Assembly Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LAP-2C and is the answer not in the manual?

Questions and answers

Related Manuals for Balt LAP-2C

Summary of Contents for Balt LAP-2C

  • Page 1 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 LAP-2C...
  • Page 2 LAP-2C Mobile Laptop Workstation Part Drawing Description Part Drawing Description Lower Receiver 1 EA P-12 Copyholder 1 EA Right Foot 1 EA Hardware List 9/16” Flat Head Screw 11 EA Left Foot 1 EA 3/4” Flat Head Screw 4 EA 1-5/8”...
  • Page 3 LAP-2C Assembly Diagram HROUGH NSTRUCTIONS FROM BEGINNING TO BEFORE STARTING TO ASSEMBLE UNIT 1. Identify and Separate all the Parts and Hardware. 2. Attach Left Foot (P-3) on the end of Lower Reciever (P-1) with drill hole using 3 Flat Head screws (C).
  • Page 4 9. Attach Storage Rack (P-8) to the Accessory Illustration # 4 Shelf (P-5) using 4 Flat Head screws (A1) and 4 Flat Washers (E) as shown in illustration # 4. 10. Attach Tilting Bracket (P-10) to the Top Platform (P-6) using 2 Flat Head screws (A). Secure Tilting Bracket to Upper Insert (P-4) using the Large Knob (G1).
  • Page 5 DETAILS OF ASSEMBLING PLASTIC CAP ‘M’ & SLEEVE ‘N’ 1. Slide Plastic Cap (M) [with Cutout on the same side as the tilting bracket on the Upper insert], then attach the Plastic sleeve (N) over the end of insert. Make sure that the hole on the Part N and the hole on the Upper insert tube line up, then attach it with a Flat Head screw (A).

Table of Contents
