Sector Alarm Domonial User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual
Domonial

Advertisement

Table of Contents
loading

Related Manuals for Sector Alarm Domonial

Summary of Contents for Sector Alarm Domonial

  • Page 1 User Manual Domonial...
  • Page 2 ID badges with photographs to prove that they work about using the system. for Sector Alarm AS. We hope you will have the pleasure of using your alarm system for many years to come and that it...

  • Page 3: Table Of Contents

    Contents Presentation of the alarm system How to use the keypad How to use the remote control P.12 How the detectors work* P.14 Maintenance and recommendations P.16 Notes P.17 * Your system may include one or more control units and/or one or more detectors.

  • Page 4: Presentation Of The Alarm System

    Presentation of the alarm system The Domonial control panel is the brain of your alarm system. It exchanges information with the wireless components that are connected. The control panel collects data that is sent by the detectors, registers arming and disarming and communicates with Sector Alarm AS.

  • Page 5: How To Use The Keypad

    How to use the keypad and tag This keypad is used to arm and disarm the alarm system using a valid code or the tag. It is equipped with a tag reader in addition to keypad entry and has an integral siren.
  • Page 6 ACTIVATION USING YOUR CODE OR TAG  Press an activation button on the keypad and enter the code, or present a registered tag 4 figure code/tag ---------------------------------------------- Arms the entire system (Away) 4 figure code/tag --------------------------------------------- Arms part of system (Home) 4 figure code/tag ------------------------------------ Arms Annex...
  • Page 7 If the system is disarmed, the sirens are also disarmed if an alarm is triggered. EVEN IF THE SIREN IS TURNED OFF, THIS DOES NOT STOP THE TRANSMISSION OF THE ALARM TO SECTOR ALARM AS. NOTE:  Always ensure that disarming is followed by the disarmed tone.
  • Page 8 Exit programming mode.  A double beep sounds and LEDs 1, 2, 3 and 4 start blinking. The keypad can have up to 10 users configured. To add, remove or configure users, please contact Sector Alarm Exit programming mode:  Press twice.
  • Page 9 There is a fault in the system. Faults include battery or power failure, monitoring failure, GSM/GPRS failure or jamming. If this indicator stays on, contact Sector Alarm AS. BLINKING SLOWLY: There is a fault registered in the system's memory that must be reset.

  • Page 10: Keypad Tones

    30 seconds* until the system is armed. ALERT 4 beeps in the event of alert ...sent via the keypad Confirms the transmission of an alarm to Sector Alarm AS. *Defined by the user on installation HOW TO USE THE KEYPAD...
  • Page 11 INFORMATION AND MAINTENANCE CLEANING THE KEYPAD Use only a dry cloth (no cleaning products) to clean the keypad/control panel. SAFETY WHEN REPLACING AND HANDLING BATTERIES Risk of fire, explosion and burns; the battery must not be recharged, dismantled, heated over 100 °C or incinerated.

  • Page 12: Using The Remote Control

    3 seconds to confirm the instruction.  The disarmed tone is given by the control panel. DISARMING ALSO STOPS THE SIREN, BUT DOES NOT STOP TRANSMISSION TO SECTOR ALARM AS USING THE REMOTE CONTROL...

  • Page 13: Panic Alarm

     The system is not disarmed at the first attempt, so as to avoid beep tones that might attract an intruder's  An alarm is sent to Sector Alarm AS. attention.  To confirm disarming, press the button once again.

  • Page 14: How The Detectors Work

    How the detectors work HOW THE DETECTORS WORK...
  • Page 15 When this detector triggers an alarm, it simultaneously 6. VIBRATION DETECTOR (SKH8M) takes photographs that are transmitted to Sector Alarm's control centre (only applies if the device has a camera A vibration detector fitted to a window or door fitted).

  • Page 16: Maintenance And Recommendations

    Maintenance and recommendations  Check your system every three months.  Avoid impacts to the components and ensure especially that you do not drop the wireless remote control.  Must not be immersed in water.  Only use a damp cloth to clean components (not cleaning products). ...

  • Page 17: Notes

    Notes _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ NOTES...
  • Page 18 Notes _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ NOTES...
  • Page 19 Notes _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ NOTES...

  • Page 20: User Manual

    Domonial User Manual Sector Alarm AS Vitaminveien 1A, PB 113 GREFSEN, 0409 OSLO Telephone 03033 23399401 E-mail post@sectoralarm.no www.sectoralarm.no P/N Z-21001-0 Rev0 2008...
