Installation manual
Operating instructions
Index
1
General ................................................................................................................................................................................... 2
2
Transport and installation ....................................................................................................................................................... 2
3
Dimensions and connections .................................................................................................................................................. 3
4
Technical data ........................................................................................................................................................................ 4
5
Installation .............................................................................................................................................................................. 5
6
Commissioning ....................................................................................................................................................................... 6
7
Maintenance and wear parts .................................................................................................................................................. 6
8
Warranties and guarantee ...................................................................................................................................................... 7
9
Installation record ................................................................................................................................................................... 8
© Wikora GmbH
Solar combi tank
with DHW heat exchanger
WIKOSOL 805
Installation
and
undertaken by a specialist.
General terms and conditions of warranty state that
all installations must be carried out by a suitably
trained and qualified plumber who observes the
local norms and regulations.
The installation and maintenance record must
be entirely completed and the user has to be
instructed accordingly.
Efficient operation can only be guaranteed if the
instructions of this manual are followed.
Warranty does not cover any damage caused due
to non-observance of this manual and the technical
rules in force.
The system is to be checked annually by a
specialized company. In addition, occurring defects
must be repaired immediately.
This document should be handed over to the
client on completion of the installation.
.
Page 1
WIKORA GmbH
Friedrichstr. 9
89568 Hermaringen
Phone: (07322) 9605-0
Fax: (07322) 9605-30
email: contact@wikora.de
commissioning
must
As of 5/12/2014
Errors excepted.
be
Advertisement
Table of Contents
Summary of Contents for WIKORA WIKOSOL 805
- Page 1 Fax: (07322) 9605-30 email: contact@wikora.de Installation manual Solar combi tank Operating instructions with DHW heat exchanger WIKOSOL 805 Installation commissioning must undertaken by a specialist. General terms and conditions of warranty state that all installations must be carried out by a suitably trained and qualified plumber who observes the local norms and regulations.
-
Page 2: General
1 General Depending on the type and design, WIKORA tanks are suitable for heating and / or storing DHW and / or heating water. The heating is achieved indirectly via heat generators, if applicable, from different heat sources. The maximum working pressure and working temperature can be found in the technical data. -
Page 3: Dimensions And Connections
Aux boiler flow / return Solar flow / return 6 / 7 Heating flow / return 10 / 11 Plug for electric heater Sensor clamp Chart 2 Gi = female thread © Wikora GmbH Page 3 As of 5/12/2014 Errors excepted. -
Page 4: Technical Data
4 Technical data Typenbezeichnung Wikosol 805-0 Wikosol 805-1 Wikosol 805-2 Capacity [litre] Max. working temperature tank [° C] Max. working temperature tank DHW / solar heat [° C] 95 / 130 95 / 130 95 / 130 exchanger Max. working pressure DHW / solar heat exchanger... -
Page 5: Installation
50 kW 100 kW 200 kW 350 kW 600 kW 900 kW 3,0 bar 56 kW 112 kW 224 kW 395 kW 678 kW 1017 kW Thread diameter (inch) ¾ © Wikora GmbH Page 5 As of 5/12/2014 Errors excepted. -
Page 6: Commissioning
Circulation connection In order to operate the combi tank with a hot water circulation, a circulation connection attachment from Wikora is to be installed between the tank and the circulation pipe. The circulation connection attachment is supplied as a pre-assembled unit, and consists of one T-piece with integrated circulation dip lance made of stainless steel and a DHW mixing valve to prevent scalding. -
Page 7: Warranties And Guarantee
Under condition that the limits of the valid DHW regulations have been respected, the anode has been examined for the first time after 2 years and afterwards annually and that the anode has been replaced by an original Wikora anode (individual receipts needed) by a specialized company. -
Page 8: Installation Record
In the case of reclamation, the receipts for maintenance must be provided as proof. Please complete the data sheet, including the reason for reclamation, and submit to Wikora. Submitting the maintenance record does not ensure any promise of guarantee or claim.
