Summary of Contents for Unicare Health SALSA 200
- Page 1 SALSA Mobile Standing Transfer Hoist Instruction & Safety Manual Please read this manual before operation, for maintenance instructions and safe usage The enabling power of applied knowledge...
-
Page 2: Table Of Contents
SALSA Mobile Standing Transfer Hoist Instruction & Safety Manual Contents Overview Important Saftey Considerations Assembly Instructions Hoist Operation Actuator Charging Charging Indicator Lights Charging Do’s and Don’ts Lifting Procedures General Maintenance Trouble Shooting Specifi cations Warranty Log Book 08 9351 7500 info@unicarehealth.com.au www.unicarehealth.com.au... -
Page 3: Overview
Overview he SALSA mobile standing hoist is designed to assist the less than able person transfer from a seated position to a supported standing position. The SALSA whilst compact and manoeuvrable has a safe working load (SWL) of 200KG. This lifter is suited to both home or institutional use. -
Page 4: Important Saftey Considerations
SALSA Mobile Standing Transfer Hoist Instruction & Safety Manual Important Safety Considerations INTENDED USE OF THE PRODUCT The SALSA compact mobile patient standing/transfer hoist has been designed to lift and transfer a less able person with the assistance of a carer. The SALSA should be used with one of the ALLEGRO range of patient slings, as assessed by a competent trained person. - Page 5 Lift Arms Push Handle Actuator Battery Pack Knee Pad 08 9351 7500 info@unicarehealth.com.au www.unicarehealth.com.au...
-
Page 6: Assembly Instructions
SALSA Mobile Standing Transfer Hoist Instruction & Safety Manual Assembly Instructions SALSA 200 All the ALLEGRO range of patient lifting and transfer hoists are fully assembled, load tested and certifi ed at the factory before being partially dismantled for packing and shipping. -
Page 7: Hoist Operation
Leg Adjust Actuator The SALSA 200 mobile patient STANDING/TRANSFER hoist uses a LINAK single speed actuator with an emergency controlled lowering release handle.( red lift up tab located at base of actuator shaft). This allows the patient to be lowered in the event of a fault in the hoist or deep discharged batteries. -
Page 8: Charging
SALSA Mobile Standing Transfer Hoist Instruction & Safety Manual Charging The SALSA is suppled with a LINAK external wall mount charger. This is activated by plugging the 3 pin plug into a standard 240Vac outlet. To recharge the battery pack perform the following steps: •... -
Page 9: Charging Do's And Don'ts
Charging Do’s and Don’ts Do charge the battery whenever possible. This will extend the battery life. A large number of cycles can be obtained from operating on the batteries, but battery lifetime is reduced with frequent discharging. • Do inspect all cables particularly the mains power cable on the charger for any damage; replace where necessary. -
Page 10: General Maintenance
SALSA Mobile Standing Transfer Hoist Instruction & Safety Manual General Lifting Procedure The information supplied below is not intended to be construed as a training manual but as a general guide to lifting procedure only. • The SALSA hoist utilises a special type of padded sling designed to fi t around the patients lower back .It utilises a restraint belt to help prevent the sling from slipping and riding up the patients back. - Page 11 Maintenance Guide Check List • General visual inspection of lifter. • Check castors are tightly attached to legs. • Check castors run & swivel freely, remove any hair & fl uff from axle. • Check castor brakes operate effi ciently. •...
-
Page 12: Trouble Shooting
SALSA Mobile Standing Transfer Hoist Instruction & Safety Manual Trouble Shooting WARNING TROUBLE SHOOTING SHOULD ONLY BE CARRIED OUT BY ALLEGRO CONCEPTS AUTHORISED PERSONNEL FAMILIAR WITH BOTH USE, ELECTRICAL AND MECHANICAL FEATURES OF PATIENT LIFTING HOISTS. The following is a guideline only to general trouble shooting. Before carrying out any trouble shooting ensure that. -
Page 13: Specifi Cations
Specifi cations 200KG BASE LENGTH 1050mm EXTERNAL BASE WIDTH 655mm INTERNAL BASE WIDTH CLOSED 585mm INTERNAL BASE WIDTH OPEN 1035mm BASE WIDTH ADJ. ELECTRIC UNDER BED CLEARANCE 125mm MIN. HEIGHT OF LIFT ARM 825mm MAX. HEIGHT OF LIFT ARM 1670mm MACHINE WEIGHT 48.2kg MINIMUM STORAGE HEIGHT... -
Page 14: Warranty
SALSA Mobile Standing Transfer Hoist Instruction & Safety Manual Warranty ALLEGRO CONCEPTS PTY LTD warrants its products to be free from defects in materials and workmanship under normal use and service and will within the period stated below, from the date of purchase, repair or replace without cost to the original customer, any part assembly or portion thereof which shall be returned to ALLEGRO CONCEPTS and from OUR inspection shows to be defective. -
Page 15: Log Book
Log Book Service Type Condition Report Date: Inspection by: Signature: Action Taken Service Type Condition Report Date: Inspection by: Signature: Action Taken 08 9351 7500 info@unicarehealth.com.au www.unicarehealth.com.au... - Page 16 PO Box 82 Bentley WA 6982 Authorised Distributor T 08 9351 7500 F 08 9350 5299 info@unicarehealth.com.au www.unicarehealth.com.au...
