INSTRUCTION MANUAL
TRAXX 5418
Electric Stapler
110-120 V AC
50-60 Hz
IMPORTANT SAFETY INSTRUCTION
WARNING: when using Electric Tools, basic safety precautions should always be followed to reduce the risk
of fire, electric shock, and personal injury, including the following:
READ AND UNDERSTAND ALL SAFETY WARNINGS AND INSTRUCTIONS, before using the tool!
GROUNDING INSTRUCTIONS (See Fig. 1). This tool should be grounded while in use to protect the operator
from electric shock. The tool is equipped with a 3 conductor cord and 3-prong grounding (A) type plug to fit
the proper grounding (B) type receptacle. The green (or green and yellow) conductor in the cord is the
grounding wire and (A1) is the grounding pin. Never connect the green (or green and yellow) wire to a live
terminal. Type (C) adapter, if approved by Safety Regulations in force, may be used for connecting (A) type
plugs to (D) 2-prong receptacles. The (C1) lug must be connected to a permanent ground by (D1) metal
screw, such as a properly grounded outlet box.
EXTENSION CORD. Make sure your extension cord is in good conditions. When using an extension cord,
be sure to use one heavy enough to carry the tool current. An undersized cord will cause a drop in line
voltage resulting in loss of power and overheating. In the Technical Specification is shown the correct size
to use depending on cord length. If in doubt, use the next heavier gage. The smaller the gage number, the
heavier the cord. Use only safety marked 3-wire extension cord that have a 3-prong grounding type plug
and 3-pole receptacle that accepts tool's plug. Replace damaged cord.
OUTDOOR USE EXTENSION CORD. When tool is used outdoor, use only extension cord intended for use
outdoors and so marked. Replace damaged cord.
ELECTRICAL SUPPLY PLANT. Must be grounded AC single phase, in accordance with all local law
ordinance. It must correspond to the voltage and current rating shown on the tool. Never connect the tool
to DC power source, to an unbalanced 3-phase derivated supply or engine generators.
Do not plug the tool to receptacles that are not properly installed and grounded.
KEEP WORK AREA CLEAN. Cluttered areas and benches invite injuries.
CONSIDER WORK AREA ENVIRONMENT. Do not expose power tools to rain. Do not use power tools in
damp or wet locations. Keep work area well lit.
DO NOT OPERATE the tool near flammable liquids or in gaseous or explosive atmospheres. Switches
normally spark and might ignite fumes.
GUARD AGAINST ELECTRIC SHOCK. Prevent body contact with grounded surfaces. For example: pipes,
radiators, ranges, refrigerator enclosures.
Advertisement
Table of Contents
Summary of Contents for TRAXX 5418
- Page 1 INSTRUCTION MANUAL TRAXX 5418 Electric Stapler 110-120 V AC 50-60 Hz IMPORTANT SAFETY INSTRUCTION WARNING: when using Electric Tools, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and personal injury, including the following: READ AND UNDERSTAND ALL SAFETY WARNINGS AND INSTRUCTIONS, before using the tool! GROUNDING INSTRUCTIONS (See Fig.
- Page 2 KEEP CHILDREN AWAY. All visitors should be kept away from work area. Do not let visitors contact tool or extension cord. STORE IDLE TOOLS. When not in use, tools should be stored in dry and high or locked-up place, out of reach of children.
- Page 3 DO NOT USE MALFUNCTIONING TOOL or if parts are missing or damaged. DO NOT ALTER THE TOOL and the plug in any way. ALL REPAIRS MUST be performed by authorized service personnel. Only tool maintenance will be executed by operators as recommended in this manual. NEVER OPERATE the tool without fasteners or off workpiece.
- Page 4 DRIVING FASTENERS Hold the tool firmly against the surface being fastened as in Fig. 3. Hold the tool firmly against the surface being fastened as in Fig. 3. 1. With your hand push the trigger (7) to fire. With your index finger, push forward the SAFETY lever (1) which is then compressed into trigger cavity. 2.
- Page 5 Fig. 1 Fig. 2 Fig. 3 Fig. 4 (OPTIONAL) Fig. 5 Fig. 6...
- Page 6 READ CAREFULLY BEFORE USING THE TOOL If warranty terms are not acceptable, return at once unused for refund LIMITED WARRANTY • WHAT IS COVERED: this warranty covers any defects in material and workmanship. • HOW LONG: the duration of this warranty is 180 days from date or purchase. •...
- Page 8 TRAXX 5418 Electric Stapler REPAIR POLICY The TRAXX 5418 Electric Carpet Stapler is warranted to be free from defects in material and workmanship for 6 months from the date of purchase. This stapler can be sent to TRAXX for repair: An RMF (Return Merchandise Form) may be obtained on-line at: www.traxxcorp.com/products/traxx-tools/electric-stapler-5418...
