AA-101(t)
AA-104(t)
Analog audio distribution amplifier
1x6 / 1x4
- for SRU rack frame
USER MANUAL FOR USE AND MAINTENANCE
Read the instructions before using the device.
Keep this manual for periodic usage.
Z10-3 edition 1
Code: 001.202
001.210
001.204
001.207
Advertisement
Table of Contents
Related Manuals for Sams AA-101
Summary of Contents for Sams AA-101
- Page 1 Keep this manual for periodic usage. Sams elektronik d.o.o. 48 Zivka Davidovica st. 11050 Belgrade Serbia Tel/Fax: +381 11 3806 253 +381 11 2402 212 sams@sams.rs www.sams.rs Copyright © 1999 - 2014 Sams elektronik d.o.o. Published: 05. april 2013. Updated: 03. july 2014.
- Page 2 Any technical failure or deficiency that occurs during the warranty period specified on the invoice of the purchased equipment will be inspected and serviced by Sams elektronik doo or an authorized service center of the manufacturer, with the conditions set out in the warranty statement.
- Page 3 BACK CONNECTORS The product is designed and manufactured according to the following regulations: - Electromagnetic Compatibility Directive (EMC) - Low Voltage Directive (ELV) Documentation confirming statements can be obtained on written request for review. Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs...
- Page 4 Design and specifications of the device may change without prior notice. TECHNICAL SUPPORT AND SERVICE Sams elektronik has made every effort to ensure that the equipment works in perfect condition. In the event that problems that occur can not be resolved, or if you have any questions regarding this...
-
Page 5: Table Of Contents
REMOVAL AND STORAGE ....................6 DESCRIPTION .......................7 MODULE INSTALATION IN SRU RACK FRAMES ..............11 BACK CONNECTORS ......................13 SRU REAR SIDE ......................14 BLOCK DIAGRAM ......................15 PCB WITH THE LAYOUT OF ELEMENTS ................16 ADJUSTMENT .......................16 NOTES .........................17 Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... -
Page 6: Unpacking And Installation
According to the user’s needs, the masses can be switched over between them. Places for fastening MAINTENANCE The system maintains only person authorized by Sams elektronik doo. Any voluntarily opening device, upgrading or servicing is strictly prohibited and is subject to warranty void, and the possibility of injury. -
Page 7: Description
001.210 AA-101t Analog audio DA (transformer) 1x6 001.503 CA-6 Back connector Power 001.600 SRU-312 Rack frame for 12 modules 001.601 SRU-310 Rack frame for 10 modules 001.605 SRU-306 Rack frame for 6 modules Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... -
Page 8: Ordering Information
Available in 66Ω or 600Ω output impedance The AA-101 mono audio distribution amplifier is designed for Broadcast Television and post Productions. Excellent output isolation and inter channel crosstalk is assured by the use of individual drivers for each output. Outputs can be customized, 600Ω... - Page 9 Power 001.219 AA-104t Analog audio DA (transformer) 1x4 001.503 CA-6 Back connector 001.600 SRU-312 Rack frame for 12 modules 001.601 SRU-310 Rack frame for 10 modules 001.605 SRU-306 Rack frame for 6 modules Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs...
- Page 10 Description Power 001.218 AA-104 Analog audio DA 1x4 001.503 CA-6 Back connector 001.600 SRU-312 Rack frame for 12 modules 001.601 SRU-310 Rack frame for 10 modules 001.605 SRU-306 Rack frame for 6 modules Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs...
-
Page 11: Module Instalation In Sru Rack Frames
POWER Lock module with lever to the position. NOTE: NEVER PLACE MODULE TO PLACE OF THE POWER SUPPLY MODULE! WARNING! POWER SUPPLY ONLY The label that indicates the place for power supply module Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... - Page 12 Distribution amplifiers elektronik 1. The module set between the guides (not metal plate). 2. Locking lever mount behind the groove. 3. Push the lever to lock in an upright position. The module is locked. Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs...
-
Page 13: Back Connectors
AUDIO AUDIO AUDIO AA-101(t) AA-104(t) Be sure to install a protective pad before installing the back connectors. AA-101 AA-101 AA-101 AA-101 AA-101 AA-101 AA-101 AA-101 AA-101 AA-101 AA-101 AA-101 AA-101 AA-101 AA-101 AA-101 Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... -
Page 14: Sru Rear Side
DO NOT INSERT SHARP METAL OBJECTS OR FINGERS INTO THE SPACE BEHIND DANGER! THE POWER PANEL! HIGH VOLTAGE! THE SIGN “LIGHTNING IN A TRIANGLE” IS TO ALERT THE USER TO THE PRESENCE OF LIFE-THREATENING HIGH POWER. LABEL IS PLACED NEXT TO POWER PANEL. Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... -
Page 15: Block Diagram
Distribution amplifiers elektronik BLOCK DIAGRAM AA-101(t) (only on AA-101t) AA-104(t) (only on AA-104t) Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... -
Page 16: Pcb With The Layout Of Elements
To adjust the distribution in the system, it is necessary to have: - Signal generator (a signal which is brought to the input of the distribution) - Adequate measuring equipment (output signal of the distribution) - A small flathead screwdriver (for adjusting) Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... -
Page 17: Notes
Distribution amplifiers elektronik NOTES Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs... - Page 18 Distribution amplifiers elektronik Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs...
