SIIG CE07xx Quick Installation Manual

Mobilecam/light pro
Hide thumbs

Advertisement

Quick Links

Download this manual
System Requirements
• Pentium-class notebook or desktop computer
with an available USB port
• Windows 98SE/ME/2000/XP
Package Contents
• One MobileCam/Light Pro
• One Driver/Utility CD
• This quick installation guide
Serial # Sticker
For future product return or exchange, this serial # is
required. Please keep it for your reference.
04-0305A
MobileCam/Light Pro
Quick Installation Guide
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the CE07xx and is the answer not in the manual?

Questions and answers

Summary of Contents for SIIG CE07xx

  • Page 1 MobileCam/Light Pro Quick Installation Guide System Requirements • Pentium-class notebook or desktop computer with an available USB port • Windows 98SE/ME/2000/XP Package Contents • One MobileCam/Light Pro • One Driver/Utility CD • This quick installation guide Serial # Sticker For future product return or exchange, this serial # is required.

  • Page 2: Software Installation

    Layout Lens (turn to focus) Snapshot Button On/Off Light Button (on the back) Light To USB Port Figure 1. MobileCam/Light Pro Layout Software Installation Important: Make sure the driver is installed before connecting the MobileCam/Light Pro to the USB port. If prompted for Windows Installation CD during installation, please insert it and follow the on-screen instructions.
  • Page 3 Windows Driver Installation 1. Boot up to Windows and insert the driver CD. 2. Autorun will start installation. If Autorun does not start, click Start, Run. Type in D:\Autorun.exe, then click OK. (Change D: to match your CD-ROM drive letter) 3.
  • Page 4 Ulead Photo Explorer 7.0 SE Platinum Ulead Photo Explorer combines easy to use tools for acquiring, viewing, organizing, adjusting, and sharing digital images. For more detail about Ulead Photo Explorer, please refer to the pdf manual located in CD-ROM:\Ulead Photo Explorer7.0SE Platinum \Document\Manual folder of the software CD.
  • Page 5 Connecting the MobileCam/Light Pro Important: Make sure the driver is installed before connecting the MobileCam/Light Pro to your system. Note: After the MobileCam/Light Pro has been connected, turn the lens to improve focus if needed. Windows 98SE: 1. Plug the MobileCam/Light Pro into an available USB port.
  • Page 6 2. At the Digital Signature Not Found window, click Yes two times. Our driver has been thoroughly tested in Windows for stability. 3. Click Finish. 4. The camera is now ready. Windows XP: 1. Plug the MobileCam/Light Pro into an available USB port.
  • Page 7 To verify successful installation: 1. Check Device Manager to verify successful driver installation. Windows 98SE/ME: From the main desktop, right click My Computer, then click Properties. Click Device Manager tab. Windows 2000/XP: Right click My Computer, then click Manage. Click Device Manager. 2.

  • Page 8: Video Capture

    AMCAP Capturing Use this utility to easily capture video and snapshots. Note: Turn the lens to improve focus if needed. (See figure 1 on page 2) Video capture: Windows 98SE/ME/2000: 1. Click Start, Programs, MobileCam Pro, then AMCAP. Important: On your very first time capturing video, click File, select Set capture file..., type in a file name with .avi extension, click Open, then click OK.
  • Page 9 Windows XP: 1. Click the Snapshot button to start AMCAP. Important: On your very first time capturing video, click File, select Set capture file..., type in a file name with .avi extension, click Open, then click OK. An example for this file name is test.avi.
  • Page 10 Windows XP: 1. Click the Snapshot button to start AMCAP. 2. Wait for an image to appear, then click the Snapshot button. 3. In the VMCap window, click File, Save As, type in a name, then click Save. Sound The MobileCam/Light Pro comes with a built-in microphone.
  • Page 11 2. In Recording, select PC Camera... as the preferred device. 3. Click Volume, move the slider bar up to increase the recording level. 4. Close the open windows when finished. Windows XP: 1. In Control Panel, double click Sounds and Audio Devices, then click Audio tab.

  • Page 12: Technical Support

    PRODUCT COMPLIANCE SIIG, Inc. 6078 Stewart Ave. Fremont, CA 94538-3152 MobileCam/Light Pro is a trademark of SIIG, Inc. All other names used in this publication are for identification only and may be trademarks of their respective companies. June, 2003 Copyright ©2003 by SIIG, Inc.
