Hunt Electronic HKB-300 Instruction Manual

Intelligent keyboard for controlling the intelligent dome
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
18
Panel Scanning (Mode Scanning)
Intelligent Keyboard Instruction Manual
17
INDEX
1
15
2
2
2
2
3
4
5
5
8
8
8
8
9
10
10
13
14
14
15
15
15
15
16
16
16
16
16
18
18
18
19
19
19
19
19
19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HKB-300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hunt Electronic HKB-300

  • Page 1: Table Of Contents

    Intelligent Keyboard Instruction Manual INDEX I. Keyboard Overview II. Intelligent Keyboard Technical Parameters III. Intelligent Keyboard Drawing 3.1 Intelligent Keyboard Connection 3.2 Keyboard Connection with Dome Camera IV. Function Key V. Keyboard Parameters Setting 5.1 Keyboard Parameters Set VI. Intelligent Keyboard Operation 6.1 Keyboard Communication Address Set 6.2 Keyboard Control for Dome Camera 6.3 Auto Scanning (2 Points Scanning,360°Scanning)

  • Page 2: Keyboard Overview

    Intelligent Keyboard Instruction Manual I. Keyboard Overview The keyboard is used for controlling the intelligent dome. The keyboard is the main device between operator and device in the monitoring system. It can be regarded as the main control keyboard and as the vice control keyboard.

  • Page 3: Keyboard Connection With Dome Camera

    Intelligent Keyboard Instruction Manual Wire Box Inner Function Picture Power Supply 12VDC RS485 Signal 3.2 Keyboard Connection with Dome Camera RS485 Wire box control l RS485 RS485A RS485A RS485A dome camera RS485B RS485B RS485B dome camera dome camera dome camera △...

  • Page 4: Function Key

    Intelligent Keyboard Instruction Manual IV. Function Key Joystick: Control Dome Camera running: Up, down, Left, Right, Left-up, Left-down, Right-up, right-down, camera lens zoom in and zoom out Keyboard joystick can’t control Dome Camera lens zoom in and zoom out. Other function same as Function Area 1: Dome Camera Selection and Auto scanning Control Number Area: Data Input, Clear and Confirmation...

  • Page 5: Keyboard Parameters Setting

    Intelligent Keyboard Instruction Manual LOCK key: After pressing this key; input the password 6688, the keyboard is under locked status. Open the keyboard by inputting 6688 SHIFT key: Such as <SHIFT> + <AUTO> stands for pressing the SHIFT key and AUTO key. SHIFT+AUTO key: Start up 360°scanning.
  • Page 6 Intelligent Keyboard Instruction Manual 5.1.2 Keyboard Baud Rate Set Press the FUN key until LCD displays: Current baud rate. Input new baud rate Optional baud rate: 9600, 4800, 2400, and 1200 Default baud rate: 9600bps. Input your required baud rate in DATA area, and press the ENTER key for confirmation. New baud rate is in effect immediately.
  • Page 7 Intelligent Keyboard Instruction Manual 5.1.6 Keyboard Test Press the FUN key until LCD displays: Press the ENTER key for confirmation, a blank screen will appear. Press any key except the <EXIT> key, the relative name will display on the screen. Press <EXIT>...

  • Page 8: Intelligent Keyboard Operation

    Intelligent Keyboard Instruction Manual VI. Intelligent Keyboard Operation The startup interface is general operation menu after the keyboard is connected to the power supply. LCD displays as follows: 6.1 Keyboard Communication Address Set Input any number within “1～1024”(Dome Camera address) in DATA area, Press<CAM>key. The relative number will display on CAM area.

  • Page 9: Set Preset Position

    Intelligent Keyboard Instruction Manual 1. To set Point A. Move the joystick to the desired position. 2. In the Main Menu enter a dwell time for Point A. Example: If Dwell time is 2 seconds the keyboard displays: 3. Press the “PAN A” key. 4.

  • Page 10: View Preset Position

    Intelligent Keyboard Instruction Manual 6.5 View Preset Position 1. Press CLR to clear the number in the data area. 2. Input the address of the dome in the Data area, press down<CAM> key and show it in DATA area. 3. Input the preset position you would like to view. Example: View preset position No.
  • Page 11 Intelligent Keyboard Instruction Manual 2. Enter the correct Speed Dome Unit and Press Enter. Example: Preset Position for Speed Dome 3. The Keyboard displays: Displays the Speed Dome Address (1-1024) 3. Now the Keyboard displays: Preset position (1-128) Running speed (1-64) Dwell time (1-60) Press F1 key on the keyboard to move the cursor up and down...
  • Page 12 Intelligent Keyboard Instruction Manual 6.6.2 Pattern Tours Set The keyboard can set pattern tour groups for the speed dome camera. Before setting the Pattern Tours please set all preset positions in advance. If the preset positions are not set the pattern tour will default to the pattern tour parameter.

  • Page 13: Guard Location Set

    Intelligent Keyboard Instruction Manual Two pattern tours styles can be used: A .To-and-from Scanning 1-2-···········.-16-1-2-···········-16-1-··········· Make an auto circle scanning by points. Press EXIT key and exit to default status of the keyboard. Input cruise Number adjust key SCAN into to-and-from scanning (as the above route) B.

  • Page 14: Guard Location Parameter Set

    Intelligent Keyboard Instruction Manual 5. Input the desired waiting time using the number keys: Example: After inputting time: 05, press Enter. 6.8 Guard Location Parameter Set 1. When the keyboard is under default (Main Menu) status, press the FUN key once, The keyboard displays: 2.

  • Page 15: Defense Set

    Intelligent Keyboard Instruction Manual Operating menu see below for reference: Operating Key Function Dome menu cursor up Dome menu cursor down AREA Dome menu cursor left Dome menu cursor right ENTER Enter function menu ENABLE Exit function Confirmation LIST Select EXIT Keyboard function menu exit to upper menu dome camera menu set should consult Dome Camera manual.

  • Page 16: Auxiliary Switch 1 Set

    Intelligent Keyboard Instruction Manual 7.3Auxiliary Switch 1 Set Press FUN until LCD display as below: 5) Auxiliary#1 Number:0001 OFF→Set “Auxiliary Switch 1” open by pressing down “F1/ON”key, Set “Auxiliary Switch 1” close by pressing down “F2/OFF”key. This Function is used for the frontal terminal device with the wash brush function only. The fan and heater in the speed dome camera is always under auto temperature control status.
  • Page 17 Intelligent Keyboard Instruction Manual (2.) Press “Exit” key to return the keyboard setting as default. Press the FUN key until LCD displays: 8) Joystick Set M: 000 M: 000 M: 000 （M:*** indicates the data of the corresponding joystick movement range(scale). 7.7.1 Set Joystick middle value (dwelling time) Press the “AUTO”...

  • Page 18: Lock Keyboard

    Intelligent Keyboard Instruction Manual AUTO for Maximum upward Movement Data Setting VIII. Lock Keyboard Press down the LOCK key, LCD displays: Input password: 6688 (This password is set by the factory and cannot be modified). Once entered, keyboard will be in locked status. It shows: Key is locked Password: When the keyboard is locked the users cannot operate the keyboard.

  • Page 19: Clear Preset Position

    Intelligent Keyboard Instruction Manual Pan-B Limited B Auto Line Scan (scanning between two points) Shift _Auto Panel Scanning (Mode Scanning) Scan Start up the perambulate group Shift + Scan Start up intercourse perambulate group LCD show CAM area address PELCO_D PELCO_P Protocol Operating Function Call Adjust preset position...
  • Page 20 Intelligent Keyboard Instruction Manual...
