- Page 1 User’s Manual LX-118A Antes de utilizar el equipo, lea la sección “Precauciones de seguridad” de este manual. Conserve este manual para futuras consultas. Before operating the device, please read the “Safety precautions” section of this manual. Retain this manual for future reference.
-
Page 2: Table Of Contents
CONTENTS SAFETY PRECAUTIONS WARRANTY DECLARATION OF CONFORMITY INTRODUCTION CONFIGURATIONS 12 aero 20A + 4 LX-118A (rigging) 8 aero 20A + 4 LX-118A (stacking) SPECIFICATIONS LINE DRAWINGS AMPLIFIER 9 to 13 Description ON / OFF Overload Indicators Equalisation Overheating Low mains voltage... -
Page 3: Safety Precautions
Any changes made to the product have to be ser documentado por escrito y aprobado por el comprador en el documented in writing and passed on to the buyer in the event momento de la reventa. of resale. Manual del Usuario / LX-118A / User’s Manual... -
Page 4: Warranty
To claim a warranty repair, do not open or intend to repair the product. Return the damaged unit, at shippers risk and freight prepaid, to the nearest service center with a copy of the purchase invoice. Manual del Usuario / LX-118A / User’s Manual... -
Page 5: Declaration Of Conformity
Part 1:Emission. EN 55103-2:2009 Electromagnetic compatibility. Product family standard for audio, video, audio-visual and entertainment lighting control apparatus for professional use. Part 2:Immunity. Manual del Usuario / LX-118A / User’s Manual... -
Page 6: Introduction
The LX-118A uses the DAS 18LXN neodymium speaker equipped with a 4" voice coil. The improved coil materials, magnet and enclosure design provide optimal results with high power, low power compression and low distortion. -
Page 7: Configurations
CONFIGURATIONS Here we can see two examples. In our website you can find more configurations. 12 x Aero 20A + 4 x LX-118A Example for rigging Cardioid eCP_20 eCP_20 PUSH PUSH PUSH eCP_20 eCP_20 6 x MCB 16A “C” 1pol. -
Page 8: Specifications
50 x 65 x 81 cm 19.7 x 25.6 x 31.9 in Weight 47 kg (104 lb) Accessories AX- LX118 Rigging System Pick-up AX-aero20 AX-118S20 Stacking aero20 accessory PL-118S Flatbed Dolly FUN-2-LX118 LINE DRAWINGS Manual del Usuario / LX-118A / User’s Manual... -
Page 9: Amplifier
Neutrik PowerCon TRUE1 mains connector. Only use this equipment with an appropriate mains cord. 12) AC OUTPUT : Neutrik PowerCon TRUE1 mains connector for connecting several units of LX-118A (please, see the maximum value on the label). 13) ID DASNET : Label with identification number for DASnet . - Page 10 The rain protectors supplied with each unit have been manufactured with fireproof materials. The rain protector features several small holes on the top side to allow convection cooling of the amplifier. Rain protector of LX-118A Manual del Usuario / LX-118A / User’s Manual...
-
Page 11: On / Off
DASnet Normally it is enough just to let the unit cool View of with the cardioid presets down after you have corrected the problem so that the system functions properly again. Manual del Usuario / LX-118A / User’s Manual... -
Page 12: Current Consumption
80 and 90 Hz. the satellite system. The use of an external delay To use LX-118A onto Aero 20A, you must select to control and adjust the phase of the subs is the 80Hz and the cardioid preset OFF. This preset recommended (with a digital processor, for is appropriate for aligning with Aero 20A. -
Page 13: Troubleshooting
2 – Faulty AC cable. 2.– Check the cables, connectors and AC power with a suitable mains 3 - Internal fuse blown tester. 3 - Replace the fuse for another of the same size and type. Manual del Usuario / LX-118A / User’s Manual... -
Page 14: Rigging System
When flying a system, the working load must be lower than the resistance of each individual flying point in the enclosure, as well as each box. This manual contains needed information for flying D.A.S. Audio line array LX-118A systems, Hanging hardware should... - Page 15 Guides Guides Triggers AX-LX118 + LX-118A Note: The way to act on all your guides is similar to the way of acting on the front guides of the Aero 20A (see rigging manual of Aero 20A). We will show the cardioid configurations separately in order to appreciate the diferences and similarities.
