Summary of Contents for Fluid FLDC2801
-
Page 1: Instruction Manual
8009640C 28" LED Combo Television/DVD Player FLDC2801 Instruction Manual Read all of the instructions before using this TV and keep the manual in a safe place for future reference. -
Page 2: Important Safety Instructions
Important Safety Instructions • Read these instructions – All the safety and operating instructions should be read before this product is operated. • Keep these instructions – The safety and operating instructions should be retained for future reference. • Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to. •... -
Page 3: Table Of Contents
Contents Important Safety Instructions ..........2 Safety Information . -
Page 4: Safety Information
Safety Information To ensure reliable and safe operation of this equipment, please read carefully all the instructions in this user guide, especially the safety information below. Electrical safety • The TV set should only be connected to a main power supply with voltage that matches the label at the rear of the product. -
Page 5: What's Included
TV Set Remote Control with Batteries 8009640C 8009640C 28" LED Combo Television/DVD Player FLDC2801 TP4X12A-HO Instruction Manual Read all of the instructions before using this TV and keep the manual in a safe place for future reference. User's Manual Initial Assembly... -
Page 6: Getting Started
Getting Started Front/Side View Button Functions POWER : Turns on/standby the TV set 2. SOURCE : Displays the input source menu 3. MENU : Displays the OSD menu. Press again to exit the menu 4. CH +/- : Scans through channels 5. -
Page 7: Rear View
Getting Started Rear View Headphone output HDMI inputs VGA input 4. PC audio input Antenna input (75 Ohm VHF/UHF) Component and audio input terminal Optical output Service Port Wall Mounting The TV is provided with mounting holes for a VESA approved wall mounting bracket (NOT SUPPLIED). -
Page 8: Connecting To External Devices
Connecting to External Devices... -
Page 9: Remote Control Button Functions
Remote Control Button Functions Mute button Power button Numeric buttons Channel setup/DVD 10+ button Return channel/DVD SUBTITLE Sound mode button MTS/AUDIO button Picture mode button SLEEP button Signal SOURCE selection button Information button Channel selection buttons Volume adjust buttons EPG/GOTO button AUTO/A-B button FREEZE/REPEAT button ASPECT button... -
Page 10: Remote Control Button Functions
Remote Control Button Functions Button DVD Functions TV Functions Position POWER: Power on/off button, press once to turn TV on and press again to turn TV off. 0, 1-9: TV channel selection button. — : Press this button to enter a program number for multiple program channels such as 2-1, etc. - Page 11 Button DVD Functions TV Functions Position Previous channel button, return to the SUBTITLE: (for DVD and Super VCD discs) previous channel watched. -Press the SUBTITLE button once to display the current subtitle. -Press again to toggle between different subtitle modes in sequence. Note: For Multi-language or subtitle DVD and Super VCD discs, press SUBTITLE button to select your desired subtitle...
-
Page 12: Operating Your Television
Operating Your Television Basic Operations Turning Your TV On and Off TURN ON TV 1. Connect to power with the main power cable. The TV will enter STANDBY mode and the LED indicator light will be red. 2. From the STANDBY mode, use the POWER button either on the main unit or on the remote, to turn the television on. -
Page 13: Navigating The Onscreen Display
Operating Your Television Navigating the Onscreen Display • Press the MENU button to display the main menu. • Use the buttons to navigate and select the available menus. Choosing a TV Channel CH+/CH- 1. Use the buttons on the side panel or CH+/CH- on the remote control. •... -
Page 14: Selecting Input Source
Operating Your Television Selecting Input Source SOURCE Display the input screen menu by pressing on the remote control SOURCE on the side of the TV. Press the button to select your choice, ” to enter using the remote, or press VOL+ directly on then press “... -
Page 15: Audio Menu Options
Operating Your Television Audio Menu Options MENU Press on the main unit or on the AUDIO remote control then use to select the menu. Press to enter (see picture). Sound Mode Press then use to select User, Standard, Music, Movie and Sports. -
Page 16: Setup Menu Options
Operating Your Television Setup Menu Options MENU Press on the side panel or MENU on the remote control, then use to select the SETUP menu. Press to enter (see picture). Menu Language Press then use to select menu language for either English, Français or Español. -
Page 17: Lock Menu Options
Operating Your Television Lock Menu Options Menu Press on the side panel or MENU on the remote control, then use to select the LOCK menu. Press d button to enter. Use the button to go to the “Enter Password” selection and use the numeric buttons to input a 4-digit password. -
Page 18: Channel Menu Options
Operating Your Television Channel Menu Options MENU Press on the side of the TV or remote control, then use to select the CHANNEL menu. Press to enter. Air/Cable Allows you to select the input signal between Air and Cable. If you select “Air” as the input signal in the “Antenna” option press the button to search the channels automatically. -
Page 19: Parental Menu Options
Parental Menu Options Parental Control Press Enter to enter the sub-menu and then use the 0-9 to enter the correct password: 0,0,0,0. If used, this option feature can “block” undesirable programming from appearing on the TV. Parental Control offers the user a wide variety of options and settings that restrict or “block”... -
Page 20: Dvd Operation
DVD Operation Preparation before playing disc • The display language is set to English. Please refer to setup operation. • Most functions are operated by the remote control or use the buttons on the front panel. Preparation • Turn the TV on and select DVD as the TV input. •... - Page 21 DVD Operation • STOP Press STOP button to stop playing (TV show “ , ”). When playback is stopped the unit memorizes the point where STOP was pressed (resume function). Press PLAY again, and play will resume again at this point.
- Page 22 DVD Operation • GO TO During play, press the GO TO button on the remote control. You can search the disc based on its title/ chapter/track. Press the GO TO button and a search menu will be displayed. Use the button to select the search item/time/title/chapter.
-
Page 23: Dvd Functions
DVD Functions Supported DVD Format 1. PLAY (for DVD/Super VCD/VCD/CD/CD-G/HD-CD and MP3/JPEG discs). For DVD disc, press the II button from the root or title menu. While playing the DVD, play a favourite title directly by the title TITLE selection by pressing the button. - Page 24 DVD Functions Supported DVD Format For DVD discs with 5 pages, press INFO button once to display the first page as shown below: Once Twice Three times Four times Title Elapsed Title Remain Chapter Elapsed Chapter Remain TT: 01/08 CH:01/01 TT: 01/08 CH:01/01 TT: 01/08 CH:01/01 TT: 01/08 CH:01/01...
-
Page 25: Mp3/Jpeg Playback
DVD Functions MP3 / JPEG Playback After loading the MP3/JPEG disc, it will start to scan for the stored MP3/JPEG folders. The folder will display the MP3 contents automatically and start to play the first file (highlighted file). Screen will show as below: MP3 File JPEG File... -
Page 26: Using The Built-In Dvd Player
DVD Functions Using the Built-in DVD Player Compatible Disc Types 1. Press the SOURCE button on the remote control to display the source list. Use the buttons to select DVD and then press the OK button to confirm. 2. Insert a disc with the label side facing towards the rear of the TV. -
Page 27: Basic Dvd Playback Functions
DVD Functions Basic DVD Playback Functions • Press the button to play the next Title/ Playing the DVD Chapter/Track. Depending on the disc, a menu may appear on If the current track is the first one, the TV screen once the disc has loaded. When pressing the button will restart the disc from the beginning.If the current... - Page 28 DVD Functions Basic DVD Playback Functions • Press the INFO button four times to display the fourth page as shown below: Repeat (for DVD/CD/Multimedia discs) Chapter Remain Press the REPEAT button once to display the current 1TT: 01/08 CH:01/01 repeat mode. 0:04:4 •...
-
Page 29: Playing Multimedia Discs
DVD Functions Playing Multimedia Discs Using the DVD Language Setup Page Menu After loading the multimedia disc, the disc contents will automatically be displayed and sorted by DISC MENU: Select the Disc Menu language. different file formats into Music/Picture/Video folders. The default language is English. -
Page 30: Using The Dvd Language Setup Page
DVD Functions Using the DVD Language Setup Page Using the DVD Screen Setup Page Encoding • 4:3 Letter box Wide screen picture shown in the full screen Select the encoding subtitle between Western with black bars on the top and bottom of the European and Central European. -
Page 31: Using The Dvd Audio Setup Page
DVD Functions TV System Contrast In order for the disc to play, the colour system of the Select the contrast of the screen in DVD mode. DVD player disc and TV should match. • NTSC: This format is used by some other countries, e.g. USA. -
Page 32: Using The Dvd Custom Setup Page
DVD Functions Using the DVD Custom Setup Page If you forget your DVD password, enter the master password “8899”. In the DVD mode, press the DVD.SETUP button on the remote control. Press the buttons to select the Custom Setup menu, and then press the buttons to select the menu options. -
Page 33: Troubleshooting
Troubleshooting If your television does not operate normally or does not turn on, please check the following troubleshooting questions. Remember to also check the other connected electronic devices, such as DVDs or Blu-ray players to pinpoint any problem. If the television still fails to operate normally, please contact Customer Service (refer to Warranty page). - Page 34 Troubleshooting Check the chart below for a possible cause of the problem you are experiencing before requesting service for this unit. Some simple checks or minor adjustments on your part may eliminate the problem and restore proper operation. Keep away from static electricity. PROBLEM POSSIBLE SOLUTION No Power...
-
Page 35: Troubleshooting
Troubleshooting NOTE : When there is a problem in VGA mode (only when VGA mode is applied) PROBLEM POSSIBLE SOLUTION The signal is out of range - Adjust resolution, horizontal frequency, or vertical frequency - Check whether the signal cable is connected or loose - Check the input source Vertical bar or stripe on background, horizontal noise and Set the auto configure or adjust clock, phase or H/V... -
Page 36: Specifications
Specifications Panel Size 27.5 inches diagonally Display Type Panel Technology Panel 60 Hz vs 120 Hz 60 Hz Display Resolution 720P HD Compatible up to 1080p Panel Resolution (min.) 1366*768 TV Demodulator Air/Cable Aspect Ratio 16:9 Contrast Ratio (Typ.) - panel 3000:1 Brightness (Centre Typ.) cd/m2 Response Time (G to G)
