Page 1: Operation Guide
AVN805 MEGAPIXEL NETWORK CAMERA SERIES OPERATION GUIDE Please read instructions thoroughly before operation and retain it for future reference. n805_system_V1.1... - Page 2 IMPORTANT SAFEGUARD All lead-free products offered by the company comply with the requirements of the European law on the Restriction of Hazardous Substances (RoHS) directive, which means our manufacture processes and products are strictly “lead-free” and without the hazardous substances cited in the directive. The crossed-out wheeled bin mark symbolizes that within the European Union the product must be collected separately at the product end-of-life.
- Page 3 MPEG4 Licensing THIS PRODUCT IS LICENSED UNDER THE MPEG4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR (i) ENCODING VIDEO IN COMPLIANCE WITH THE MPEG4 VISUAL STANDARD (“MPEG-4 VIDEO”) AND/OR (ii) DECODING MPEG4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG4 VIDEO.
-
Page 4: Table Of Contents
3.4 Record Timer............................13 3.4.1 Record................................13 3.4.2 Record Timer..............................14 3.5 Storage..............................14 3.5.1 Memory ................................14 3.6 Trigger ..............................14 3.6.1 Trigger ................................14 3.6.2 Push Video ..............................16 3.7 General ..............................16 3.7.1 General................................16 3.7.2 Time................................17 3.7.3 Server Log..............................17 3.7.4 Online ................................18 3.7.5 Account................................18 3.7.6 Maintenance..............................19... -
Page 5: Overview
Memory storage built-in for video recording Push Video support to send an event notification to your iPhone, iPad and Android mobile devices immediately once the specified event type is triggered, and play video recording once you confirm the receipt. -
Page 6: Reset Default
1.4 Reset Default 1. Push to remove the white cover from the camera. 2. Insert and slightly push the clip to the reset button, and hold till the camera is rebooted. Note: This operation will restore all configurations to factory default values, including network setup. -
Page 7: Camera Access With Internet Explorer
2. CAMERA ACCESS WITH INTERNET EXPLORER This network camera can be accessed via Microsoft® Internet Explorer® and iPhone / iPad / Android mobile devices with our self-developed program “EagleEyes” installed depending on different using situations. Note: For details about accessing network cameras via iPhone / iPad / Android mobile devices, please refer to http://www.eagleeyescctv.com. - Page 8 SXVGA (1280 x 960) 720P (1280 x 720) VGA (640 x 480) QVGA (320 x 240) When Push Video is on, the live resolution will be fixed to VGA. Supervisor / Power User Live View Size: / Normal User The current live view size is the same as the selected resolution.
-
Page 9: Digital Ptz (Dptz) Operations
2.3 Digital PTZ (DPTZ) Operations This camera has PTZ capability, i.e. digital PTZ (hereafter called “DPTZ”), for wide area monitoring. STEP1: Click “DPTZ” to show the DPTZ control panel. STEP2: Select the functions when needed: ICON FUNCTION DESCRIPTION There are several display resolutions available. When the selected resolution is out of your current live view support, a part of your surveillance area might get covered on the screen, and you need to manually move on the screen to check the covered part. -
Page 10: Event Record Search & Playback
2.4 Event Record Search & Playback Click to jump to the next / previous time interval in an hour, for example, 11:00 ~ 12:00 or 14:00 Previous / Next Hour ~ 15:00, and start playing the earliest event video clip recorded during this whole hour. Fast Forward Increase the speed for fast forward. -
Page 11: Camera Configurations
Check the current storage capacity and clear all recorded data when needed. Trigger Trigger Configure how the camera reacts for any event. Push Video Set Push Video rules. 1. Select the language of the web browser. General General 2. Check the MAC address of the camera. -
Page 12: Network
3.2 Network 3.2.1 Network You can set the network configuration of the network camera depending on your network type. For details, please refer to “Advanced Network Setup” from www.surveillance-download.com/user/n805.swf. 3.2.2 DDNS Select “On” when the selected network type in “Network” is “PPPOE” or “DHCP”. For details, please refer to “Advanced Network Setup”... -
Page 13: Mail
3.2.5 MAIL Enter the detailed e-mail information and click “Save” to confirm. The information you set here will be applied when “Email” is selected in “Trigger” → “Trigger”. Function Description SMTP Server Enter the SMTP server address provided from your e-mail system supplier. Port Enter the port number provided from your e-mail system supplier. -
Page 14: Upnp
3.2.7 UPnP “UPnP” stands for “Universal Plug and Play”, which allows devices to connect seamlessly in the home and corporate environments and simplify installation of computer components. Check “Enable” to allow the network camera to be detected among devices within the same network area, and set the identification name of the camera in “Friendly name”. -
Page 15: Preset
Item Description Set the desired image frame rate to the maximum (FULL) or to a specified frame rate (1/2; 1/3; 1/4; 1/5; 1/10; 1/15). The actual frame rate depends on the actual network connection, and may be lower than the specified one. Power Line Frequency Select only when your camera video keeps flashing. -
Page 16: Cruise
3.3.3 Cruise Note: Before using this function, make sure you have finished setting several preset points. Here defines how the auto mode of the camera is going to work when is selected: Sequence or Auto Pan. Auto Pan When “Auto Pan” is selected here and is clicked on the DPTZ page, the camera will start panning in the 5x zoom-in ratio. -
Page 17: Color
3.3.4 Color Adjust the color performance from Brightness, Contract, Hue and Saturation. Click and drag the slider to preview the color change on the right side of ths page and adjust the image color. To restore the default values, click “Reset Default”. 3.4 Record Timer 3.4.1 Record In “Record Configuration”, you can:... -
Page 18: Record Timer
3.4.2 Record Timer To schedule alarm or human detection recording, click “External Alarm” or “Internal Alarm” to enable the recording, and select the time for recording. Note: The timer must be enabled for the record function to work properly. 3.5 Storage 3.5.1 Memory In “Memory”, you can check the remaining capacity of flash memory storage, or clear all recorded data saved if needed. - Page 19 Click “Select All” to set the whole area under detection. Enable (ON) or disable (OFF) PIR detection. For Push Video to work properly, make sure this function is enabled. Trigger Duration Set the duration time for trigger recording (5 / 10 / 20 / 40 seconds).
-
Page 20: Push Video
When this function is enabled, the image resolution is fixed to “VGA”. Slow Shutter Lock Select to fix the slow shutter level to level 2 (Enable) or remain the current slow shutter level (Disable) when Push Video is enabled. When this function is enabled, it could ensure Push Video recording to get clear images when the environment is dark. -
Page 21: Time
3.7.2 Time Set daylight saving time and the current time, and click “Save” to confirm. Function Description Time Configuration Set the current date. Date Set the current time. Time Daylight Saving Time Configuration Specify whether to use daylight saving time (Enable / Disable). Daylight Saving Time If this function is enabled, set the time period (Start Time / End Time), and adjust the daylight saving time in hours (Adjust Time). -
Page 22: Online
3.7.4 Online Note: This function is available only for “Supervisor”. You can check the current online user(s) with respective online information. To refresh the list, click “Reload”. To allow anonymous login, select “Enable” in “Anonymous Viewer Login”. To disable image code verification at login, select “No” in “Login with CAPTCHA Image”. 3.7.5 Account Note: This function is available only for “Supervisor”. -
Page 23: Maintenance
System Configuration Backup This function is used to copy your system configuration to a “System.bin” file. You may import the same system configuration to another AVN805, or restore your system configuration when AVN805 is reset to default values. Select “System.bin” in “Firmware Upgrade”, and select “Upgrade” to import the system configuration. -
Page 24: Appendix 1 Product Specifications
& Android mobile device Memory Storage Built-in RTC (real-time clock) Motion Detection Digital Pan / Tilt / Zoom Push Video / FTP / Email Event Notification Pentium 4 CPU 1.3 GHz or higher, or equivalent AMD ‧ 256 MB RAM ‧... -
Page 25: Appendix 2 Bit Rate Table For Reference
APPENDIX 2 BIT RATE TABLE FOR REFERENCE The data below is for reference only. The bit rates listed here may vary depending on the resolution, image quality & frame rate you choose, the complexity of your monitoring area, and how often the moving objects show in your monitoring area. Testing Environment ... - Page 26 Resolution Quality Frame Rate (Dynamic) kbps (Static) kbps SXGA Best 1/15 High Normal Basic Best High Normal Basic QVGA Best High Normal Basic...
-
Page 27: Appendix 3 Q&A
(Recommended) To have the best image fluency, select QVGA; to have the best image quality, select “SXVGA”; to have normal image fluency and quality, select “VGA”. “Push Video” is an active notification system, different from traditional FTP & Email notification methods. What’s “Push Video”? When “Push Video”...
