SPECIFICATIONS AND DIMENSIONS

Figure 1. Dimensions of boiler
Boiler
A
Model
mm in
KC-50 394 15-1/2
KC-100 470 18-1/2
Boiler
High Fire
Model
W Btuh
KC-50 14 500 50,000
KC-100 29 500 100,000 14 500 50,000
2
B
mm in
254 10
330 13
Input
No. of
Low Fire
Sections
W Btuh
7 500 25,000 1
2
DIMENSIONS
C D
mm in mm
102 4 152
178 7 229
Gas Supply
Pressure
Gas
Max
Type
mm in
Natural 229 9
Propane 356 14
Natural 229 9
Propane 356 14
E
in mm in
6 267 10-1/2
9 343 13-1/2
Shipping
Weight
Max
mm in kg lb
89 3.5
100 220
279 11
89 3.5
127 280
279 11
F
mm in
32 1-1/4
89 3-1/2
Boiler
Water
Volume
L U.S. gal
1.9 0.5
3.8 1.0
