TOP VIEW
IMPORTANT
Use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.

Player Function :

1. POWER BUTTON
Press the power switch to turn the unit on. To switch the POWER off press the POWER switch
again.
2. MIC INPUT
Plug 1/4" microphone plug in here.
3. SD CARD SLOT
Slot for inserting SD/MMC card.The contacts of the card must point downwards.The unit cannot
read cards with a capacity of more than 4GB.The unit is not compatible to SDHC cards and only
supports the MP3 format.
4. USB PORT
Allows the connection of any USB memory stick.
5. MIC GAIN
Adjusts microphone level.
6. MASTER LEVEL
Adjusts master level output signal.
7. PHONE LEVEL
Adjust phone level
8. When you enter into SD work mode.the lamp can light.
9. When you enter into USB work mode. the lamp can light.
10 ． ． ． ． SD/USB BUTTON
Press this button to choose SD or USB mode.
11. PHONES
Use to connect for audio monitoring with headphones.
12. TRACK/FOLDER
Press the control to indicate the name of the folder currently select.
3
