INSTALLATION MANUAL
AIR CONDITIONER
• Please read this installation manual completely before installing the product.
• Installation work must be performed in accordance with the national wiring
standards by authorized personnel only.
• Please retain this installation manual for future reference after reading it
thoroughly.
TYPE : VENTILATOR
P/NO : 3828A20469K
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG LZ-H050GBA2
Summary of Contents for LG LZ-H050GBA2
- Page 1 • Please read this installation manual completely before installing the product. • Installation work must be performed in accordance with the national wiring standards by authorized personnel only. • Please retain this installation manual for future reference after reading it thoroughly. TYPE : VENTILATOR www.lg.com P/NO : 3828A20469K...
-
Page 2: Table Of Contents
Ventilator Installation Manual TABLE OF CONTENTS Installation Required Parts Required Tools Requirements Safety Precaution....3 Introduction ......6 Symbols Used in this manual ......6 Feature Dimension Diagram.......6 Installation ......11 Installation Map ....11 • Screws • Screw Driver Installation of Main Body ...14 •... -
Page 3: Installation
