LumeLEX 2030/2031 SERIES INSTALLATION INSTRUCTIONS
Important
THIS SHEET CONTAINS IMPORTANT SAFETY INSTRUCTIONS.
SAVE THESE INSTRUCTIONS.
Warning
This product must be installed in accordance with National Electrical Codes and all other
local codes by a person familiar with the construction and operation of the product and
the hazards involved.
To prevent electrical shock, turn off the power during installation or maintenance.
To reduce the risk of fire, keep away from combustible materials.
The LumeLEX 2030/2031 Series is a clean,
Product
elegant stem mounted LED spotlight with a
Overview
discreetly hidden driver, making it appear no
different than a traditional halogen source.
With independent ratings of 97CRI, the
LumeLEX 2030/2031 series, based on the
latest in Remote Corrected Cold Phosphor
Technology by Xicato, has the highest Color
Rendering Index of any LED on the market
today, producing the most consistent, highest
quality white light and maintaining extremely
tight color control (within 2 MacAdam ellipses,
vs. the NEMA standard of 7). The LumeLEX
2030/2031 series also features a snap-out
cross baffle and accessory cartridge which
accepts up to two optical accessories, size
'AAA'.
See the fixture label for voltage and wattage
input.
Please consult our Product Catalog or web
site for available accessories.
We recommend that you first install the
reflector and any accessories before
installing the fixture.
The purpose of this sheet is to provide step-by-step instructions to help you:
Purpose of
This Sheet
Install the fixture with any of the following: -00E fitting on an LSI track, -BUSE fitting on an LSI
Busway, -5AE canopy.
Install accessory filters and reflectors
Aim the self-locking and wrench-locking fixture
Clean the optical surfaces and reflector
www.LightingServicesInc.com
LumeLEX 2030 Series Spotlight
Page 1 of 6
IS-0139_A
Advertisement
Summary of Contents for LSI LumeLEX 2030 Series
- Page 1 The purpose of this sheet is to provide step-by-step instructions to help you: Purpose of This Sheet Install the fixture with any of the following: -00E fitting on an LSI track, -BUSE fitting on an LSI Busway, -5AE canopy. Install accessory filters and reflectors ...
- Page 2 Before Changing Reflector: To maintain the Changing fixture’s current orientation, change the reflector with the fixture in its location. If the orientation Installing does change, refer to the “Aiming the Fixture” section of this sheet. Refer to our Product Catalog Reflector or web site for reflector options.
- Page 3 Installing FOR USE WITH LSI 3, 4, 5, 6, 8, AND 9 SERIES TRACK the Fixture AND LSI 20 SERIES BUSWAY SYSTEMS ONLY. with the INSTALLATION INSTRUCTIONS: The track or busway -00E Fitting must already be installed according to code requirements.
- Page 4 The LumeLEX 2030/2031 has a Installing Before Installing: removable accessory cartridge that holds size-AAA LSI filters Accessory and accessories, as well as other reflectors. The LumeLEX Filters and 2030/2031 package includes accessory cartridges and a Reflectors reflector. Consult our Product Catalog or web site for accessory recommendations.
- Page 5 Before Aiming: For self-locking, you do not need Aiming the an external locking device to set the horizontal and Self- vertical focus. For wrench locking, use the Locking supplied Allen key (3/32 inches) to set and lock the horizontal and vertical focus. Wrench- Locking STEP...
-
Page 6: Materials Required
CLEANING INSTRUCTIONS for LumeLEX 2000 REFLECTORS Important FOLLOW THESE INSTRUCTIONS SO TO PREVENT DAMAGE TO YOUR REFLECTOR. NOT CLEANING THE REFLECTOR CORRECTLY CAN REDUCE THE EFFICIENCY OF THE OPTICAL SURFACE. DO NOT TOUCH THE SURFACE OF THE REFLECTOR WITH YOUR BARE SKIN, AS HUMAN SKIN OIL WILL DEGRADE THE OPTICAL SURFACE.
