Installation Instructions
Ultra-Violet Air Purifier Residential/Commercial Duct
Installation Applications -
SAFETY CONSIDERATIONS
Installation and servicing of air-conditioning equipment
can be hazardous due to system pressure and electri-
cal components. Only trained and qualified service per-
sonnel should install, repair, or service air-conditioning
equipment.
Untrained personnel can perform basic maintenance
functions such as changing lamps. All other operations
should be performed by trained service personnel.
When working on air-conditioning equipment, observe
precautions in the literature, tags and labels attached to the
unit or accessory, and other safety precautions that may
apply.
Follow all safety codes. Wear safety glasses and work gloves.
WARNING:
Before installing the RX4000, RX4000B, RX1700
or performing maintenance or service on the
purifier, turn off main power switch to unit.
Electrical shock can cause injury or death. There
may be more than one disconnect switch.
WARNING:
Never expose eyes or skin to ultraviolet
light from any source. The Purifier MUST be
DISCONNECTED from power source before
performing maintenance or service. Personal
injury may result.
WARNING:
Do not touch Lamp glass without gloves. Reduced
performance of Lamp may result. Clean Lamp
after handling.
WARNING:
The UV Lamp contains a small quantity of
mercury. If a Lamp breaks, clean and dispose of
with care.
RX4000, RX4000B, RX1700
WARNING:
Use only specified replacement Lamps with your
Purifier. Use of an incorrect Lamp can result in
damage to the Purifier an/or Lamp.
GENERAL
The Maytag HVAC RX4000, RX4000B and the RX1700
residential ultra-violet air purifiers are designed to kill bacteria,
viruses, odor causing mold and fungus as well as chemical
odors and VOC's that may be transmitted through the air
ducts of the HVAC equipment. The purifiers are installed
in the return (preferred) or supply air plenum of the HVAC
equipment. The ultra-violet band light inhibits and kills mold,
fungus, bacteria, viruses and microbial growth on 100% of the
air flowing through the 6" square aluminum tube.
Location
The preferred installation location for the purifier is in the re-
turn duct as the air will be treated before the filter and HVAC
coil. If it is not possible to install in the return duct, it may be in-
stalled in the supply duct. The painted steel power supply
Control Panel section of the purifier is installed on the outside
of the duct.
Make sure site can be supplied with the necessary power
requirements. The RX4000 and RX4000B have a power
consumption of 35 watts, the RX1700 26 watts, and require
a 110/220 v, 50-60 Hz power source. Insure that there is
adequate clearance for service. If a humidifier is present, the
air purifier should be installed in the air stream before the
humidifier and the humidifier must be protected from UV
rays.
NOTE: The Ballast for ALL models has been factory set at 110
Volts. If the power source is 220 Volt, the switch on the ballast
must be changed to the 220 volt position, and the plug at the
end of the wire set (RX4000) fit with a 110/220 volt adapter,
or cut off and wired into the 220 volt circuit.
The operating temperature range is 40 to 150 F. Operating
the models outside this range will result in decreased
performance.
NOTE: The purifiers are NOT waterproof. If installing outdoors,
the purifiers must be installed in a watertight enclosure.
