Explorer 2200 Installation Instructions

Explorer ®

Before Installing the DHCT

Before you begin to install the DHCT, locate the DHCT serial number. The serial number is located on the back panel of the DHCT, and looks
similar to this example:
The serial number is located in the lower left corner of the bar code. Write the serial number here: _______________ . It is always good to
have the serial number on file. If your system requires troubleshooting in the future, our customer service professional may ask for the serial
number. If you plug the DHCT into an outlet that is controlled by a wall switch, keep the switch in the ON position. The on-screen guide is
updated nightly. If the wall switch is in the OFF position, your DHCT will not receive the latest programming updates. Keep the top of the
DHCT free of all objects and electronic devices, including your TV. It is recommended that you use a surge protector with your cable equip-
ment and electronic devices.
1 Message Indicator
2 LED Display
3 Guide
4 Info
5 Bypass Indicator
6 USB (Universal Serial Bus) Connects to external equipment, such as a keyboard, external modem, or similar equipment*
7 Exit
8 Settings
9 Smart card slot
10 Select
11 CH+ and CH-
12 VOL+ and VOL-
13 Power
*Contact our Customer Service Professionals at 816-268-3000 for more information.
2200 Digital Home Communications Terminal

Installation Instructions

T9883
Indicates a message from Everest is waiting when blinking or illuminated. To access
the message, press the Info key.
Displays the selected channel number and time of day
Accesses on-screen services, such as the on-screen guide and pay-per-view
Displays a description of the selected program; available from the on-screen guide and while viewing a
program
Indicates the optional bypass feature is on when illuminated*
Exits menus, on-screen guide, and program information
Accesses the Settings menu
Allows smart card access*
Accesses your on-screen selection
Scrolls up and down through the channels
Increases and decreases volume
Provides power to the DHCT. The light to the left of the Power key illuminates when the power is on. To
receive nightly programming updates, keep the power on.
0003B4287797
SABDQXTL N0006246618

DHCT Front Panel

GUIDE
BYPASS
1 2 3 4 5 6
CH +
INFO
VOL ó VOL +
EXIT
SETTINGS
POWER
CH ó
7 8 9 10 11 12 13
