USER GUIDE

IP ROUTER
IP ROUTER
NAT·DHCP·FIREWALL·10/100Mbp SWITCH
Version 1.0
2003.11
-1-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP ROUTER and is the answer not in the manual?

Questions and answers

Summary of Contents for Generic IP ROUTER

  • Page 1: User Guide

    USER GUIDE IP ROUTER IP ROUTER NAT·DHCP·FIREWALL·10/100Mbp SWITCH Version 1.0 2003.11...

  • Page 2: Before You Start

    IP Router. Before you start… First, read Chapter 4, Installation section for installation information before you install the IP Router. Second, read Chapter 6. IP Router Setup section to setup the IP Router to best fit your Internet environment.

  • Page 3: Table Of Contents

    5.LOCAL COMPUTER SETUP..……………………………………………………15 5.1 Windows 95/98/ME Setup……………………………………………………15 5.2 Windows 2000 Setup……………………………………………………………20 5.3 Windows XP Setup……………………………………………………………24 6.IP ROUTER SETUP…………………………………………………………………29 6.1 Start Internet Explorer to Login………………………………………………29 6.2 PPPoE User Setup……………………………………………………………30 6.3 Dynamic IP User (Cable Modem...) Setup……………………………………33 6.4 Static IP User Setup.…………. ……………….….……..……….……………36 6.5 Status……………………………………………………………………………37...

  • Page 5: Warning

    Using other power adapter may cause an error or damage to the IP Router. 2. Do not drop or give a physical shock to the IP Router. It may affect internal circuit. 3. Do not disassemble the IP Router without sufficient understanding of your action.

  • Page 6: Package Contents

    2.PACKAGE CONTENTS Package contents of IP Router IP ROUTER are as follows; IP ROUTER Switch DC Power Adapter (5V, 1000mA) Ethernet Cable UserGuide...

  • Page 7: Specification

    Gateway, Switch, DHCP Server, Firewall etc： Network Address Transform (NAT)：With providing Internet application this IP Router can allow more than one user to connect with Internet at the same time by sharing one public IP address; It supports many connection ways：xDSL、Cable Modem、LAN/ Leased Line and so on.
  • Page 8 Remote Management：Users can totally manage office or home network wherever they are. DDNS：By this function users can set up their own web station. Detailed Specification ITEM IP ROUTER IEEE 802.3, IEEE 802.3u, IEEE 802.x, IEEE Fast Standard Ethernet, TCP/IP, NAT, DHCP ,UDP, FTP, PPPoE, PPTP, Protocol L2TP,HTTP,DNS, IPSec/VPN Pass-through…...
  • Page 9 10/100Mbps switch LAN/WAN port auto sense cross cable WAN port static/dynamic IP flexible setting up PPPoE dial-up and connection time setting up PPPoE dial-up and automatic/manual connection Support VPN Pass-through DHCP Service DNS relaying Inside DMZ Server function Connection setting up and stat. Firewall Remote control DDNS...

  • Page 10: Installation

    Windows 95/98/ME/NT/2000/XP Mac OS Linux or other UNIX system * If the specification and functions of IP Router have been changed, it will not be informed. The users please take care of it by themselves. 4. INSTALLATION 4.1 BEFORE INSTALLATION：...

  • Page 11: Installation

    4.2.2. Setup LAN connection: connect your computer LAN card’s port or your switch UPLINK port with one LAN port of IP Router by a common network cable. Note: All LAN ports of IP Router can automatically sense cross cable, so you can either use through cable or cross cable to connect LAN card or switch.

  • Page 12: Network Sketch Map

    LAN PORT ： connects power adapter xDSL/Cable Modem or personal computer (DC 5V/1A) Special cable hub, switch and so on. NOTE：After switch or hub expand, IP Router can connect at most 253 client computers in LAN . 4.3 NETWORK SKETCH MAP -12-...
  • Page 13 DC Adapter: 5V/1A 3. connects with power adapter Modem connects with 2. connects with PC xDsl Modem EXAMPLE 1. Server Interne Router Cable/xDSL Modem -13-...
  • Page 14 Modem Server Note：During the usage, the sequence of turn on is：firstly turn on Modem’s power supply ， 1 minute after Modem startup turn on IP Router power supply , then turn on the computer . 5. LOCAL COMPUTER SETUP Users should configure local network to access Internet by IP Router.

  • Page 15: Local Computer Setup

    Users must connect with IP Router again After configure computer’s local network. Please make sure your computer setting is as follows, Otherwise IP Router can not be correctly connected (Linux and Mac users please setup as follows by relative conference).
  • Page 16 Click “TCP/IP” and “Properties”. (6) Click “IP address” option and choose “Obtain an IP address -16-...
  • Page 17 automatically”. Click “Gateway” menu and make sure “Installed gateways” is blank. Click the “DNS Configuration” and select “Disable DNS”, then Click “OK”. During the TCP/IP installation process there will ask you to insert Window installation CD. After inserting it then click “OK”. (10) After TCP/IP configuration has completed, the window of “System Setting Chang”...
  • Page 18 (11) After restart, click “start” ->“run”. (12) Input command ，then click “OK”。 (13) Input “ipconfig” in pop-up command window, then “Enter”. (14) Please make sure your IP is the same with below. If same then your configuration is successful , or please redo the above steps and restart your computer.
  • Page 19 (15) Input “ping 192.168.10.1 ” then “Enter”. (16) If you can see “Reply from 192.168.10.1 : bytes=32 time=2ms TTL=64”，the connection between your computer and IP Router is completed. -19-...

  • Page 20: Windows 2000 Setup

    5.2 Windows 2000 SETUP Install IP Router. Start Windows 2000 and check LAN LED is on or off. If off, please confirm the connection of your computer with IP Router. Click “start”->“Setting”->“Panel Control”. Double click the “Network and Dial-up Connection” in “control panel”.
  • Page 21 Click “Local area connection”->“Properties”->“Internet protocol （TCP/IP）”and “Properties”. Click “General ” bar ,Select “Obtain an IP address automatically” and “Obtain DNS server address automatically” Click “OK”. -21-...
  • Page 22 Click ”Start” ->“Run”. Input ”cmd” ,then click “OK”. (10) Input “ipconfig” in Pop-up Command window. (9) Please make sure your IP is the same with below. If same then your configuration is successful, or please redo the above steps and restart your computer.
  • Page 23 The subnet mask is 255.255.255.0 The default gateway is 192.168.10.1 (10) Input “ping 192.168.10.1 ”, then “Enter”. (11) If you can see “Reply from 192.168.10.1 : bytes=32 time=2ms TTL=64”，then the connection between your computer and IP Router is completed. -23-...

  • Page 24: Windows Xp Setup

    5.3 Windows XP SETUP Install IP Router. Start Windows XP and check LAN LED is on or off. If off, please confirm the connection of your computer with IP Router. Click “Start”->“Setting”->“Panel Control” Double click the “Network and Internet Connections” in “control panel”.
  • Page 25 -25-...
  • Page 26 -26-...
  • Page 27 Click “Start”->“Run” -27-...
  • Page 28 The subnet mask is 255.255.255.0 The default gateway is 192.168.10.1 (12) Input “ping 192.168.10.1 ”, then “Enter”. (13) If you can see “Reply from 192.168.10.1 : bytes=32 time=2ms TTL=64”，then the connection between your computer and IP router is completed. -28-...

  • Page 29: Ip Router Setup

    6. IP ROUTER SETUP 6.1 START INTERNET EXPLORRE TO LOGIN ) ， Run Internet Explorer and click the “Stop( )“ button in Internet Explorer’s toolbar. Input http://192.168.10.1 in Internet Explorer’s address bar. 192.168.10.1 is Default IP address of Router. You may see the following login web page. Click “Login” button and make relative configuration..

  • Page 30: Pppoe User Setup

    6.2 PPPoE(ADSL) USER SETUP This connection way is suitable for virtual dial-up Internet connection. Open external ADSL Modem and check the WAN LED of IP ROUTER. If WAN LED is off, check the network cable between external modem and WAN port.
  • Page 31 Input the “User ID” and “Password” provided by your Internet service provider. Click the “Apply” button. Confirm the WAN connection status: If WAN connection is successfully established, then by clicking “Status” you can enter status web page. -31-...
  • Page 32 “Connect” is manual connection button. By clicking it the system can be connected to Internet again. Click “Save Configuration” to save current configuration. Restart all PCs connect with IP Router. Notes: Please save IP Router Configuration after completion, otherwise configuration will lose when power off or restart. -32-...

  • Page 33: Dynamic Ip User (Cable Modem

    Static IP: Allow user setup the static IP. Disconnect PPP session if idle time is longer than Min: If you choose this option and set up the time T, then the IP router automatically disconnects from Internet after T idle time.
  • Page 34 Click Apply to complete. Check the WAN Connection Status: click “Status” to enter status page. If WAN connection is successfully established, you can see the following. -34-...
  • Page 35 (These addresses are provided by your ISP). Disconnect button as follows is manual WAN port IP address release function button. If click it IP Router will release WAN port IP address and disconnect with Internet. “Connect” button is manual WAN port IP address refresh function button.

  • Page 36: Static Ip User Setup

    6.4 STATIC IP USER SETUP If you have static IP address provided by ISP, you can choose this option. Turn on the external modem and check the WAN LED of IP Router If the WAN LED is off, please check the network cable between external modem and the WAN port.

  • Page 37: Status

    Click the “Save Configuration” button to keep current configuration, then restart computers in LAN to re-get IP relative information. Note: After completion please save the configuration, otherwise configuration will be lost when IP Router is power off or restarts. 6.5 Status Click “Status” as following:...
  • Page 38 WAN Status: This page shows current Internet connection status (WAN port), including Connection Type, Connection Status,WAN IP address, Subnet mask, Default Gateway and DNS server. If it is dynamic IP way, “Disconnect” button or “Connect” button will be shown above. Click“Disconnect” button to release current WAN Port IP Address, then click “Connect”...

  • Page 39: Lan Setup

    LAN port basic parameter and DHCP server parameter can be set up in this web page. System IP Setup：If you want to change IP Router LAN port address, you can set up as follows: System IP address：IP address in LAN. This IP address is factory default value 192.168.10.1 , and you can change it.

  • Page 40: Routing Table

    DHCP IP Pool：IP address range automatically allocated by DHCP Server is address pool. Notes: In order to use DHCP function of the IP Router, TCP/IP protocol of computers in LAN must be configured as “automatically get IP address”. After completion please click “Apply” to make the configuration valid.

  • Page 41: Virtual Server

    Type：Routing Type.Have two option:NET/Host. Enter in the IP of the specified network or host that you Target: want to access using the static route Mask: Enter in the subnet mask to be used for the specified network, Gateway: Enter in the gateway IP address to the specified network. For Complete Setup ,Please click “Add”...
  • Page 42 LAN through the IP Router, under default configuration the firewall protection will not allow the access, then conflict occurs – at the same time IP Router has to protect computers in LAN from WAN, at the other time it has to allow access of valid users in WAN.
  • Page 43 Choose the Server which you want to be open to Internet, then input Server IP address. Click “Add” button to make current setup valid. Note: All open protocol port should be standard port, otherwise IP Router can not transfer the data package from the invalid port which you have configured;...

  • Page 44: Port Triggering

    NOTE： If you want to save all values after IP Router power off or restart, please click “Save Configuration” button which is in right-above to save current values.
  • Page 45 Function： If application program is connected form forward ports. All in trigger ports will be opened to prepare for connection. Port Triggering: Port trigger module dynamically register virtural server rules when any IP host generate the packet from the specified trigger protocol and port. Port trigger module use forward protocol type and port number and use the IP address of host which generates the trigger packet when it registers a rule.

  • Page 46: Firewall

    6.10 Firewall Click “Firewall” as follows: Connection Filtering: The specified IP host traffic can be blocked by using firewall. Enter the IP address to block in Source IP Address field. Enter the Net Mask field to block the subenet traffic in net mask field. Don't enter the net mask field if you want to block just one IP host.

  • Page 47: Misc Setup

    With Internet connections ways such as ADSL or Cable Modem, normally ISP will allocate a dynamic IP address. Dynamic domain name service is a method of keeping a domain name linked to dynamic IP address get from ISP. But dynamic domain name service depends on dynamic domain name service system.
  • Page 48 Remote Mgmt: This function to setup IP Router’s remote management and WEB management ports. After start Remote Management, users can remote manage the IP Router by “http://WAN port IP address: Your setup Port (between is colon)”; If you want to start remote management, please setup “Management port” then click “Apply”.
  • Page 49 After restore to factory default values, IP Router will restart automatically. Click “System Reload” button, IP Router will restart. Firmware Upgrade: By updating the IP Router software, you can get new functions or performance. Software update steps: Login our company homepage：www.globalzio.com, download new version software to your local hard disk.

  • Page 50: Error Report And Advise

    IP Router will be damaged. 7. ERROR REPORT AND ADVISE If you find any error of the IP Router or If you have any advise, please send it to us. Address:...

  • Page 51: Appendix Autp Cable Specification

    Appendix A UTP Cable specification Twisted pair Category-5 straight-through cable Twisted pair Category-5 Cross over cable Straight-through Cable Cross over Cable -51-...
