for 20 seconds, the system will return to the previous screen.
  • Page 185 OM47614U_PRIUS_U.book Page 189 Monday, January 11, 2010 11:02 AM 3-1. Using the touch screen “Day Mode” When the headlights are turned on, the screen dims. However the screen can be switched to day mode. The screen will stay in day mode when the headlights are turned on until is touched again.
  • Page 186 OM47614U_PRIUS_U.book Page 190 Monday, January 11, 2010 11:02 AM 3-1. Using the touch screen Screen settings Press STEP Touch on the “Information” screen. STEP The following screen settings can be changed. Automatic transition 20 seconds after air-conditioning or audio system use, the system will return the display to the previ- ous screen.
  • Page 187 OM47614U_PRIUS_U.book Page 191 Monday, January 11, 2010 11:02 AM 3-1. Using the touch screen Setting automatic transition Touch on the “Screen Setting” screen. STEP Press STEP Setting the switch color Touch on the “Screen Setting” screen. STEP Press STEP To delete personal data Touch the on the “Screen Setting”...

  • Page 188: Setting The Touch Screen (Vehicles Without Aux (Vehicle With Aux Adapter)

    OM47614U_PRIUS_U.book Page 192 Monday, January 11, 2010 11:02 AM 3-1. Using the touch screen Setting the touch screen (Vehicles without AUX adapter) You can change the touch screen to your desired settings. Language settings The language used for all voice guidance, messages and touch screen switches may be changed.
  • Page 189 OM47614U_PRIUS_U.book Page 193 Monday, January 11, 2010 11:02 AM 3-1. Using the touch screen Adjusting the display Press STEP Adjust the display as desired using STEP If you do not touch the screen for 20 seconds, the system will return to the previous screen.
  • Page 190 OM47614U_PRIUS_U.book Page 194 Monday, January 11, 2010 11:02 AM 3-1. Using the touch screen “Day Mode” When the headlights are turned on, the screen dims. However the screen can be switched to day mode. The screen will stay in day mode when the headlights are turned on until is touched again.

  • Page 191: Screen Settings

    OM47614U_PRIUS_U.book Page 195 Monday, January 11, 2010 11:02 AM 3-1. Using the touch screen Screen settings Press STEP Touch on the “Information” screen. STEP The following screen settings can be changed. Automatic transition 20 seconds after air-conditioning or audio system use, the system will return the display to the previ- ous screen.
  • Page 192 OM47614U_PRIUS_U.book Page 196 Monday, January 11, 2010 11:02 AM 3-1. Using the touch screen Setting automatic transition Touch on the “Screen Setting” screen. STEP Press STEP Setting the background color Touch on the “Screen Setting” STEP screen. Press STEP PRIUS_U_(OM47614U)
  • Page 193 OM47614U_PRIUS_U.book Page 197 Monday, January 11, 2010 11:02 AM 3-2. Using the air conditioning system and defogger Automatic air conditioning system (Vehicles with AUX adapter) Airflow and outlets are automatically adjusted according to the tem- perature setting. Press to display the air conditioning operation screen. Passenger compartment temperature display Outside temperature display...
  • Page 194 OM47614U_PRIUS_U.book Page 198 Monday, January 11, 2010 11:02 AM 3-2. Using the air conditioning system and defogger Using the automatic mode Press STEP indicator located in the instrument panel. The air conditioning system will begin to operate. Air outlets and fan, and automatically switches between outside air and recirculated air modes are automatically adjusted according to the temperature setting.
  • Page 195 OM47614U_PRIUS_U.book Page 199 Monday, January 11, 2010 11:02 AM 3-2. Using the air conditioning system and defogger Adjusting the fan speed (decrease ↔ Touch any switch of increase) on the operating screen. Press to turn the fan off. Changing the air outlets Touch any mode on the operat- ing screen.
  • Page 196 OM47614U_PRIUS_U.book Page 200 Monday, January 11, 2010 11:02 AM 3-2. Using the air conditioning system and defogger Air flows to the feet. Air flows to the feet and the windshield defogger operates. PRIUS_U_(OM47614U)
  • Page 197 OM47614U_PRIUS_U.book Page 201 Monday, January 11, 2010 11:02 AM 3-2. Using the air conditioning system and defogger Switching between outside air and recirculated air modes Press The mode switches between (recycles air inside the vehicle) and (introduces air from outside the vehicle) modes each time the but- ton is pressed.
  • Page 198 OM47614U_PRIUS_U.book Page 202 Monday, January 11, 2010 11:02 AM 3-2. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets Front outlets Direct air flow to the left or right, up or down Turn the knob to open or close the vent Using the automatic mode...
  • Page 199 OM47614U_PRIUS_U.book Page 203 Monday, January 11, 2010 11:02 AM 3-2. Using the air conditioning system and defogger CAUTION To prevent the windshield from fogging up Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the wind- shield can cause the outer surface of the windshield to fog up, blocking your vision.

  • Page 200: Automatic Air Conditioning System (Vehicles Without Aux Adapter)

    OM47614U_PRIUS_U.book Page 204 Monday, January 11, 2010 11:02 AM 3-2. Using the air conditioning system and defogger Automatic air conditioning system (Vehicles without AUX adapter) Airflow and outlets are automatically adjusted according to the tem- perature setting. Press to display the air conditioning operation screen. Outside temperature display Passenger compartment Air conditioning ON/OFF...
  • Page 201 OM47614U_PRIUS_U.book Page 205 Monday, January 11, 2010 11:02 AM 3-2. Using the air conditioning system and defogger Using the automatic mode Press STEP indicator located in the instrument panel. The air conditioning system will begin to operate. Air outlets and fan, and automatically switches between outside air and recirculated air modes are automatically adjusted according to the temperature setting.
  • Page 202 OM47614U_PRIUS_U.book Page 206 Monday, January 11, 2010 11:02 AM 3-2. Using the air conditioning system and defogger Adjusting the fan speed (decrease ↔ Touch any switch of increase) on the operating screen. Press to turn the fan off. Changing the air outlets Touch any mode on the operat- ing screen.
  • Page 203 OM47614U_PRIUS_U.book Page 207 Monday, January 11, 2010 11:02 AM 3-2. Using the air conditioning system and defogger Air flows to the feet. Air flows to the feet and the windshield defogger operates. PRIUS_U_(OM47614U)
  • Page 204 OM47614U_PRIUS_U.book Page 208 Monday, January 11, 2010 11:02 AM 3-2. Using the air conditioning system and defogger Switching between outside air and recirculated air modes Press The mode switches between (recycles air inside the vehicle) and (introduces air from outside the vehicle) modes each time the but- ton is pressed.
  • Page 205 OM47614U_PRIUS_U.book Page 209 Monday, January 11, 2010 11:02 AM 3-2. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets Front outlets Direct air flow to the left or right, up or down Turn the knob to open or close the vent Using the automatic mode...
  • Page 206 OM47614U_PRIUS_U.book Page 210 Monday, January 11, 2010 11:02 AM 3-2. Using the air conditioning system and defogger CAUTION To prevent the windshield from fogging up Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.

  • Page 207: Using The Steering Wheel Climate Remote Control Switches

    OM47614U_PRIUS_U.book Page 211 Monday, January 11, 2010 11:02 AM 3-2. Using the air conditioning system and defogger Using the steering wheel climate remote control switches Some air conditioning features can be controlled using the switches on the steering wheel. Automatic mode Temperature control Recirculated air mode Windshield defogger mode...
  • Page 208 OM47614U_PRIUS_U.book Page 212 Monday, January 11, 2010 11:02 AM 3-2. Using the air conditioning system and defogger Changing the recirculated air mode Press . (→P. 201, 208) Using the windshield defogger mode Press . (→P. 201, 208) Using the rear window and outside rear view mirror defogger mode Press .

  • Page 209: Rear Window And Outside Rear View Mirror Defoggers

    OM47614U_PRIUS_U.book Page 213 Monday, January 11, 2010 11:02 AM 3-2. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers These features are used to defog the rear window, and to remove raindrops, dew and frost from the outside rear view mirrors. (vehi- cles with mirror defoggers) Press to display the air conditioning operation screen.
  • Page 210 OM47614U_PRIUS_U.book Page 214 Monday, January 11, 2010 11:02 AM 3-2. Using the air conditioning system and defogger Operating conditions The “POWER” switch must be in the ON mode. CAUTION When the outside rear view mirror defoggers are on (vehicles with mir- ror defoggers) Do not touch the rear view mirror surfaces, as they can become very hot and burn you.

  • Page 211: 3-3. Using The Audio System

    OM47614U_PRIUS_U.book Page 215 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Audio system type (Vehicle with AUX adapter) CD and CD changer and AM/FM radio Press to display the audio operation screen. AUDIO This illustration below is for a vehicle equipped with the CD changer player.
  • Page 212 OM47614U_PRIUS_U.book Page 216 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system CD player:Plays audio CDs, CD text, MP3 discs and WMA discs. Title Page Using the radio P. 221 Using the CD player P. 235 Playing MP3 and WMA discs P.
  • Page 213 OM47614U_PRIUS_U.book Page 217 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system CAUTION For vehicles sold in the U.S.A. and Canada Part 15 of the FCC Rules FCC Warning: Any unauthorized changes or modifications to this equipment will void the user’s authority to operate this device.

  • Page 214: Audio System Type (Vehicle Without Aux Adapter)

    OM47614U_PRIUS_U.book Page 218 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Audio system type (Vehicle without AUX adapter) CD and AM/FM radio Press to display the audio operation screen. AUDIO ITY33P002 PRIUS_U_(OM47614U)

  • Page 215: Title Page

    OM47614U_PRIUS_U.book Page 219 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system CD player:Plays audio CDs and CD text. Title Page Using the radio P. 230 Using the CD player P. 243 Optimal use of the audio system P.
  • Page 216 OM47614U_PRIUS_U.book Page 220 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system NOTICE To prevent 12 volt battery discharge Do not leave the audio system on longer than necessary when the hybrid system is not operating. To avoid damaging the audio system Take care not to spill drinks or other fluids over the audio system.

  • Page 217: Using The Radio (Vehicle With Aux Adapter)

    OM47614U_PRIUS_U.book Page 221 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Using the radio (Vehicle with AUX adapter) Press to choose either an AM or FM band. When you press while listening to the radio, the following AUDIO audio control screen appears.
  • Page 218 OM47614U_PRIUS_U.book Page 222 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system ® Setting station presets (excluding XM satellite radio) TUNE FILE Search for desired stations by turning the dial or press- STEP ing ∧ or ∨ on Touch and hold one of the preset stations (1 - 6) until you hear STEP a beep.
  • Page 219 OM47614U_PRIUS_U.book Page 223 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Scanning all radio stations within range AM station Touch on the screen or press STEP SCAN “SCAN” appears on the screen and all stations with reception will be played for a few seconds each.
  • Page 220 OM47614U_PRIUS_U.book Page 224 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system The type of program changes each time the button is pressed. l ROCK l EASYLIS (Easy listening) l CLS/JAZZ (Classical music and Jazz) l R & B (Rhythm and Blues) l INFORM (Information) l RELIGION l MISC (Miscellaneous)
  • Page 221 OM47614U_PRIUS_U.book Page 225 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Traffic announcement Touch on the screen. “TRAF SEEK” appears on the screen, and the radio will start seeking any station broadcasting traffic program information. If no traffic program station is found, “NOTHING”...
  • Page 222 OM47614U_PRIUS_U.book Page 226 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system ® Scanning XM satellite radio channels l Scanning channels in the current category Touch on the screen or press STEP SCAN “SCAN” appears on the screen. When the desired channel is reached, touch STEP press the button once again.
  • Page 223 OM47614U_PRIUS_U.book Page 227 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system When the 12 volt battery is disconnected All preset stations are erased. Reception sensitivity Maintaining perfect radio reception at all times is difficult due to the con- tinually changing position of the antenna, differences in signal strength and surrounding objects, such as trains, transmitters, etc.
  • Page 224 XM antenna cable is attached securely. ANTENNA There is a short-circuit in the antenna or the sur- rounding antenna cable. See a Toyota certified dealer. ® You have not subscribed to XM satellite radio. The radio is being updated with the latest encryp- ®...
  • Page 225 OM47614U_PRIUS_U.book Page 229 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to the previous channel or “CH001”. If it does not change automatically, select another channel.

  • Page 226: Using The Radio (Vehicle Without Aux Adapter)

    OM47614U_PRIUS_U.book Page 230 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Using the radio (Vehicle without AUX adapter) Press to choose either an AM or FM band. When you press while listening to the radio, the following AUDIO audio control screen appears.
  • Page 227 OM47614U_PRIUS_U.book Page 231 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Setting station presets Search for desired stations by turning the dial or STEP TUNE pressing ∧ or ∨ on Touch and hold one of the preset stations (1 - 6) until you hear STEP a beep.
  • Page 228 OM47614U_PRIUS_U.book Page 232 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Scanning all radio stations within range AM station Touch on the screen or press STEP SCAN “SCAN” appears on the screen and all stations with reception will be played for a few seconds each.
  • Page 229 OM47614U_PRIUS_U.book Page 233 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system The type of program changes each time the button is pressed. l ROCK l EASYLIS (Easy listening) l CLS/JAZZ (Classical music and Jazz) l R & B (Rhythm and Blues) l INFORM (Information) l RELIGION l MISC (Miscellaneous)
  • Page 230 OM47614U_PRIUS_U.book Page 234 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Traffic announcement Touch on the screen. “TRAF SEEK” appears on the screen, and the radio will start seeking any station broadcasting traffic program information. If no traffic program station is found, “NOTHING”...

  • Page 231: Using The Cd Player (Vehicle With Aux Adapter)

    OM47614U_PRIUS_U.book Page 235 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Using the CD player (Vehicle with AUX adapter) Insert a CD or press with a CD inserted. When you press while listening to a CD, the following audio AUDIO control screen appears.
  • Page 232 OM47614U_PRIUS_U.book Page 236 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Loading CDs Loading a CD (CD player without changer) Insert a CD. Loading a single CD (CD player with changer) Press STEP When the indicator changes from flashing amber to green, STEP insert a CD after the CD player door opens.
  • Page 233 OM47614U_PRIUS_U.book Page 237 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Ejecting all CDs (CD player with changer) Press and hold until you hear a beep, then remove the CDs. Selecting, fast forwarding and scanning tracks Selecting a track Press ∧...
  • Page 234 OM47614U_PRIUS_U.book Page 238 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Selecting a CD (CD player with changer only) To select a CD to play Touch the desired disc number (1 - 6) on the screen. To scan loaded CDs Touch and hold on the screen until you hear a beep.
  • Page 235 If a CD-TEXT disc is inserted, the title of the disc and track will be displayed. Up to 13 letters can be displayed. Error messages Refer to the following table and take the appropriate measures. If the prob- lem is not rectified, take the vehicle to your Toyota dealer. Correction Message Cause Procedures •...
  • Page 236 OM47614U_PRIUS_U.book Page 240 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Discs that can be used Discs with the marks shown below can be used. Playback may be possible depending on recording format or disc features, or due to scratches, dirt or deterioration. CDs with copy-protect features may not be used.
  • Page 237 OM47614U_PRIUS_U.book Page 241 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system NOTICE Discs and adapters that cannot be used Do not use the following types of discs, 3 in. (8 cm) disc adapters or Dual Discs. Doing so may damage the player and render the disc insert/eject function unusable.
  • Page 238 OM47614U_PRIUS_U.book Page 242 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system NOTICE Player precautions Failure to follow the precautions below may result in damage to the discs or the player itself. Do not insert anything other than discs into the disc slot. Do not apply oil to the player.

  • Page 239: Using The Cd Player

    OM47614U_PRIUS_U.book Page 243 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Using the CD player (Vehicle without AUX adapter) Insert a CD or press with a CD inserted. When you press while listening to a CD, the following audio AUDIO control screen appears.
  • Page 240 OM47614U_PRIUS_U.book Page 244 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Loading a CD Loading a single CD Insert a CD. Ejecting a CD Ejecting a CD Press and remove the CD. Selecting, fast forwarding and scanning tracks Selecting a track Press ∧...
  • Page 241 OM47614U_PRIUS_U.book Page 245 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Displaying the disc and track title Touch on the screen. Random playback Current CD Touch on the screen. Songs are played in random order until random playback is canceled. Repeating a track Repeating a track Touch...
  • Page 242 If a CD-TEXT disc is inserted, the title of the disc and track will be displayed. Up to 29 letters can be displayed. Error messages Refer to the following table and take the appropriate measures. If the prob- lem is not rectified, take the vehicle to your Toyota dealer. Correction Message Cause Procedures •...
  • Page 243 OM47614U_PRIUS_U.book Page 247 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Discs that can be used Discs with the marks shown below can be used. Playback may be possible depending on recording format or disc features, or due to scratches, dirt or deterioration. CDs with copy-protect features may not be used.
  • Page 244 OM47614U_PRIUS_U.book Page 248 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system NOTICE Discs and adapters that cannot be used Do not use the following types of discs, 3 in. (8 cm) disc adapters or Dual Discs. Doing so may damage the player and render the disc insert/eject function unusable.
  • Page 245 OM47614U_PRIUS_U.book Page 249 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system NOTICE Player precautions Failure to follow the precautions below may result in damage to the discs or the player itself. Do not insert anything other than discs into the disc slot. Do not apply oil to the player.

  • Page 246: Playing Mp3 And Wma Discs

    OM47614U_PRIUS_U.book Page 250 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system ∗ Playing MP3 and WMA discs Insert an MP3 or WMA disc or press with a disc inserted. When you press during playback of the disc, the following AUDIO audio control screen appears.
  • Page 247 OM47614U_PRIUS_U.book Page 251 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Loading, ejecting and selecting MP3 and WMA discs Refer to the section entitled “Using the CD player” for details. (→P. 235) Selecting a folder Selecting a folder Touch “FOLDER ”...
  • Page 248 OM47614U_PRIUS_U.book Page 252 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Selecting and scanning files Selecting one file at a time TUNE FILE dial or press ∧ or ∨ on Turn the to select the desired file. Selecting a file from the file list Touch on the screen to turn the folder list on.
  • Page 249 OM47614U_PRIUS_U.book Page 253 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Selecting a desired file by cueing the files in the folder Touch on the screen. When the desired file is reached, touch once again. File repeat Touch on the screen.
  • Page 250 OM47614U_PRIUS_U.book Page 254 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system CD player protection feature To protect the internal components, playback is automatically stopped when a problem is detected while the CD player is being used. If CDs are left inside the CD player or in the ejected position for extended periods CDs may be damaged and may not play properly.
  • Page 251 OM47614U_PRIUS_U.book Page 255 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system WMA file compatibility • Compatible standards WMA Ver. 7, 8, 9 • Compatible sampling frequencies 32, 44.1, 48 (kHz) • Compatible bit rates Ver. 7, 8: CBR 48, 64, 80, 96, 128, 160, 192 (kbps) Ver.
  • Page 252 OM47614U_PRIUS_U.book Page 256 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system File names The only files that can be recognized as MP3/WMA and played are those with the extension .mp3 or .wma. Multi-sessions As the audio system is compatible with multi-sessions, it is possible to play discs that contain MP3 and WMA files.
  • Page 253 OM47614U_PRIUS_U.book Page 257 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Extensions If the file extensions .mp3 and .wma are used for files other than MP3 and WMA files, they will be mistakenly recognized and played as MP3 and WMA files.
  • Page 254 OM47614U_PRIUS_U.book Page 258 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system CD-R/CD-RW discs may be damaged by direct exposure to sunlight, high temperatures or other storage conditions. The unit may be unable to play damaged discs. If you insert a CD-RW disc into the MP3/WMA player, playback will begin more slowly than with a conventional CD or CD-R disc.

  • Page 255: Optimal Use Of The Audio

    OM47614U_PRIUS_U.book Page 259 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Optimal use of the audio (Vehicle with AUX adapter) Press on the panel to display the audio/video control screen. AUDIO Operating the radio and CD player (type A) Adjust sound quality and balance...
  • Page 256 OM47614U_PRIUS_U.book Page 260 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Adjusting sound quality and balance Touch on the screen. STEP Adjust the settings, referring to STEP the following table. Once you have finished, touch Sound quality Display Level Touch...
  • Page 257 OM47614U_PRIUS_U.book Page 261 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Setting DSP The following features can be set as desired by touching on the screen. Type B only Turning Automatic Sound Levelizer (ASL) Type A Touch ASL automatically adjusts the volume and tone quality according to the noise level as you drive your vehicle.
  • Page 258 OM47614U_PRIUS_U.book Page 262 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Trademark owned by SRS Labs, Inc. ® ® The audio systems utilize SRS FOCUS and SRS TruBass audio enhancement technologies, under license from SRS Labs, Inc., in all mode except AM radio mode.

  • Page 259: Optimal Use Of The Audio System (Vehicle Without Aux Adapter)

    OM47614U_PRIUS_U.book Page 263 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Optimal use of the audio system (Vehicle without AUX adapter) Press on the panel to display the audio/video control screen. AUDIO Operating the radio and CD player Adjust sound quality and balance...
  • Page 260 OM47614U_PRIUS_U.book Page 264 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Sound quality Display Level Touch mode High-pitched -5 to 5 tones Low-pitched -5 to 5 tones Front/rear F7 to R7 volume balance Left/right volume L7 to R7 balance : The sound quality level is adjusted individually in each radio or CD mode.

  • Page 261: Using The Aux Adapter

    OM47614U_PRIUS_U.book Page 265 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system ∗ Using the AUX adapter This adapter can be used to connect a portable audio device and lis- ten to it through the vehicle’s speakers. Connect the portable STEP audio device.

  • Page 262: Using The Steering Switches

    OM47614U_PRIUS_U.book Page 266 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Using the steering switches Some audio features can be controlled using the switches on the steering wheel. Volume Power on, select audio source Radio: Select radio stations CD:Select tracks, discs and folder Turning on the power...
  • Page 263 OM47614U_PRIUS_U.book Page 267 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Adjusting the volume Press “+” on to increase the volume and “-” to decrease the volume. Hold down the button to continue increasing or decreasing the volume. Selecting a radio station Press to select the radio mode.
  • Page 264 OM47614U_PRIUS_U.book Page 268 Monday, January 11, 2010 11:02 AM 3-3. Using the audio system Canceling automatic selection of a radio station Push the same switch. CAUTION To reduce the risk of an accident Exercise care when operating the audio switches on the steering wheel. PRIUS_U_(OM47614U)

  • Page 265: Using The Hands-Free System (For Cellular Phone)

    OM47614U_PRIUS_U.book Page 269 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Hands-free system (for cellular phone) The hands-free system is a function that allows you to use your mobile phone without touching it. ® ®...
  • Page 266 OM47614U_PRIUS_U.book Page 270 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Status display You can check such indicators as signal strength and battery charge on the “Telephone” screen. Connection status Battery charge 1 2 3 Call area Signal strength ITY34P003...
  • Page 267 OM47614U_PRIUS_U.book Page 271 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) When using the hands-free system The audio system and voice guidance are muted when making a call. If both parties speak at the same time it may be difficult to hear. If the received call volume is overly loud, an echo may be heard.
  • Page 268 OM47614U_PRIUS_U.book Page 272 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) ® About Bluetooth Bluetooth is a registered trademark of Bluetooth SIG. Inc. Compatible models Compatible with HFP (Hands Free Profile) Ver. 1.0 and OPP (Object Push Profile) Ver.
  • Page 269 OM47614U_PRIUS_U.book Page 273 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CAUTION: Radio Frequency Radiation Exposure This equipment complies with FCC radiation exposure limits set forth, for...

  • Page 270: Using The Bluetooth

    OM47614U_PRIUS_U.book Page 274 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) ® Using the Bluetooth phone Telephone screen ® Bluetooth Connection Status Character Deletion Display Last Person Called Make A Call ITY34P004 To display the screen shown above, press , then touch on the “Information”...
  • Page 271 OM47614U_PRIUS_U.book Page 275 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Touch STEP ITY34P005 Touch STEP ITY34P006 Input the passkey displayed on STEP screen into your phone. If the message “Bluetooth con- nection successful” is displayed, registration is complete.
  • Page 272 OM47614U_PRIUS_U.book Page 276 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) ® Bluetooth phone connection There are two connection methods available—automatic and man- ual. Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Choose one of the following methods.
  • Page 273 OM47614U_PRIUS_U.book Page 277 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Making a call ® Once the Bluetooth phone is registered, you can make a call using the following procedure. nDialing Press STEP Touch on the “Information”...
  • Page 274 OM47614U_PRIUS_U.book Page 278 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) nDialing from the phone book You can dial a number from the phone book data imported from your mobile phone. Up to 1000 entries may be stored in the phone book.
  • Page 275 OM47614U_PRIUS_U.book Page 279 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) nDialing from history You can make a call from past dialed numbers or received calls. Up to 5 numbers are stored, with the last recent number being deleted to make room for a new number.
  • Page 276 OM47614U_PRIUS_U.book Page 280 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) nCalling using speed dial You can make a call using numbers registered from the phone book and call history. (→P. 289) Press STEP Touch on the “Information”...
  • Page 277 OM47614U_PRIUS_U.book Page 281 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) nCalling using voice recognition Using voice recognition, you can call by name from the “Phone Book” screen, call by number from the “Telephone” screen, and send tones from the “Call”...
  • Page 278 OM47614U_PRIUS_U.book Page 282 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) lCalling by number from the “Telephone” screen Press the talk switch. STEP ITY34P017 Following the system guidance, wait until the beep and then STEP say the desired number.
  • Page 279 OM47614U_PRIUS_U.book Page 283 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Made/Received call history list If you make a call to or receive a call from a number registered in the phone book, the name is displayed in the call history. If you make multiple calls to the same number, only the last call made is displayed in the made calls history.
  • Page 280 OM47614U_PRIUS_U.book Page 284 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) To display the voice recognition operating guide STEP After pressing the talk switch, touch . If the “Com- mand List” screen is display- ing, touch STEP Touch...
  • Page 281 OM47614U_PRIUS_U.book Page 285 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) nTo refuse a call Touch and hold nTo adjust the received call volume Touch the . You can also adjust the volume using the steering switches.
  • Page 282 OM47614U_PRIUS_U.book Page 286 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) nInputting a key When using phone services such as an answering service or a bank, you can store phone numbers and code numbers in the phone book.
  • Page 283 OM47614U_PRIUS_U.book Page 287 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Transferring calls It is not possible to transfer from hands-free to the mobile phone while driving. If you transfer from the mobile phone to hands-free, the hands-free screen will be displayed, and you can operate the system using the screen.

  • Page 284: Setting The Hands-Free System (For Cellular Phone)

    OM47614U_PRIUS_U.book Page 288 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Setting the hands-free system (for cellular phone) You can speed dial, register in and edit the phone book, and set the ® Bluetooth phone.
  • Page 285 OM47614U_PRIUS_U.book Page 289 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Registering/Deleting a speed dial item nRegistering a speed dial item You can register a number from the phone book or the call history. Up to 17 entries may be stored.
  • Page 286 OM47614U_PRIUS_U.book Page 290 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Select the number to be regis- STEP tered. ITY34P027 Press the desired switch. STEP The last dialed number will be registered in position 6. ITY34P028 nDeleting a speed dial item Press...
  • Page 287 OM47614U_PRIUS_U.book Page 291 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) To delete all speed dial items Follow the steps for “Deleting a speed dial item” to “STEP 5”. In the “Speed Dial” section of the “Speed Dial Settings” screen, touch the .
  • Page 288 OM47614U_PRIUS_U.book Page 292 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Input the number and touch STEP ITY34P031 Touch the desired switch. STEP ITY34P032 nEditing a speed tone Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone”...
  • Page 289 OM47614U_PRIUS_U.book Page 293 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Touch the switch to be edited. STEP ITY34P033 Input the name and touch STEP Input the number and touch STEP nDeleting a speed tone Press STEP Touch...
  • Page 290 OM47614U_PRIUS_U.book Page 294 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Setting the volume Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch to lower or STEP...
  • Page 291 OM47614U_PRIUS_U.book Page 295 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Changing the screen settings The following settings can be changed. “Incoming Call Display” The incoming call screen set- tings can be changed. “Auto Answer” When a call is received, the system automatically switches to the talking screen after the...
  • Page 292 OM47614U_PRIUS_U.book Page 296 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) n“Incoming Call Display” settings Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Select the desired switch.
  • Page 293 OM47614U_PRIUS_U.book Page 297 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) n“Show Bluetooth connection status at startup” settings Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch in the “Show Bluetooth...
  • Page 294 OM47614U_PRIUS_U.book Page 298 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Phone book settings Up to 1000 names, 2 items per name, can be registered. nTransferring mobile phone data Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone”...
  • Page 295 OM47614U_PRIUS_U.book Page 299 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) overwrite data, touch STEP To add to existing data, touch ITY34P038 Transfer will begin. If you wish to STEP cancel the transfer before fin- ished, touch Transfer complete...
  • Page 296 OM47614U_PRIUS_U.book Page 300 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Touch the in the “Phone STEP Book” section. ITY34P040 PRIUS_U_(OM47614U)
  • Page 297 OM47614U_PRIUS_U.book Page 301 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Choose the switch to register. STEP : Input the name on the “Name” screen. Input the number(s) on the “Telephone Number” screen. When you touch , the “Select Icon”...
  • Page 298 OM47614U_PRIUS_U.book Page 302 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) nAdd history data to a registered entry Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Choose the desired number from the list. STEP To choose from the received call history, touch then select...
  • Page 299 OM47614U_PRIUS_U.book Page 303 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) nEditing phone book data Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch in the “Phone Book”...
  • Page 300 OM47614U_PRIUS_U.book Page 304 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) To delete all data Follow the steps “Deleting phone book data” to “STEP 5”. In the “Phone Book” section of the “Phone Book Management” screen, touch .
  • Page 301 OM47614U_PRIUS_U.book Page 305 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Changing the phone book group name settings nRegistering a group name Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings”...
  • Page 302 OM47614U_PRIUS_U.book Page 306 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) nDeleting a group name Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch the switch in the “Group Name”...
  • Page 303 OM47614U_PRIUS_U.book Page 307 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Deleting the history Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Select the data to delete from the list. STEP To delete data from the received calls history, touch , then...
  • Page 304 OM47614U_PRIUS_U.book Page 308 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Changing the security settings You can disable certain hands-free system functions. Use the secu- rity settings when you do not wish other people to see the registered data, for example when having the vehicle valet parked at a hotel.
  • Page 305 OM47614U_PRIUS_U.book Page 309 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Input the current security code, STEP and touch ITY34P048 Input the new security code, and touch STEP A confirmation message will appear. If everything is correct, STEP touch nEnabling security...
  • Page 306 OM47614U_PRIUS_U.book Page 310 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) nSetting the security code to default Press STEP Touch on the “Information” screen. STEP Touch ; on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch on the “Phone Book Lock”...
  • Page 307 When changing the security code Be sure to choose a number difficult for strangers to guess. Do not forget the security code. Even your Toyota dealer will be unable to disable the security. If you do forget the code, initialize all personal data.
  • Page 308 OM47614U_PRIUS_U.book Page 312 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) Select the phone to be use, then STEP touch If no phones are registered, “Empty” will be displayed. If “Bluetooth connection suc- cessful” is displayed, registration was successful.
  • Page 309 OM47614U_PRIUS_U.book Page 313 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) ® nTo change the Bluetooth settings You can change the device name and passkey. Press STEP STEP Touch on the “Information” screen. Touch on the “Telephone”...
  • Page 310 OM47614U_PRIUS_U.book Page 314 Monday, January 11, 2010 11:02 AM 3-4. Using the hands-free system (for cellular phone) ® nTo delete the Bluetooth settings Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch in the “Bluetooth...

  • Page 311: 3-5. Using The Interior Lights

    OM47614U_PRIUS_U.book Page 315 Monday, January 11, 2010 11:02 AM 3-5. Using the interior lights Interior lights list Illuminated entry system: The various lights automatically turn on/ off according to the presence of the electronic key, whether the doors are locked/unlocked, whether the doors are open/closed, and the “POWER”...
  • Page 312 “DOOR” position, the lights will go off automati- cally after 20 minutes. Customization that can be configured at Toyota dealer Setting (e.g. The time elapsed before lights turn off) can be changed. Customizable features → P. 486)

  • Page 313: Interior Lights

    OM47614U_PRIUS_U.book Page 317 Monday, January 11, 2010 11:02 AM 3-5. Using the interior lights Interior lights Front “ON” “OFF” “DOOR” The interior lights are turned on/ off by the illuminated entry sys- tem. Rear “ON” “OFF” “DOOR” The interior lights are turned on/ off by the illuminated entry sys- tem.
  • Page 314 OM47614U_PRIUS_U.book Page 318 Monday, January 11, 2010 11:02 AM 3-5. Using the interior lights Customization that can be configured at Toyota dealer. Settings can be changed. (Customizable features →P. 486) PRIUS_U_(OM47614U)

  • Page 315: 3-6. Using The Storage Features

    OM47614U_PRIUS_U.book Page 319 Monday, January 11, 2010 11:02 AM 3-6. Using the storage features List of storage features Overhead console Auxiliary box Glove box Cup holders Console box Bottle holder PRIUS_U_(OM47614U)

  • Page 316: Glove Box

    OM47614U_PRIUS_U.book Page 320 Monday, January 11, 2010 11:02 AM 3-6. Using the storage features Glove box Push the button. Glove box light The glove box light turns on when the headlight switch is on. CAUTION While driving Keep the glove box closed. Injuries may result in the event of an accident or sudden braking.

  • Page 317: Overhead Console

    OM47614U_PRIUS_U.book Page 321 Monday, January 11, 2010 11:02 AM 3-6. Using the storage features CAUTION While driving Keep the console box closed. Injuries may result in the event of an accident or sudden braking. Overhead console The overhead console is useful for temporarily storing sunglasses and similar small items.

  • Page 318: Cup Holders

    OM47614U_PRIUS_U.book Page 322 Monday, January 11, 2010 11:02 AM 3-6. Using the storage features Cup holders Front open, press down release the front cup holder lid. Rear To open, press in and release the rear cup holder on the arm- rest.

  • Page 319: Bottle Holders

    OM47614U_PRIUS_U.book Page 323 Monday, January 11, 2010 11:02 AM 3-6. Using the storage features Bottle holders CAUTION Items unsuitable for the bottle holder Do not place anything other than pet bottles in the bottle holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
  • Page 320 OM47614U_PRIUS_U.book Page 324 Monday, January 11, 2010 11:02 AM 3-6. Using the storage features Auxiliary box Type A Push the button. Type B Push the lid. Type C Lift the tray and pull it forward. PRIUS_U_(OM47614U)
  • Page 321 OM47614U_PRIUS_U.book Page 325 Monday, January 11, 2010 11:02 AM 3-6. Using the storage features Removing the separate tray (type A) Pull up. ITY36P011 CAUTION While driving Keep the auxiliary boxes closed. Injuries may result in the event of an acci- dent or sudden braking.

  • Page 322: 3-7. Other Interior Features

    OM47614U_PRIUS_U.book Page 326 Monday, January 11, 2010 11:02 AM 3-7. Other interior features Sun visors Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. ITY37P001 PRIUS_U_(OM47614U)

  • Page 323: Vanity Mirror

    OM47614U_PRIUS_U.book Page 327 Monday, January 11, 2010 11:02 AM 3-7. Other interior features Vanity mirror Slide the cover. ON: The light turns on when the cover is opened. OFF: Turns the light off. PRIUS_U_(OM47614U)

  • Page 324: Clock

    OM47614U_PRIUS_U.book Page 328 Monday, January 11, 2010 11:02 AM 3-7. Other interior features Clock Adjusts the hour Adjusts the minutes. The clock is displayed when The “POWER” switch is in ACCESSORY or ON mode. When the 12 volt battery is disconnected The time display will automatically be set to 1:00.

  • Page 325: Power Outlet

    OM47614U_PRIUS_U.book Page 329 Monday, January 11, 2010 11:02 AM 3-7. Other interior features Power outlet The power outlet can be used for 12V accessories that run on less than 10A. Instrument panel Rear console box The power outlet can be used when The “POWER”...
  • Page 326 OM47614U_PRIUS_U.book Page 330 Monday, January 11, 2010 11:02 AM 3-7. Other interior features NOTICE To avoid damaging the power outlet Close the power outlet lid when not in use. Foreign objects or liquids that enter the power outlet may cause a short cir- cuit.

  • Page 327: Armrest

    OM47614U_PRIUS_U.book Page 331 Monday, January 11, 2010 11:02 AM 3-7. Other interior features Armrest Pull the armrest down for use. ITY37P006 NOTICE To prevent damage to the armrest Do not place too much strain on the armrest. PRIUS_U_(OM47614U)

  • Page 328: Floor Mats

    OM47614U_PRIUS_U.book Page 332 Monday, January 11, 2010 11:02 AM 3-7. Other interior features Floor mats Securely place a mat that matches the size of the space on the car- pet. Secure the floor mat using the hooks provided. CAUTION When inserting the floor mat Observe the following precautions.

  • Page 329: Luggage Compartment Features

    OM47614U_PRIUS_U.book Page 333 Monday, January 11, 2010 11:02 AM 3-7. Other interior features Luggage compartment features Cargo hooks Cargo hooks are provided for securing loose items. ITY37P008 Auxiliary box Turn knob STEP “UNLOCK” position and open the lid. LOCK UNLOCK LOCK UNLOCK ITY37P009...
  • Page 330 OM47614U_PRIUS_U.book Page 334 Monday, January 11, 2010 11:02 AM 3-7. Other interior features Luggage cover (If equipped) Adjust the cover so that “TOP” STEP is facing upwards. ITY37P011 Pull out the luggage cover and STEP secure it to the hook brackets. ITY37P012 Removing the luggage cover The luggage cover can be removed by following the procedure below.
  • Page 331 OM47614U_PRIUS_U.book Page 335 Monday, January 11, 2010 11:02 AM 3-7. Other interior features Stowing the luggage cover Remove the side deck boards and STEP open the auxiliary box. Adjust the cover so that “TOP” is facing STEP ITY37P015 CAUTION While driving To avoid injury, always return the cargo hooks to their positions when they are not in use.

  • Page 332: Garage Door Opener

    OM47614U_PRIUS_U.book Page 336 Monday, January 11, 2010 11:02 AM 3-7. Other interior features Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, and security systems, and other devices. ®...
  • Page 333 OM47614U_PRIUS_U.book Page 337 Monday, January 11, 2010 11:02 AM 3-7. Other interior features Press and hold down one of the STEP ® buttons on the HomeLink the button on the transmitter. When the indicator light on the ® HomeLink changes from a slow to a rapid flash after 20 seconds, you can release both buttons.
  • Page 334 OM47614U_PRIUS_U.book Page 338 Monday, January 11, 2010 11:02 AM 3-7. Other interior features Programming a Rolling Code system (for U.S.A. owners) If your device is Rolling Code equipped, follow the steps under the ® heading “Programming the HomeLink ” before proceeding with the steps listed below.
  • Page 335 ® the remaining HomeLink buttons. Programming other devices To program other devices such as home security systems, home door locks or lighting, contact your authorized Toyota dealer for assistance. Reprogramming a button ® The individual HomeLink buttons cannot be erased but can be reprogrammed.
  • Page 336 OM47614U_PRIUS_U.book Page 340 Monday, January 11, 2010 11:02 AM 3-7. Other interior features Before programming Install a new battery in the transmitter. The battery side of the transmitter must be pointed away from the ® HomeLink Certification for the garage door opener This device complies with Part 15 of the FCC Rules and with RSS-210 of the IC Rules.

  • Page 337: 4-1. Maintenance And Care

    OM47614U_PRIUS_U.book Page 342 Monday, January 11, 2010 11:02 AM 4-1. Maintenance and care Cleaning and protecting the vehicle’s exterior Perform the following to protect the vehicle and maintain it in prime condition. l Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
  • Page 338 OM47614U_PRIUS_U.book Page 343 Monday, January 11, 2010 11:02 AM 4-1. Maintenance and care To prevent paint deterioration and corrosion on the body Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...

  • Page 339: 4-1. Maintenance And Care

    OM47614U_PRIUS_U.book Page 344 Monday, January 11, 2010 11:02 AM 4-1. Maintenance and care Cleaning and protecting the vehicle’s interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
  • Page 340 OM47614U_PRIUS_U.book Page 345 Monday, January 11, 2010 11:02 AM 4-1. Maintenance and care Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. Shampooing the carpets There are several commercial foaming-type cleaners available.
  • Page 341 OM47614U_PRIUS_U.book Page 346 Monday, January 11, 2010 11:02 AM 4-1. Maintenance and care NOTICE Cleaning detergents Do not use the following types of detergent, as they may discolor the vehicle interior or cause streaks or damage to painted surfaces. Non-seat portions: Organic substances such as benzine or gasoline, alka- line or acidic solutions, dye, or bleach.

  • Page 342: Maintenance Maintenance Requirements

    It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
  • Page 343 OM47614U_PRIUS_U.book Page 348 Monday, January 11, 2010 11:02 AM 4-2. Maintenance Allow inspection and repairs to be performed by a Toyota dealer Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.

  • Page 344: General Maintenance

    “Scheduled Maintenance Guide” or “Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items...

  • Page 345: Vehicle Interior

    OM47614U_PRIUS_U.book Page 350 Monday, January 11, 2010 11:02 AM 4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven pedal Accelerator pedal effort or catching)? Automatic transmission • Can the vehicle be hold securely on an “Park” mechanism incline with the shift lever in “P”? •...

  • Page 346: Vehicle Exterior

    OM47614U_PRIUS_U.book Page 351 Monday, January 11, 2010 11:02 AM 4-2. Maintenance Vehicle exterior Items Check points Doors • Operate smoothly? Engine hood • The lock system works properly? Fluid leaks • Is there any leakage after parking? • Inflation pressure is correct? •...

  • Page 347: Emission Inspection And Maintenance (I/M) Programs

    The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test:...

  • Page 348: Do-It-Yourself Maintenance Do-It-Yourself Service Precautions

    Brake fluid level (→P. 369) • Rag or paper towel • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology.
  • Page 349 OM47614U_PRIUS_U.book Page 354 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Items Parts and tools • “Toyota Genuine Motor Oil” or equivalent Engine oil level (→P. 361) • Rag or paper towel, funnel (used only for adding engine oil) •...
  • Page 350 OM47614U_PRIUS_U.book Page 355 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury observe the following precautions. When working on the engine compartment: Keep hands, clothing, and tools away from the moving fan and engine drive belt.
  • Page 351 OM47614U_PRIUS_U.book Page 356 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance NOTICE If you remove the air cleaner filter Driving with the air cleaner filter removed may cause excessive engine wear due to dirt in the air. Also a backfire could cause a fire in the engine compart- ment.

  • Page 352: Hood

    OM47614U_PRIUS_U.book Page 357 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release STEP lever. The hood will pop up slightly. ITY43P001 Lift the hood catch and lift the STEP hood.

  • Page 353: Positioning A Floor Jack

    OM47614U_PRIUS_U.book Page 358 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. Front Rear ITY43P005 PRIUS_U_(OM47614U)
  • Page 354 OM47614U_PRIUS_U.book Page 359 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance CAUTION When raising your vehicle Make sure to observe the following to reduce the possibility of death or seri- ous injury. Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.

  • Page 355: Engine Compartment

    OM47614U_PRIUS_U.book Page 360 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Engine compartment Washer fluid tank Inverter coolant reservoir (→P. 374) (→P. 367) Brake fluid reservoir Fuse box (→P. 394) (→P. 369) Radiator (→P. 369) Engine oil filler cap Condenser (→P.
  • Page 356 OM47614U_PRIUS_U.book Page 361 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Engine compartment cover Removing the cover Front Installing the clips Push up center portion Insert Press Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick.
  • Page 357 OM47614U_PRIUS_U.book Page 362 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Hold a rag under the end and STEP pull the dipstick out. Wipe the dipstick clean. STEP Reinsert the dipstick fully. STEP Holding a rag under the end, pull the dipstick out and check STEP the oil level.
  • Page 358 OM47614U_PRIUS_U.book Page 363 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
  • Page 359 OM47614U_PRIUS_U.book Page 364 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Recommended viscosity SAE 5W-30 is the best choice for good fuel economy, and good starting in cold weather. : If SAE 5W-30 oil is not avail- able, SAE 10W-30 oil may be used.
  • Page 360 Oil consumption: Max. 1.1 qt./600 miles, 0.9 lmp. qt./600 miles (1.0 L per 1000 km). If the vehicle consumes more than this amount, contact your Toyota dealer. Resetting the engine oil maintenance data (U.S.A. only) Perform the following steps: STEP Turn the “POWER”...
  • Page 361 Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. Do not leave used engine oil within the reach of children.
  • Page 362 OM47614U_PRIUS_U.book Page 367 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Engine/inverter coolant The coolant level is satisfactory if it is between the “FULL” and “LOW” lines on the reservoir when the engine is cold. Engine coolant reservoir Reservoir cap FULL If the level is on or below the “LOW”...
  • Page 363 Visually check the radiator, hoses, engine coolant filler cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer pressure test the cap and check for leaks in the cooling system. Coolant selection Only use “Toyota Super Long Life Coolant”...
  • Page 364 Check the radiator and condenser and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION When the engine is hot Do not touch the radiator or condenser, as they may be hot and you may be burned.
  • Page 365 OM47614U_PRIUS_U.book Page 370 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Brake fluid can absorb moisture from the air Excess moisture in the fluid can cause a dangerous loss of braking effi- ciency. Use only newly opened brake fluid. CAUTION When filling the reservoir Take care because brake fluid can harm your hands or eyes and damage...
  • Page 366 OM47614U_PRIUS_U.book Page 371 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance 12 volt battery Location The 12 volt battery is located in the right-hand side of luggage compartment. 12 volt battery exterior Make sure that the 12 volt battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps.
  • Page 367 With the shift lever in “P” and the “POWER” switch in the OFF mode, open and close any door, then attempt to start the hybrid system. If the system will not start even after multiple attempts at both methods, con- tact your Toyota dealer. PRIUS_U_(OM47614U)
  • Page 368 OM47614U_PRIUS_U.book Page 373 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance CAUTION Chemicals in the 12 volt battery The 12 volt battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the 12 volt battery: Do not cause sparks by touching the 12 volt battery terminals with tools.

  • Page 369: Washer Fluid

    OM47614U_PRIUS_U.book Page 374 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance NOTICE When recharging the 12 volt battery Never recharge the 12 volt battery while the hybrid system is operating. Also, be sure all accessories are turned off. Washer fluid If any washer does not work, the washer tank may be empty.

  • Page 370: Tires

    The tire pressure warning system Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (→P. 426) The compact spare tire is not equipped with a tire pressure warning valve and transmitter.
  • Page 371 ID codes must be registered in the tire pressure warning computer and tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by Toyota dealer. (→P. 378) Initializing the tire pressure warning system...
  • Page 372 OM47614U_PRIUS_U.book Page 377 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance How to initialize the tire pressure warning system Park the vehicle in safe place and turn the “POWER” switch to STEP OFF mode. While the vehicle is moving, initialization is not performed. Adjust the tire inflation pressure to the specified cold tire infla- STEP tion pressure level.
  • Page 373 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
  • Page 374 OM47614U_PRIUS_U.book Page 379 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Tire types 1 Summer tires Summer tires are high-speed performance tires best suited to highway driving under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
  • Page 375 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. When operating the tire pressure warning reset switch, the tire pres- sure warning light does not flash 3 times.
  • Page 376 OM47614U_PRIUS_U.book Page 381 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Tire pressure warning system certification FCC ID: PAXPMV107J FCC ID: HYQ13BCG IC ID: 3729A-PMV107J IC ID: 1551A-13BCG For vehicles sold in the U.S.A. NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 377 Do not mix tires of different makes, models, tread patterns or tread- wear. Do not use tire sizes other than those recommended by Toyota. Do not mix radial, bias-belted, or bias-ply tires. Do not mix summer, all season and winter tires.
  • Page 378 Repairing or replacing tires, wheels and tire pressure warning valves and transmitters When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled cor- rectly.

  • Page 379: Tire Inflation Pressure

    OM47614U_PRIUS_U.book Page 384 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (→P. 468) ITY43P019 PRIUS_U_(OM47614U)
  • Page 380 OM47614U_PRIUS_U.book Page 385 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Inspection and adjustment procedure Tire valve Tire pressure gauge Remove the tire valve cap. STEP Press the tip of the tire pressure gauge onto the tire valve. STEP Read the pressure using the graduations of the gauge.
  • Page 381 Reduced driving comfort and tire life Reduced safety Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: Check only when the tires are cold.
  • Page 382 OM47614U_PRIUS_U.book Page 387 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance CAUTION Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. Excessive wear Uneven wear Poor handling...

  • Page 383: Wheels

    Used wheels l Bent wheels that have been straightened Aluminum wheel precautions l Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. l When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
  • Page 384 4-3. Do-it-yourself maintenance When replacing wheels The wheels of your Toyota are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advanced warning in the event of a loss in tire inflation pressure.

  • Page 385: Air Conditioning Filter

    OM47614U_PRIUS_U.book Page 390 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Turn the “POWER” switch to OFF mode. STEP Open the glove box slide off STEP the damper.
  • Page 386 OM47614U_PRIUS_U.book Page 391 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Replacement method Remove the air conditioning filter from the filter case and replace it with a new one. “ ↑UP” marks shown on the filter and the filter case should be pointing up.

  • Page 387: Electronic Key Battery

    OM47614U_PRIUS_U.book Page 392 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is discharged. You will need the following items: l Small Phillips-head screwdriver l Lithium battery (CR2032) Replacing the battery Take out the mechanical key.
  • Page 388 The smart key system and wireless remote control will not function prop- erly. The operational range is reduced. Use a CR2032 lithium battery Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. Replace only with the same or equivalent type recommended by a Toy- ota dealer.

  • Page 389: Checking And Replacing Fuses

    OM47614U_PRIUS_U.book Page 394 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the “POWER”...
  • Page 390 OM47614U_PRIUS_U.book Page 395 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Luggage compartment Remove the cover. After a system failure, see “Fuse layout and amperage rat- STEP ings” (→P. 397) for details about which fuse to check. Remove the fuse with the pull- STEP out tool.
  • Page 391 Type B Normal fuse Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type C Normal fuse Blown fuse Contact your Toyota dealer. PRIUS_U_(OM47614U)
  • Page 392 OM47614U_PRIUS_U.book Page 397 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings Driver’s side instrument panel Fuse Ampere Circuit Power windows 30 A Rear window defogger 40 A M/HTR Outside rear view mirror heater 15 A Windshield wiper 30 A RR WIP...
  • Page 393 OM47614U_PRIUS_U.book Page 398 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Touch screen, power windows, air ECU-B 15 A conditioning system Hybrid system 7.5 A Tail lights, license plates light, TAIL 10 A parking lights Touch screen, clock, audio sys- PANEL 7.5 A tem, instrument panel lights...
  • Page 394 OM47614U_PRIUS_U.book Page 399 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Engine compartment Fuse Ampere Circuit SPARE 30 A Spare SPARE 15 A Spare 7.5 A Daytime running light system 10 A H-LP LO RH Right-hand headlight (low beam) 15 A 10 A H-LP LO LH...
  • Page 395 OM47614U_PRIUS_U.book Page 400 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Fuse Ampere Circuit ABS-1 25 A Anti-lock brake system ETCS 10 A Electronic throttle control system BATT FAN 10 A Battery cooling fan Turn signal lights, emergency 10 A flasher Audio system, interior lights, smart key system, gauge and meter, turn...

  • Page 396: Luggage Compartment

    OM47614U_PRIUS_U.book Page 401 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Luggage compartment Fuse Ampere Circuit DC/DS-S Inverter and converter MAIN 120 A Hybrid system PRIUS_U_(OM47614U)
  • Page 397 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix.

  • Page 398: Light Bulbs

    4-3. Do-it-yourself maintenance Light bulbs You may replace the following bulbs yourself. For more information about replacing other light bulbs, contact your Toyota dealer. Prepare a replacement light bulb. Check the wattage of the light bulb being replaced. (→P. 469) Remove the engine compartment cover if necessary.

  • Page 399: Replacing Light Bulbs

    OM47614U_PRIUS_U.book Page 404 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Replacing light bulbs Headlights (vehicles with halogen bulbs) Unplug the connector. STEP ITY43P040 Remove the rubber cover. STEP ITY43P041 Release bulb retaining STEP spring. ITY43P042 PRIUS_U_(OM47614U)
  • Page 400 OM47614U_PRIUS_U.book Page 405 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Remove the bulb. STEP ITY43P043 Parking and front side marker lights Turn the bulb base counterclock- STEP wise. ITY43P044 Remove the light bulb. STEP ITY43P045 PRIUS_U_(OM47614U)

  • Page 401: Front Turn Signal Lights

    OM47614U_PRIUS_U.book Page 406 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Front turn signal lights Turn the bulb base counterclock- STEP wise. ITY43P046 Remove the light bulb. STEP ITY43P047 PRIUS_U_(OM47614U)
  • Page 402 OM47614U_PRIUS_U.book Page 407 Monday, January 11, 2010 11:02 AM 4-3. Do-it-yourself maintenance Back-up lights, tail and rear side maker lights, rear turn signal light Open the back door and remove STEP the cover. ITY43P048 Turn the bulb base counterclock- STEP wise.

  • Page 403: License Plate Lights

    License plate lights Remove the upper trim board. STEP ITY43P051 Turn the bulb base counterclock- STEP wise. ITY43P052 Remove the light bulb. STEP Front fog lights If the high mounted stoplight has burnt out, have it replaced by your Toyota dealer. PRIUS_U_(OM47614U)
  • Page 404 LED light bulbs The stop and high mounted stoplights consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced. If two or more LEDs in a stoplight burn out, your vehicle may not conform to local laws (SAE).
  • Page 405 Doing so could result in electric shock and death or serious injury. High-intensity discharge (HID) headlights Contact your Toyota dealer before replacing high-intensity discharge headlights (including light bulbs). Do not touch the high-intensity discharge headlight’s high voltage socket when the headlights are turned on.

  • Page 406: Essential Information Emergency Flashers

    OM47614U_PRIUS_U.book Page 412 Monday, January 11, 2010 11:02 AM 5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, push the switch once again.

  • Page 407: If Your Vehicle Needs To Be Towed

    If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
  • Page 408 OM47614U_PRIUS_U.book Page 414 Monday, January 11, 2010 11:02 AM 5-1. Essential information Towing eyelet ITY51P001 Emergency towing procedure STEP Release the parking brake. STEP Put the shift lever in “N”. STEP Turn the “POWER” switch to ACCESSORY (hybrid system off) or ON mode (hybrid system on).
  • Page 409 OM47614U_PRIUS_U.book Page 415 Monday, January 11, 2010 11:02 AM 5-1. Essential information Installing towing eyelet Remove the eyelet cover using a STEP flathead screwdriver. To protect the bodywork, place a rag between the screwdriver and the vehicle body, as shown in the illustration.
  • Page 410 OM47614U_PRIUS_U.book Page 416 Monday, January 11, 2010 11:02 AM 5-1. Essential information CAUTION Installing towing eyelet to the vehicle Make sure that towing eyelet is installed securely. If not securely installed, towing eyelet may come loose during towing. This may lead to accidents that cause serious injury or even death. Towing with a sling-type truck ITY51P005 NOTICE...
  • Page 411 OM47614U_PRIUS_U.book Page 417 Monday, January 11, 2010 11:02 AM 5-1. Essential information Towing with a wheel lift-type truck From front Release the parking brake. ITY51P006 From rear Use a towing dolly under the front wheel. ITY51P007 PRIUS_U_(OM47614U)
  • Page 412 OM47614U_PRIUS_U.book Page 418 Monday, January 11, 2010 11:02 AM 5-1. Essential information NOTICE To prevent causing serious damage to the transmission Never tow this vehicle from the rear with the front wheels on the ground. To prevent damaging the vehicle Do not tow the vehicle with the “POWER”...
  • Page 413 OM47614U_PRIUS_U.book Page 419 Monday, January 11, 2010 11:02 AM 5-1. Essential information Using a flat bed truck If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°. Do not overly tighten the tie downs or the vehicle may be damaged.

  • Page 414: If You Think Something Is Wrong

    5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms l Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)

  • Page 415: Event Data Recorder

    OM47614U_PRIUS_U.book Page 421 Monday, January 11, 2010 11:02 AM 5-1. Essential information Event data recorder Your vehicle has computers that monitor and control certain aspects of your vehicle. These computers assist in driving and maintaining optimal vehicle performance. Besides storing data useful for troubleshooting, there is a system to record data in a crash or a near car crash event.
  • Page 416 OM47614U_PRIUS_U.book Page 422 Monday, January 11, 2010 11:02 AM 5-1. Essential information Disclosure of the data Toyota will not disclose the data recorded in an EDR to a third party except when: l An agreement from the vehicle’s owner (or the leasing company for...

  • Page 417: 5-2. Steps To Take In An Emergency

    Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake sys- tem. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Brake system warning light and warning buzzer...
  • Page 418 Indicates a malfunction in the hybrid system. : This warning light is displayed on the touch screen. Have the vehicle inspected by your Toyota dealer immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident.
  • Page 419 OM47614U_PRIUS_U.book Page 425 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency Warning light Warning light/Details Vehicle stability control system warning light (if equipped) Indicates a malfunction in the Enhanced VSC system. Automatic headlight leveling system warning light (if equipped) Indicates a malfunction in the automatic headlight level- ing system.
  • Page 420 When the light comes on: Adjust the tire inflation Low tire inflation pressure. pressure. When the light stays on after blinking for 1 minute: Have the system checked Malfunction in the tire by your Toyota dealer. pressure warning system. PRIUS_U_(OM47614U)
  • Page 421 “N” position. If this light comes on with the “READY” light on in this The hybrid battery is dis- case, have the system charged. checked by your Toyota dealer. High coolant temperature warning light →P. 454 Indicates high engine cool-...
  • Page 422 OM47614U_PRIUS_U.book Page 428 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency :Driver’s and front passenger’s seat belt reminder buzzer: The driver’s and front passenger’s seat belts reminder sounds to alert the driver and front passenger that his or her seat belt is not fastened. The buzzer sounds intermittently for 10 seconds after the vehicle has reached a speed of at lest 12 mph (20 km/h).
  • Page 423 OM47614U_PRIUS_U.book Page 429 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency Warning Alarm Details Correction procedure light The lock button has Exterior alarm: been pressed while One beep Turn the hybrid sys- the hybrid system is (sounds for 2 tem OFF.
  • Page 424 Is the fuel tank cap loose? If it is, tighten it securely. The light will go off after taking several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. Power steering warning light When the voltage is low or drops, the power steering warning light may come on.
  • Page 425 OM47614U_PRIUS_U.book Page 431 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency Front passenger detection sensor and passenger seat belt reminder If luggage is placed on the front passenger seat, the front passenger detec- tion sensor may cause the warning light to flash, even if a passenger is not sitting in the seat.
  • Page 426 If there is a lot of snow or ice on the vehicle, in particular around the wheels or wheel housings. If non-genuine Toyota wheels are used (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.).
  • Page 427 Check the tires. If the tire is flat, change to the spare tire and have the flat tire repaired by the nearest Toyota dealer. Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could lose control of the steering wheel or the brakes.
  • Page 428 OM47614U_PRIUS_U.book Page 434 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency CAUTION Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
  • Page 429 OM47614U_PRIUS_U.book Page 435 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency CAUTION Your vehicle has also been equipped with a TPMS (tire pressure warning system) malfunction indicator to indicate when the system is not operat- ing properly.

  • Page 430: If You Have A Flat Tire

    OM47614U_PRIUS_U.book Page 436 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. Before jacking up the vehicle l Stop the vehicle on a hard, flat surface. l Set the parking brake.
  • Page 431 OM47614U_PRIUS_U.book Page 437 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency Compact spare tire The compact spare tire saves space in your luggage compart- ment, and its lighter weight helps to enhance fuel economy and permits easier installation in case of a flat tire.
  • Page 432 OM47614U_PRIUS_U.book Page 438 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency Taking out the jack. Open the auxiliary box. STEP (→P. 333) ITY52P002 Unlock the tightening strap. STEP After storing the jack, make sure it is securely held by the tightening strap.
  • Page 433 OM47614U_PRIUS_U.book Page 439 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency Taking out the spare tire Loosen the center fastener that secures the spare tire. ITY52P004 Replacing a flat tire Chock the tires. STEP ITY52P005 Flat tire Wheel chock positions Left-hand side...
  • Page 434 OM47614U_PRIUS_U.book Page 440 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency Slightly loosen the wheel nuts STEP (one turn). ITY52P006 Turn the tire jack portion “A” by STEP hand until the notch of the jack is in contact with the jack point.
  • Page 435 OM47614U_PRIUS_U.book Page 441 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- STEP ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may...

  • Page 436: Tightening Torque

    OM47614U_PRIUS_U.book Page 442 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency Firmly tighten each nut two or STEP three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) ITY52P013 Stow the flat tire, the tire jack and all tools.
  • Page 437 OM47614U_PRIUS_U.book Page 443 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency CAUTION Using the tire jack Improper use of the tire jack may lead to death or injuries due to the vehicle suddenly falling off the jack. Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
  • Page 438 OM47614U_PRIUS_U.book Page 444 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency CAUTION When using the compact spare tire Remember that your spare tire is specifically designed for use with your vehicle. Do not use your spare tire on another vehicle. Do not use two spare tires simultaneously.
  • Page 439 When replacing the tires When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. To avoid damaging the tire pressure warning valves and transmit- ters Do not use liquid sealants on flat tires.

  • Page 440: If The Hybrid System Will Not Start

    One or both of the 12 volt battery terminals may be discon- nected. l The 12 volt battery may be discharged. (→P. 449) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. PRIUS_U_(OM47614U)

  • Page 441: If You Lose Your Keys

    OM47614U_PRIUS_U.book Page 447 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency If you lose your keys New genuine Toyota keys can be made by your Toyota dealer using master key and the key number stamped on your key number plate. PRIUS_U_(OM47614U)

  • Page 442: If The Electronic Key Does Not Operate Properly

    OM47614U_PRIUS_U.book Page 448 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency If the electronic key does not operate properly If the electronic key battery is discharged, the doors can be opened by the mechanical key. The hybrid system can be still started by fol- lowing the procedure.

  • Page 443: If The 12 Volt Battery Is Discharged

    You can call your Toyota dealer, or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12 volt battery, you can jump start your Toyota following the steps below.
  • Page 444 OM47614U_PRIUS_U.book Page 450 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency Connecting the jumper cables. STEP ITY52P017 Exclusive jump starting terminal on your vehicle. Positive (+) battery terminal on the second vehicle. Negative (-) battery terminal on the second vehicle. Connect the jumper cable to ground on your vehicle as shown in the illustration.
  • Page 445 Turn the hybrid system off. Open and close the driver’s door. Then push the “POWER” switch briefly and firmly. If the light does not come on, contact your Toyota dealer. Once the vehicle’s hybrid system has started, remove the STEP jumper cables in the exact reverse order in which they were connected.
  • Page 446 OM47614U_PRIUS_U.book Page 452 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency When the 12 volt battery is removed or discharged The following systems must be initialized. → Power windows ( P. 76) The hybrid system may not start. (→P. 446) CAUTION Avoiding 12 volt battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam-...
  • Page 447 OM47614U_PRIUS_U.book Page 453 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency NOTICE To prevent damaging the vehicle The exclusive jump starting terminal is to be used when charging the 12 volt battery from another vehicle in an emergency. It cannot be used to jump start another vehicle.

  • Page 448: If Your Vehicle Overheats

    OM47614U_PRIUS_U.book Page 454 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency If your vehicle overheats The following may indicate that your vehicle is overheating: The high engine coolant temperature warning light comes on: The hybrid system may be overheating. Follow the correction procedure as described blow.
  • Page 449 Water can be used in an emer- gency measure if coolant is unavailable. (→P. 465) ITY52P019 Have the vehicle checked at your nearest Toyota dealer as soon as possible. Overheating In the following situations, your vehicle may be overheating. High coolant temperature warning light is displayed on the touch screen.
  • Page 450 OM47614U_PRIUS_U.book Page 456 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency CAUTION To prevent an accident or injury when inspecting under the hood of your vehicle If steam is seen coming from under the hood, do not open the hood until the steam has subsided.

  • Page 451: If The Vehicle Becomes Stuck

    OM47614U_PRIUS_U.book Page 457 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Stop the hybrid system.
  • Page 452 OM47614U_PRIUS_U.book Page 458 Monday, January 11, 2010 11:02 AM 5-2. Steps to take in an emergency PRIUS_U_(OM47614U)

  • Page 453: 6-1. Specifications

    OM47614U_PRIUS_U.book Page 460 Monday, January 11, 2010 11:02 AM 6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weight Overall length 175.0 in. (4445 mm) Overall width 67.9 in. (1725 mm) Overall height 58.7 in. (1490 mm) Wheelbase 106.3 in. (2700 mm) Front 59.3 in.
  • Page 454 6-1. Specifications Vehicle identification The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
  • Page 455 OM47614U_PRIUS_U.book Page 462 Monday, January 11, 2010 11:02 AM 6-1. Specifications Engine Model 1NZ-FXE Type 4-cylinder in line, 4-cycle, gasoline × × Bore and stroke 2.95 3.33 in. (75.0 84.7 mm) Displacement 91.4 cu. in. (1497 cm 44 - 88 lbf(196 - 392 N, 20 - 40 kgf)* Idler assembly Drive belt tension Water pump...
  • Page 456 OM47614U_PRIUS_U.book Page 463 Monday, January 11, 2010 11:02 AM 6-1. Specifications Electric motor (Traction motor) Type Permanent magnet synchronous motor Maximum output 50 kW Maximum torque 400 N•m (40.8 kgf•m, 295 ft•lbf) Hybrid battery (Traction battery) Type Nickel-Metal hydride battery Voltage 7.2 V/module Capacity...

  • Page 457: Lubrication System

    3.9 qt. (3.7 L, 3.3 lmp.qt.) without filter 3.6 qt. (3.4 L, 3.0 lmp.qt.) Oil grade ILSAC multigrade engine oil Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the grade and viscosity shown below. Recommended oil viscosity Outside temperature :5W-30 is an oil that provides optimal levels of fuel efficiency.

  • Page 458: Cooling System

    9.0 qt. (8.6 L, 7.5 lmp.qt.) Power control unit 2.9 qt. (2.7 L, 2.4 lmp.qt.) Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non- Coolant type silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technol- Do not use plain water alone.

  • Page 459: Electrical System

    Toyota Genuine ATF WS NOTICE Transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle. PRIUS_U_(OM47614U)
  • Page 460 OM47614U_PRIUS_U.book Page 467 Monday, January 11, 2010 11:02 AM 6-1. Specifications Brakes Pedal clearance 3.98 in. (101.0 mm) Min. Pedal free play Less than 0.04 - 0.24 in. (1.0 - 6.0 mm) Brake pad wear limit 0.04 in. (1.0 mm) Parking brake pedal 6 ⎯...
  • Page 461 OM47614U_PRIUS_U.book Page 468 Monday, January 11, 2010 11:02 AM 6-1. Specifications Steering Free play Less than 1.2 in. (30 mm) Tires and wheels P195/55R16 86V, P185/65R15 86S, Tire size T125/70D16 96M (spare) Front and rear tire inflation Front tire: pressure 35 psi (240 kPa, 2.4 kgf/cm or bar) (Recommended cold tire...
  • Page 462 OM47614U_PRIUS_U.book Page 469 Monday, January 11, 2010 11:02 AM 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights ⎯ Discharge bulbs ⎯ Halogen bulbs 60/55 Front fog lights 9006 Parking/front side marker ⎯ lights Exterior ⎯ Front turn signal lights ⎯...

  • Page 463: Fuel Information

    ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada. Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. If your engine knocks Consult your Toyota dealer.
  • Page 464 Toyota allows the use of oxygenate blended gasoline where the oxygen- ate content is up to 10% ethanol or 15% MTBE. If you use gasohol in your Toyota, be sure that it has an octane rating no lower than 87.
  • Page 465 OM47614U_PRIUS_U.book Page 472 Monday, January 11, 2010 11:02 AM 6-1. Specifications NOTICE Notice on fuel quality Do not use improper fuels. If improper fuels are used the engine will be damaged. Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle’s three-way catalytic converters causing the emission control system to malfunction.

  • Page 466: Tire Information

    OM47614U_PRIUS_U.book Page 473 Monday, January 11, 2010 11:02 AM 6-1. Specifications Tire information Typical tire symbols Standard tire Compact spare tire Tire size (→P. 476) DOT and Tire Identification Number (TIN) (→P. 475) Location of treadwear indicators (→P. 375) PRIUS_U_(OM47614U)
  • Page 467 OM47614U_PRIUS_U.book Page 474 Monday, January 11, 2010 11:02 AM 6-1. Specifications Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire. Summer tire or all season tire (→P.
  • Page 468 OM47614U_PRIUS_U.book Page 475 Monday, January 11, 2010 11:02 AM 6-1. Specifications Typical DOT and tire identification number (TIN) DOT symbol Tire Identification Number (TIN) Tire manufacturer’s identifica- tion mark Tire size code Manufacturer’s optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year :The DOT symbol certifies that...
  • Page 469 OM47614U_PRIUS_U.book Page 476 Monday, January 11, 2010 11:02 AM 6-1. Specifications Tire size Typical tire size information Standard tire The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Spare tire Tire construction code...
  • Page 470 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. DOT quality grades All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades.
  • Page 471 OM47614U_PRIUS_U.book Page 478 Monday, January 11, 2010 11:02 AM 6-1. Specifications Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speci- fied government test course. For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on the government course as a tire graded 100.
  • Page 472 OM47614U_PRIUS_U.book Page 479 Monday, January 11, 2010 11:02 AM 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either sepa- rately or in combination, can cause heat buildup and possible tire fail- ure.
  • Page 473 OM47614U_PRIUS_U.book Page 480 Monday, January 11, 2010 11:02 AM 6-1. Specifications Tire related term Meaning Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb.
  • Page 474 OM47614U_PRIUS_U.book Page 481 Monday, January 11, 2010 11:02 AM 6-1. Specifications Tire related term Meaning The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between components Bead separation in the bead...
  • Page 475 OM47614U_PRIUS_U.book Page 482 Monday, January 11, 2010 11:02 AM 6-1. Specifications Tire related term Meaning The layer(s) forming the inside surface of a Innerliner tubeless tire that contains the inflating medium within the tire The parting of the innerliner from cord material Innerliner separation in the carcass (a)The sidewall that contains a whitewall, bears...
  • Page 476 OM47614U_PRIUS_U.book Page 483 Monday, January 11, 2010 11:02 AM 6-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, including eleva- Overall width tions due to labeling, decorations, or protective bands or ribs A tire intended for use on passenger cars, mul- tipurpose passenger vehicles, and trucks, that Passenger car tire...
  • Page 477 OM47614U_PRIUS_U.book Page 484 Monday, January 11, 2010 11:02 AM 6-1. Specifications Tire related term Meaning A tire that attains a traction index equal to or greater than 110, compared to the ASTM E- 1136 Standard Reference Test Tire, when using the snow traction test as described in ASTM F-1805-00, Standard Test Method for Snow tire Single Wheel Driving Traction in a Straight Line...
  • Page 478 OM47614U_PRIUS_U.book Page 485 Monday, January 11, 2010 11:02 AM 6-1. Specifications Designated seating Occupant distribution in Vehicle normal load, capacity, Number of a normally loaded Number of occupants occupants vehicle 2 through 4 2 in front 2 in front, 1 in second 5 through 10 seat 2 in front, 1 in second...

  • Page 479: Customization Customizable Features

    Programming these preferences requires specialized equipment and may be performed by an autho- rized Toyota dealership. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Customized Item Function...
  • Page 480 OM47614U_PRIUS_U.book Page 487 Monday, January 11, 2010 11:02 AM 6-2. Customization Customized Item Function Default setting setting Operation indicator (Emergency flashers) Operation indicator Wireless (Buzzer) remote control Panic function → P. 49) Buzzer sounds when pushing with any door not closed Driver’s door unlocked in 1- All doors...
  • Page 481 OM47614U_PRIUS_U.book Page 488 Monday, January 11, 2010 11:02 AM 6-2. Customization Customized Item Function Default setting setting 7.5 seconds Time elapsed before 15 seconds lights turn off 30 seconds Operation when the doors are unlocked Illumination Operation after the → P. 315) “POWER”...

  • Page 482: Initialization Items To Initialize

    OM47614U_PRIUS_U.book Page 489 Monday, January 11, 2010 11:02 AM 6-3. Initialization Items to initialize After reconnecting or performing maintenance on the 12 volt battery, the following items must be initialized for normal system operation. Item When to initialize Reference • After reconnecting or changing the Power window 12 volt battery P.
  • Page 483 OM47614U_PRIUS_U.book Page 490 Monday, January 11, 2010 11:02 AM 6-3. Initialization PRIUS_U_(OM47614U)

  • Page 484: Reporting Safety Defects For U.s. Owners

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 485: Seat Belt Instructions For Canadian Owners (In French)

    OM47614U_PRIUS_U.book Page 493 Monday, January 11, 2010 11:02 AM Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English.
  • Page 486 OM47614U_PRIUS_U.book Page 494 Monday, January 11, 2010 11:02 AM PRIUS_U_(OM47614U)

  • Page 487: Abbreviation List

    OM47614U_PRIUS_U.book Page 496 Monday, January 11, 2010 11:02 AM Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Air Conditioning Anti-lock Brake System Accessory Automatic Locking Retractor Child Restraint System Electronic Control Unit Event Data Recorder Emergency Locking Retractor Electronic Power Steering GAWR Gross Axle Weight Ratings Emission inspection and maintenance LATCH...
  • Page 488 OM47614U_PRIUS_U.book Page 497 Monday, January 11, 2010 11:02 AM PRIUS_U_(OM47614U)

  • Page 489: Alphabetical Index

    OM47614U_PRIUS_U.book Page 498 Monday, January 11, 2010 11:02 AM Alphabetical index Alphabetical index A/C..........197 Back-up lights ABS ...........166 Wattage......... 469 Air conditioning system Back door Air conditioning filter....390 Back door........54 Automatic air conditioning Wireless remote control ..49 system ........197 Smart key system ....36 Steering wheel climate Battery remote control switches ..211...
  • Page 490 OM47614U_PRIUS_U.book Page 499 Monday, January 11, 2010 11:02 AM Alphabetical index How your child should wear Driver’s seat belt reminder the seatbelt ......67 light .........426 Installing child restraints ..111 Driving Power window lock switch..76 break-in tips......123 Power window precautions..78 Correct posture .......87 Removed electronic key battery Procedures......122...
  • Page 491 OM47614U_PRIUS_U.book Page 500 Monday, January 11, 2010 11:02 AM Alphabetical index Engine compartment cover..361 Garage door opener ....336 Engine/inverter coolant Gas station information ..508 Capacity ........465 Gauges........145 Checking .......367 Glove box ......... 320 Preparing and checking before winter .......173 Hands-free system Engine oil (for cellular phone)....
  • Page 492 OM47614U_PRIUS_U.book Page 501 Monday, January 11, 2010 11:02 AM Alphabetical index Interior lights Maintenance data....460 Interior lights......317 Maintenance Switch........317 requirements.......347 Wattage ........ 469 Meter Instrument panel light control .........146 Jack Meters ........145 Positioning a floor jack ..358 Mirrors Vehicle-equipped jack ..
  • Page 493 OM47614U_PRIUS_U.book Page 502 Monday, January 11, 2010 11:02 AM Alphabetical index Rear turn signal lights Side airbags .......89 Replacing light bulbs .....403 Side marker lights Wattage.........469 Switch ........152 Rear view monitor system ..163 Side mirror Rear window defogger ....213 Adjusting and folding....74 Replacing Smart key system...
  • Page 494 OM47614U_PRIUS_U.book Page 503 Monday, January 11, 2010 11:02 AM Alphabetical index Tire information Warning buzzers Glossary ....... 479 Brake system ......423 Size ........476 Open door ......426 Tire identification number ..475 Seat belt reminder....426 Uniform tire quality grading .. 477 Warning lights Tires Anti-lock brake...

  • Page 495: What To Do If

    OM47614U_PRIUS_U.book Page 504 Monday, January 11, 2010 11:02 AM What to do if... What to do if... A tire punctures If you have a flat tire P. 436 P. 82 Immobilizer system The hybrid system does not start If the hybrid system will not start P.
  • Page 496 OM47614U_PRIUS_U.book Page 505 Monday, January 11, 2010 11:02 AM What to do if... Instrument cluster ITYPP011 Touch screen ITYPP013 PRIUS_U_(OM47614U)
  • Page 497 OM47614U_PRIUS_U.book Page 506 Monday, January 11, 2010 11:02 AM What to do if... n Warning lights Brake system warning Charging system warn- light (red indicator) ing light P. 424 Malfunction indicator lamp P. 423 P. 424 Driver’s seat belt reminder ABS warning light light /VSC warning light...
  • Page 498 OM47614U_PRIUS_U.book Page 507 Monday, January 11, 2010 11:02 AM What to do if... PRIUS_U_(OM47614U)

  • Page 499: Gas Station Information

    (L, Imp.qt.) Engine oil capacity With filter 3.9 (3.7, 3.3) (Drain and refill) Without filter 3.6 (3.4, 3.0) “Toyota Genuine Motor Oil” or equivalent Engine oil type Oil grade: ILSAC multigrade engine oil P. 464 Recommended oil viscosity: SAE 5W-30 PRIUS_U_(OM47614U)
