Lithium ion battery pack/ charger
Hide thumbs


Advertisement

<Battery pack>
Product name
Product code
Battery type
Nominal voltage DC14.4 V (3. 6V x 4 cells)
Nominal capacity 3.0 Ah (3,000 mAh)
Charging time
(When charger
JC925 is used)
Accessories
Weight
∗ Please note that the main functions, shapes and other features in the above specifi-
cations are subject to change for purposes of improvement.
Indication of Quick Charger Lamps
Charger LED lamp
Red lamp blinks.
It blinks every second.
Red lamp lights.
It remains lit.
The green lamp blinks.
It blinks every second.
The green lamp lights up. Fully recharged.
It remains lit.
The red lamp lights up.
The orange lamp
lights up.
They remain lit.
The orange lamp
lights up.
It remains lit.
JPL914-Print.fm 8 ページ 2012年10月18日 木曜日 午後2時16分
LITHIUM ION BATTERY PACK
JPL91430A
Lithium ion battery
Quick charging - Approximately 30 min-
utes (Approximately 90% of capacity)
Full charging - Approximately 45 min-
utes (100% of capacity)
Pack cap (For preventing short circuit) Pack cap (For preventing short circuit)
0.5 kg (1.1 lbs)
Buzzer sound
The power cord is plugged
into the receptacle.
Two short beeps (Pi, pi)
The battery pack is
mounted.
One short beep (Pi)
The battery has been
recharged.
A long beep for approx. 2
seconds (Piii...)
A long beep for approx. 2
seconds (Piii...)
JPL92530A
Lithium ion battery
DC25.2 V (3. 6V x 7 cells)
3.0 Ah (3,000 mAh)
Quick charging - Approximately 45 min-
utes (Approximately 90% of capacity)
Full charging - Approximately 60 min-
utes (100% of capacity)
0.9 kg (2.4 lbs)
Recharging status
The charger is
The charger power cord is
powered.
plugged into a wall socket.
The battery is
being re-
Quick recharging continues.
charged.
The battery has been recharged
The battery
to approx. 90% of its capacity.
has been re-
If you leave the battery pack on
charged.
the charger, recharging will con-
tinue.
Battery is "fully"
Recharged to 100% capacity.
recharged.
The battery is recharged
with a low current to protect
Protective
the charger and battery.
charging
(If the battery pack is cold or
over-discharged.)
If the temperature of the bat-
tery pack is too high: Battery
recharging starts automatical-
ly when the temperature
drops below the limit.
Standby
If the temperature of the bat-
tery pack is too low: Place the
battery pack in a room tem-
perature location for a while,
then retry recharging it.
