Table of Contents

Need help?

Do you have a question about the KE-5500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kronen KE-5500

Page 1: Juice Extractor
Juice extractor KE-5500 Type: Translation of the Original Instruction Manual English...
Page 2: Instruction Manual Ke
Instruction Manual KE-5500 Instruction Manual KE-5500 Version: 1.1 Date of release: 14.09.2012...
Page 3: Table Of Contents
Instruction Manual KE-5500 Contents General Information ..................... 4 Safety ........................... 8 Technical Characteristics ................... 10 Installation and Function .................... 11 Transportation and Packaging ................... 16 Installation and Initial Operation ................17 Use and Operating ..................... 18 Malfunctions ......................25 Maintenance ......................27 10.
Page 4: General Information
Instruction Manual KE-5500 1. General Information Always keep the instruction manual and all the other documents near the juice extractor. Before using the machine the first time, make sure that you read the instruction manual first. Explanation of the symbols used in the documents Attention, you have to follow the instructions to avoid harm for you and the machine.
Page 5 Instruction Manual KE-5500 Defects and Claims 1. Claims based on material defects shall be subject to a limitation period of 2 years after surrender of the merchandise. The Seller does not assume any liability for material defects in pre-owned merchandise.
Page 6 Kronen Küchengeräte GmbH 4. Kronen Küchengeräte GmbH restricts the terms and conditions of warranty for appliances which are intended for sale abroad. In such cases, Kronen Küch- gengeräte GmbH grants a warranty covering the original Küchengeräte GmbH spare parts. This warranty covers the functional capability of the spare parts, provided that they are installed correctly.
Page 7 Instruction Manual KE-5500 6. Kronen Küchengeräte GmbH grants a function warranty of 6 months for each and every original Kronen Küchengeräte spare part, provided that it has been installed correctly. Kronen Küchengeräte GmbH shall provide an original part in the event of failure. No further claims, including claims for the cost of the re- placement, can be acknowledged.
Page 8: Safety
Instruction Manual KE-5500 Safety General Sources of Danger Wrongful use or limited knowledge of the safety instruc- tions could result in accidents and injuries on hands and fingers. That is why, we advise you to respect and follow the safety instructions.
Page 9 Instruction Manual KE-5500 Intended Use The Juice extractor is a technical tool which exclusively should be used for its’ intended purpose. Juice extractor can only be used for juicing vegetables or fruits. For example: carrots, potatoes, beets (raw), celery, pineapple (without drink), apples, pears, etc.
Page 10: Technical Characteristics
Instruction Manual KE-5500 Technical Characteristics Weight: 22 kg Dimensions: 270 x 415 x 580 mm Connected load: Line voltage 230-240 V Mains frequency 48-62 Hz Electricity 4.5 A Operating conditions: Temperature 10°C till +40°C Humidity max. 90% (no conden- sation water)
Page 11: Installation And Function
Instruction Manual KE-5500 Installation and Function Accordance with the mounted machine parts the juice extractor juices fruit and vegetables. These are placed in this collecting bowl. The juice comes from the juice outlet. The marc, produced during the processing, passes through the chute at the GN- container.
Page 12 Instruction Manual KE-5500 Parts and Description  Body (1): Built out of stainless steel; fundamental base for the vegeta- ble juice extractor.  Lid (2): The removable lid makes sure that there is no unintended con- tact with the inside of the collecting bowl. In the lid there is a chute.
Page 13 Instruction Manual KE-5500 Assembled Parts Body Round Plunger Lever Centrifugal basket Collecting bowl Intermediate ring Marc chute GN-container Box spanner...
Page 14 Instruction Manual KE-5500 Operating Elements The juice extractor has one push button (11) to start the extractor. By pressing the push button (11) the engine will be started and with another press on the button the engine will be stopped.
Page 15 Instruction Manual KE-5500 Accessories Lengthen Marc chute Mounting chute for table installation...
Page 16: Transportation And Packaging
Instruction Manual KE-5500 Transportation and Packaging Always transport the juice extractor in the intended box. Always transport the machine upright and make sure juice extractor is secured. In case there is more than one juice extractor on the pallet do not put another pallet on top of it.
Page 17: Installation And Initial Operation
Instruction Manual KE-5500 Installation and Initial Operation The juice extractor is shipped ready for use. The installation and the initial oper- ation can be done by the user. The table has to fulfill certain requirements: Horizontal and flat Not slippery...
Page 18: Use And Operating
Instruction Manual KE-5500 Use and Operating Safety instruction for operating the slicer It is strictly prohibited to put your fingers in the marc chut or in the opening in the lid while the machine is running. The risk of injury is too high.
Page 19 Instruction Manual KE-5500 Emergency Turn Off In case of emergency you have to push the push button (11) or rotate away the lever (4) to turn off the engine. When rotating away of the lever (4) while the engine is running, the power supply is interrupted and the built-in braking device stops centrifugal basket within seconds.
Page 20 Instruction Manual KE-5500 Removing of the centrifugal basket and the collecting bowl Release the lid (2) with the lever (4) and take it from the intermedi- ate ring (7). To remove the centrif- ugal basket (5) you have loose the screw in the centrifugal basket it by using the box spanner (10).
Page 21 Instruction Manual KE-5500 Removal of the marc chute For cleaning or to remove blockage the marc chute (9) can be removed. For this loosen the star knob (13) and re- move the marc chute (9) from the outlet of the intermediate ring.
Page 22 Instruction Manual KE-5500 Installation of the mounting chute For installation in the work table, place the mounting chute (15) in the opening in the work table. Then put the marc chute (8) into the mounting chute (15) and put the marc chute (8) over the outlet of the intermediate ring and fasten it with the star knob (13) firmly.
Page 23 Instruction Manual KE-5500 Cleaning Before you use the juice extractor the first time make sure you clean it thor- oughly. Also, clean the machine multiple times during the day after use. Always use standard cleansers for cleaning the juicer. The juice extractor is only protected against splash water.
Page 24 Instruction Manual KE-5500 While processing vegetables, especially carrots, a layer is formed which gradu- ally clogs the sieve if left and heavily impairs the working of the juice extractor less juice. Therefore, it is necessary to soak the centrifugal basket in a normal, diluted washing up liquid for dishes for an hour or two at least once a week and clean it with a brush.
Page 25: Malfunctions
Instruction Manual KE-5500 8. Malfunctions Safety instructions In case of unfamiliar noises or decreasing power turn of the machine immediately. In case of blockage turn of the juice extractor and unplug the juice extractor from the outlet. After doing this you can try to remove the blocking material.
Page 26 Instruction Manual KE-5500 Error Correction Error Solution The appliance doesn‘t - Make sure the mains cable is plugged into a wall socket - The safety clasp is properly closed - Press the appliance switch off and press again - Check the fuse in the applicable building electrical circuit - see chapter „Safety features and protection“...
Page 27: Maintenance
Instruction Manual KE-5500 Maintenance Safety Instructions Maintenance, if not specifically mentioned, is not to be done by the user. Maintenance is done by customer ser- vice only. Maintenance Schedule Once a week, the user needs to check all safety devices.
Page 28 Instruction Manual KE-5500 Advice for vital function devices The replacement of vital function devices is only be made by your customer service. These include:  circuit board  switch to lock the lid Support / Customer Service / Hotline Sales Department and customer service: Kronen Küchengeräte GmbH...
Page 29: Appendix
Manufacturer : KRONEN Küchengeräte GmbH Gewerbestraße 3 D-77731 Willstätt declares that the following product: Product name: Juice extractor KE-5500 Serial Number: ________________________ conform with the guideline mentioned on top - including the changes of the statement at this point of time.
Page 30: Index
Instruction Manual KE-5500 Index Accessories ...................... 15 Centrifugal basket ................13, 19, 20 Cleaning ......................23 Collecting bowl ....................20 Collection bowl ....................19 Connected load ....................10 Customer service ..................... 28 Declaration of Conformity ................. 29 Defects and Claims .................... 5 Disposal ......................
