AutoCommand 40026 Installation Manual

DesignTech International, Inc. • 7955 Cameron Brown Court • Springfield, Virginia 22153 USA • www.designtech-intl.com • 703-866-2000 or 800-337-4468
Congratulations on your purchase of the AutoCommand
control from the comfort of your home or office in order to cool it down in the summer or heat it up in the winter.
AutoCommand ® is for automatic transmission / fuel injected gasoline vehicles only. Please see pages 6-7 for important information about vehicles with
factory anti-theft systems. AutoCommand
• Will start your car by remote control, and run the heater, defroster,
or air conditioner to warm up or cool down the car.
• Is designed to start the car if it is in park, and only if the
hood is closed.
• Will attempt to start the car for up to six seconds, but no
longer (to avoid damage to the starter motor). Should the
car not start, or if it stalls after starting, the remote starter
will make two further attempts to start it.
• Will not let the car be driven without the key in the ignition.
Tools required to install the AutoCommand
Wire Cutters/Strippers
Soldering Iron
Pliers
Testmeter
We highly recommend that all connections be soldered for reliability.
Parts List included with the AutoCommand
Remote Starter Receiver Module
Transmitter
Antenna
Control Harness (6 position)
6 Power & Ignition Wires
Yellow Headlight Wire
The following parts are included in the plastic bag:
Alcohol Pad Alchohol
Pad
Green 30 A Fuse
On/Off Control Switch
Warning Label
WARNING
This car is equipped with a remote control starting device.
Disable before working on car!
AVERTISSEMENT
Co véhicule est équipé d'un systéme de démarrage á distance. Mettez-le hors
fonctuin avant d'eflectuer toule opération d'entretian ou de répanation!
2 Protected by
DesignTech Labels
Remote Car Starter Installation Manual for Model 40026
PLEASE READ COMPLETELY BEFORE BEGINNING
®
Remote Car Starter. AutoCommand
®
is an extremely sophisticated system with multiple built-in safety and security features.
AutoCommand
®
Unit:
Electrical Tape
Screwdriver
Drill with
1 / "and
4
drill bits
®
Unit:
Ring Terminal
Hood Pin Switch Set
2 Cable Ties
Yellow Butt Connector
®
Remote Car Starter allows you to start the car by remote
®
Remote Car Starter:
• Shuts itself off automatically after 10 or 15 minutes (pro-
grammable) if you forget to come out to your car.
• Will shut off if the brake pedal is pushed, the hood is opened, or
the transmission is shifted out of park - unless the key is in the
ignition and in the "run" position.
• Is quality engineered, microprocessor controlled, and made
in the USA to provide many years of reliable use.
• Comes with a Limited 2-Year Warranty.
Power Harness
5 / "
16
ON/OFF Switch Jack
Control Harness
C o l o r F u n c t i o n
Green Tach
Brown/White Alarm Disarm
W
hite/Black IGN 3
Color Function Circuit Type
Purple Hood Switch (-) Input
Orange Brake (+)
B l u e Horn (-) 400mA Output
*For free vehicle-specific wire information consult our website at
w w w . d e s i g n t e c h - i n t l . c o m
1

Wiring Diagram

Circuit
Color Function Type
Pink Power (+12V) Input
White Accessory Relay output
Yellow Starter Relay output
Blue Ignition 1 Relay output
Green Ignition 2 Relay output
Black Ground Input
Small Yellow HeaLights Relayoutput
Coax
Antenna Jack
Circuit Type R e q u i r e d
(-) Input No
(–) 400 mA Output Consult Wiring Guide*
(–) 400 mA Output Consult Wiring Guide*
Required
Yes
Input Yes
No
Required
Yes
Yes
Yes
Yes
Consult Wiring Guide *
Yes
Optional
