Summary of Contents for Elixier tech ET-STONE
- Page 1 S O L A R P O W E R B A N K WITH LED LAMP & TORCH U S E R M A N U A L EXPLORE. ENDURE. EVOLVE.
- Page 2 1. High Efficiency Solar Panel 8. Lamp Button 2. Solar Charging Indicator 9. LED Torch 3. Power Button 10. Torch Button 4. Battery Level Indicator 11. Kickstand 5. MICRO USB Pin 12. Lanyard Holes 6. USB A 13. Tripod Thread 7.
-
Page 3: Specifications
SPECIFICATIONS Battery - 3.7V, 3100 mAh Li-Po Input Current - 2A Output Current - 1.5A Material - Special grade engineering polymer Solar Panel - Mono-crystalline 2.75V / 550mA LED (3 Nos) - 110mA i/p current each Dimensions - 84mm x 135mm x 16.8mm Multipurpose Kickstand - 360˚... -
Page 4: Solar Charging
Angle can change according to your co-ordinates. Find the best angle for your location Charging rate depends upon the intensity of the sun. During summer, ET-Stone should get fully charged in less than 14 hours but during winter, charging rate will be slightly slower. -
Page 5: Power Management
POWER MANAGEMENT POWER BUTTON Press: Battery Level Indicator 2nd Press: Charge ON for USB compatible devices 3rd Press: Charge OFF No Press Solar Charge ON in sufficient light BATTERY LEVEL & CHARGING INDICATOR Battery Level: Four green LED’s indicate the battery level. Charging Indicator: First LED turns red while charging external device. - Page 6 WALL MOUNT / LAPTOP CHARGING MICRO USB ET-Stone can be charged using any Micro-USB charger (upto 2A) in approximately 3 hours. ET-Stone can be charged using any USB to Micro-USB cable connected to a laptop / PC in approximately 6 hours.
- Page 7 To charge a device, connect it to the USB A port of ET-Stone using a USB cable (The ET USB Flash Cable will give better results) and press the power button twice. The first LED will turn red.
- Page 8 ET-Stone™. HOW AC DUAL CHARGING WORKS: Connect any wall-mount adapter to ET-Stone™ Connect ET USB Flash Cable from ET-Stone™ to your device AC Dual Switch on the wall-mount adapter and press Charging power button twice on ET-Stone™...
-
Page 9: Lamp Button
LED LAMP & TORCH LED LAMP 100% 3 Intensity Lamp SOS Light Feature Wide Angle Lens LAMP BUTTON Press: Highest Intensity (14hrs of light) 2nd Press: Medium Intensity (22hrs of light) 3rd Press: Low Intensity (40hrs of light) 4th Press: Long Press(2 secs): SOS Light TORCH BUTTON... - Page 10 DESIGN KICKSTAND 360˚ Kickstand Hand held Easy wall hanging The revolutionary kickstand developed and patented by us, has been made after months of research, keeping in mind usability, convenience and durability as the main aspects to redefine user experience. It also provides protection to the main body thus facilitating additional rigidity.
- Page 11 DESIGN LANYARD Bag Lanyard Lanyard Holes We have provided 3 separate provisions (2 at the bottom & 1 on the top of the kickstand) to attach a lanyard so as to give you a complete hands free experience. TRIPOD THREAD The kickstand boasts two ¼”...
- Page 12 (FCM) The Flexi Car Mount (FCM) takes the usability factor of ET-Stone™ to the next level. You can affix the FCM to the windshield or any window of your car (using the suction cup) and pair it with ET-Stone™ using the threads given on the kickstand.
- Page 13 The Whip is a carefully designed accessory that not only helps in charging electronic devices but also assists in data transfer. All in all, it is a perfect extension of ET-Stone™.
- Page 14 TECHNOLOGY Pre-Charge - Fast Charge - Natural Charge - Charge Termination – It basically protects your power bank battery & increases battery life Constant boosting @ 5v giving extremely stable output Low voltage boosting for solar (Low light charging) During solar charging, power bank provides safety against current spiking and excess sun Dual Charging while charging through AC &...
- Page 15 APPLICATIONS On the go charging During black outs While traveling During car breakdowns Ideal camping tool During natural calamities Kerosene lamp replacement WARNING Above 80˚C FIRE WATER TEMPERATURE DROP DIRECT LAMP DISASSEMBLE EXPOSURE...
- Page 16 ET-Stone™ is the result of our 2 years of careful designing, research & combination of the best components from all over the globe. A seamless intergration of state of the art technology & ergonomic design makes it by far the smartest solar power bank &...
