- Page 1 User Manual V1.0 User Manual -Installation -Operation OXYGEN 3400 OXYGEN 4500 OXYGEN 5000 SOLEOS solar GmbH...
-
Page 3: Table Of Contents
Catalog Notes on this Manual..........................3 Scope of Validation ..........................3 Symbols Used ............................3 Target Group ............................4 Preparation ..............................5 Safety Instructions ..........................5 Explanations of Symbols on Inverter ....................6 Product Information ..........................8 Overview .............................. 8 Major Characteristics ........................... - Page 4 Set Language............................. 36 Choosing Safety Regulation After Starting Up ................. 37 State Information ..........................39 Recycling and Disposal ......................... 40 Troubleshooting ............................. 41 10. Abbreviation ............................42 11. Contact ..............................43...
-
Page 5: Notes On This Manual
1. Notes on this Manual 1.1 Scope of Validation The main purpose of this User’s Manual is to provide instructions and detailed procedures for installing, operating, maintaining, and troubleshooting the following three types of SOLEOS solar GmbH-Solar Inverters: OXYGEN 3400 ... -
Page 6: Target Group
Chapter 1, 2, 3, 4, 7, 8, 9, 10 and chapter 11 are intended for anyone who is intended to use Soleos Grid Tie Solar Inverter. Before any further action, the operators must first read all safety regulations and be aware of the potential danger to operate high- voltage devices. -
Page 7: Preparation
Please contact your dealer to get the information of authorized repair facility for any maintenance or repairmen. Any unauthorized actions including modification of product functionality of any form will affect the validation of warranty service; Soleos may deny the obligation of warranty service accordingly. -
Page 8: Explanations Of Symbols On Inverter
NOTICE Public utility only The PV inverter designed to feed AC power directly into the public utility power grid，do not connect AC output of the device to any private AC equipment. CAUTION The PV inverter will become hot during operation; please don’t touch the heat sink or peripheral surface during or shortly after operation. - Page 9 Equipment with the CE mark fulfils the basic requirements of the Guideline Governing Low-Voltage and Electromagnetic Compatibility. No unauthorized perforations or modifications Any unauthorized perforations or modifications are strictly forbidden, if any defect or damage (device/person) is occurred, Soleos shall not take any responsibility for it.
-
Page 10: Product Information
3. Product Information 3.1 Overview Industrial Layout Excellent Heat Elimination... -
Page 11: Major Characteristics
Effective Shield For DC/AC/Communication Connections 3.2 Major Characteristics Soleos inverter has following characteristics which make Soleos inverter “High Efficiency, High Reliability, High Cost Effective Ratio” Wide DC input voltage and current range, enables more PV panels connected. Wide MPP voltage range ensure high yield under various weather conditions. -
Page 12: Datasheet
3.3 Datasheet OXYGEN 3400 OXYGEN 3400 Type Input (DC) Max. PV-generator power 3400 Max DC voltage max(DC) 120 – 500 MPPT DC voltage range mppt Turn off DC Voltage min(DC) Max. DC current max(DC) Nominal DC current N(DC) Number of DC connection... - Page 13 61000-6-4 EN61000-3-2, EN61000-3-3, EN61000-3-12, EN61000-3-11 Dimensions and weight Dimensions (WxHxD) [mm] 367x526x163 Weight [kg] Environmental limits IP protection type IP 65 according to IEC 60529 Operating temperature range -20° C to +60° C Relative humidity 0% to 98%, no condensation Maximum altitude (above sea level) 2000 Noise level...
- Page 14 AC Connector Plug-in connector Power consumption Own consumption in operation own(AC) Power consumption at night nig(AC) Power consumption at standby std(AC) Efficiency Max. Efficiency (at 360VDC) 97.6% Euro efficiency (at 360VDC) 97.0% MPPT efficiency 99.9% Safety and protection Internal overvoltage protection DC Insulation monitoring Earth fault protection According to VDE 0126-1-1, RD1663, ENEL2010,C10/11,...
- Page 15 OXYGEN 5000 Type OXYGEN 5000 Input (DC) Max. PV-generator power 5000 Max DC voltage max(DC) 120 – 500 MPPT DC voltage range mppt Turn off DC Voltage min(DC) Max. DC current max(DC) Nominal DC current N(DC) Number of DC connection DC-connection Number of MPP trackers Turn on power...
- Page 16 61000-6-4 EN61000-3-2, EN61000-3-3, EN61000-3-12, EN61000-3-11 Dimensions and weight Dimensions (WxHxD) [mm] 367x526x163 Weight [kg] Environmental limits IP protection type IP 65 according to IEC 60529 Operating temperature range -20° C to +60° C Relative humidity 0% to 98%, no condensation Maximum altitude (above sea level) 2000 Noise level...
-
Page 17: Packing Checklist
4. Packing Checklist 4.1 Assembly Parts After you receive the Soleos inverter, please check if there is any damage on the carton, and then check the inside completeness for any visible external damage on the inverter or any accessories. Contact your dealer if anything is damaged or missing. -
Page 18: Product Appearance
4.2 Product Appearance Front Object Description Removable front shield LED light(Green) – RUN LED light(Red) – FAULT LED light(Yellow) – COM Function key for displays and choice of language Monitoring LCD with backlighting Bottom... -
Page 19: Product Identification
The name plate is on the middle part of the right side of the inverter housing. And the following figure is the side name plate example as on OXYGEN 3400. 4.4 Further Information... -
Page 20: Installation
5. Installation 5.1 Safety DANGER DANGER to life due to potential fire or electricity shock. DO NOT install the inverter near any inflammable or explosive items. This inverter will be directly connected with HIGH VOLTAGE power generation device, the installation must be performed by qualified personnel only in compliance with national and local standards and regulations. -
Page 21: Safety Clearance
Soleos inverter is designed for indoors and outdoors installation Please mount the inverter in the direction as illustrated above Install the inverter in the vertical direction is recommended, with a max.15 degrees backwards. For the convenience of checking the LCD display and possible maintenance activities, please install the inverter at eye level. -
Page 22: Mounting Procedure
Direction Minimum clearance Above 30 cm Below 30 cm Sides 10 cm Mounting Procedure 1) Mark 4 positions of the drill holes on the wall according to the wall mounting bracket in the carton box. （ Depth 50mm ） 2) According to the marks, drill 4 holes in the wall. Then, place four expansion tubes in the holes using a rubber hammer. - Page 23 3) Check the 4 holes in the backside of the inverter. Then, lift the inverter carefully, align the 4 holes in the inverter and the 4 hooks on the bracket, and finally attach the inverter to the hooks slightly.
-
Page 24: Safety Lock （With The Wall Mounting Bracket
5.5 Safety lock （with the wall mounting bracket） After the inverter is hang up on the bracket, lock up the device and the bracket together at the Lower Right Corner of the inverter (as the picture showed below). Padlock... -
Page 25: Electrical Connection
Recommended padlock dimension: A A. Shackle Diameter 5~7 mm B．Vertical Clearance 8~15 mm C．Horizontal Clearance 12~20 mm Stainless, solid hanger and secured lock cylinder NOTICE For further maintenance and possible repair, please keep the key of the padlock in a safe place. 6. -
Page 26: Overview Of Connection Area
NOTICE Electrical connections shall be carried out in accordance with the applicable regulations, such as conductor sections, fuses, PE connection. 6.2 Overview of Connection Area Object Description Plug connectors for DC input. RS232/RS485 interface Terminal for grid connection (AC output) -
Page 27: Ac Side Connection
DANGER to life due to potential fire or electricity shock. NEVER connect or disconnect the connectors under load. 1) Integrated RCD and RCM The Soleos inverter is equipped with integrated RCD (Residual Current Protective Device) and RCM Residual Current Operated Monitor). The current sensor will detect the volume of the leakage current and compare it with the pre-set value, if the leakage current exceeds the permitted range, the RCD will disconnect the inverter from the AC load. - Page 28 c. Pass the cable through each component from left to the right as follows. d. Use a screw driver and loose the three screws at the side of the straight plug. Then insert the stripped N, L and PE cable accordingly to the corresponding position and fully tighten the screws.
-
Page 29: Dc Side Connection
Inverter, and it can be used to connect or disconnect the DC source from Inverter. For OXYGEN 3400, OXYGEN 4500 and OXYGEN 5000, there are two MPP Trackers, and the DC characteristics of them are illustrated as the following table. - Page 30 Unplugging under load: PV plug connections must not be unplugged while under load. They can be placed in a no load state by switching off the DC/AC converter or breaking the DC circuit interrupter. Plugging and unplugging while under voltage is permitted.
- Page 31 (ill.2) Interchangeable crimping inserts incl. hexagonal screwdriver A/F 2,5. Type: PV-ES-CZM-18100 PV-ES-CZM-19100 (ill.3) Open-end spanner PV-MS 1 set = 2 pieces Order No. 32.6024 (ill.4) PV-WZ-AD/GWD socket wrench insert to tighten, Order No. 32.6006 (ill.5) PV-SSE-AD4 socket wrench insert to secure PV-SSE-AD4, Order No. 32.6026 (ill.6) Open-end spanner A/F 15 mm (ill.7) Torque screwdriver A/F 12 mm...
- Page 32 Cable preparation (ill.9) Important: Cables with class 2, 5 or 6 construction can be connected. It is advantageous to use tinned conductors. It is unadvisable to use non-tinned cables of type H07RN-F, since with oxidised copper wires the contact resistances of the crimp connection may exceed the permitted limits.
- Page 33 Assembly control (ill.13) Insert the test pin with the corresponding side into the socket or plug to the end position. If the contact is correctly assembled, the white marking on the test pin must be still visible. (ill.14) Screw on the cable gland, hand- tight, with the tools PV-MS.
-
Page 34: Communication And Monitoring Device
Refer to cable manufactures specification for minimum bending radius. 6.5 Communication and Monitoring Device There are 2 plugs in the bottom side of the Soleos inverter as the following figure: These 2 plugs are used for multipoint communications, that is, up to 50 Soleos inverters can... -
Page 35: Display
In addition, the user can press the function key to illuminate the LCD screen. NOTICE Soleos inverter is not an aligned measuring instrument for current, voltage or power co nsumption. A slight deviation of a few percent points is intrinsic to the system;... -
Page 36: Lcd Display
7.2 LCD Display NOTICE Make sure the DC switch (Optional) is switched to “On” position, otherwise the inverter cannot work due to power shortage. The display content consists of 2 lines. The bottom line (Line 2) always displays the output power (Pac = xxxx W). - Page 37 State information Pac = xxxx W E-today Pac = xxxx W E-total Pac = xxxx W Pac = xxxx W Pac = xxxx W Pac = xxxx W Frequency Pac = xxxx W Model Pac = xxxx W Pac = xxxx W Set language Pac = xxxx W Pac = xxxx W...
-
Page 38: Set Language
0.0.0.0) 7.3 Set Language The Soleos inverter provides several languages for users to use. At the entry of “Set Language”, press the key for approx. 5 seconds, you can enter the language selection menu. Choose the language which you need with the function key, and keep this state without any... -
Page 39: Choosing Safety Regulation After Starting Up
7.4 Choosing Safety Regulation After Starting Up Attentions before the operation Only perform this operation when the voltage value displayed on Soleos inverter’s LCD falls between 150V and 450V for 1.5kW/2.0kW inverters or between 150V and 550V for 3.0kW/4.0kW/5.0kW inverters. - Page 40 c. When the LCD displays your desired Safety Standard, hold the Function button for 5 seconds or more until it shows ”Safety Standard OK”. d. The Safety Standard setup is now completed.
-
Page 41: State Information
7.5 State Information State Display State information Waiting Initialization & waiting Wait Reconnect s Reconnect Checking s Checking Normal Normal Normal state Ground I Fault GFCI failure oversized leakage current Fac Failure Grid frequency failure Vac Failure Grid voltage failure Utility Loss No Utility&Island PV Over Voltage... -
Page 42: Recycling And Disposal
8. Recycling and Disposal To comply with European Directive 2002/96/EC on waste Electrical and Electronic Equipment and its implementation as national law, electrical equipment that has reached the end of its life must be collected separately and returned to an approved recycling facility. Any device that you no longer required must be returned to your dealer or you must find an approved collection and recycling facility in your area. -
Page 43: Troubleshooting
2. Find a way to reduce the ambient temperature. 3. Or move the inverter to a cooler environment. 1. Check the open PV voltage, see if it is greater than or too close to 590VDC (for OXYGEN 3400 or OXYGEN PV over Voltage 4500 or OXYGEN 5000). -
Page 44: Abbreviation
10. Abbreviation Liquid Crystal Display Light Emitting Diode MPPT Maximum Power Point Tracking Photovoltaic Voltage at the DC side Voltage at the AC side Vmpp Voltage at the Maximum Power Point Impp Amperage at Maximum Power Point Alternating Current ( Form of electricity supplied by Utility Company ) Direct Current ( Form of electricity generated by PV modules ) German... -
Page 45: Contact
Device model Data collector serial number The number of connected inverter SOLEOS solar GmbH Add: Lise-Meitner-Strasse 8 D-53332 Bornheim, Germany Tel: +49 2227 92 91 0 Fax: +49 2227 92 91 22 Mail: info@soleos-solar.de...
