Summary of Contents for Sonken DSP-220
- Page 1 DSP-220 PROCESSOR SOUND SYSTEM FOR KTV DIGITAL KARAOKE PROCESSOR REFERENCE MANUAL Kindly please go through this reference manual before operation of this appliance and keep this manual for further uses...
- Page 3 Be sure to switch the power off. The white input/output jacks of the amplifier are designed for the left channel, while the Red jacks are for the Right channel. Insert the plugs of the connection cords securely into the jacks.
-
Page 4: Remote Control
REMOTE CONTROL USER1 USER2 Four effect storage key Four effect storage key USER3 USER4 MUTE F.B-EX INPUT AOTO Mut e ke y F.B-EX from weak to Audio input key strong,level 0-3 Music rising/falling Tone key Effect level control EFF VOL MIC volume control MIC VOL MASTER VO L... - Page 5 NAME OF FRONT PANEL AND FUNCTION 18 19 1.MIC1 AND A EFFECT LEVEL KNOB Control MIC1 & MIC A effect level 2.MIC2/3 AND B EFFECT LEVEL KNOB Control MIC2/ MIC3 and MIC B effect level 3. ADJUST PARAMETER STORE KEY Adjust the pre-store parameter, pre-store custom effect/factory setting 4.
- Page 6 NA ME O F RE AR PAN EL A ND F UN C TI O N 15 16 17 VIDEO OUT1 LEFT RIGHT CENTER SUBWOOF MIC INPUT DIGITAL IN S/PDIF SURR RS 232 CENTER MIC MIX LEVEL VIDEO OUT2 PRE OUT SURR MIC B MIC A...
-
Page 7: System Connection
SYSTEM CONNECTION surround speaker master speaker personal computer microphone PMA 1200 CLIP STAND BY SIGNAL Class H Professional Amplifier PROTECT POWER ACTIVE CH 1 CH 2 professional amplifier PMA 1200 CLIP STAND BY SIGNAL Class H Professional Amplifier PROTECT POWER ACTIVE CH 1 CH 2... - Page 8 MENU LIST MIC CHANNEL FUNCTION MENU EFFECT STORAGE FUNCTION 中置音量，遥控进入菜单出现 最大话筒音量控制 低音音量，遥控进入菜单出现 话筒回声延时 最大音乐音量限制（0-63） 卡拉ok话筒输出模式 低音衰减器（OFF0 +20） 噪声门 低通滤波器（40～150Hz） 话筒激励 音乐自动电平（1 6） 反馈抑制时间 音乐消歌声 五段均衡器 环绕音量 五段均衡器 环绕声输出模式选择 五段均衡器 声道输出平衡 五段均衡器 音乐高音 五段均衡器 音乐中音 混响电平 音乐低音 混响时间 背景音乐音量 回声重复次数 （数字信号输入通道下出现。PCM频率选择） 混响模式（数字信号输入通道下出现）...
-
Page 9: Troubleshooting
TROUBLESHOOTING... -
Page 10: Specifications
SPECIFICATIONS When largest volume, input 1 kHz analog signal, output 1V (RMS), testing in 10K ohms load condition: MUSIC CHANNEL Music frequency response 20Hz ~ 20KHz Music input signal sensitivity 185mv BGM input signal sensitivity 285mv Maximum music output effect level 4.5V（THD≤0.5%）...
