HQTELECOM.com Number Blocker
(Model LX009B-V6, Last Revised in January, 2016)
FEATURES:
Block up to 1,000 unwanted phone numbers
Block up to 5 area codes or prefixes (1-5 digits)
Block calls showing as "OUT OF AREA" (--- O
---) or "PRIVATE" (--- P ---)
Block calls with no phone number displayed
Simple set up and easy to use
Easy to read LCD display (2.5" x 1") with Blue
backlight & 4 levels of brightness
Stores phone numbers in non-volatile memory
(retains stored data if loses power)
Stores up to 100 incoming calls (most recent)
Stores up to 50 outgoing calls (most recent)
Visual incoming call alert LED light
Backup power via batteries (not included)
FSK / DTMF dual system
WHAT'S IN THE BOX:
(1) Number Blocker Unit
(1) User Manual
INSTALLATION:
Installing/Replacing Batteries (Optional but recommended):
This device is powered by your phone line but uses batteries as backup. To install/replace the
batteries, open the battery cover located in the back of the unit and insert three (3) AAA
batteries (not included). Please note the correct positioning (+ and -). Warning: Please
disconnect the AC adapter from the unit or the power outlet PRIOR to inserting or changing the
batteries.
Series Installation (option 1): Connect your phone line to the "LINE" port coming from wall or
form your phone service provider and then use small cord to connect "PHONE" port or socket
directly to actual phone set as shown in the figure below:
Version 6 User Manual
(1) Telephone Cable Patch Cord (~1 feet, 0.3 meters)
IMPORTANT:
CALLER ID
SERVICE IS REQUIRED FOR
THIS DEVICE TO WORK
PROPERLY.
Advertisement
Table of Contents
Summary of Contents for HQTELECOM.com LX009B-V6
- Page 1 HQTELECOM.com Number Blocker Version 6 User Manual (Model LX009B-V6, Last Revised in January, 2016) FEATURES: Block up to 1,000 unwanted phone numbers Block up to 5 area codes or prefixes (1-5 digits) Block calls showing as “OUT OF AREA” (--- O ---) or “PRIVATE”...
- Page 2 PARALLEL (Option 2): You may also install it in parallel with your phone(s) using a 2-way splitter (not included), as shown below: IMPORTANT: If using the parallel setup, you will still need to plug in a telephone handset to the PHONE socket (at least temporarily) to program your call blocker. PROGRAMMING: PREPARATION: Before programming your call blocker, you will need the following: 1) A telephone handset connected on the PHONE socket of the Call Blocker.
- Page 3 Step 1. Press the [ SET ] button (LCD display set 123456). Step 2. Lift off up the handset (hear the dialtone), and press [ 2 ] using the dialpad. The LCD should display “LCD 2”). Step 3. Press the [ DWN ] key to switch from 1 to 4. Step 4.
- Page 4 LCD will display the phone number (up to 16 digits), date and time of each call. NOTE: This device will only display telephone numbers in the LCD, not names. 9. Check / Review / Browse Outgoing Phone Numbers Press the [ OUT ] button to view recent outgoing calls records, press the [ DWN ] button to browse list, LCD display “NO CODE”...
- Page 5 - the “Mail” icon shows if you have the voicemail notification service activated as part of the caller id information received from your phone service provider. If need any help setting up or using your Number Blocker device, please visit – PLEASE DO NOT RETURN THIS DEVICE BEFORE https://HQTELECOM.com CONTACTING US FIRST.
