- Page 1 00054823 (IR110) 00054829 (IR111) Internet Radio Internetradio Operation instructions...
- Page 2 Technical Data Radio Receiver/ DAB+ Internet Spotify Radio Empfänger ü ü Connectivity/ LAN (10/100), WIFI(b/g/n), USB (Play/Charge 5V Verbindungsfähigkeit Display/ 2.6“ Full Dot LCD Bildschirm Encryption/ WEP, WPA, WPA2, WPS Verschlüsselung Speaker/ 10 W RMS (2x 5 W) Lautsprecher Impedance/ 6 Ohm Impedanz Speaker 2.75“...
- Page 3 DC IN AUX IN LINE OUT...
- Page 4 MODE MENU INFO MUTE ALARM SLEEP SNOOZE...
-
Page 5: Operating Instructions
G Operating instructions Controls and Displays A: Front C: Remote Control [volume -/+] / Rotate: Volume control Press: On/off switch On/off switch [info] Display additional information ≙ Press [volume -/+]/ [ [menu] Direct access to the menu Confirm [OK] ≙ Press [enter/navigate] Changing operating mode [mode] ∧... - Page 6 ▲ Up / ▼ Down / C: Remote Control ◄ Back one menu level Navigation ≙ [back] / keys ► Forward/ Confirm On/off switch ≙ Press [enter/navigate]/[OK] ≙ Press [volume -/+]/ [ Confirm Mute [OK] ≙ Press [enter/navigate] Direct access to operating [IR] Rewind (operating mode: mode Internet radio ≙...
-
Page 7: Table Of Contents
7.4.1 Save favourites ....... .14 14. Hama Smart Radio (Android / iOS) ....28 7.4.2 Access favourites. -
Page 8: Menu Structure
Menu structure MAIN MENU INTERNET RADIO Last listened Station list My Favourites Local Stations Location Genre Search stations Popular stations New stations Podcasts Location Genre search podcasts My Added Stations Help Get access code System settings Main menu SPOTIFY System settings Main menu MUSIC PLAYER Shared media... - Page 9 Rock Movie Classic News My EQ My EQ profile setup Bass Treble Loudness Save Network Network wizard PBC Wlan setup View settings Manual settings NetRemote PIN Setup Network profile Keep network connection Time/Date Set Time/Date Auto update Update from Network No update Set format Set timezone...
-
Page 10: Explanation Of Warning Symbols And Notes
Thank you for choosing a Hama product. 3. Safety Notes Take your time and read the following instructions and • The product is intended for private, non-commercial use information completely. Please keep these instructions in a only. safe place for future reference. If you sell the device, please •... -
Page 11: Informations And Notes Before Getting Started
4. Informations and notes before getting started 5. Getting started Network connection/ 5.1 Remote control Preparing the internet connection • Open the battery compartment cover. It is located on the You can integrate this radio into a local network and rear of the remote control. -
Page 12: Radio - Connecting And Starting Up
You can find an appropriate selection of Hama products at • The buttons on the remote control – corresponding www.hama.com. to the control buttons on the device ( )- you will find ≙... - Page 13 Navigation and controls Additional information • Select among menu items by turning [enter/navigate]. Press [info] to display context-dependent additional • Confirm the selection by pressing [enter/navigate]. information. The information shown depends on the operating mode as well as the current selection of radio This procedure is indicated in these operating instructions station, music file, etc.
-
Page 14: Initial Setup
5.4 Initial setup Date/ Time • 12/24 hours format When it is first connected to the power supply, a list of • Auto update available languages for the menu is displayed. Proceed as • Update from Network follows to set your preferred language. Choose this option to set the time and date automatically from the internet. -
Page 15: Main Menu / Modes
6. Main menu / modes 7. Internet radio Access the main menu as follows: The radio uses the station list on the vTuner* portal. You can use stations without direct registration on the following portal: http://www.wifiradio-froniter.com. [menu] You will find detailed operating instructions under Section 7.5 Favourites Note * If necessary, it is possible to switch providers in order... -
Page 16: Search By Country Or Region
7.1.1 Search by country or region 7.1.3 Search by name To search for a station by continent, country and region, If you know the name of the desired station, you can proceed as follows: search for it directly. [menu] [menu] Station list Station list ... -
Page 17: New Stations
7.1.5 New stations 7.2 Podcasts Stations that have recently been added to the database Podcasts are programs on various topics and include, can be found as follows: for example, talk shows, news and much more. Podcasts can be downloaded from the Internet. There are normally approximately 10,000 programs available. -
Page 18: Search By Name
7.2.3 Search by name 7.4.1 Save favourites If you know the name of the desired Podcasts, you can • Set the station that you would like to save as a favourite search for it directly. station preset. • If the station is received, press and hold [memory] on front of the radio. -
Page 19: Management Of Favourites With The Remote Control
7.4.3 Management of favourites with 7.5 Favourites the remote control (vTuner - http://www.wifiradio-frontier.com) The remote control enclosed has number keys 1-10. In addition to the local station memory slots, you can A favourite can be assigned to each of these number key. create additional lists of favourites using the vTuner •... -
Page 20: Managing Favourites Online (Vtuner - Http://Www.wifiradio-Frontier.com)
• During registration, the radio’s ID is associated with your 7.5.4 My Added Stations e-mail address and saved in the web interface. If a station you desire is not yet available, you can add it • If multiple radios are registered to you and you wish to manually to the portal, or suggest a station be added to delete one of those registrations or just compare them, the database (Recommend station). - Page 21 Use: • Choose Available devices to access an overview of • In the Spotify app, start playback of a playlist or title as all devices available on the network. usual. • Select the radio. The audio is now played back on the •...
-
Page 22: Music Player (Upnp, Usb)
9. Music player (UPNP, USB) 9.2 Playback from a computer (streaming) This operating mode enables the playback of MP3, WMA You can manage the radio and stream music to it from your or FlAC files that are saved on a PC, data storage medium computer. -
Page 23: Playback From The Network - Accessing Files Using The Radio
9.3 Playback from the network – Accessing files 9.4 Playback of playlist using the radio You can create a local playlist on the radio, in which you To access one of the existing network shared files directly save files shared on the network or from connected data from the radio, proceed as follows: storage devices. -
Page 24: General Playback Options
• To delete the entire playlist, proceed as follows: 10. Auxiliary Input Via the analogue audio input (AUX IN socket) you can connect mobile devices (for example smartphone, tablet [menu] PC, M3 player etc.) to the radio and play the audio files using the radio´s speakers. -
Page 25: Sleep
11. Sleep 12. Alarms The radio has a sleep function, after a defined time the The Radio has two individually adjustable alarm times. radio switches to standby mode. • Repeatedly press [ ] or [SLEEP] on the remote 12.1 Alarm settings control to set the desired time interval (Sleep OFF/ •... -
Page 26: Activating/ Deactivating The Alarm
Volume: 13. System settings You can set the volume at which the alarm sound should You can modify all settings and access important be played. This setting makes it irrelevant how loud you information about the radio in the System settings. last listened to the radio. -
Page 27: Network
13.2 Network 13.2.2 Wireless network connection (WLAN) 13.2.1 Network wizard – Configuration of internet Depending on the network, there are a number of ways to connection / Automatic search connect to it. Networks that support connection via WPS (Wi-Fi Protected The network wizard supports you to set up a connection Setup) are identified in the list as [WPS]. -
Page 28: Wired Network Connection (Lan)
• Alternatively, PBC setup can be initiated from the internet Open network settings of the radio: Note • We recommend against establishing unsecured [menu] connections and advise you to always protect your network against unauthorised access. • If you plan to use an open network, you just have to select the network ID from the list of available System settings networks and confirm. -
Page 29: View Settings
DHCP enable 13.2.6 NetRemote PIN Setup / Smart Radio-App • Select the option Wireless. The radio can be controlled using the application Hama • Select the option DHCP enable. Smart Radio. • In the input screen, enter the whole SSID (network name) For this, you have to have installed the app on your and then confirm with OK. -
Page 30: Network Profile
13.2.7 Network profile 13.2.8 Keep network connected The radio automatically saves all successfully connected This setting is a radio energy-saving function. network profiles. This means that re-establishing these connections (for example, after the radio was disconnected [menu] from the power supply) does not require you to re-enter the network access information. -
Page 31: Language
No update Note The time and date (DD-MM-YYYY) must be set manually; no automatic calibration takes place. • Resetting to the factory default settings can solve some problems and malfunctions. Set Time/ Date • However, all settings made previously, such as custom Set the date (DD-MM-YYYY) and time (hh:mm) manually equaliser presets, favorites, and network profiles, are using [enter/navigate]. -
Page 32: Setup Wizard
13.7 Setup wizard • Proceed as follows: You can restart the setup wizard (5.4.1. Setup wizard) at any time by proceeding as follows: [menu] [menu] System settings Backlight System settings Setup wizard • For the operation modes Operation Mode and Slumber mode, select between various brightness levels. -
Page 33: Hama Smart Radio (Android / Ios)
14. Hama Smart Radio (Android / iOS) 14.2 First startup The Hama Smart Radio app allows you to access and control many features of the radio from your tablet computer or smartphone, without using the remote control. The current version of the app can be found here: For iPhone and iPad http://www.hama.com/hama-smart-radio-apple-itunes... -
Page 34: Source Selection
14.4 Source selection Source selection / active device Settings Playback source (DAB, FM, Internet, etc.) Playback window Search (stations or directories) Manage favourites Shuffle / Mix Share Repeat (function mode-dependent) Station information Navigation buttons (function mode- dependent) Navigation buttons (function mode- dependent) Navigation buttons (function mode- dependent) -
Page 35: Station Search And Favourites
14.5 Station search and favourites 14.5.2 Searching for stations / station lists 14.5.1 Managing favourites You can also search for stations using the app. Tap any of the search results to open it. To access favourites management, tap this button in the playback window (6). -
Page 36: Settings And Standby
16. Warranty Disclaimer Hama GmbH & Co. KG assumes no liability and provides no warranty for damage resulting from improper installation/ mounting, improper use of the product or from failure to observe the operating instructions and/ or safety notes. -
Page 37: Service And Support
17. Service and Support Please contact Hama Product Consulting if you have any questions about this product Hotline: +49 9091 502-115 (German/English) Further support information can be found here: www.hama.com 18. Recycling Information Note on environmental protection: After the implementation of the European Directive... - Page 38 Hama GmbH & Co KG 86652 Monheim / Germany www.hama.com The Spotify software is subject to third party licenses found here: www.spotify.com/connect/third-party-licenses All listed brands are trademarks of the corresponding companies. Errors and omissions excepted, and subject to technical changes. Our general terms of delivery and payment are applied.
