Remote Sensor
LED Power Mode indication
Red
= Standby or protection
Green = ON
5
Indicators and Remote Control
Indicates which source
is selected.
Indicates that Tape 2 has been
selected. In this case, only the
output of the tape deck connected
to the TAPE 2 jacks can be heard.
INDEPENDENT REMOTE
CONTROL
The keys on the remote control unit
function the same as the corresponding
buttons on the amplifier itself.
The remote control unit also includes
many keys that allow for easy control of
compatible Harman/Kardon cassette
tape deck, CD player and tuner.
Please refer to the owner's manual for
each unit for operating instructions.
TAPE 2
Some of these units must be connected
to the amplifier's remote control output
jacks so that the system remote control
can operate them.
OPERATING CONDITIONS
The control unit operates effectively
within a distance of 7 meters and an
angle of 30° from the amplifier. Using the
VID 2
control near fluorescent lights may
shorten this range, as will any dust or dirt
PHONO
that accumulates on the front of the
remote control, or the remote sensor
area of the amplifier. Also avoid blocking
the line of sight between amplifier and
remote.
The control unit is powered by two AA
batteries, included with your amplifier.
When you replace weak batteries,
replace both at the same time. When the
remote is to be unused for an extended
HK 650/690
period, remove the batteries to prevent
damage from corrosion.
