Related Manuals for Panasonic KX-TGC210S
Summary of Contents for Panasonic KX-TGC210S
- Page 1 3(TGCA21) Up to 6 KX-TG433SK 1(TGC220) 3(TGCA21) Up to 6 KX-WP110 1(WP110) 1(WPA20) Up to 6 KX-WP120 1(WP120) 1(WPA20) Up to 6 KX-TGDA20 1(TGDA20) © Panasonic System Networks Co., Ltd. 2014 Unauthorized copying and distribution is a violation of law.
- Page 2 KX-TGC210S/KX-TGC212S/KX-TGC213S/KX-TGC220S/KX-TGC222S/KX-TG403SKS/KX-TG433SKS/ KX-TGCA20S/KX-TGCA21S/KX-TGDA20N/KX-WP110B/KX-WP120B/KX-WPA20B WARNING This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product. Products powered by electricity should be serviced or repaired only by experienced professional technicians.
-
Page 3: Table Of Contents
KX-TGC210S/KX-TGC212S/KX-TGC213S/KX-TGC220S/KX-TGC222S/KX-TG403SKS/KX-TG433SKS/ KX-TGCA20S/KX-TGCA21S/KX-TGDA20N/KX-WP110B/KX-WP120B/KX-WPA20B TABLE OF CONTENTS PAGE PAGE 1 Safety Precautions----------------------------------------------- 4 1.1. For Service Technicians --------------------------------- 4 2 Warning -------------------------------------------------------------- 4 2.1. Battery Caution--------------------------------------------- 4 2.2. About Lead Free Solder (PbF: Pb free)-------------- 4 2.2.1. Suggested PbF Solder ------------------------------ 5 2.3. -
Page 4: Safety Precautions
KX-TGC210S/KX-TGC212S/KX-TGC213S/KX-TGC220S/KX-TGC222S/KX-TG403SKS/KX-TG433SKS/ KX-TGCA20S/KX-TGCA21S/KX-TGDA20N/KX-WP110B/KX-WP120B/KX-WPA20B 1 Safety Precautions 1.1. For Service Technicians • Repair service shall be provided in accordance with repair technology information such as service manual so as to prevent fires, injury or electric shock, which can be caused by improper repair work. -
Page 5: Suggested Pbf Solder
KX-TGC210S/KX-TGC212S/KX-TGC213S/KX-TGC220S/KX-TGC222S/KX-TG403SKS/KX-TG433SKS/ KX-TGCA20S/KX-TGCA21S/KX-TGDA20N/KX-WP110B/KX-WP120B/KX-WPA20B 2.2.1. Suggested PbF Solder There are several types of PbF solder available commercially. While this product is manufactured using Tin, Silver, and Copper (Sn+Ag+Cu), you can also use Tin and Copper (Sn+Cu), or Tin, Zinc, and Bismuth (Sn+Zn+Bi). Please check the manufacturer's specific instructions for the melting points of their products and any precautions for using their product with other materials. -
Page 6: Specifications
KX-TGC210S/KX-TGC212S/KX-TGC213S/KX-TGC220S/KX-TGC222S/KX-TG403SKS/KX-TG433SKS/ KX-TGCA20S/KX-TGCA21S/KX-TGDA20N/KX-WP110B/KX-WP120B/KX-WPA20B 3 Specifications Standard: Bit rate: DECT 6.0 (Digital Enhanced Cordless 1,152 Mbit/s Telecommunications 6.0) Modulation: Number of channels: GFSK (Gaussian Frequency Shift Keying) 60 Duplex Channels RF transmission power: Frequency range: 115 mW (max.) 1.92 GHz to 1.93 GHz... -
Page 7: Location Of Controls And Components
KX-TGC210S/KX-TGC212S/KX-TGC213S/KX-TGC220S/KX-TGC222S/KX-TG403SKS/KX-TG433SKS/ KX-TGCA20S/KX-TGCA21S/KX-TGDA20N/KX-WP110B/KX-WP120B/KX-WPA20B 4 Location of Controls and Components Refer to the Operating Instructions. Note: You can download and refer to the Operating Instructions (Instruction book) on TSN Server. 5 Installation Instructions Refer to the Operating Instructions. Note: You can download and refer to the Operating Instructions (Instruction book) on TSN Server. -
Page 8: Schematic Diagram
KX-TGC210S/KX-TGC212S/KX-TGC213S/KX-TGC220S/KX-TGC222S/KX-TG403SKS/KX-TG433SKS/ KX-TGCA20S/KX-TGCA21S/KX-TGDA20N/KX-WP110B/KX-WP120B/KX-WPA20B 7 Schematic Diagram 7.1. For Schematic Diagram 7.1.1. Base Unit (Base Unit (Main)) Notes: 1. DC voltage measurements are taken with voltmeter from the negative voltage line. Important Safety Notice: Components identified by mark have special characteristics important for safety. - Page 9 KX-TGC210S/KX-TGC212S/KX-TGC213S/KX-TGC220S/KX-TGC222S/KX-TG403SKS/KX-TG433SKS/ KX-TGCA20S/KX-TGCA21S/KX-TGDA20N/KX-WP110B/KX-WP120B/KX-WPA20B Memo...
-
Page 10: Base Unit (Main)
KX-TGC210S/KX-TGC212S/KX-TGC213S/KX-TGC220S/KX-TGC222S/KX-TG403SKS/KX-TG433SKS/ KX-TGCA20S/KX-TGCA21S/KX-TGDA20N/KX-WP110B/KX-WP120B/KX-WPA20B 7.2. Base Unit (Main) 7.2.1. KX-TGC210/KX-WP110 RF Block ANT1 ANT- Pattern Wm=0.4mm ANT1_Short Lm=10mm C872 1.3p C895 C873 C871 ANT1_S-GND 1.5p SHORT1 SHORT W 0.2mm W 0.15mm L 3.8mm L 6.2mm 1st layer 1st layer W=0.3mm W=0.3mm W=0.3mm W=0.25... - Page 11 KX-TGC210S/KX-TGC212S/KX-TGC213S/KX-TGC220S/KX-TGC222S/KX-TG403SKS/KX-TG433SKS/ KX-TGCA20S/KX-TGCA21S/KX-TGDA20N/KX-WP110B/KX-WP120B/KX-WPA20B +3.0V Q141 R160 REFERENCE 1XX : TEL LINE 3XX : POWER, CHARGE 4XX : MIC, SP Q161 R141 5XX : BBIC 6XX : FLASH, EEPROM, KEY, LCD 100k 7XX : FOR DK/BT 8XX : RF C173 R177 R164...
-
Page 12: Kx-Tgc220/Kx-Wp120
KX-TGC210S/KX-TGC212S/KX-TGC213S/KX-TGC220S/KX-TGC222S/KX-TG403SKS/KX-TG433SKS/ KX-TGCA20S/KX-TGCA21S/KX-TGDA20N/KX-WP110B/KX-WP120B/KX-WPA20B 7.2.2. KX-TGC220/KX-WP120 RF Block ANT1 ANT- Pattern Wm=0.4mm ANT1_Short Lm=10mm C872 1.3p C895 C873 C871 ANT1_S-GND 1.5p SHORT1 SHORT W 0.2mm W 0.15mm L 3.8mm L 6.2mm 1st layer 1st layer W=0.3mm W=0.3mm W=0.3mm W=0.25 L=12.45mm L=6.95mm L=6.5mm... - Page 13 KX-TGC210S/KX-TGC212S/KX-TGC213S/KX-TGC220S/KX-TGC222S/KX-TG403SKS/KX-TG433SKS/ KX-TGCA20S/KX-TGCA21S/KX-TGDA20N/KX-WP110B/KX-WP120B/KX-WPA20B +3.0V Q141 R160 REFERENCE 1XX : TEL LINE 3XX : POWER, CHARGE 4XX : MIC, SP Q161 R141 5XX : BBIC 6XX : FLASH, EEPROM, KEY, LCD 100k 7XX : FOR DK/BT 8XX : RF C173 R177 R164...
-
Page 14: Base Unit (Operation)
KX-TGC210S/KX-TGC212S/KX-TGC213S/KX-TGC220S/KX-TGC222S/KX-TG403SKS/KX-TG433SKS/ KX-TGCA20S/KX-TGCA21S/KX-TGDA20N/KX-WP110B/KX-WP120B/KX-WPA20B 7.3. Base Unit (Operation) DOWN LED901 (ANS_LED) KEYIN2 LOCATOR KEYS_C KEYIN1 KEYS_E KEYIN3 KEYS_D ANSWER ANS_LED ERASE MSG_LED LED_VDD SKIP REPEAT LED902 (MSG_LED) NC: No Components KX-TGC220/KX-WP120 SCHEMATIC DIAGRAM (Base Unit_Operation) - Page 15 KX-TGC210S/KX-TGC212S/KX-TGC213S/KX-TGC220S/KX-TGC222S/KX-TG403SKS/KX-TG433SKS/ KX-TGCA20S/KX-TGCA21S/KX-TGDA20N/KX-WP110B/KX-WP120B/KX-WPA20B Memo...
-
Page 16: Handset (Main)
KX-TGC210S/KX-TGC212S/KX-TGC213S/KX-TGC220S/KX-TGC222S/KX-TG403SKS/KX-TG433SKS/ KX-TGCA20S/KX-TGCA21S/KX-TGDA20N/KX-WP110B/KX-WP120B/KX-WPA20B 7.4. Handset (Main) Charge Current VBAT VBAT F1 2.5A BATT+ K0.1u SOCp 6.3V BATT- 220u J39p SOCn To Battery SHORT * When "SFR" command is executed, 13.824MHz frequency will be output. K1000p CHG+ CHG+ R8 4.3 CP3V (3216) K0.1u... - Page 17 KX-TGC210S/KX-TGC212S/KX-TGC213S/KX-TGC220S/KX-TGC222S/KX-TG403SKS/KX-TG433SKS/ KX-TGCA20S/KX-TGCA21S/KX-TGDA20N/KX-WP110B/KX-WP120B/KX-WPA20B RF BLOCK *open-stub RX-balun SLx2 W1=0.2mm W=0.170mm L1=3.3mm L=3.6mm ANT-Short 50 ohm line W2=0.7mm W=0.25mm S=0.125mm L=2mm L=2mm L2=5.0mm ANT-Short-GND RF_RXn ANT1_TP RX_RF W=0.25mm L=2mm 50 ohm line RF_RXp SHORT Total L=4mm +1.8V W=0.3mm W=0.25mm W=0.3mm C859 L=6.95mm L=5mm L=6.5mm...
-
Page 18: Exploded View And Replacement Parts List
PNYNTGDA20NR LID, BATTERY ASS’Y (*5) ABS-HB Note: (*1) You can download and refer to the Operating Instructions (Instruction book) on TSN Server. (*2) For KX-TGC210S, KX-TGC212S, KX-TGC213S, KX-TGC220S, KX-TGC222S, KX-TG403SKS. (*3) For KX-TG433SKS. (*4) For KX-WP110B, KX-WP120B. (*5) For KX-TGDA20N. - Page 19 KX-TGC210S/KX-TGC212S/KX-TGC213S/KX-TGC220S/KX-TGC222S/KX-TG403SKS/KX-TG433SKS/ KX-TGCA20S/KX-TGCA21S/KX-TGDA20N/KX-WP110B/KX-WP120B/KX-WPA20B 3, 4, 5, 6 * ttached the Spacer to the exact location 13, 14, 15 describe below. 8, 9, Battery cover Spacer (No. 11, 12) Stick it between ribs. 11, 12(*)
- Page 20 KX-TGC210S/KX-TGC212S/KX-TGC213S/KX-TGC220S/KX-TGC222S/KX-TG403SKS/KX-TG433SKS/ KX-TGCA20S/KX-TGCA21S/KX-TGDA20N/KX-WP110B/KX-WP120B/KX-WPA20B KXTGC210S KXTGC212S KXTGC213S KXTGC220S KXTGC222S KXTG403SKS KXTG433SKS KXTGCA20S KXTGCA21S KXTGDA20N KXWP110B KXWP120B KXWPA20B...
