Cautions
Do not subject the device to severe impact or drop it from high position.
Do not use the player in extreme hot or cold, dusty or damp field. Do not
expose it to direct sunshine.
Excessive sound pressure from earphones and headphones can cause
hearing loss.
Avoid using the player in strong magnetic field.
Keep the device away from water or other liquids. In the event that water or
other liquids enter the device, power off the product immediately, and clean
the device.
Do not use chemical solution to clean the device in order to avoid corrosion.
Clean it with a dry cloth.
We are not responsible for the damages or lost data caused by malfunction,
misusing, repairing the device or battery replacement.
Do not attempt to disassemble, repair or modify the product. This will
1
Advertisement
Table of Contents
Related Manuals for Sylvania SMPK4068
Summary of Contents for Sylvania SMPK4068
- Page 1 Cautions Do not subject the device to severe impact or drop it from high position. Do not use the player in extreme hot or cold, dusty or damp field. Do not expose it to direct sunshine. Excessive sound pressure from earphones and headphones can cause hearing loss.
-
Page 2: Key Features
invalidate guarantee. The design of the player or actual display may be different from what is shown in this manual. It should be subject to the actual display or design. 1. Key Features MP3&WMA Player AVI Video player JPEG image viewer Memory card reader Folder Navigation Voice Recorder... -
Page 3: System Requirements
2. System Requirements Hardware: IBM PC & Compatible PC, Notebook with USB interface Operating System: Windows98/SE, Windows Me, Windows2000/XP, Windows Vista 3. Package Content Main Unit Stereo earphones USB cable User Manual CD with video converter 4. Before Using 4.1 Connect to a PC and download audio files This player is plug &... - Page 4 you are required to install a driver before connection. To connect it with PC for transferring files, Plug the larger end of the USB cable to the USB port of the PC, and plug the smaller end to the USB port of the player. When the “...
- Page 5 MP3 player. 4.3 Charge the battery The device has a built-in lithium-icon rechargeable battery. It is charged via USB connection. You are required to charge it when you use it for the first time. It takes about 3 hours to fully charge the battery. Connect the larger end of the USB cable to the USB interface of PC, and connect the other smaller end of the USB cable to the USB interface of this player.
- Page 6 (1) Insert a Micro-SD card to the card slot on the unit body. (2) Press and hold the MENU button to display the main menu. (3) Select “Explorer” and press the MENU button to enter the folder browser mode. (4) In the folder browser mode, you see two folders named “Internal memory” and “Micro SD”.
-
Page 7: Keys Description
5. Keys Description LCD Display Earphone Jack VOL+: Increase the volume MENU: Briefly press to confirm selection. Press and hold to enter the main menu. PREVIOUS: Play the previous track NEXT: Play the next track VOL-: Decrease the volume PLAY/PAUSE: Press to play, pause or escape. -
Page 8: Power On/Off
6. Power On/Off To power on, (1) Turn on the ON/OFF button. (2) Press and hold the PLAY/PAUSE key until you see prompt on the display. To power off, (1) Press and hold the PLAY/PAUSE key until you see prompt on the display. (2) Turn off the ON/OFF button. -
Page 9: Function Operation
Function Operation Play/Pause Press the PLAY/PAUSE button to play or pause. Adjust Volume Shortly press the VOL+/VOL- button to decrease or increase volume. Previous Track Shortly press the PREVIOUS button. Next Track Shortly press the NEXT button. Fast Forward Press and hold the NEXT button. Rewind Press and hold the PREVIOUS button. -
Page 10: Playing Music
To stop A-B repeat, press the VOL+ button. Lock/Unlock To protect the buttons against being pressed accidentally or buttons unlock buttons, hold down the MENU button and the VOL- together. 8. Playing music 8.1 Enter the music mode Press and hold the MENU button to display the main menu. Use the PREVIOUS/NEXT... -
Page 11: Folder Navigation
button to select “Music” menu, and press the MENU button to confirm selection. Now you are in the MUSIC mode, refer music playing to the basic operations. 8.2 Folder navigation To navigate through folders: In the MUSIC mode, shortly press the MENU button to enter folder navigation mode. Press the PREVIOUS/NEXT button to select a folder or track, and press the MENU button to confirm selection, or press the PLAY/PAUSE button to return. -
Page 12: Playing Videos
9. Playing videos Press and hold the MENU button to display the main menu. Use the PREVIOUS/NEXT button to select the “Video” menu, and press the MENU button to enter the video player mode. Press the PREVIOUS/NEXT button to search a video file that you want to play, and press the MENU button to play. - Page 13 Note This player can only play AVI videos. For other formats, you need to use the converting tool included on the driver CD to convert them. For detail information about the converter, see AVI Converter Quick User Guide on the CD. Detail information for converter tool: Before installing the AVI converter, make sure that the Windows OS is installed with DirectX9.0 or above.
- Page 14 Select an installation interface language.
- Page 15 Click “Next” to continue. Browse to a destination for the installation.
- Page 16 Click “Install” to start installation.
- Page 17 Wait for the installation to be completed before you see the following window. Click “Finish” to finish installation.
- Page 18 2) Use the AVI converter (1) Select “Program files” → “AVI Converter” on the Start menu to see the following...
- Page 19 window. (2) Click button to display “Conversion Setting” window.
- Page 20 (3) For the “Source File” field, specify the file that you want to convert by clicking the button on the right. For the “Target File Path” field, specify the destination where the converted file is saved. Set the conversion quality in the Quality field and display mode in the Aspect Ratio filed.
- Page 21 (7) Click “Convert Now” to start converting. (8) Click “Finish” after the converting is finished.
-
Page 22: Viewing Photos
10. Viewing photos To view photos, Press and hold the MENU button to display the main menu. Select “Photo” and press the MENU button to confirm. Press the PREVIOUS/NEXT button to select a folder or image, and press the MENU to confirm. -
Page 23: Reading E-Book
previous or the next photo. Press the PLAY/PAUSE to start or stop an auto slide show. Press the MENU button to enter folder navigation mode. Note: Some images may not be displayed. Try to use an image viewer to convert them or save them as other files. - Page 24 11.1 Reading Press and hold the MENU button to display the main menu. Select “E-book” and press the MENU button to confirm. Press the PREVIOUS/NEXT button to select a .txt file, and press the MENU button to open the selected file. Press the PREVIOUS/NEXT button to page up or page down manually, or press the PLAY/PAUSE button to page up or down automatically (by setting the time interval between 1 and 5 in Settings/Auto Slide show/Text).
-
Page 25: Browsing All Files
press the MENU button to confirm. The bookmark is saved. It starts from the first line of current page. To read the page that you marked, shortly press the VOL- button to show up the “Load Bookmark” window. Press the PREVIOUS/NEXT button to select a bookmark and press the MENU button to confirm. -
Page 26: Voice Recording
To browse all files stored in the player, Press and hold the MENU button to display the main menu. Select“Explorer” ，and press the MENU button to enter the browser mode. Press PREVIOUS/NEXT button to select a file that you want to view, and press the MENU button to play or display it. - Page 27 Press and hold the MENU button to display the main menu. Select“Record” ，and press the MENU button to enter the recorder mode. Shortly press the PLAY/PAUSE button to start recording. During recording, you can press the PLAY/PAUSE button to pause or resume recording. Shortly press the MENU button to stop and save recording.
-
Page 28: Deleting File
14. Deleting file To delete a file, Select “Explorer” on the main menu to enter the folder navigate mode. Briefly press the VOL- button to display a dialogue box. Use the PREVIOUS/NEXT button to select “YES” and press the MENU button to confirm. -
Page 29: Customizing Settings
15. Customizing Settings To customize the player settings: On the main menu, select the “Settings” item and press the MENU button to enter the system settings mode. Press the PREVIOUS/NEXT button to select setting item and press the MENU button to confirm or press the PLAY/PAUSE button to cancel/return. - Page 30 Music Repeat mode Once（Play current track once and then stop） Repeat One (Repeat current track) Folder Once（Play all audio files in the current folder and stop after playing） Folder Rep.（Repeat all audio files in the current folder） Normal（Play all audio files stored in the player and stop after playing all）...
- Page 31 Play mode Order（Play audio files in order） Shuffle（Play audio files randomly） Preset EQ Normal, 3D, Rock, Pop, Classical, Bass, Jazz, User EQ User EQ set Press the PREVIOUS/NEXT button to (User-defined switch EQ column. equalizer Press the VOL+/VOL- button to adjust setting) the value of the selected column.
-
Page 32: Power Save
Record REC Quality High Quality, General Quality REC Volume +1、+2、+3、+4、+5 Auto Slide Show Text Browse (Set interval between the previous and the next page when the device is in auto page up/down mode.) Photo Browse (Set interval between the previous and the next slide in auto slide show mode.) Display Backlight time... - Page 33 System About - Information about the product Upgrade - Upgrade the firmware Load Default - Restore the player to default setting Power OFF Off, 10 minutes, 15minutes, 30 minutes, 60 minutes, 120 (Set the continuous minutes playing time before the player is turned off automatically.) Language English, French, Spanish...
-
Page 34: Troubleshooting
16. Troubleshooting Problem Possible Cause Solution displays nothing when Battery is too low. Charge the battery. device is started. The volume is too low. Adjust the volume. sound when playing an audio file. Bad audio file. Delete or skip the file. - Page 35 The USB interface is not The player cannot be Update or replace the PC’s supported PC’s connected to the PC. motherboard. motherboard. The bit rate of the MP3 The displayed time is Try to use fixed bit rate to file is changing during changing constantly.
- Page 36 displayed to store programs and player display characters. accordance with the marked amount. file 1. Delete the unsupported compressed Some of MP3 files MP3 files. standard, such as MPEG cannot played 2. Use MPEG I Layer 3 I Layer 1 or Layer 2 that properly.
- Page 37 corrupted Try to use an image editor The file format is not to convert it or save it as supported another file. device supports The photo cannot be maximum resolution displayed The image resolution is 2560 X 2048 pixel. Make beyond limitation of the sure resolution of the image device.
-
Page 38: Technical Specifications
17. Technical Specifications Item Specification Capacity Battery Type Rechargeable lithium-ion polymer battery Battery Life 8 - 10 Hours (Max.) LCD Display 1.8-inch CSTN screen, 160 x 128 pixel Earphone Power 5mW+5Mw Video Format AVI (XviD) Audio Format MP3, WMA Photo Format JPEG Image Resolution 2560 X 2048 (Max.) - Page 39 USB Port USB2.0 Operational Temperature 0℃ ~ +55℃ -20℃ ~ +55℃ Storage Temperature Operational Relative 20% ~ 90% (40℃) Humidity * 20% ~ 93% (40℃) Storage Relative Humidity * 18. Notice Make sure all keys are enabled before operation. If they are locked, hold down the MENU and VOL- button to unlock them.
- Page 40 manufacturers. Please disconnect the player from PC properly to avoid data loss. The transfer rate displayed on the PC may be different depending on the operating system. Exact transfer rate should be subject to the player's indication.
