Summary of Contents for SGM Giotto Spot 400 CMY

  • Page 2: General Warnings And Instructions

    S SERIAL NUMBER AND MODEL WHEN CONTACTING YOUR RESELLER FOR INFORMATION OR ASSISTANCE Protect the environment: don't throw packing material into your garbage can return it to your SGM retailer or take it to the nearest special waste collection point.

  • Page 3: Table Of Contents

    ............23 ESERVED FUNCTIONS Giotto Spot 400 CMY rel.1.00...

  • Page 4: Presentation

    Presentation Giotto Spot cmy is SGM's innovative professional moving head spot, specifically manufactured for use in high profile shows, thea- tres, Television studios and entertainment venues in general. Thanks to its cutting edge performance, the result of SGM's lengthy experience in mechanical and electronic design, Giotto Spot is one of the world's best.

  • Page 5: Main Features

    Input signal DMX 512 - RS 232 Mounting System - "Fast-Lock" clamps supplied as standard with fixture - Several clamp mounting points to enable the fixture to be mounted on any type of truss - Safety chain/cable mounting points Giotto Spot 400 CMY rel.1.00...

  • Page 6: Accessories

    Accessories - Single flight case cod:0061745 - Double flight case cod:0061746 Symbols used THIS SYMBOL INDICATES A GENERAL RISK THIS SYMBOL INDICATES ELECTRIC SHOCK RISK THIS SYMBOL INDICATES A HOT SURFACE THIS SYMBOL MEANS “DO NOT PLACE THE UNIT ON INFLAMMABLE PARTS OR MATERIAL” THIS SYMBOL INDICATES THAT THE MINIMUM DISTANCE BETWEEN THE FIXTURE AND THE SURFACE TO BE LIT MUST BE NO LESS THAN 1.5 METRES GiottoSpot 400 rel.1.01...

  • Page 7: Electrical Specifications

    ERMOPLAST WEIGHT: 33 KG. DIMENSIONS (MM.) SGM Elettronica reserves the right to improve or modify its products at any time. Always refer to the manual supplied with the unit to avoid any risk of mistakes or operation which does not correspond to manual indications.

  • Page 8: Installation

    Changes to this manual SGM has an on-going product development policy, so the information printed in this manual may not be completely up to date. If any doubts arise regarding the topics covered in this manual or should any further help be required, our online services (internet-server www.sgm.it...

  • Page 9: Access To Internal Components

    2. Remove the cover in the direction indicated by the arrow (Fig. 3) Fig. 1 Fig. 2 3. Unscrew the two threaded pins (1)(2) as shown in Fig.4 4. Swivel the whole block downwards (Fig. 5) Fig. 3 Fig. 4 Fig. 5 Giotto Spot 400 CMY rel.1.00...

  • Page 10: Installing The Lamp

    2. Open the fixture (see paragraph 1.2) and fit the lamp as shown in figures 4, 5, 6 and 7 Fig. 4 Fig. 5 ATTENTION!! When fitting a lamp, always use gloves or soft lint-free cloth - never touch it with your bare hands. Fig. 6 Fig. 7 Giotto Spot 400 CMY rel.1.00...

  • Page 11: Lamp Alignment

    Dichro: After opening the fixture, locate the gobo to be replaced, press delicately downwards (Fig.1) until the spring, ring and the gobo come out, making sure they don't fall inside the fixture. Install the new gobo (3) as shown (Fig.2), followed by the ring (4) and the locking spring (5). Fig.1 Fig 2 Giotto Spot 400 CMY rel.1.00...

  • Page 12: Fitting/Removal Animation Wheel

    Choose which of the wheel's dichroic filters is to be replaced, grip it firmly between your fingers, carefully widen the discs (1), slide the filter out in the direction indicated by the arrow (2). Carefully widen the discs again (3) and slide the new filter in (4) until it fits into its engraved slot. Giotto Spot 400 CMY rel.1.00...

  • Page 13: Constructing A Power Cord

    T LIFT THE FIXTURE HOLDING IT BY THE MOVING PART THE HEAD • P OSITION THE FIXTURE AT LEAST FROM THE SURFACE TO BE LIT • K EEP ANY INFLAMMABLE MATERIAL AT A DISTANCE OF AT LEAST M FROM THE FIXTURE Giotto Spot 400 CMY rel.1.00...

  • Page 14: Positioning The Fixture

    •Fix the fixture to the support structure using safety chains fitted to the 2 holes on the underside of the fixture's base (Fig.2). •Don't fix the safety chain to the handles. 256mm CLAMPS CAN BE USED AS FOLLOWS: Fig. 1 Fig. 2 Fig. 3 Fig. 4 Giotto Spot 400 CMY rel.1.00...

  • Page 15: Signal Cable

    The termination is prepared by soldering a 120Ohm 1/4 W resistor between pins 2 and 3 of the 5-pin male XLR connector (see diagram). 120Ω Giotto Spot 400 CMY rel.1.00...

  • Page 16: Rs232 Connection

    CONNECTOR 2.3 Upgrading the fixture’s firmware To carry out this procedure, the uploader kit connected to a PC and the file containig the software upgrade are required. Up to eight fixtures can be upgraded simultaneously. Giotto Spot 400 CMY rel.1.00...

  • Page 17: Control Microcomputer

    - UP/DOWN keys: used to scroll the various items in the menu. In the selected menu, used to change the required parameters. - ENTER key: used to access to the selected menu and, once the necessary changes have been made, is used to confirm them. Accel down enter Accel enter down Giotto Spot 400 CMY rel.1.00...

  • Page 18: Menu

    Enables to set the offset for calibrating the starting position of the rotating gobos RGOB2=1100 Enables to set the offset for calibrating the starting position of the rotating gobos TEST=RESET Fixture RESET. TEST=ALL TEST=PAN TEST=TILT TEST=COLOR TEST=GOBO1 TEST=GOBO2 TEST TEST=RGOB1 TEST=RGOB2 TEST=SHUTT TEST=DIMM TEST=FROST TEST=FOCUS TEST=ZOOM Giotto Spot 400 CMY rel.1.00...

  • Page 19: Allocating The Start Channel ( Addressing )

    Use the UP/DOWN keys to find the “Pmove” menu Press ENTER to confirm. The message on the display will start to flash. Use the UP/DOWN keys to select which of the two available options is required (see table pag.17). Press ENTER to confirm. Giotto Spot 400 CMY rel.1.00...

  • Page 20: Pan

    Connect Giotto Spot to the power supply, wait till it has completed reset operations and “DMX signal” appears on the display. Use the UP/DOWN keys to find the “Lmp_H” menu. The total number of hours the lamp has been lit will be displayed automatically. Giotto Spot 400 CMY rel.1.00...

  • Page 21: Lamp Strike ( Ignition ) Counter

    Use the UP/DOWN keys to find the ““SMD” menu. Press ENTER to confirm. The message on the display will start to flash. Use the UP/DOWN keys to select the type of resolution required. Press ENTER to confirm the modifications. Giotto Spot 400 CMY rel.1.00...

  • Page 22: Remote Controlled Fixture Reset

    Use the UP/DOWN to find the “DMXDLY” menu. Press ENTER to confirm. The message on the display will start to flash. Use the UP/DOWN keys to select the required time. Press ENTER to confirm changes. Giotto Spot 400 CMY rel.1.00...

  • Page 23: Locking/Unlocking The Shutter

    Set the offset with the UP/DOWN keys Press ENTER to confirm (the writing stops flashing) and return to the SETTING submenu Once all the settings have been done, press ENTER for 4 seconds to exit the Setting menu. GOB2=0 RGOB1=0 RGOB2=0 Giotto Spot 400 CMY rel.1.00...

  • Page 24: Test Functions

    Some fixture functions can't be accessed by operators as they regard software sections as yet to be defined in this Reserved firmware release. When RESERVED appears on the display, you're in this section. Access is forbidden. Giotto Spot 400 CMY rel.1.00...
  • Page 25 Animation Wheel Rotation Animation wheel rotation ch30 Cyan Linear Cyan insertion ch31 Magenta Linear Magenta insertion ch32 Yellow Linear Yellow insertion ch33 Linear Cto insertion Iris (Ch5) FUNCTION VALUE 0 - 255 LINEAR OPENING REGULATION 0 – 100% Giotto Spot 400 CMY rel.1.00...
  • Page 26 MUSIC HARD CHANGE FULL COLOR 176 – 191 SPEED 12 128 – 255 MUSIC HARD CHANGE ALF COLOR 192 – 207 SPEED 13 208 – 223 SPEED 14 224 – 239 SPEED 15 240 – 255 SPEED 16 Giotto Spot 400 CMY rel.1.00...
  • Page 27 OPEN AUTOSHADE ON COLORS 188 -- 204 OPEN AUTOSHADE ON GOBOS AND COLORI 205 -- 221 OPEN WITH SLOW GOBO CHANGE 222 -- 255 OPEN Dimmer (Ch9) FUNCTION VALUE 0 – 255 LINEAR REGULATION 0 – 100% Giotto Spot 400 CMY rel.1.00...
  • Page 28 DOWN ROTATION [MAX . . .MIN] 112 – 144 FIXED 145..255 UP ROTATION [MIN … MAX] Gobo2 rotation mode (Ch27) FUNCTION VALUE 0..127 GOBO2 INDEXABLE POSITION 128 . . 255 GOBO2 ROTATION AT DIFFERENT SPEED IN BOTH DIRECTIONS Giotto Spot 400 CMY rel.1.00...
  • Page 29 INSERTED. Animation wheel rotation (Ch29) FUNCTION VALUE 0 . . 111 ROTATION DOWN [MAX . . MIN ] 112 – 143 ANIMATION WHEEL FERMA 144 . . 255 ROTATION UP [MAX . . MIN ] Giotto Spot 400 CMY rel.1.00...
  • Page 30 178 – 190 GOBOSHAKE SPEED 11 191 – 203 GOBOSHAKE SPEED 12 204 – 216 GOBOSHAKE SPEED 13 217 – 229 GOBOSHAKE SPEED 14 230 – 242 GOBOSHAKE SPEED 15 243 – 255 GOBOSHAKE SPEED 16 Giotto Spot 400 CMY rel.1.00...
  • Page 31 4 . . 255 SLOWEST . . FASTEST Remote lamp striking and reset (Ch18) FUNCTION VALUE 10 – 60 LAMP 61 – 129 HYSTERESIS 130 -- 179 180 – 239 HYSTERESIS RESET 240 – 255 RESET Giotto Spot 400 CMY rel.1.00...
  • Page 32 160 – 167 168 – 175 176 – 183 184 – 191 192 – 199 200 – 207 208 – 215 216 – 223 224 – 231 232 – 239 240 – 247 248 – 255 Giotto Spot 400 CMY rel.1.00...
  • Page 33 Channels Conversion table MSPEED MSPEED MSPEED MSPEED VALUE (in seconds) VALUE (in seconds) VALUE (in seconds) VALUE (in seconds) 0 -- 1 cross fade cross fade cross fade Giotto Spot 400 CMY rel.1.00...
