Equipment
Unpack the camera and assemble the following equipment:
1. TS3 / TS4 /TS5 camera
2. Camera power adapter with AC power cord, or charged battery inserted in the camera. (The battery is fully
charged when shipped from the factory.)
3. Lens
Camera Views
1. Power LED
2. Network activity LED
3. Storage activity LED
4. Camera status LED
5. Sync activity LED
6. Battery status LED
7. Power ON/OFF button
8. Arm button
9. Display button
10. Menu button
11. D-Pad
1. USB OTG (Micro connector)
2. SDHC (SD-card slot)
3. GigE Port (RJ45 connector)
4. LVTTL I/O, Sync, Trigger, etc. (Lemo connector)
5. HDMI Port (Type A connector)
6. DC Power In (Lemo connector)
1. Trigger button
2. Power button
3. USB port
4. Top mount 1/4 -20
5. Camera strap attachment
6. 1/4-20 Tripod mount
7. Hand strap attachment point
8. Battery door
TS3 / TS4 / TS5 Quick Start Guide
1
2
3
4
3
1
2
5
6
7
4
5
8
9
10
11
6
7
8
1
Advertisement
Table of Contents
Related Manuals for Fastec TS3
Summary of Contents for Fastec TS3
- Page 1 TS3 / TS4 / TS5 Quick Start Guide Equipment Unpack the camera and assemble the following equipment: 1. TS3 / TS4 /TS5 camera 2. Camera power adapter with AC power cord, or charged battery inserted in the camera. (The battery is fully charged when shipped from the factory.)
- Page 2 In the Record Menu Select Mode Setup. The choices available will depend on the camera model. The TS4 will have both Standard and Long Record options available, while the TS3 and TS5 will only have the Standard options. (The TS4 will reboot when going back and forth from Standard to Long Record.)
- Page 3 Download images to a USB thumb drive installed in the USB port in the camera. View or transfer the images by installing the USB thumb drive in the USB port of the desired PC. Contact Information Fastec Imaging Corporation 17150 Via Del Campo, Ste.301, San Diego, CA 92127 +1-858-592-2342...
