SC
Artikel Nr. / Item No. / Atricle No : 124000013 RTR / 122000018 KIT
Länge / Length / Longuer .................................................................................475mm
Breite / Width / Largeur ....................................................................................250mm
....................................................................................160mm
Höhe / Height / Taille
Wheel distance
..........................................................................................283mm
...............................................................................................................540
Motor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC and is the answer not in the manual?

Questions and answers

Related Manuals for ANSMANN SC

Summary of Contents for ANSMANN SC

  • Page 1 Artikel Nr. / Item No. / Atricle No : 124000013 RTR / 122000018 KIT Länge / Length / Longuer ………………………………………………………………………475mm Breite / Width / Largeur …………………………………………………………………………250mm …………………………………………………………………………160mm Höhe / Height / Taille Wheel distance ………………………………………………………………………………283mm …………………………………………………………………………………………………540 Motor...

  • Page 3: Front Suspension

    Aufhängung vorne / Fronst Suspension / Suspension avant Front Suspension 125000499 125000413 125000516 125000455 2.3 E-ring 125000455 ………………………………4 125000499 125000455 3x34.5 Hinge pin front inner ………………………………2 125000455 Front Suspension 125000458 125000498 125000407 125000481 M3x15 Screw ……………4 125000458 Ball stud - long ……………………2 125000481 Assemble left and right sides the same way...
  • Page 4 Lenkung / Steering / pilotage Buffer 125000478 125000478 125000517 125000422 125000517 125000517 125000460 125000422 125000442 125000478 125000422 125000517 4.0 E-ring …………………………1 4.0mm 125000478 3x6x2.5 Ball Bearing 125000517 ………………………4 125000460 Ball stud - silvery 125000478 ………………………1 Buffer 125000443 125000443 Block Carrier 125000459 ……………………………2 125000459...
  • Page 5 Aufhängung vorne / Fronst Suspension / Suspension avant 125000480(3x10) Front Suspension 125000502 125000409 125000480(3x10) 125000480 M3x10 Screw ………………8 Front Suspension 125000453 3x27.5 Hinge pin front outer 125000453 2.3 E-ring …………4 ……………8 125000441 4.0 E-ring 125000459 Ball stud - short <Right> …………2 ………………………4 125000477 5x10x4...
  • Page 6 Aufhängung vorne / Fronst Suspension / Suspension avant Front Suspension Front Upper(Right) 125000512 approx.38mm 125000518 125000512 Front Upper (Left) approx.38mm 125000518 Steering Tip(Left) 125000512 approx.34mm 125000518 125000512 Steering Tip(Right) approx.34mm 125000518 3x54 Pull rod 125000512 4.8mm Ball End(Long) 4.8mm Steering-Ball End(Left) 4.8mm Steering-Ball End(Right) ………………6 ………………1...

  • Page 7: Differential Gear

    Antrieb / Drivetrain / Conduire Front Suspension 125000619 125000480 M3x10 Screw ………4 125000480(M3x10) Differential Gear 125000476 (10x15x4) 125000449(2.6x6x3) 125000519 125000448 (17x23x1) 125000406(2.5x25) 125000475 (5x8x2.5) 125000448 (17x23x1) 125000519 125000447 (2.37) 125000446 125000406(M2.5) 125000491 125000475 (5x8x2.5) 125000448 17x23x1 Washer 125000406 M2.5x25 Screw 125000476 (10x15x4) 125000406...

  • Page 8: Motor Mounts

    Antrieb / Drivetrain / Conduire Transmission <L> 125000493 125000477 125000520 125000440 <R> 125000477 125000493 125000477 5x10x4 Contain oil ball bearing 125000450 …………………4 125000450 5x16.8 idler gear shaft 125000477 ……………………1 125000490 125000440 Top shaft spacer 125000477 …………………1 125000480(3x25) Motor mounts Screw Cement 125000480(3x25) Screw...

  • Page 9: Rear Bulkhead

    Antrieb / Drivetrain / Conduire Main Gear 125000482 M4 Flanged Nylon Nut 125000438 …………1 125000437 125000617 125000437 approx.18mm 125000439 125000439 125000482 Rear Bulkhead 125000480 125000480 125000501 125000458 125000458 Ball stud - Long 125000480 M3x10 Screw …………4 ……………2...

  • Page 10: Rear Suspension

    Aufhängung / Suspension / Suspension Rear Chassis 125000497 125000408 125000481 M3x8 Screw 125000481 …………2 Rear Suspension 125000497 3x48 Hinge pin Rear inner 125000454 ……2 125000500 125000481 M3x8 Screw 125000481 125000454 ………………………………2 Rear Suspension 125000481 M3x10 Screw …………2 125000481...
  • Page 11 Aufhängung / Suspension / Suspension Rear Transmission 125000480 125000480 M3x10 Screw ……………2 125000481 M3x8 Screw 125000481 ……………2 Rear Shock Tower & Rear Fender 125000504 125000480 125000480 M3x10 Screw …………6 125000480 Screws which were semi tightened in P8 125000481(3x8) Schrauben bereits in schritt 16 verwendet 125000509 Assemble in the specified order Reihenfolge beachten...
  • Page 12 Antrieb / Drivetrain / Conduire Rear Suspension <L> <R> 125000522 125000496 125000477 125000459 125000477 125000433 125000433 125000459 Ball stud - short …………………2 Contain oil ball 125000477 5x10x4 bearing 125000433 2x9.8 Shaft …………………2 ……………4 Rear Suspension 125000455 2.3 E-ring 125000496 125000455 …………………………4 125000496 3.1x6 Plastic Washer 125000455 3x30.5 Hinge pin Rear outer...
  • Page 13 Antrieb / Drivetrain / Conduire Rear Suspension Rear Upper Hinten oben approx.35mm 125000428 4.8mm Ball End(Long) …………………………4 125000428 125000428 125000518 125000518 3x54 Turnbuckle …………………………2 Rear Suspension Battery column 125000481 M3x8 Screw …………2 125000508 125000481(3x8) Assemble as many times as specified Ture-to -scale diagram Anzahl der ben.
  • Page 14 Dämpfer / Shock absorber / amortisseur Front Rear Shock Absorber Vorne Hinten avant arriére 125000463(125000464) 2.3 E-ring Put a little oil 125000524 …………………………8 125000523 Put a little oil 125000468 125000467 Shock Piston 125000468 125000468(2.8x1.9) …………………4 125000468(2.8x1.9) 125000463 125000464 125000468(3x1mm) 125000468(3x1mm) 125000468(2.8x1.9) 125000468 2.8x1.9 O-ring 125000468(2.8x1.9)
  • Page 15 Dämpfer / Shock absorber / amortisseur Shock Absorber Front Short for adjusting the spring tension Compress the spring and install 125000523 Long 125000514 125000524 125000469(Short) 3mm adjuster ring …………4 125000514 Rear 125000470(Long) Front Suspension 125000480 (3x22) 125000482 125000462 125000480 (3x15) Short 125000480 M3x15 Screw 125000480...
  • Page 16 Endmontage / Final assembly / montage final Rear Suspension 125000480(3x22) 125000462 125000482 Long 125000480 (3x15) M3 Nylon Nut 125000480 M3x15 Screw 125000482 125000480 M3x22 Screw ……2 ……2 …………2 Motor 125000481 M3x8 Screw 125000480 M3x5 Screw …………2 …………2 125000479 3x7x0.8 Washer M3x3 Screw ……………2 ……………1...
  • Page 17 Bumper support M3x8 Screw ………………8 Rear bumper support (M3x12) M3x10 Screw …………4 (M3x10) M3x12 Screw ……4...
  • Page 18 M3x8 Screw Rear Bumper support ………………8 M3x10 Screw ………………2 Front Suspension (M3x10) M3x10 Screw (M3x10) …………6 M3x12 Screw ……4 (M3x12)
  • Page 19 Rear Suspension M3x12 125000480 M3x10 Screw ………………4 M3x12 Screw ……………2 125000480 Steering Servo 125000513 Select for your servo 125000479 Steering Servo-H(24T) Steering Servo-S(23T) 125000460 Other servo 125000511 125000511 125000434 125000480 125000510 Steering Servo-F(25T) 125000480(2.6x8) 125000513 4.8 Ball End(Short) 125000479 3x7x0.8 Washer 125000460 Ball stud - silvery ……………2 ………………4...
  • Page 20 Endmontage / Final assembly / montage final Steering Servo 125000481 M3x8 Screw ……2 125000481 125000485 Antenna pipe Radio set cover Receiver Antenna pipe 125000485 Electronic speed controller Double-sided Tape Assemble in the specified order Reihenfolge beachten...
  • Page 21 Endmontage / Final assembly / montage final Battery 125000484 If using loose battery cells 125000506 Please put the battery panel conversely 125000484 125000506 Battery Battery 125000484 Small clip …………2 Body Washer Small clip …………4 Must be purchased separately...

  • Page 22: Front - Right

    Wheels Rear - Left Front - Left Rear - Right Front - Right Wheels After fitting wheels to tyres,apply instant glue as shown Nach dem Anbringen der Reifen auf die Felgen, Sekundenkleber verwenden. Après la pose des pneus sur les jantes, utilisez la colle. Front - Left Rear - Left Front - Right...
  • Page 23 Endmontage / Final assembly / montage final Body shell Body Mounting & Wheels 125000482 M4 Flanged Nylon Nut 125000484 …………4 125000484 Small clip …………4 125000482 Drill holes with the specified diameter Cut off shaded portion Löcher im angegebenen Durchmesser Schattierten Teil abschneiden...
  • Page 24 Diagramm / Diagram / Graphique...
  • Page 25 Ersatzteile / Spareparts / Pièces détachées 125000617 125000490 125000491 125000492 1 pcs. 1pcs Gear Cover Getriebeabdeckung engins de couverture 52T Spur Gear 28T Spur Gear 86T Spur Gear Zahnrad 28Z Zahnrad 52Z 1pcs. Hauptzahnrad 80Z train 28D train 52D Train principal 80D 125000407 125000493 125000406...
  • Page 26 Ersatzteile / Spareparts / Pièces détachées 125000509 125000510 125000511 125000512 2pcs. 4.8 Ball End - Long 6PCS Servomount Front bumper & Motorguard Servo arm Set Servo arm Set Servohalter Rammer und Motorschutz Servo bras Set Servomount Pare-chocs avant et Motorguard 125000513 125000514 125000433...
  • Page 27 Ersatzteile / Spareparts / Pièces détachées 125000520 125000453 125000454 125000455 2.3 E-ring 2.3 E-ring 4pcs. 4PCS 3x27.5 Hinge pin front outer 3x34.5 Hinge pin front inner 3x48 Hinge pin Rear inner Gearshaft 20T 2pcs. 2pcs. 2pcs. Ritzelwelle 20Z engins de l'arbre 20D 125000456 125000522 125000458...
  • Page 28 Ersatzteile / Spareparts / les pièces de rechange 125000479 125000480 125000481 3x5 Screw 3x15 Screw 3x8 Screw 8PCS 8PCS 8pcs. 3x8 Screw 3x12 Screw 3x10 Screw 8PCS 8PCS 8pcs. 3x22 Screw 3x15 Screw 3x10 Screw 3x7x0.8 Washer 8PCS 8pcs. 8PCS 10pcs.
  • Page 29 Tuningteile / Optionparts / Pièces Tuning 125000307 125000314 125000308 125000309 C-Type-Holder C-Type-Holder C-Type-Holder C-Type-Holder Rear arm mount F/R 1Set Front arm mount 1Set 30 Degree - L 30 Degree - R 25 Degree - L 25 Degree - R 125000312 125000310 125000316 125000311...
  • Page 30 Service: ANSMANN AG Division Racing Abt. Service Industriestr. 10 97959 Assamstadt Tel.: +49 (0) 629 4204 34 Fax.: +49 (0) 629 4204 47 ANSMANN AG DIVISION RACING Thomas-Mann-Str.63 D-90471 Nuernberg Germany Tel.: +49 (0) 911 817 44 0 Fax.: +49 (0) 911 817 44 22...
