Summary of Contents for DeltaPix Modus M28Z
- Page 1 Modus M28Z Table version User Manual Revision 1...
-
Page 2: Table Of Contents
The following menu options are available........7 External Keypad control of Main Menu ........9 Troubleshooting ................10 Changing the Output Frame Rate ...........10 Taking Care of your Modus M28Z ..........10 Firmware Upgrade ..............11 Specifications ................12 Declaration of Conformity ............12 Warranty ..................13... -
Page 3: Package Contents
Grounding Cable USB Memory Stick Optional External Keypad KP1 Foot Switch Please retain the packaging in case there is a need to return the unit for service or repair. Page 3 Modus M28Z Table English Rev 1... -
Page 4: Installation
Plug the power supply into a mains socket. Plug the power lead from the power supply into the Modus M28Z, at the rear of the unit as shown below. Plug the HDMI cable into the Modus M28Z and the other end into your HDMI compatible monitor. Plug the external keypad (optional) into the Mini-Din socket. -
Page 5: Light Adjustment
Foot Switch A footswitch is available for the Modus M28Z Table. This allows control of the zoom functions. The left pedal will zoom in and the right will zoom out. This is useful for hands free operation of the zoom function. -
Page 6: Magnification
Factory defaults Press Capture while powering-on the Modus M28Z to restore factory settings for sound, lighting, brightness settings and video frame rate. The factory default settings are lights on, sound on and the frame rate that was set for your country before shipping. -
Page 7: Main Menu Controls
To re-balance later – turn the white balance off and on again * Note :- The White Balance Data is lost when the unit is powered down. Focus Lock : On / Off Page 7 Modus M28Z Table English Rev 1... - Page 8 Turning the OSD Screen Display ( OSD ) off removes all the static messages from the screen. Time : xx:xx Enter the current time starting with minutes and then hours. Note:- Time and Date are only used to Date Stamp the captured images. Page 8 Modus M28Z Table English Rev 1...
-
Page 9: External Keypad Control Of Main Menu
Changing the Camera Macro Lens The Modus M28Z is shipped with a Ø52mm lens with a focal length of 250 mm (+4 Dioptre). It is threaded into the camera using an adaptor which has a 46mm thread size on one side and a 52mm on the other side. -
Page 10: Troubleshooting
Most monitors and HD televisions can display the many different standards of HD signals, however some cannot. If your monitor/TV does not display the image from the Modus M28Z you should try the following: Power-off the Modus M28Z, press and hold the Overview button and power on the unit. -
Page 11: Firmware Upgrade
Firmware Upgrade The Modus M28Z includes a Firmware Upgrade Function allowing end users to install new versions of the firmware which includes new feature additions and bug fixes. 1. Make a directory called “Upgrade” in the USB Flash Drive. If the directory already exists then delete all the files from that directory. -
Page 12: Specifications
Declaration of Conformity We, DeltaPix, declare under our sole responsibility that this product Modus M28Z, of the brand DeltaPix to which this declaration relates, is in conformity with the following standards or other normative documents: EN 60601-1-2:2007 Medical Electrical Equipment – Electromagnetic Compatibility. -
Page 13: Warranty
DeltaPix or its agents and that it is solely serviced by DeltaPix or its agents.
