Series 1600
Heat Circulating Fireplace
Installation Instructions
K & W Manufacturing Co., Inc.,
951-277-3300 Phone
Dimensions
Heating
Model
Capacity
No.
(Cu. Ft.)
A
1634A
5300
33
1636A
5800
36
1642A
6000
42
1648A
7000
48
Heating capacity ratings based on 20
•
Made from Heavy Gauge Steel
•
Poker or Optional Rotary Control
23107 Temescal Canyon Road, Corona CA 92883
951-277-2070 FAX
www.k-and-w-mfg.com
B
C
D
E
28
22.75
16.5
39.5
19.5
28
25.75
16.5
42.5
19.5
28
30.75
16.5
47.5
19.5
29
36.75
20.5
53.5
23.5
o
F above zero. All dimensions are in inches unless stated otherwise.
•
Conforms with IBC
•
Insulation provided to prevent
masonry cracking
J
F
G
H
Min.
Min.
28
50
65
31
50
68
37
50
74
42
54
80
®
®
& IRC
Page 1 of 6
K
28
28
28
32
Advertisement
Table of Contents
Related Manuals for FireMagic 1600
Summary of Contents for FireMagic 1600
- Page 1 Series 1600 Heat Circulating Fireplace Installation Instructions Dimensions Heating Model Capacity (Cu. Ft.) Min. Min. 1634A 5300 22.75 16.5 39.5 19.5 1636A 5800 25.75 16.5 42.5 19.5 1642A 6000 30.75 16.5 47.5 19.5 1648A 7000 36.75 20.5 53.5 23.5 Heating capacity ratings based on 20 F above zero.
- Page 2 When a raised hearth is used, the inlets should be placed in the hearth at floor level. The Series 1600 circulator is designed with a single hot air outlet directly over the fireplace opening.
- Page 3 Series 1600 Heat Circulating Fireplace Installation Instructions Alternative Configurations The drawings on this page and the following page show alternative fireplace configurations that can be achieved with a Fire Magic heat circulating fireplace. Model Min. Min. 1634A Drawings and dimensions depicting a fireplace that projects 1636A into the room with air inlets on the sides.
- Page 4 Series 1600 Heat Circulating Fireplace Installation Instructions Alternative Configurations ...continued Model Min. Min. Min. 1634A 1636A 1642A 1648A Drawing and dimensions depicting a corner fireplace. The left side shows a straight front. The right shows an angled front. Drawing and dimensions depicting two fireplaces set back to back.
- Page 5 Series 1600 Heat Circulating Fireplace Installation Instructions Construction Details Continued from page 2 Fire Magic Circulator: Set the Fire Magic unit on the firebrick without mortar or other material underneath. Completely cover the unit with the insulation furnished. A thin mixture of mortar brushed on the unit will hold insulation in place. This insulation material is important.
- Page 6 Series 1600 Heat Circulating Fireplace Installation Instructions Construction Details Continued from page 5 IMPORTANT: The air from the hot air outlet is just as hot (if not hotter) as the heat produced inside the firebox. For that reason, the combustible clearances for the hot air outlet is the same as the clearances from the fireplace opening. Ducting the hot air directly from the outlet through any combustible materials is not recommended.
