- Page 1 INSTALLATION INSTRUCTIONS 412 137 Certification reference guide Family 4 NF205 No. 4061 Index C www.marque-nf.com Date 01/2011...
-
Page 2: Table Of Contents
5.1. Inserting the batteries into the mobile control ... 7 6.6. Input-Output diagram for the circuit board ..22 5.2. Linking procedure for your Duolix Max unit ... 8 6.7. Maintenance of the Duolix MAX unit ..23 5.3. Positioning the mobile control....... 8 5.4. -
Page 3: Warnings
1. WARNINGS CAUTION: This appliance is not designed for use by people (including children) of reduced physical, sensory or metal capacity, or those inexperienced or ignorant unless they have received prior instruction or supervision from someone responsible for their safety, about the use of the appliance The central unit must be installed in the living area of the house and not in the roof spaces. -
Page 4: Technical Specifications
2.4. Technical specifications Max. flow 300 m3/h under 100 Pa. Electrical specifications: • Certified electrical power: 24.1 to 70.5 W-Th-C. • Max. 200 W consumption for the two fans (maximum current = 1 A) • In the case of optional output wiring: max. consumption of 100 W (maximum additional current = 0.5 A) 3. -
Page 5: Installation/Accessory Precautions
• The duct cover is in three sections. • Attach each section to the other using the lugs designed for this purpose. • Position the front panel on top of the Duolix MAX, with the sides apart and then clip them onto the designated hooks. -
Page 6: Condensation Connections
3.7. Condensation connections Clip the condensation union under the product (supplied). Connect the waste pipe (not supplied) to the drain. Fill the siphon and immerse the waste pipe to prevent suction noises. Use a transparent siphon, if possible, so that the water level can be checked. The siphon should always be filled. -
Page 7: Upstream Connection
To connect the product to the 230 VAC electrical supply, it does not need to be opened. The Duolix MAX is a class I device and must be connected to earth. Supply with a 1.5 mm² rigid, dual-insulation cable or 1.5 mm² wires under an annealed sleeve with a maximum diameter of: 16 mm held in position by a tear protection compliant with standard NF C15- 100 and good practice. -
Page 8: Linking Procedure For Your Duolix Max Unit
The flashing message «OFF» is displayed and the symbol appears on the screen. The «OFF» message indicates that the control is not linked to the Duolix MAX unit. Linking them enables the control and the Duolix MAX unit to recognise each other and to communicate with each other (no interference possible with another unit in the vicinity). - Page 9 To solve this, move towards the Duolix MAX unit’s mobile control. If the problem persists, carry out the linking procedure again. Refer to paragraph 5.2 «Linking procedure with the unit».
-
Page 10: Configuring The Product According To The Installation
- a specific menu for the occupant of the house To configure the Duolix Max it is necessary to go into the «installer» menu. To do this, press the «left arrow» and «right arrow» at the same time for three seconds. -
Page 11: Adjusting The Flows
5.4.2. Adjusting the flows Duolix has optimum flow management to limit energy consumption as much as possible while complying with regulations in force. It adjusts the extraction flow and air flow with precision in accordance with the order to activate the large kitchen flow or not. To do this, it is necessary to provide the unit with two flow values. -
Page 12: Adjusting The Imbalance
Provide the control with the «Val 1» value from the previous table. Use the navigation arrows to increase or reduce the desired flow value. Then validate the desired value by pressing Val 1 When the symbol OK appears, the choice is confirmed. Provide to the control with the value «Val 2»... -
Page 13: Choosing The Night Cooling Management Mode
5.4.5. Choice of night cooling management mode The Duolix MAX manages by default, automatically, night cooling in accordance with certain temperature conditions. For example, during a summer’s night, the system will increase the ventilation flow (to the value set in the previous chapter) when the temperature conditions are satisfactory to benefit from efficient night cooling. -
Page 14: Adjusting The Filter's Service Life
Upper threshold value: (recommended as 24°C) Use the navigation arrows to increase or reduce the upper temperature threshold. Then confirm the desired value by pressing When the Ok symbol appears, the choice is confirmed. °C Lower threshold value: (recommended as 12°C) ... -
Page 15: Choosing The Absence Management Mode
5.4.8. Choosing the absence management mode The Duolix MAX enables you to reduce the flows when the occupant is not at home. There are two management modes: • Default, with no additional options, the occupant may, before his departure, activate absence mode and program the time he will be absent. -
Page 16: Defining The Connected Accessories
In the temperature range between these thresholds, the duct is negligible; it is therefore preferable to pass through the fresh air inlet directly. The Duolix MAX therefore controls this valve managing the fresh air source to be used in the house. Lower threshold value: (recommended as 5°C) ... -
Page 17: Finishing Configuration
Upper threshold value: (recommended as 25°C) Use the navigation keys to increase or reduce the value of the upper threshold. Then confirm the desired value by pressing When the Ok symbol appears, the choice is confirmed. °C 5.4.12. End of configuration ... -
Page 18: Appendix
6.2. Option to control the night cooling via a remote switch The Duolix MAX provides the option of controlling the night cooling (either internally or externally) by the mobile control, of course, but also a wired remote switch (usually in the bathroom). -
Page 19: Operational Description
Within the temperature range between these thresholds, the duct is negligible, it is therefore preferable to pass through the fresh air inlet directly. The Duolix MAX controls this valve by managing the source of fresh air used in the house. N.B.: These min. -
Page 20: Wiring An Ground-Connected Heat Exchanger
Relevant example: • Limit the use of the anti-frost function to improve the efficiency of the Duolix MAX in cold or very cold regions: valve on the fresh air network enabling a source of temperate air to be mixed with the fresh air, in a non-living area (garage, cellar, etc.) -
Page 21: Wiring An Auxiliary Device
The output is a «dry contact» type to supply an external component via an external power supply. (see diagram below) Provide a dedicated circuit breaker for this supply. from Separate power supply the Duolix Max unit protected in accordance with the specifications of the auxiliary Duolix MAX circuit board Auxiliary 6.5. -
Page 22: Input-Output Diagram For The Circuit Board
6.6 Circuit board input-output diagram... -
Page 23: Maintenance Of The Duolix Max Unit
